Operating Instructions
COLOUR TELEVISIONS
17” WIDE SCREEN LCD TV

-4-
Important Information
Cleaning the screen and the cabinet...
After turning off the power, clean the screen and the cabinet with a soft, dry cloth. We
recommend that you do not use any proprietary polishes or solvents on the screen or
cabinet as this may cause damage.
Disposal...
The cold cathode fluorescent lamp in the LCD panel contains a small amount of mercury,
when the set reaches the end of its useful life please dispose of it in accordance with
Local Government Regulations or at a recycling centre.
The LCD display panels are manufactured using an extremely high level of precision technology,
however sometimes some parts of the screen may have missing picture elements or have luminous
spots. This is not a sign of a malfunction.

-5-
Television
Thank you for buying this television which is designed to give you many years
of satisfactory service.
You may already be familiar with using a television but do please take time to
read these instructions. They are designed to familiarise you with the unit’s
many new features and to ensure you get the very best out of your purchase.
Special features
• 17” wide TFT-LCD WXGA Panel
• 1152x864 resolution
• 16,722,216 colors (8 bit)
• PAL
• 450 cd/ brighthess
• 600:1 Contrast ratio
• 2x3W Stereo Sound
• 124 page teletext
• Wide viewing angles
• 2 Scart , AV , Audio Out.
• Low Power
• AVL
• ATS
• Intelligent programme switch
• On timer
• Off timer
• Graphical equaliser
• On screen display
• Manual fine tuning
• 100 Programme memory
• Full function remote control
• VGA INPUT (P.C.) Model dependant.
• Child Lock
• Stereo headphone socket

-6-
Safety is Important
Your safety and the safety of others is important. Please, therefore, ensure you read
the Safetyinstructions before you operate this television.
Safety instructions
Read all the safety instructions before first use of your TV.
!
• Position the television so that direct light does not fall on
the screen. Excessive light will cause a washed out effect.
• Position the power supply lead and other leads so that
they are not likely to be walked on or pinched by things
placed on or against them.
• Do not place objects filled with liquid such as vase or
flower pot near the television.
• Do not expose the TV to dripping or splashing of liquids.
• Do not place naked flame sources such as lighted candles
on the TV set.
1m
12 V
4.5 A
• Make sure that no naked flame sources, such as lighted
candles, are placed on top of the appliance.
• The heat built up in the set escapes through ventilation
holes, so do not cover the set by drapes, clothes etc. that may
block air circulation. Do not place the television on carpet
or soft furnishings.
• Clean the TV Screen using a slightly damp cloth or chamois
leather. Never use abrasive cleaning agents like liquid or
aerosol cleaners.
• Your TV set is designed to operate with the adapter provided
12V DC.-4,5A.
• Do not place the television near heat sources such as
radiators, ovens, stoves, etc.
• NEVER let children push anything into the holes or slots
on the case.
• Remove the mains plug from the socket outlet while cleaning.
• Do not push, hit or screw the screen of your product.
• Use the adaptor supplied with the product. Never connect
any other power sources to the product.
• Never apply pressure on the screen when cleaning.
• Never put your screen on hard objects. Your TFT screen
may be damaged.

