Beijer Electronics Korenix JetWave 2310 Series User manual

5 Years Warranty
Each of Korenix’s product line is designed, produced, and tested with high industrial
standard. Korenix warrants that the Product(s) shall be free from defects in materials and
workmanship for a period of ve (5) years from the date of delivery provided that the
Product was properly installed and used.
is warranty is voided if defects, malfunctions or failures of the warranted Product are
caused by damage resulting from force measure (such as oods, re, etc.), other external
forces such as power disturbances, over spec power input, or incorrect cabling; or the
warranted Product is misused, abused, or operated, altered and repaired in an unauthorized
or improper way.
Attention! To avoid system damage caused by sparks, please DO NOT plug in power
connector when power is on.
Support
e product is in compliance with Directive 2002/95/EC and 2011/65/EU of the European
Parliament and of the Council of 27 January 2003 on the restriction of the use of certain
hazardous substances in electrical and electronics equipment(RoHS Directives & RoHS 2.0)
Korenix Customer Service
KoreCARE is Korenix Technology's global service center, where our professional stas are
ready to solve your problems at any time Korenix global service center's e-mail is
[e-mail].
For more information and documents download please visit our website:
http://www.korenix.com/downloads.htm
JetWave 2310 Series
Quick Installation Guide V1.0
e JetWave 2310 is an industrial grade Secure 3G Modem/IP gateway which enables
Ethernet access over 3G network. e JetWave 2310 is equipped with one embedded 3G
module, 2 Gigabit Ethernet ports and dual SIM to support UMTS/ HSPA+ band and
backward support of GSM/GPRS/ EDGE quad-band.
Band Information
GSM/GPRS/EDGE: Quad band 850/900/1800/1900MHz
UMTS/HSPA+: Five band 800/850/900/1900/2100MHz
Package Check List
 JetWave 2310 Industrial 3G Modem/IP Gateway
 3G Antenna
 Quick Installation Guide
 DIN rail mount kits
 Wall mount plate
JetWave 2310 Appearance
Dual SIM Socket & Direction
Antenna Number
C: 3G Antenna for JetWave 2310.
A/B/D: Reserved for JetWave 2311 WIFI/LTE
Overview
Appearance
A Beijer Electronics Group Company
e JetWave 2310 Series provides web management interface for basic and advanced settings.
Before conguration, please make sure your system meets the following requirements:
 A computer coupled with 10/100/1000 Base-T(X) adapter
 Congure the computer with a static IP address of 192.168.10.X (X cannot be 0, 1,
nor 255)
 e default IP Address of JetWave 2310 is 192.168.10.1.
 e 2 gigabit ports work as Bridge mode in default. All are the LAN port and you can
connect either of them to access the Web GUI.
 Open web browser (Ex: IE, Chrome, Firefox…) and enter the IP address
(Default: 192.168.10.1). You will see the System Login page.
 e default User Name is “admin”.
 e default Password is “admin”.
 Check User Manual for advanced settings.
 IF the web browser is not access, please check your rewall, JAVA version or contact your
support window for further help.
Note: If you forget the IP Address, you can use Korenix View Utility to search the device’s IP
address.
Web GUI

DC Input
Insert the positive and negative wires into the V+ and V- contact on the terminal block
connector. e device supports dual DC power input, the typical power source is DC 24V
(range from 12~48VDC).
Insert the SIM
 Unlock the front plate of Dual SIM Socket
 Insert the SIM card into SIM 1 (Default startup SIM Socket is SIM 1) before power on
system.
 e system may take around 1 minutes to startup, and then it will search the 3G SIM
card in SIM1 socket and automatically connect to your ISP.
 If you want to use SIM 2 for carrier provider redundant, please insert the 2 SIM cards
before power on the system.
 If you want to use SIM 2 as startup SIM socket, please go to Web GUI to modify the
setting.
If the 3G connection is not connected, please go to Web GUI to check the 3G Status and
Settings.
Mounting The Unit/Antenna
 JetWave 2310 support Din-Rail mounting, the mounting kit is pre-installed. You can
mount the device to the DIN Rail directly.
 Mount the default antenna to the antenna number C.
Installation
e Korenix View Utility provides you convenient tool to scan the network and congure
the device.
Step 1: Open the Korenix View Utility. (Must later than JetView V1.6)
Step 2: Select the correct NIC (Network Interface Card) from the NIC list.
Step 3: Click “Discovery”, and then the Nodes and its IP address can be found and listed in
Node list.
Step 4: After you scan the network, select the device
and click “Open Web GUI” to access the web
management interface. You can also modify the IP
address/Netmask directly on the selected entry and
then click “Change IP“ to change IP settings.
Note: Please check the User Manual to congure the
other software settings.
Korenix View Utility

