Behringer COMPOSER PRO MDX2200 User manual

COMPOSER® PRO MDX2200
www.behringer.com
Version 1.1 May 2000
Technical Specifications
ENGLISH

2
MDX2200
COMPOSER PRO
Interactive 2-channel expander/gate/compressor/limiter of the reference class
sIKA (Interactive Knee Adaptation) compressor concept combines the advantages of “hard knee” and
“soft knee” characteristics
sAttackandReleasetimescontrollableautomaticallyormanually
sSwitchable high-pass filter in control signal path avoids low-frequency signals from dominating compres-
sor action
sCompression characteristics switchable between IKA and “hard knee” characteristics
sIRC circuit in expander/gate allows for “inaudible” elimination of disturbing noise signals
sIGC (Interactive Gain Control) peak limiter combines clipper with program limiter circuits
sExtremelylow-noiseoperational amplifiers and high-grade VCA’s
sHigh-qualitydetentpotentiometersandbacklitswitches
sStereoCouplefunction selectable with real totaling of RMS output
sAccurate 12-digit LED meters for input level, output level and gain reduction
sTraffic-light function for easy threshold setting
sSwitchable side-chain input with side-chain monitor function
sOperating level switchable from +4 dBu to -10 dBV
sServo-balanced inputs and outputs featuring 1/4" jack and XLR connectors
sHigh-gradeoutputtransformerBEHRINGEROT-1 can be retrofitted
sRelay-controlled hard-bypass switch with auto-bypass function (fail-safe relay)
sManufacturedunderISO9000certifiedmanagementsystem

3
SPECIFICATIONS
AUDIOINPUT
Connectors XLR and 1/4" jack
Type RFfiltered,servo-balancedinput
Impedance 50kOhmbalanced,25kOhm unbalanced
NominalOperatingLevel +4 dBu/-10 dBV switchable
Max.InputLevel +21 dBu balanced and unbalanced
CMRR typ. 40 dB, >55 dB @ 1 kHz
AUDIO OUTPUT
Connectors XLR and 1/4" jack
Type electronicallyservo-balancedoutputstage (optional transformer-
balanced)
Impedance 60Ohmsbalanced,30 Ohm unbalanced
Max.OutputLevel +21 dBu, +20 dBm balanced and unbalanced
SC INPUT
Connector 1/4" jack
Type RF-rejecting, DC de-coupled, unbalanced input
Impedance >10kOhm
Max.Input Level +24 dBu
SC OUTPUT
Connector 1/4" jack
Type RF-rejecting,DCde-coupled,unbalanced output
Impedance 2kOhm
Max.OutputLevel +21 dBu
SYSTEMSPECIFICATIONS
Bandwidth 20 Hz to 20 kHz, +0/-0.5 dB
FrequencyResponse 0.35 Hz to 200 kHz, +0/-3 dB
Noise > 95 dBu, unweighted, 22 Hz to 22 kHz
THD 0.008 % typ. @ +4 dBu, 1 kHz, Gain 1
0.04 % typ. @ +20 dBu, 1 kHz, Gain 1
IMD 0.01 % typ. SMPTE
Crosstalk < -100 dB, 22 Hz to 22 kHz
StereoCoupling true RMS detection
EXPANDER/GATE SECTION
Type IRC(InteractiveRatioControl) Expander
Threshold variable (OFF to +15 dB)
Ratio variable (1:1 to 1:8)
Attack <1 ms / 50 dB, program dependent
Release variable (SLOW: 100 ms / 1 dB, FAST: 100 ms / 100 dB)
COMPRESSOR SECTION
Type IKA(InteractiveKneeAdaption) Compressor
Threshold variable (-40 dB to +20 dB)
Ratio variable (1:1 to oo:1)
Threshold characteristics variable (Interactive or Hard Knee)
Auto characteristics WaveAdaptiveCompressor
ManualAttackTime variable (0.5 ms / 20 dB to 100 ms / 20 dB)
ManualReleaseTime variable (0.05 ms / 20 dB to 5 s / 20 dB)
AutoAttack Time typ. 15 ms at 10 dB, 5 ms at 20 dB, 3 ms at 30 dB
AutoReleaseTime program dependent, typ. 125 dB/s
Output variable (-20 to +20 dB)

4
PEAKLIMITER SECTION
Type IGC (Interactive Gain Control) Peak Limiter
Threshold variable (+4 dB to OFF (+22 dBu))
Ratio oo:1
Stage1Limiter Type Clipper
Attack “zero”
Release “zero”
Stage2Limiter Type ProgramLimiter
Attack program dependent, typ. < 5 ms
Release program dependent, typ. 20 dB/s
FUNCTIONSWITCHES
SCEXTERN switches the detector section to the external SC input
SCMON monitoringthe externalSCinput, disengaging the normal audio
INTERACTIVE enablesthe “Interactive Knee Adaption” characteristics
CONTOUR allowsfor frequency dependent detection
AUTO enablestheautomatic and program dependent setting of the
Attack-/Releasetimes,disengagingthe manual Attack-/Release
controls
I/OMETER switchesbetweeninput and output for the level meter
IN/OUT relaycontrolled hard-bypass
OPERATINGLEVEL changes the internal reference level from +4 dBu to -10 dBV
COUPLE linking both channels for stereo operation and channel 1 becomes
master
INDICATORS
GAINREDUCTION 12 element LED display: 1/2/4/6/9/12/15/18/21/24/27/30 dB
INPUT/OUTPUTLEVEL 12 element LED display: -30/-24/-18/-12/-6/0/+3/+6/+9/+12/+18 dB
Expander/GateThreshold 2 LED for under “+” and above “-”
CompressorThreshold 3 LEDs for under “+”, Interactive “0” and above “+”
PeakLimiter Threshold 1 LED for Indication of Limiter function
Functionswitch LED indicator for each
OPTIONS
OutputTransformer BEHRINGERtransformerOT-1 refittable
POWER SUPPLY
MainsVoltages USA/Canada 120 V ~, 60 Hz
U.K./Australia 240 V ~, 50 Hz
Europe 230 V ~, 50 Hz
Generalexport model 100 - 120 V ~,200 - 240 V ~, 50 - 60 Hz
Fuse 100 - 120 V ~: T 250 mA H
200 - 240 V ~: T 125 mA H
PowerConsumption max. 20 Watts
Mains Connection standard IEC receptacle
PHYSICAL
Dimension (H * W * D) app. 1 3/4" (44.5 mm) * 19" (482.6 mm) * 8 1/2" (217 mm)
NetWeight app. 2.2 kg
ShippingWeight app. 3.4 kg
BEHRINGER is constantly striving to maintain the highest professional standards. As a result of these efforts, modifications may be made from time
to time to existing products without prior notice. Specifications and appearance may differ from those listed or illustrated.