-7-
Getting started
Remove your Television carefully from the box.
You may wish to store the packaging for future
use.
Please Note
When not in use disconnect the plug from the
mains power supply.
Please Note
Do not leave the television in standby unattended
or overnight.
Switching the TV on for the first time
To install your TV, please read the sections
“TV controls” and “ Tuning the television”.
4. Press the Power button on the side
of the TV. The standby indicator will
illuminate.
5. Press a Numeric button or the
Program up or Program down button
on the remote handset or Program
up, Program down or MENU button
on the front panel to switch the TV
on.
The standby indicator remains on.
The picture will appear after a few
seconds.
Press the Standby button to switch the
TV to standby. The standby indicator will
brighten.
Please note
If you live in a poor reception area or use an
indoor aerial you may experience loss or
corruption of teletext transmissions.
In the box
Aerial connection
Switching on and First Use
1. Connect the power cord to the mains adapter.
2. Connect the input socket of the adapter to
the12 V DC socket at the back panel of the
LCD TV.
3. Connect adapter to a suitable mains socket.
Note 1: Your TV will switch to stand-by mode
in five minutes when there is no broadcast signal.
Note 2: Your TV is equipped to operate with
front panel buttons, “MENU”, “PR+”, “PR-”,
“VOL+”, “VOL–” in case your R/C is broken or
the batteries are exhausted.
Inside the carton box you should have:
• Accessories box
• Power cord
• Adapter
• Remote control
• Batteries
Read these instructions before use.
You can use an outdoor or indoor aerial.
However, if you use an indoor aerial the quality
of the reception may be reduced and adjustment
of the aerial may be required when changing
programs.
To connect an aerial, plug the aerial lead
into the aerial socket on the rear of the
TV.
The batteries
Remove the remote back cover to reveal the
battery compartment and make sure you insert
the batteries the right way round.
Suitable battery types for this remote are
UM-4, IEC R03 or AAA 1.5V.
Do not throw your old batteries into a fire, dispose
of them in a designated disposal area.
Do not combine a used, old battery with a new
one or mix battery types.
The performance of the remote control will
deteriorate beyond a distance of 8 metres or
outside an angle of 30 degrees from the centre
of the TV.
7

Control Unit
10
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
Stand-by Led
Remote control sensor
Power on / off
Volume down
Volume up
Menu button
TV/AV
Program down
Program up
Speaker
11.
12.
13.
14.
15.
16.
17.
18.
19.
20.
Audio phono (R)
Audio phono (L)
Video input phono connector
S-VHS
Headphone socket
Aerial input
Audio out (R,L)
2 Scart
DC 12V Power supply input
VGA (PC Input)
Please note
•See the external connections table on next page for avaible connections.
•Do not use Video Phono and S-Video connections at the same time, otherwise they
will effect the picture quality.
•RGB inputs from scart will give you better picture quality.
1112 13 1417 19 20
AUDIO OUT
AV3
L R VIDEOL R S-VHS
AVS
DC 12V VGA
-8-
15
16
18

Remote control
External connections table
LCD panel
size/type
17” 16:9
active
matrix TFT
AV1 Scart
Headphone
socket
Audio/Video
PHONO
S-Video
socket
Back audio
out
STD.
STD.
STD.
STD.
STD.
AV2 Scart STD.
STD
OPT
N/A
: Standard
: Optional
: Not available
123
4
7
AV
5
8
0
6
9
-/--
OK
TV/TX
MENU
PP
SWAP
REVEAL
DOUBLE
HOLD
SUB
UPDATE
MIX
P100
SMART CONTROLS
16:9
TV/PC
Volume up
Program down
Sound smart control
Menu
Program up
Standby
Numeric
Two digit
Features Menu button
Blue teletext button
Setup Menu button
Swap
Picture format
Double heigth (Text)
Sub page button (Text)
Volume down
TV/Teletext
Index page (Text)
Reveal info (Text)
TV mode button (Text)
Stop button
Picture smart control
Personal preference
Text mode button
Red teletext button
Sound Menu button
Green teletext button
Picture Menu button
Yellow teletext button
Program table button
OK
AV
Mute
-9-

-10-
Using the TV
Turning on for the first time and Tuning
TV controls
Stand-By mode
Programme selection
Press the Program up/Program down
buttons on the TV or on the remote
control or press a Numeric button to
select a programme.
To mute the sound press the Mute button
on the remote control. A loudspeaker
symbol will appear on the screen.
Press the Volume + or Volume - button
on the TV or the Vol or Vol button
on the remote control. A sound level
bar will appear on the screen.
Mute
Volume
OK
TV/TX
You can also select a program by
pressing the Yellow button to see the
Program Table.
To select a programme whose number
is greater than 9 using the numeric
buttons, press the -/-- button first and
then press the two Numeric buttons.
For example, to select programme
12, press the -/- button followed by
1 then and 2.
Use the Program up and Program
down buttons to scroll through the
programme numbers. When you
find the program number you want
press the OK button.
Press the TV/TX button to close the
Program Table.
Please Note: If you will not use your TV for
a long period, do not leave it on Stand-By
mode, instead switch it off from the power
button on the side panel of the TV set.
When your TV is working, press the
red “STAND-BY” button on the right
upper corner of your remote control
to switch off and the Stand-By indicator
(Led) will be brighter. To turn on your
TV again, press the numeric buttons,
or Program up or Program down.
1
-/--
1
2

-11-
Press the Mute button again to restore
the sound. The symbol will disappear.
Pressing Volume up button will also
restore the sound.
But pressing the Volume down
button will decrease the volume
without restoring.
PP
Personal preference. Press the PP
button to revert to the default settings
for the TV. (See TV setup).
Swap
Tuning the television
There are two ways of tuning your television:
Manual, where you control the tuning process
or Autoprogram where the television does it
all automatically.
This function will automatically tune name and
arrange programs found in the followıng order.
PROGRAM NO
1 BBC1
2 BBC2
3 ITV
4 CHANNEL 4
5 CHANNEL 5
Please Note
If the TV is set to a channel with no signal the
TV will return to standby in 5 minutes.
The last minute remaining is displayed on
the screen.
Automatic tuning (Autoprogram)
There are two ways to access the SETUP
menu:
Press the blue Setup button. Or Press
the Menu button and use the Program
down button to select SETUP. Press the
OK button to enter the SETUP menu.
Your TV has 2 scarts so each time you
press your AV button, your input will
change as follows:
Press the AV button again to return
to TV mode.
1 AV1 when using SCART socket 1
(RGB support).
2 AV2 when using SCART socket 2.
3 AV3 when using the phono sockets
of the TV.
4 AVS when using the S-video socket.
SWAP
PP
AV
OK
MENU
Press swap button to recall the last
programme you watched.
AV
MAIN MENU
SOUND
PROGRAM TABLE
SETUP
FEATURE
SETUP
CHANNEL
SYSTEM
SEARCH
FINE TUNE
PROGRAM NUMBER
AUTO PROGRAM
STORE
I

12-
When you are sure the aerial is
connected properly press the OK button.
Autoprogam will start.
Use the Program down button to select
AUTOPROGRAM and then the OK
button. A list of countries will appear.
Select (UK) using Program and Volume
buttons.
To cancel Autoprogram whilst it is
working press the Menu button
repetitively.
Please note:
If auto sort fails to arrange the programmes in
the required sequence please refer to programme
organising.
In the Setup menu select
PROGRAM No. using the Program
down button and use the Volume
up button to change the Program
No to 01.
Starting with Program 01, tune
in the first channel as follows:
Use the Program down button to
select SEARCH.
Press the Volume up or Volume
down button to start the tuning
search.
When the search finds a strong
channel signal it will stop
searching. The picture will appear.
Use the Program down button to
select PROGRAM No.
Use the Volume up/down or
numeric buttons to select the
desired programme number.
Use the Program down button to
select STORE. Press the OK button
and STORED will appear on the
STORE line.
You have now stored the first
channel.
Use the Program up button to
select again SEARCH and
continue the tuning procedure
until you have tuned in all the
programmes you want or the
television can receive.
Manual tuning
If you want to tune manually:
Please note
If you do not press any buttons for 15 seconds
the TV will exit the menu system.
OK
MENU
OK
As Autoprogram stores a channel it will
appear briefly on the screen before the
search continues.
OK
Your TV is now tuned and ready to use.
SETUP
CHANNEL
SYSTEM
SEARCH
FINE TUNE
PROGRAM NUMBER
AUTO PROGRAM
STORE
I

