Beko BDP810W User manual

BDP810W
Dryer
User Manual
2960311948/020419.1332
EN

2 Dryer / User Manual
Please read this user manual first!
Dear Customer,
Thank you for prefering a Beko product.
We hope that your product which has been
manufactured with high quality and technology
will give you the best results. We advise you
to read through this manual and the other
accompanying documentation carefully
before using your product and keep it for
future reference. If you transfer the product
to someone else, give its manual as well. Pay
attention to all details and warnings specified
in the user manual and follow the instructions
given therein.
Use this user manual for the model indicated
on the cover page.
• Read the instructions.
Explanation of symbols
Throughout this user manual the following
symbols are used:
BDANGER!
• Warning against electric shock.
DANGER!
• Warning against fire hazard.
AWARNING!
• Warning for hazardous situations with regard
to life and property.
WARNING!
• Warning against hot surfaces.
This product was manufactured using the latest technology in environmentally friendly conditions.
WARNING!
• Warning against scalding hazard.
CNOTE
• Important information or useful hints about
usage.
Packaging materials of the product
are manufactured from recyclable
materials in accordance with our
National Environment Regulations.
Do not dispose of the packaging wastes with
the domestic waste or other wastes, discard
them to the dedicated collection points
designated by the local authorities.

3
Dryer / User Manual
1Important instructions for safety and environment
CNOTE
• This section contains safety
instructions that will help protect
from risk of personal injury or
property damage. Failure to follow
these instructions shall void any
warranty.
1.1 General safety
AWARNING!
The dryer can be used by children
at and above 8 years old and by
persons whose physical, sensory
or mental capabilities were not fully
developed or who lack experience
and knowledge provided that they
are supervised or trained on the
safe usage of the product and the
risks it brings out. Children should
not play with the product. Cleaning
and maintenance works should not
be performed by children unless
they are supervised by someone.
• Children of less than 3 years
should be kept away unless
continously supervised.
• Adjustable feet should not be
removed. The gap between the
dryer and the floor should not be
reduced with materials such as
carpet, wood and tape. This will
cause problems with the dryer.
AWARNING!
• Always have the installation and
repairing procedures carried out by
the
Authorised Service Agent.
The manufacturer shall not be held
liable for damages that may arise
from procedures carried out by
unauthorised persons.
• Never wash the dryer by spraying
or pouring water onto it! There is
the risk of electric shock!
For the products with a steam
function:
AWARNING!
• Use only distilled water or water
condensed in the water tank of the
machine in steam programs. Do
not use mains water or additives.
When using condensed water in the
water tank, it should be filtered and
cleared of fibres.
• Do not open the door when steam
programs are running. Hot water
may be expelled.
• Before putting laundry in a steam
program, stains on it should be
removed.
• You may only put laundry that is not
dirty or stained but permeated with
unpleasant odour in steam (odour
removal) program.
• Do not use any dry cleaning sets
or additional materials in a steam
program or in any program.

4 Dryer / User Manual
1.1.1 Electrical safety
BDANGER!
• Electrical safety instructions
should be followed while
electrical connection is made
during the installation.
• The appliance must not be
supplied through an external
switching device, such as a
timer,or connected to a circuit
that is regularly switched on
and off by utility.
• Connect the dryer to a grounded
outlet protected by a fuse at the
value specified on the type label.
Have the grounding installation
performed by a qualified electrician.
The manufacturer shall not be liable
for any damages that will arise when
the dryer is used without grounding
in accordance with the local
regulations.
• The voltage and allowed fuse
protection is stated on the type label
plate.
• The voltage specified on the type
label must be equal to your mains
voltage.
• Unplug the dryer when it is not in
use.
• Unplug the dryer from the mains
during installation, maintenance,
cleaning and repair works.
• Do not touch the plug with wet
hands! Never unplug by pulling
on the cable, always pull out by
grabbing the plug.
BDANGER!
• Do not use extension cords, multi-
plugs or adaptors to connect the
dryer to power supply in order to
decrease the risk of fire and electric
shock.
• Power cable plug must be easily
accessible after installation.
• Damaged mains cable should
be changed notifying the
Authorised Service Agent.
• If the dryer is faulty, it must not
be operated unless it is repaired
by an authorised service agent!
There is the risk of electric
shock!
1.1.2 Product safety
DANGER!
• Superheating of the clothes inside
of the dryer can occur if you cancel
the programme or in the event of
a power failure whilst the dryer is
running, this concentration of heat
can cause self-combustion and fire
so always activate the ventilation
programme to cool down or quickly
remove all laundry from the dryer in
order to hang them up and dissipate
the heat.
Points to be taken into
consideration for fire hazard:
Below specified laundry or items
must not be dried in the dryer
considering fire hazard.
• Unwashed laundry items

