JetWave 3220v3/3420v3 Series
Industrial 802.11ac Multi-Radio
Wireless AP/ 4G Gateway / LTE Gateway
User Manual
V1.0 Jan, 2020

JetWave 3220v3/3420v3 Series User Manual
Copyright
Copyright © 2014 all rights reserved. No part of this publication may be reproduced, adapted, stored in
a retrieval system, translated into any language, or transmitted in any form or by any means without
the written permission of the supplier.
About This Manual
This user manual is intended to guide professional installer to install the JetWave 3220v3/3420v3 and
how to build the infrastructure centered on it. It includes procedures to assist you in avoiding unforeseen
problems.
Conventions
For your attention on important parts, special characters and patterns are used in this manual:
This indicates an important note that you must pay attention to.
The Blue Wording is important note that you must pay attention to.
The Blue Wording with Big Case is very important note you must pay more attention to.
This indicates a warning or caution that you have to abide.
The Red wording is very important you must avoid.
Bold: Indicates the function, important words, and so on.
Note:
Warning:
