Ultra-Fast and Fully Automatic Dual-Channel Feedback Suppression Processor

TN6232

Features Product Overview

The TN6232 professional dual-channel feedback

suppression processor is the latest state-of-the-art

advancement from BEHRINGER, one of the world’s

leading manufacturers of feedback suppressors.

Fromconference rooms to concert halls, any venue with

a sound reinforcement system will benet from TN6232’s

unprecedented performance and value.

In designing the TN6232, our engineers have delivered

fully automatic feedback suppressor that requires no

advance setup or tuning. Functioning in real time,

andwith detection accuracy to within one-sixth of a cycle,

the TN6232 is an elegant, “plug and play”solution to one

of live sound’s most vexing problems. Say goodbye to

feedback forever with the EUROCOM TN6232.

• Dual-channel feedback suppression

processor designed for fully automatic and

zero-conguration setup

• Oers up to 10 dB increase in system gain

• Instantly detects and stops acoustic feedback. Highly

eective with both speech and music

• Ultra-fast and highly accurate DSP selects and applies

up to 32 lters per channel

• Two fully independent audio channels to process

stereo or separate zone signals

• Extremely narrow lters (up to 1/30th octave)

to retain overall signal integrity

• Two balanced/unbalanced inputs on combination line

level XLR/TRS and 3-pin Euroblock connectors

• Hinged front door panel covers the control surface

featuring suppression and lter reset buttons plus the

power switch

• Rack ear screw covers, IEC-type AC power cord and all

mating Euroblock connectors included

• Ultra-light, ultra-low noise and ultra-ecient

switch-mode power supply for noise-free

audio, superior transient response and low

powerconsumption

• High-quality components and exceptionally rugged

construction ensure long life

Ultra-Fast and Fully Automatic Dual-Channel Feedback Suppression Processor

TN6232

Audio Inputs

• Connections 2xXLR/TRScombo

2x3-pinEuroblock

• Inputimpedance appr.10kΩ

• Normalinputlevel +4dBu

• Max.inputlevel +22dBu

Audio Outputs

• Connections 2xXLR

  2x3-pinEuroblock

• Outputimpedance appr.120Ω

• Normaloutputlevel +4dBu

• Max.outputlevel +22dBu

System Information

• Controls Poweron/o

Suppression(momentary)

  Filterreset(momentary)

  IndicatorsBehringerlogo

  (Poweron)

  Active

  Bypass

  Reset

• Frequencyresponse 20Hz–20kHz,±0.5dB

• Dynamicrange 102dBA-weighted,

>100dBaudiolter

• THD+N <0.1%@20Hz–20kHz

• Crosstalk <-100dB,-120dBtypical

• S/NRatio ≥100dB

• CMRR >45dB

• Processersystemgain 0dB

• Additionalacousticgain 10dB

Digital Signal Processing (DSP)

• Converters 24-bit

• Samplerate 48kHz

• FeedbackSuppressor(FBQ)

• Feedbackreductionmethod Automaticallydetectandapply

notchlter

• Filters 32independentdigital

notchltersperchannel

• Filterwidth min.1/126thoctave,

max.1/38thoctave

• Resolution 0.2Hz

• Timetondone 100–400msecfeedbackmode

• Timetondmultiple 2–4secfeedbackmodes

• Type Auto-switchingpowersupply

• Mainsvoltage(allregions) 100–240VAC,50/60Hz

• Fuse T1.25AH250V

• Powerconsumption appr.10W

• Mainsconnector StandardIECreceptacle

Dimensions/Weight

• Dimensions(HxWxD) appr.1.7x19x7.6"

appr.44x482x192mm(1U)

• Weight appr.4.6lbs/2.1kg

Technical Specications

Ultra-Fast and Fully Automatic Dual-Channel Feedback Suppression Processor

TN6232

The automatic feedback suppressor shall be a dual-channel digital signal processor with thirty-two (32) 1/30th octave lters

per channel. The lters shall be of the processor-controlled variable Q type (lter skirts narrow and widen at the discretion of

the processor).

The device may be used on selected insert points, sub-groups, monitor feeds, or the entire mix. It shall detect feedback,

determine the oending frequency, and then assign a notch lter to eliminate the feedback automatically. The device

shall continue to provide this function throughout the program or performance, andshall use dynamic notch lters,

whichwill be automatically assigned to new frequencies should feedback occur during the program. The unit shall include:

anActive/Bypass button with an LED indicator for each mode of operation, allowing the user to set the unit to control

feedback (activemode) or remove the device from the signal path (bypass mode); and a Filter Reset button with LED

indicator, so all lters may be re-congured.

The product shall be equipped with a rear-mounted power switch, an power socket congured to operate at 115 VAC,

balanced and unbalanced inputs on 3-pin Euroblock and combination ¼" TRS / XLR-3 connectors, with balanced and

unbalanced outputs on both 3-pin Euroblock and XLR connectors. The automatic feedback controller shall be the EUROCOM

TN6232 Feedback Suppressor.

(Specications Subject to Change Without Notice)

Architect’s and Engineer’s Specications

TN6232

Ultra-Fast and Fully Automatic Dual-Channel Feedback Suppression Processor