5
Dryer / User Manual
DANGER!
• Items soiled with oil, acetone,
alcohol, fuel oil, kerosene, stain
removers, turpentine, paraffin or
paraffin removers must be washed
in hot water with plenty of detergent
before being dried in the dryer.
For this reason especially the items
containing the above specified
stains must be washed very well,
to do this use adequate detergent
and choose a high washing
temperature.
Below specified laundry or
items must not be dried in the
dryer due to the fire hazard:
• Garments or pillows bolstered with
rubber foam (latex foam), shower
bonnets, water resistant textiles,
materials with rubber reinforcement
and rubber foam pads.
• Clothing cleaned with industrial
chemicals.
Items such as lighter, match,
coins, metal parts, needle etc. may
damage the drum set or may lead
to functional problems. Therefore
check all the laundry that you will
load into your dryer.
Never stop your dryer before the
programme completes. If you must
do this, remove all laundry quickly
and lay them out to dissipate the
heat.
• Clothes that are washed
inadequately may ignite on their
own and even may ignite after
drying ends.
DANGER!
• You must provide enough ventilation
in order to prevent gases exiting
from devices operating with other
types of fuels including the naked
flame from accumulating in the
room due to the back fire effect.
• Oil-affected items can ignite
spontaneously, especially when
exposed to heat sources such as in
a tumble dryer. The items become
warm, causing an oxidation reaction
in the oil. Oxidation creates heat. If
the heat cannot escape, the items
can become hot enough to catch
fire. Piling, stacking or storing oil-
affected items can prevent heat
from escaping and so create a fire
hazard.
• If it is unavoidable that fabrics that
contain vegetable or cooking oil or
have been contaminated by hair
care products be placed in a tumble
dryer they should first be washed in
hot water with extra detergent - this
will reduce, but not eliminate, the
hazard.
AWARNING!
• Underwear that contains metal
reinforcements should not be dried
in the dryer. Dryer may be damaged
if metal reinforcements come loose
and break off during drying.

6 Dryer / User Manual
CNOTE
• Use softeners and similar products
in accordance with the instructions
of their manufacturers.
Always clean the lint filter before or
after each loading. Never operate
the dryer without the lint filter
installed.
AWARNING!
• Never attempt to repair the dryer
by yourself. Do not perform any
repair or replacement procedures
on the product even if you know
or have the ability to perform the
required procedure unless it is
clearly suggested in the operating
instructions or the published service
manual. Otherwise, you will be
putting your life and others’ lives in
danger.
• There must not be a lockable,
sliding or hinged door that may
block the opening of the loading
door in the place where your dryer
is to be installed.
• Install your dryer at places suitable
for home use. (laundry room)
• Make sure that pets do not enter
the dryer. Check the inside of the
dryer before operating it.
• Do not lean on the loading door
of your dryer when it is open,
otherwise it may fall over.
• The lint must not be allowed to
accumulate around the tumble dryer
• The tumble dryer is not to be used if
industrial chemicals have been used
for cleaning.
AWARNING!
• Fabric softeners, or similar products.
should be used as specified by the
fabric softener instructions.
• Exhaust air must not be discharged
into a flue which is used for
exhausting fumes from appliances
burning gas or other fuels.
• The final step of the drying cycle
(cool-down cycle) occurs without
applying heat to ensure that the
items are left at a temperature that
will not damage them.
1.2 Stacking over a washing machine
• A fixing device should be used between
the two machines when stacking the
dryer above a washing machine. Ensure
you follow the instructions on the
Stacking Kit very carefully.
• Total weight of the washing machine
and the dryer -with full load- when
they are placed on top of each other
reaches to approx. 180 kilograms. Place
the products on a solid floor that has
sufficient load carrying capacity!
AWARNING!
• Washing machine cannot be placed on
the dryer. Pay attention to the above
warnings during the installation on your
washing machine.
Installation Table for Washing Machine and Dryer
Dryer
Depth
Washing Machine Depth
62 cm 60 cm 54 cm < 50 cm
54 cm Can be installed Cannot be
installed
60 cm Can be
installed Cannot be installed
1.3 Intended use
• Dryer has been designed for domestic
use. It is not suitable for commercial
use and it must not be used out of its
intended use.
• Use the dryer only for drying laundry that