-13-
Tuning with channel numbers
Enter the SETUP menu by pressing
the blue button.
To exit the SETUP menu press the TV/TX
button.
In the SETUP menu use the Program
up/down buttons to select FINE
TUNING. Use the Volume up/down
buttons to fine tune.
When you have finished use the
Program down button to select
STORE and press the OK button.
Press the OK button when CHANNEL
row is blue.
Use the OK button to select “S” for
cable channels and “C” for terrestrial
broadcast.
Enter the channel number using the
Numeric buttons or use the
Volume up/down buttons to tune
channels.
Use the Program down button to select
PROGRAM NUMBER.
Use the Volume up/down or numeric
buttons to select the desired
programme number.
Use the Program down button to select
STORE. Press the OK button and
STORED will appear on the STORE
line.
You have now stored the first channel.
Use the Program up button to select
again CHANNEL and continue
the tuning procedure until you
have tuned in all the programmes
you want or the television can
receive.
OK
7
OK
OK
TV/TX
Fine tuning
Although the search and Autoprogram
will automatically try and tune to the
best reception, in areas of poor reception
fine tuning may be required.
SETUP
CHANNEL
SYSTEM
SEARCH
FINE TUNE
PROGRAM NUMBER
AUTO PROGRAM
STORE
I
OK

-14-
Program organising
Once you have tuned in all the channels you
want, you can change their programme
number, if required, and name them.
To enter the PROGRAM TABLE menu
press the Menu button and select
PROGRAM TABLE and press the OK
button or press directly the Yellow
button.
The buttons used to edit the programs are
shown at the bottom of the display:
Blue button
Green button
Purple button
Red button
Please Note
1. Some TV channels may send their
names with teletext transmission. In this
case their names will be automatically
shown on the name line.
2. Child locked programmes will be
shown as “ “
MENU
OK
To name the programmes
Press the Blue button again to store
the name.
Repeat this process to name all the
programmes.
You can name the programmes and
AV inputs.
Press the Blue button, the selected
programme will be highlighted.
Use the Program up and Program
down buttons to select the letters
and numbers and the Volume up and
Volume down buttons to move
through the name.
Select the programme you want to
move and press the Green button.
The programme will turn to
yellow.Select the number you want
to move to and press the Green
button again the programme will
be moved to that number.
All the following programmes will
be shifted down by one place.
To skip programmes
Skipped programmes will not
appear when you move through
the program list using the
Program up/Program down
buttons. They can still be selected
using the numeric buttons or the
OK button.
Select the programs you want to
skip and press the Red button. The
program will turn red. To unskip
the program press the Red button
again.To exit the PROGRAM EDIT
press the TV/TX button once or
the Menu button twice.
When you select a programme,
the information you entered in the
PROGRAM EDIT menu will appear
on the top of the screen i.e. P1
BBC1. This will disappear after
about three seconds.
To delete a programme
To delete a programme, select it
and press the Purple button. The
programme will be deleted.
All the following programmes are
shifted up by one position.
To move the programmes
You can move the programmes around the
programme list to get the order you want
MENU
TV/TX
- Name
- Move
- Delete
- Skip
PROGRAM TABLE
05.
06.
07.
08.
09.
10.
11.
12.
13.
14.
00. ----
01.
02. BBC
03.
04.
SKIP MOVE DELETE
NAME

