Behringer XENYX 302USB User manual

Premium 5-Input Mixer with XENYX
Mic Preamp and USB/Audio Interface
Ultra-compact and
ultra-low noise analog mixer
with USB/Audio interface
Powered through USB or
external adaptor
Built-in stereo USB/Audio interface
to connect directly to your computer
Free audio recording,
editing and podcasting software
plus 150 instrument/eect
plug-ins and ultra-low latency
driver downloadable
State-of-the-art XENYX Mic Preamp
comparable to stand-alone
boutique preamps
Neo-classic “British” 2-band graphic
EQ for warm and musical sound
2-Track input assignable to
Headphone or Main Mix output
Main Mix plus separate
Phones output
High-quality components and
exceptionally rugged construction
ensure long life
Conceived and designed by
BEHRINGER Germany
Need a handy little mixer you can
grab with your laptop on the way out
the door? Or maybe you don’t want to
give up valuable desktop real estate to
a large mixer? The new XENYX 302USB
is ideally suited for a small home studio
or the on-the-go recording enthusiast.
At approximately 4" long and 5" wide
(117 x 135 mm), the XENYX 302USB
respects your desk space, while providing
a phantom-powered XLR & ¼"
combination socket, stereo USB/Line
channel plus a dedicated 2-Track input.
Small, but mighty!
Don’t let the XENYX 302USB’s
diminutive size fool you—this little
gem is loaded with features typically
reserved for larger, more expensive
mixers. For instance, we equipped the
Mic input with our XENYX mic preamp,
which is legendary for its sonic clarity and
high-headroom performance , and we
included phantom power for use with
high-quality condenser mics. We also
gave the Mic and Line/USB channels our
2-band British-style EQs (Low and High),
and provide a 2-Track input that can
be assigned to either the Main Mix
or Phones.
You can even power the XENYX
302USB from your computer’s USB
port, which is great for capturing the
sounds of migratory birds in ight, or for
posting your podcast straight to the Web.
Sports announcers, radio and TV reporters
will denitely want one of these in their
eld bag. Incredible sonic performance,
versatility and extreme value in a small
package—that’s the XENYX 302USB!
302
Small Format Mixers

Page 2 of 3
Front Panel
Combination
balanced XLR &
¼" TRS MIC IN jack
Stereo LINE
Inputs (RCA)
FROM Line In/
USB Play source
selector switch
Stereo 2-TRACK
Inputs (RCA) acquit
MIC IN
GAIN control
LOW and HIGH
EQ faders
PAN faders adjust
signal placement
in stereo image
MIC channel
volume control
LINE/USB channel
volume control
MAIN MIX
volume control
Output metering
TO Line/USB switch
assigns signal to
Main Mix or Phones
PHONES volume
control
TO 2-Track switch
assigns signal to
Main Mix or Phones
Stereo MAIN MIX
Outputs (RCA)
HEADSET connections
(MIC/PHONES)
Power LED
USB socket (rear panel)
XENYX 302USB recording setup XENYX 302USB podcasting setup
XM8500
Laptop
Mp3 player
Laptop
Mp3 player
Headset
(not included)
302

Page 3 of 3
For service, support or more information contact the BEHRINGER location nearest you:
Technical specifications and appearances are subject to change without notice and accuracy is not guaranteed. BEHRINGER is part of the MUSIC Group (music-group.com). All trademarks are the property of their respective owners. MUSIC Group accepts no liability for any loss
which may be suffered by any person who relies either wholly or in part upon any description, photograph or statement contained herein. Colors and specifications may vary from actual product. MUSIC Group products are sold through authorized fullfillers and resellers only.
Fullfillers and resellers are not agents of MUSIC Group and have absolutely no authority to bind MUSIC Group by any express or implied undertaking or representation.This manual is copyrighted. No part of this manual may be reproduced or transmitted in any form or by any
means, electronic or mechanical, including photocopying and recording of any kind, for any purpose, without the express written permission of MUSIC Group IP Ltd. ALL RIGHTS RESERVED. © 2012 MUSIC Group IP Ltd.Trident Chambers,Wickhams Cay, P.O. Box 146, RoadTown,
Tortola, BritishVirgin Islands. 985-10000-00484
Europe
MUSIC Group Services UK
Tel: [phone]
Email: [email protected]om
USA/Canada
MUSIC Group Services NV Inc.
Tel: [phone]
Email: [email protected]om
Australia
MUSIC Group Services AU Pty Ltd
Tel.: [phone]
Email: [email protected]om
Japan
MUSIC Group Services JP K.K.
Tel.: [phone]
Email: [email protected]om
Specications
Mic Input
Microphone Input
Type XLR/¼" combo connector,
electronically balanced
Mic E.I.N. (20 Hz - 20 kHz)
@ 0 source resistance -130 dB / -133.1 dB A-weighted
@ 50 source resistance -128 dB / -131.5 dB A-weighted
@ 150 source resistance -127 dB / -129.8 dB A-weighted
Frequency response (–1 dB) 18 Hz - 40 kHz
Frequency response (–3 dB) < 10 Hz - 75 kHz
Gain range +15 dB to +55 dB
Max. input level +12 dBu @ +10 dB Gain
Impedance 2 k
Signal-to-noise ratio 98 dB / 101 dB A-weighted
(0 dBu in @ +22 dB Gain)
Distortion (THD+N) 0.013%
Frequency Response (Mic In �Main Out)
18Hz - 40kHz +0 dB / -1 dB
10Hz - 75kHz +0 dB / -3 dB
Stereo Line Input
Type RCA jacks, unbalanced
Impedance 6 k
Gain range -∞ to +20 dB
Max. input level +20 dBu
2-Track In
Type RCA jacks, unbalanced
Impedance 20 k
Max. input level +20 dBu
Headset Mic In
Type ⁄" TRS mini jack
Impedance 6 k
Max. input level +22 dBu @ Gain Min
Equalizer
Low 80 Hz / ±15 dB
High 12 kHz / ±15 dB
Main Outputs
Type RCA, unbalanced
Impedance 470 
Max. output level +22 dBu
Phones Output
Type ⁄" TRS mini jack
Max. output level +7 dBu / 150 
System Data (Noise)
Main mix @ -∞, -96 dBu / -101 dBu A-weighted
channel fader @ -∞
Main mix @ 0dB, -82 dBu / -87 dBu A-weighted
channel fader @ -∞
Main mix @ 0dB, -80 dBu / -85 dBu A-weighted
channel fader @ 0dB
External USB Switching Power Supply
Mains voltage 100-240 V, ~ 50/60 Hz
Power consumption 0.9 W
Power connector USB, type A
USB
Connector Type B
Converter 16-bit
Sample Rate 48 kHz
Size/Weight
Dimensions (H x W x D) 1.8 x 4.5 x 5.4"
46 x 114 x 136 mm
Weight 0.83 lbs / 0.38 kg
Please note these specifications are preliminary and conceptual in nature, and as such are subject
to change as product development progresses. This information is supplied for market research
purposes only and is not to be made public in any manner. This document is solely the property of
The MUSIC Group, or one of its subsidiaries, and must be surrendered upon request of the owner.