7
Dryer / User Manual
are marked accordingly.
• The manufacturer waives any
responsibility arisen from incorrect usage
or transportation.
1.4 Child safety
• Packaging materials are dangerous for
the children. Keep packaging materials
away from children.
• Electrical products are dangerous for the
children. Keep children away from the
product when it is operating. Do not let
them tamper with the dryer. Use the child-
proof lock in order to prevent the children
to tamper with the dryer.
CNOTE
Child-proof lock is on the control panel.
(See Child lock)
• Keep loading door closed even when the
dryer is not in use.
1.5 Compliance with the WEEE
regulation and disposing of the waste
product
This product complies with EU
WEEE Directive (2012/19/EU). This
product bears a classification
symbol for waste electrical and
electronic equipment (WEEE).
This product has been
manufactured with high quality
parts and materials which can be reused and
are suitable for recycling. Do not dispose of
the waste product with normal domestic and
other wastes at the end of its service life. Take
it to the collection center for the recycling of
electrical and electronic equipment. Please
consult your local authorities to learn about
these collection centers.
1.6 Compliance with RoHS Directive:
The product you have purchased complies
with EU RoHS Directive (2011/65/EU). It does
not contain harmful and prohibited materials
specified in the Directive.
1.7 Package information
Packaging materials of the product are
manufactured from recyclable materials in
accordance with our National Environment
Regulations. Do not dispose of the packaging
materials together with the domestic or other
wastes. Take them to the packaging material
collection points designated by the local
authorities.
1.8 Technical Specifications
* Min. height: Height with adjustable feet are
closed.
Max. height: Height with adjustable feet are
opened maximum.
** Dry laundry weight before washing.
*** Type label is located behind the loading
door.
CNOTE
• Technical specifications of the dryer are
subject to specification without notice to
improve the quality of the product.
• Figures in this manual are schematic and
may not match the product exactly.
• Values stated on markers on the dryer
or in the other published documentation
accompanying with the dryer are
obtained in laboratory in accordance with
the relevant standards. Depending on
operational and environmental conditions
of the dryer, these values may vary.
EN
Height (Min. /
Max.) 84,6 cm / 86,6 cm*
Width 59,7 cm
Depth 58,9 cm
Capacity (max.) 8 kg**
Net weight (± 4
kg) 44 kg
Voltage
See type label***Rated power input
Model code

8 Dryer / User Manual
2 Your Dryer
11
10
1
2
3
4
5
6
7
8
9
2.1 Overview
1. Top panel
2. Control panel
3. Loading door
4. Kick plate opening button
5. Ventilation grids
6. Adjustable legs
7. In models where the tank is placed below,
the water tank is inside the toe board
8. Type label
9. Lint filter
10. Water tank drawer (in models where the
tank is placed above)
11. Power cord
2.2 Package Contents
1. Water
drain
hose *
5. Drying
basket
user
manual*
2. Filter
drawer
spare
sponge*
6. Water
Filling
Container*
3. User
Manual
7. Pure
Water*
4. Drying
basket*
8.
Fragrance
Capsules
Group*
*Optional - may not be included, depends on
model.
3 Installation
Before installation, ensure that electrical
installation and water drain is appropriate
referring to the user’s manual.If they are not
suitable, contact a qualified electrician and
technician to make necessary arrangements.
CNOTE
• Preparation of the dryer’s location
as well as the electrical and waste
water installations is under customer’s
responsibility.
AWARNING!
• Prior to installation, visually check if the
dryer has any defects on it. If the drier
is damaged, do not have it installed.
Damaged products cause risks for your
safety.
• Let your dryer wait for 12 hours before
starting to use it.
3.1 Appropriate installation location
Install the dryer on a stable and level surface.
Dryer is heavy. Do not move it by yourself.
• Operate your dryer in a well ventilated,
dust-free environment.
• The gap between the dryer and the
surface should not be reduced by the
materials such as carpet, wood and tape.
• Do not cover the ventilation grills of the
dryer.
• There must not be a lockable, sliding or
hinged door that may block the opening
of the loading door in the place where
your dryer is to be installed.
• Once the dryer is installed, it should stay
at the same place where its connections
have been made. When installing the
dryer, make sure that its rear wall does
not touch anywhere (tap, socket, etc.).
• Place the dryer at least 1 cm away from
the edges of other furniture.
• Your dryer can be operated at
temperatures between +5°C and +35°C.