Patent No. (Taiwan):
Granted Invention: I 313547
Granted Invention: I 321415
Granted Invention: I 344766
Granted Invention: I 346480
Granted Invention: I 356616
Granted Invention: I 364684
Granted Invention: I 376118
Granted Invention: I 393317
Granted Invention: I 398066
Granted Invention: I 398125
Utility Model: M 339841
Utility Model: M 339840
Tel:[phone]
Fax:[phone]
Business service:[email protected]
Customer service:[email protected]
www.korenix.com
CPQ000W2310000
Korenix Technology Co., Ltd.
(A Beijer Electronics Group Company)
导言
JetWave 2310 是工业级的3G Modem/IP Gateway安全网关 ，便于用户通过3G网络接入
工业以太网。JetWave 2310配置有内建的3G模块、2个千兆以太接口与双SIM卡并支
援UMTS/HSPA+ 并相容GSM/GPRS/EDGE等频段。
频段信息
GSM/GPRS/EDGE: Quad band 850/900/1800/1900MHz
UMTS/HSPA+: Five band 800/850/900/1900/2100MHz
包装内容
 JetWave 2310 Industrial 3G Modem/IP Gateway
 3G天线
 快速安装向导
 DIN导轨安装套件
 壁挂板
JetWave 2310 外观
外观说明
JetWave 2310系列提供了网页接口可管理基本配置与进阶配置。
开始配置以前，请先确认您的系统满足以下需求：
 一台具有10/100/1000 Base-T(X) 网络接口的计算机。
 设定一组静态IP地址192.168.10.X (X 不可为0、1或255)到这台计算机。
 JetWave 2310 的默认 IP 地址为192.168.10.1。
 默认这两个以太千兆接口是桥接模式，全部皆为LAN的接口，您可以任选一个接
口来存取网页管理接口。
 打开网页浏览器(如: IE, Chrome, Firefox…)并输入IP地址(预设: 192.168.10.1)，您
将会开启系统登入画面。
 默认的使用者名称为 “admin”。
 默认的密码为 “admin”。
 如需进阶设定请参考使用手册。
 如果网页浏览器无法存取,请检查计算机的防火墙，JAVA版本或连系您的技术支
持窗口提供更进一步的协助。
备注: 若您不清楚设备的IP地址，您可以使用Korenix View Utility 去搜寻设备的IP地
址。
Web 软件接口
双 SIM 卡槽与方向
天线号码
C: JetWave 2310 3G天线位置
A/B/D: 预留给 JetWave 2311 WIFI/LTE
JetWave 2310可支持最新版本的 Korenix View Utility管理软件，这个管理软件方便您
搜寻网络地址与部分基本设定。
步骤 1：打开 Korenix View Utility管理软件 (必须是V1.6版之后) 。
步骤 2：在网络卡列表中选取指定的网络卡或选All Interface(全部) 。
步骤 3：按下 “Discovery”(搜寻), 接着所有此网络的Korenix交换机/AP/网关和它们的
产品名称，IP地址，MAC地址，Netmask地址与软件版本…等讯息将可以被找到，
并显示在设备列表下。
步骤 4：在搜寻到设备后，选取指定设备按下鼠标右
键“Open Web GUI”即可允许您直接连上Web设定接口
，妳也可以于此直接修改IP/Netmask地址后按下
“Change IP“ 直接修改其设定。
备注: 其他进阶软件设定部分请参考用户使用手册。
Korenix View Utility
本机与天线的安装
 JetWave 2310支持导轨安装，相关导轨配件已先安装完成，您可以直接将装置挂
在导轨上。
 请安装您的3G天线在天线号码C的位置。
Support
5年质保
所有科洛理思产品的设计、制造及测试都是采用较高的工业标准。科洛理思保证
自产品出货日起提供最高5 年之免费保修服务，保修期间如因零件损坏或制程不良
而导致产品故障，我们将提供免费维修服务。
然而，自然外力(火、水、雷灾)所造成的产品故障，或其它外部因素如电源干扰、
不当电源输入、不当接线等造成的损坏，不列入产品保固范围；此外，产品被误
用、未经授权的修理及修改等行为将造成保固条款失效。
注意! 请勿于电源开启时插拔接线端子，以避免产生火花造成系统损坏。
此产品保证完全符合欧盟2003年1月27日电气和电子设备危害物质限制委员会所提
出的限用指令2002/95/EC(ROHS禁令)及2011/65/EU(RoHS 2.0)。
Korenix售后服务
KoreCARE 是科洛理思科技全球服务中心，我们专业的技术人员随时准备解答您的
疑问。科洛理思全球服务中心 EMAIL: [e-mail]
详细说明及文件请至网站下载: http://www.korenix.com.cn/support_downloads.htm
业务服务: [email protected]
官网: www.korenix.com.cn
客户服务
直流输入
将正负极导线分别接入V+与V-的终端连接器.，此装置支持双直流电源，标准电压为
直流24V (直流电压范围为 12V~48V) 。
安装SIM卡
 卸下双SIM卡插槽的前版。
 关闭电源，安装SIM卡到SIM 1的插槽(SIM 1为预设启用的SIM卡插槽)。
 系统会在一分钟内启，并侦测SIM1插槽的3G卡，自动联机上电信运营商。
 如果要使用SIM2做为3G联机备援，请在开机前分别安装好两张SIM卡到SIM1与
SIM2插槽。
 如果要使用SIM2做为SIM卡的启动插槽，可以透过网页接口来修改设定。当3G
无法联机时，请到网页接口检查3G状态与设定。
安装
