Behringer B-Control Fader BCF2000 User manual

Version 1.1 July 2004
Technical Specifications
ENGLISH
B-CONTROL FADER BCF2000

2
B-CONTROL FADER MODEL BCF2000
BCF2000
B-CONTROL FADER
Total Recall USB/MIDI Controller Desk with 8 Motorized Faders
sUnique, total recall cascadable desktop MIDI controller wit analog feel and an intuitive user interface
s8 ultra-precise 100-mm motorized faders for ultimate control of virtual mixers, organ-drawbars
(inverse mode) or virtual synt s and samplers
s4 virtual groups wit 8 dual-mode, ig -resolution encoders t at feature LED rings and an additional
pus function
s16 + 4 illuminated buttons freely assignable to all types of MIDI functions from note on/off, control c ange
and program c ange to MMC and system exclusive data
sAll panel elements freely assignablemanually or via user-friendly learn mode
sAdditional multi-function foot switc and foot controller connectors can be used to address all types of
MIDI data
s32 user presets eac wit 4 encoder groups
sConfigurable MIDI and USB modes for ultra-flexible system integration
s1 MIDI In plus 2 MIDI Outs, usable as an additional USB to MIDI interface
sMulti-function 4-digit LED display wit real-time parameter indication plus write-in fields for your own labeling
sMIDI input wit merge function for cascading several control units
sEasy connection to any computer/expander etc. using standard MIDI In/Out connectors
sGeneric USB MIDI support wit WINDOWS® XP and MAC OS X®
sAdditional drivers and editor/librarian software available for free download on our website soon
sHig -quality components and exceptionally rugged construction for long life and durability
sConceived and designed by BEHRINGER Germany. Made in C ina
WINDOWS®, MAC OS X® as well as the names of companies, institutions or publications pictured or mentioned and their
respective lo os are re istered trademarks of their respective owners. Their use neither constitutes a claim of the trademarks
by BEHRINGER® nor affiliation of the trademark owners with BEHRINGER®.

3
B-CONTROL FADER MODEL BCF2000
SPECIFICATIONS
USB INTERFACE
Type Full-speed 12 MBit/sec.
USB MIDI class-compliant
MIDI INTERFACE
Type 5-pin DIN connectors IN, OUT A,
OUT B/THRU
CONTROL ELEMENTS
Controls 8 motorized 100-mm faders
8 infinitely variable push encoders
with LED rin s
Keys 20 keys
10 system keys (4 x Encoder Group,
4 x pro rammin , 2 x Preset)
DISPLAY
Type 4-di it 7-se ment LED display
SWITCHED INPUTS
Footswitch 1 x ¼" TS connector
with automatic polarity detection
Footcontroller 1 x ¼" TRS connector
POWER SUPPLY
Volta e 85 - 250 V~, 50 - 60 Hz
Power consumption max. 10 W
Fuse T 1 A H 250 V
Mains connection Standard IEC receptacle
DIMENSIONS/WEIGHT
Dimensions
(W x H x D) 13" x 4" x 11 4/5"
(330 mm x 100 mm x 300 mm)
Wei ht approx. 5 ¾ lbs. (2.60 k )
BEHRINGER is constantly striving to manintain the highest professional
standards. As a result of these efforts, modifications may be made from
time to time to e isting products without prior notice. Specifications and
appearance may differ from those listed or illustrated.