9
Dryer / User Manual
If the operating conditions fall outside
of this range, operation of the dryer will
be adversely affected and it can get
damaged.
• The rear surface of the tumble dryer shall
be placed against a wall.
BDANGER!
Do not place the dryer on the power cable.
*Ignore following warning if your
product’s system does not contains
R290.
DANGER!
• Dryer contains R290 refrigerant.*
• R290 is an environment-friendly, but
flammable refrigerant.*
• Ensure that the air inlet of the dryer is
open and it is well-ventilated.*
• Keep potential flame sources away from
the dryer.*
3.2 Removing the transportation
safety assembly
AWARNING!
• Remove the
transportation
safety assembly
before using the
dryer for the first
time.
• If the door swing
side of your
appliance can
be modified, see
the reversible
door mounting
instructions.
3.3 Connecting to the drain
You can directly drain accumulated water
through the water drain hose supplied with
the product instead of periodically draining the
water collected in the water tank.
Connecting the water drain hose
1
3 4
2
1-2 Pull hose at
the behind of
the dryer by
hand in order
to disconnect
it from where it
is connected.
Do not use
any tools to
remove the
hose.
3Connect one end of the drain hose
supplied with the dryer to the connection
point from where you removed the hose of
the product in previous step.
4Connect the other end of the drain hose
directly to the wastewater drain or to the
washbasin.
CNOTE
• Water drain hose should be attached to a
height of maximum 80 cm.
• Make sure that the water drain hose is not
stepped on and it is not folded between
the drain and the machine.
• If there is an accessories pack supplied
with your product, please see the detailed
description.
3.4 Adjusting the feet
• Turn the feet to
left or right until
the dryer stands
level and firmly.

10 Dryer / User Manual
3.5 Transportation of the dryer
Drain all water that has remained in the dryer.
If direct water drain connection is made, then
remove the hose connections.
AWARNING!
• We recommend carrying the dryer in
upright position. If it is not possible to
carry the machine in the upright position,
we recommend carrying it by tilting
towards the right side when looked from
the front.
3.6 Warnings about sounds
CNOTE
• It is normal to
hear a metallic
noise from the
compressor
sometimes during
operation.
• Water collected during operation is
pumped to water tank. It is normal to
hear pumping noise during this process.
3.7 Changing the illumination lamp
In case an illumination lamp is used in your
laundry dryer.To change the Bulb/LED used
for illumination of your tumble dryer, call your
Authorised Service Agent.The lamp(s) used
in this appliance is not suitable for household
room illumination. The intended purpose of
this lamp is to assist the user to place laundry
in the tumble dryer in a comfortable way. The
lamps used in this appliance have to withstand
extreme physical conditions such as vibrations
and temperatures above 50 °C

11
Dryer / User Manual
4 Preparation • For models with a condenser unit: clean
the condenser once in a month or after
every 30 operations regularly. .
• Clean the filter periodically.Read the
Maintenance and cleaning of filters for
detalied information.
• For models with flue unit: comply with the
flue connection instructions and clean the
flue.
• During the drying process, air the room
well where your tumble dryer is operating.
4.5 Correct load capacity
Follow the instructions
in the “Programme
selection and
consumption table”.
Do not load more than
the capacity values
stated in the table.
Following weights are given as examples.
Laundry Approximate
weights (g)* Laundry Approximate
weights (g)*
Cotton
quilt covers
(double)
1500 Blouses 150
Cotton quilt
covers (single) 1000 Cotton shirts 300
Bed sheets
(double) 500 Shirts 250
Bed sheets
(single) 350 Cotton
dresses 500
Large
tablecloths 700 Dresses 350
Small
tablecloths 250 Jeans 700
Tea Towels 100 Handkerchiefs
(10 pieces) 100
Bath towels 700 T-Shirts 125
Hand towels 350
*Dry laundry weight before washing.
4.1 Laundry suitable for drying in the
dryer
Always obey the instructions given on the
garment tags. Dry only the laundry having a
label stating that they are suitable for drying in
a dryer.
4.2 Laundry not suitable for drying in
the dryer
Items with this symbol
Do not dry
with dryer should not be
dried in the dryer.
CNOTE
• Delicate embroidered fabrics, woollen,
silk garments, delicate and valuable
fabrics, airtight items and tulle curtains
are not suitable for machine drying.
4.3 Preparing laundry for drying
• Laundry may be tangled with each other
after washing. Separate the laundry items
before placing them into the dryer.
• Dry garments having metal accessories
such as zippers, inside out.
• Fasten the zippers, hooks and buckles
and button sheets.
4.4 Things to be done for energy
saving
• Spin your laundry at the highest speed
possible when washing them. Thus,
the drying time is shortened and energy
consumption is reduced.
• Sort out the laundry depending on their
type and thickness. Dry the same type of
laundry together. For example thin kitchen
towels and tableclothes dries earlier than
thick bathroom towels.
• Follow the instructions in the user manual
for programme selection.
• Do not open the loading door of the
machine during drying unless necessary.
If you must open the loading door, do not
keep it open for a long time.
• Do not add wet laundry while the dryer is
in operation

12 Dryer / User Manual
5 Operating the product
5.1 Control Panel
1. On/Off/Program selection button
2. Start/Pause button
3. Time Program button
4. End Time button
5. Drying Level Button
6. Buzzer volume button
Select the desired program using the On/Off/
Program selection knob, the machine will turn
on.
CNOTE
• Selecting a program using the On/Off/
Program selection button does not mean
that the program started. Press the Start
/ Stand-by button to start the program.
5.3. Preparation of drying machine
• Plug the drying machine.
• Open the loading door.
• Place the laundry to the drying machine
without jamming them.
• Push and close the loading door.
AWARNING!
• Ensure that no
laundry is jammed
to the loading
door.
Volume up
Filter
cleaning
Tank
full
Child-proof
lock
Mute
Filter drawer /
Heat exchanger
cleaning
End/anti-
creasing
On/O Timer
Delay
Drying Cupboard
Dry
Iron Dry
Express
14’
Delicates
Jeans BabyProtect Extra dry Cupboard
dry plus
Sport Freshen Up
Start
pause
cancel
Cottons
Synthetics
Mix
Express
30’
Drying Rack/
TimeDry
Daily Bedding
Duvet/
DownWear
Express
Shirt 30'
Wool Refresh Hygiene
(BabyProtect+)
Shirts Cottons Eco
Refreshment Low
temparature
select
Dryness
Level+
Dryness
Level++
4
5 6
3
1
2
5.2 Symbols

13
Dryer / User Manual
5.4 Program selection and consumption chart
EN
Programmes Programme Description
Capacity (kg)
Spin speed in
washing machine
(rpm)
Drying Time
(minutes)
Cottons Iron Dry
You may dry your cotton laundry to be ironed in
this program to have them slightly damp for ease
of ironing. (Shirt, T-shirt, tablecloth, etc.)
8 1000 150
Cottons Eco
You may dry all your cotton laundry in this
program. (T-shirt, pants, pyjamas, baby clothes,
underwear, linen, etc.) You can put your laundry
in the wardrobe without ironing.
8 1000 209
Cottons Cupboard Dry
You may use this program for extra dryness in
thick laundry such as pants, tracksuit. You can
put your laundry in the wardrobe without ironing.
8 1000 219
Cottons Extra Dry
You may dry your thick cotton laundry in this
program such as towels, bathrobe, etc. You can
put your laundry in the wardrobe without ironing.
8 1000 229
Synthetics Iron Dry
You may dry your synthetic laundry to be ironed
in this program to have them slightly damp for
ease of ironing. (Shirt, T-shirt, tablecloth, etc.)
4 800 55
Synthetics Cupboard Dry
You may dry all your synthetic laundry in this
program. (Shirt, T-shirt, underwear, tablecloth,
etc.) You can put your laundry in the wardrobe
without ironing.
4 800 75
TimeDry
You may select from time programmes
between 10 and 160 minutes to achieve the
desired drying level at low temperature. In this
programme, tumble drier’s operation lasts for
the set time independently from the dryness of
laundry. This product is available to be used with
a drying basket as option. For products that are
sold without a basket, you can obtain a basket
from an authorised service agent and use the
drying programs specified above. For details of
use, see the drying basket user guide.
- - -
Freshen Up
Ventilates for 10 minutes without blowing hot air.
You can ventilate the cotton and linen clothes
that have been enclosed for a long time with this
program to remove their odour. You can use this
program to ventilate and soften wool laundry that
can be washed in a washing machine. Do not
use for full drying.
- - 10

14 Dryer / User Manual
Shirts It dries the shirts in a more sensitive manner, and
causes less creasing and easier ironing. 1,5 1200 65
Jeans You may dry denim pants, skirts, shirts or jackets
in this program. 4 1200 130
Outdoor/Sports
Use it to dry your clothes made of synthetics,
cotton or mixed fabrics or waterproof products
such as functional jacket, raincoat etc. Turn them
inside out prior to drying.
2 1000 135
Mix / Daily
You can dry both cotton and synthetic laundry
with this programme.Sports and fitness clothes
may be dried with this program.
4 1000 125
BabyProtect
It is a long-term program that you can use for the
clothes (baby clothes, towels, underwear, etc.
cotton) you require hygeine. Hygiene is provided
with high temperature. It is especially suitable for
durable fabrics. ((This program is identified and
approved by England’s “The British Foundation”
(Allergy UK).))
5 800 215
DownWear
You can dry your feather or fibre filled textile
that bears can be dried in dryer label as a single
piece of laundry. You can dry king size quilt,
pillow or coats as single piece of laundry. Dry
your clothes such as coats and jackets turned
inside out.
- 800 165
Daily Express Use this program to have 2 shirts ready for
ironing. 0,5 1200 30
Energy consumption values
Programmes Capacity (kg) Energy consumption
value kWh per year
Energy rating
star
Cottons-Extra Dry*
Dryness Level 1
8 180 6
Contains fluorinated greenhouse gases. Hermetically sealed R450a / 0,20 kg - GWP:604 -
0,121 tCO2e
* : Energy Label standard program (EN 61121:2012) All values in the table are determined
according to EN 61121:2012 standard. Consumption values may vary from the values in the chart
depending on laundry type, wringing speed, ambient conditions and voltage levels.
* : Energy Label standard program (AS/NZS 2442) “All the filters must be cleaned prior to test
series.”
All values given in the table have been fixed according to standard laboratory conditions.
These values may deviate from the table according to the laundry type, laundry spin speed,
environmental conditions and voltage fluctuations.

15
Dryer / User Manual
CNOTE
• You can add or remove laundry within
end time. Displayed time is the sum of
normal drying time and end time. End
Time LED will turn off at the end of
countdown, drying starts and drying LED
will illuminate.
Changing the end time
If you want to change the duration during the
countdown:
Cancel the program by turning the On/Off/
Program selection knob. Select the program
you want and repeat the End Time selection
process.
Cancelling the end time function
If you want to cancel the end time countdown
and start the program immediately:
Cancel the program by turning the On/Off/
Program selection knob. Select the program
you want and press the Start/Stand-by button.
5.6 Warning indicators
CNOTE
• Warning indicators may vary depending
on the model of your dryer.
Filter cleaning
When the program is completed, the warning
indicator for filter cleaning turns on.
Water tank
If the water tank fills up while the program
continues, the warning indicator starts flashing
and the machine goes into stand-by. In this
case, empty the water tank and start the
program by pressing the Start / Stand-by
button. Warning indicator turns off and program
resumes.
Filter drawer /Heat exchanger cleaning
When the programme is finished, the cleaning
symbol of the heat exchanger or filter drawer
may light up.
5.7 Starting the program
Press the Start/Stand-by button to start the
program.
Start/Stand-by and Drying indicators will
illuminate to indicate that program started.
Allergy UK is the brand of the
British Allergy Association. Seal
of Approval is created to guide
people that require
recommendation about a
product that the related
product restricts / reduces / eliminates the
allergens or reduces the allergen content
significantly in the ambient where allergy
patients exist. It aims to provide assurance
that the products are tested scientifically or
examined in a way to provide measurable
results.
5.5 Auxiliary functions
Buzzer / time
Drying machine makes an audible warning
when the program is completed. If you don’t
want the machine to make an audible warning,
press the “Buzzer / Time” button. When you
press the Buzzer/Time button, a light will
illuminate and no audible warning will be made
when the program ends.
CNOTE
• You can select this function before or
after the program starts.
Buzzer/Time button is used to adjust program
duration while the Rack/Time programs are
selected.
Drying Level
Drying Level button is used for adjusting to
desired dryness level. Program duration may
change depending on the selection.
CNOTE
• You can activate this function only prior
to start of program.
End time
You can delay the end time of the program up
to 24 hours with End time function.
1. Open the loading door and place the
laundry.
2. Select the drying program.
3. Press the End Time selection button and
set the delay time you wish. End Time
LED will illuminate. (When pressed and
hold the button, End Time proceeds non-
stop).
4. Press the Start / Stand-by button. End
Time countdown starts. “:” Separator in
the middle of displayed delay time flashes.

16 Dryer / User Manual
5.8 Child Lock
The drying machine has a child lock which
prevents the program flow from being
interrupted when the buttons are pressed
during a program. When the child lock is
activated, all buttons on the panel except
the On/Off/Program selection knob are
deactivated.
Press the Drying Level and Buzzer buttons
simultaneously for 3 buttons to activate the
child lock.
The child lock has to be deactivated to be
able to start a new program after the current
program is finished or to be able to interfere
with the program. To deactivate the child lock,
keep the same buttons pressed for 3 seconds.
CNOTE
• When the child lock is activated, the child
lock warning indicator on the screen
turns on.
• Child lock deactivates when the drying
machine is turned off and on by the On/
Off/Cancel knob.
CNOTE
• When the drying machine runs and
the child lock is active, it beeps twice
when the program selection knob is
turned. If the child lock is deactivated
without returning the program selection
knob to its previous position, program
will terminate due to the change in the
program selection knob position.
5.9 Changing the program after it is
started
You can change the program you selected to
dry your laundry with a different program after
the drying machine starts running
• For instance, select Extra Dry program
by turning the On/Off/Program selection
knob to select Extra Dry instead of Iron
Dry.
• Press the Start/Stand-by button to start
the program.
Adding and removing clothes during
stand-by
If you want to add or remove clothes to/from
the drying machine after the drying program
starts:
• Press the Start/Stand-by button to put
the drying machine in Stand-by state. The
drying operation stops.
• Open the loading door while in Stand-
by state, and close the door after you
remove or add laundry.
• Press the Start/Stand-by button to start
the program.
CNOTE
• Adding laundry after the drying operation
starts may cause the dried laundry inside
the machine to mix with wet laundry and
leave the laundry damp at the end of
operation.
CNOTE
• Adding or removing laundry during drying
may be repeated as many times as you
wish. But this operation continuously
interrupts the drying operation, and thus
increases program duration and energy
consumption. So, it is recommended to
add laundry before the program starts.
• If a new program is selected by turning
the program selection knob while the
drying machine is in stand-by, the
running program terminates.
WARNING!
• Do not touch the inner surface of the
drum while adding or removing clothes
during a continuing program. The drum
surface is hot.

17
Dryer / User Manual
5.10 Cancelling the program
If you want to cancel the program and
terminate the drying operation for any reason
after the drying machine starts running, turn
the On/Off/Cancel knob, the program will be
cancelled.
AWARNING!
• The inside of the drying machine shall
be extremely hot when you cancel the
program during machine operation, so
run the refresh program to allow it to cool
down.
5.11 End of program
When the program ends, the Last/Anti-Wrinkle
and Fibre Filter Cleaning Warning LEDs on
the program follow up indicator will illuminate.
Loading door may be opened and the dryer
machine becomes ready for another run.
Bring the On/Off/Program selection knob to
On/Off position to turn the drying machine off.
CNOTE
• If the laundry is not removed after the
program is completed, the wrinkle
prevention function activates for 2 hours
to prevent the laundry inside the machine
to get wrinkled. The program tumbles
the laundry with 10-minute intervals to
prevent them from wrinkling.

18 Dryer / User Manual
6 Maintenance and cleaning
Service life of product extends and frequently
experienced problems will be reduced if it is
cleaned at regular intervals.
AWARNING!
• Please unplug your product before
performing maintenance and cleaning
instructions. (eg control panel, body, etc.)
6.1 Cleaning Lint Filter / Loading
Door Inner Surface
Lint and fiber released from the laundry to the
air during the drying cycle are collected in the
Lint Filter.
CNOTE
• You can clean the lint filter housing with a
vacuum cleaner.
AWARNING!
• Always clean the lint filter and the inner
surfaces of the loading door after each
drying process.
To clean the lint filter:
• Open the
loading door.
• Remove the
lint filter by
pulling it up
and open the
lint filter.
• Clean lint, fiber, and cotton raveling by
hand or with a soft piece of cloth.
• Close the lint filter and place it back into
its housing.
A layer can build up
on the filter pores that
can cause clogging
of the filter after using
the dryer for a while.
Wash the lint filter with
warm water to remove
the layer that builds
up on the lint filter
surface. Dry the lint
filter completely before
reinstalling it.
• Clean the entire inner surface of the
loading door and loading door gasket
with a soft damp cloth.
6.2 Cleaning the sensor
There are
dampness sensors
in the dryer that
detect whether
the laundry is dry
or not.
To clean the
sensors:
• Open the loading door of the dryer.
• Allow the machine to cool down if it is still
hot due to the drying process.
• Wipe the metal surfaces of the sensor
with a soft cloth, dampened with vinegar
and dry them.
CNOTE
• Clean metal surfaces of the sensors 4
times a year.
• Do not use metal tools when cleaning
metal surfaces of the sensors.
AWARNING!
• Never use solvents, cleaning agents or
similar substances for cleaning due to the
risk of fire and explosion!

19
Dryer / User Manual
6.3 Draining the water tank
Dampness of the laundry is removed and
condensed during drying process and the
water that arise accumulates in the water tank.
Drain the water tank after each drying cycle.
AWARNING!
• Condensed water is not drinkable!
• Never remove the water tank when the
program is running!
If you forget to drain the water tank, the
machine will stop during the subsequent drying
cycles when the water tank is full and the Water
Tank warning symbol will flash. If this is the
case, drain the water tank and press Start /
Pause button to resume the drying cycle.
To drain the water tank:
1. Remove the water tank in the drawer
or container carefully.
2. Drain the water in the tank.
• If there is lint accumulation in the funnel
of the water tank, clean it under running
water.
• Place the water tank into its seat.
CNOTE
• If the direct water draining is used as an
option, there is no need to empty the
water tank.
6.4 Cleaning the filter drawer
Lint and fiber that could not be captured by the
lint filter are blocked in the filter drawer behind
the kick plate. Clean the filter periodically when
there is visible air collection on it or when
the symbol lights up, if there is a filter drawer
cleaning warning symbol available.
There is an one stage filter. This one stage filter
is from sponge
To clean the filter drawer:
• Press the kick
plate button to
open the kick
plate.
• Open the filter drawer cap turning the
cap lock on it and pull it out..
• Open the filter
drawer by
pressing the red
button.
• Take out the filter
drawer sponge.
• Clean the fluff and lint over the filter
sponge washing it with your hands.
Remove the moisture squeezing the
sponge with your hands after washing it.
• Clean the fluff, lint and cotton pellets with
your hands or with a soft cloth.

20 Dryer / User Manual
• If you observe a
layer over the filter
which can block
the filter, remove
the layer washing
with a water and
then cleaning it.
Dry the filter cloth
properly before
replacing the filter
drawer.
CNOTE
• There may be no cloth in the filter
cassette of your drying machine,
depending on its model.
• Place the sponge
back into its
place.
CNOTE
• Please place the sponge carefully inside
the frame of the filter cassette shown by
arrows in order to avoid squeezing when
filter drawer closed”.:
• Close the filter
drawer as to lock
the red button.
• Replace the filter drawer and tighten the
cap turning the filter drawer lock turning it
in the arrow direction.
• Close the kick plate
cover.
AWARNING!
• Drying without the filter drawer sponge in
place will damage the machine!
CNOTE
• A dirty lint filter and filter drawer will cause
longer drying periods and higher energy
consumption.
6.5 Cleaning the evaporator
• Clean the lint
accumulated
on the fins of
the evaporator
located behind
the filter drawer
with a vacuum
cleaner.
AWARNING!
• You can also clean by hand provided that
you wear protective gloves. Do not attempt
to clean with bare hands. Evaporator fins
can harm your hand.