-15-
Volume
Set a default volume level using the Volume
up and down buttons.
To save your settings, select STORE
and press the OK button, STORED
will be displayed. Press the Menu
button to go back to the previous
menu.
Balance
Set the sound balance level using
the Volume up and down buttons.
To save your settings, select STORE
and press the OK button, STORED
will be displayed. Press the Menu
button to go back to the previous
menu.
Sound type
This item shows STEREO when receiving
stereo transmission and MONO for mono
transmissions.
If the channel you are watching is in Nicam
stereo the On Screen Display will show
NICAM STEREO for a while.
TV set up
The TV set up is accessed through the menu
system.
Once you have stored your set up, this is the
set up the TV will default to when you switch
on.
To enter the MAIN menu press the
Menu button.
Once in the MAIN menu use the
Program up and Program down
buttons to select items in the menu and
the OK to access sub menus or use the
coloured fastext buttons for quick
access.
Please note
If you do not press any buttons for 15 seconds
the TV will exit the menu system.
Sound menu (red button)
Blue button - TUNING
Red button - SOUND
Green button - PICTURE
Purple button - FEATURE
Please Note
If, while watching a nicam stereo channel,
the signal strength drops and the system
cannot receive nicam stereo the OSD will
show MONO. If the signal strength increases
again and nicam stereo can be received
again, the OSD will show NICAM STEREO.
Select the required item in the menu
using the Program up/down buttons
and make the changes by pressing
the Volume up/down buttons. Use the
OK button to enter headphone from
the main menu.
OK
MENU
OK
OK
MAIN MENU
SOUND
PROGRAM TABLE
SETUP
FEATURE
SOUND
VOLUME
BALANCE
SOUND TYPE
SOUND MODE
AVL
EQUALISER
HEADPHONE
STORE
MONO
SPATIAL
ON
MENU
MENU
To save your settings, select STORE
and press the OK button. STORED
will be displayed. Press the Menu
menu.button to go back to the
previous MENU.
MENU
OK

-16-
Equalizer
In this menu there are a series of preset
equalizer settings for different types of sound
output.
There are four music settings - MUSIC, SPORTS,
CINEMA, SPEECH and
USER1 & USER2 modes.
MUSIC, SPORTS, CINEMA, SPEECH are
factory presets.
USER modes allow you to set your own
sound outputs as follows:
To access the 5 band equalizer menu
press Program up or down button and press
OK on the Equalizer line.
Press the OK button to enter the
EQUALIZER menu.
Use the Program down button to
select USER1.
Press the OK button to adjust the
frequency band levels.
Use the Volume up button to select
the KHz column you want to change.
Use the Program up/down buttons
to make the changes.
To save your settings, press the OK
button.
Press the Menu button to
go back to the previous menu.
Press the sound Smart control to scroll
through the different equalizer settings
and select the one you want.
Once you have switched the TV off the
equalizer setting will revert to the stored
setting.
Headphone
You can set up the volume, balance, bass
treble and sound type (stereo or mono)
of the headphone output.
Use the OK button to enter the HEADPHONE
menu.
To save your settings, select STORE
and press the OK button. STORED
will be displayed. Press the Menu
button to go back to the previous
menu display.
MENU
OK
OK
OK
MENU
OK
EQUALIZER
MUSIC
SPORTS
CINEMA
SPEECH
USER1
USER2 120
Hz 500 Hz 1,5 KHz 5 KHz 10 KHz
Sound mode
Select sound mode using Program up/down
buttons. You can select NORMAL or SPATIAL
with Volume up/down buttons.
SPATIAL sound is an ‘expanded stereo’. It gives
the impression that the two speakers in the
TV are further apart than they really are.
Select AVL using Program up/down buttons.
TV transmitters have different sound levels.
AVL (automatic volume limiting) maintains the
same sound level as you switch from program
to program.
To apply this press Volume up or down
button and select ON for AVL in Sound
Features menu.
AVL
You can also adjust the settings of USER2
by the same method.
You can change the equalizer setting whilst
watching the TV using the sound Smart control
on the Remote control.
HEADPHONE
VOLUME
BALANCE
BASS
TREBLE
SOUND TYPE
STORE
MONO

-17-
Features Menu (Purple button)
To select Features menu press the
menu button and using the Program
up and down buttons select Features.
You can also select the Features menu
directly by pressing the purple button
on the remote control.
The Features menu allows you to set
up the following:
CHILD LOCK
CLOCK
TIMER
BACKROUND
LANGUAGE
Use the Program up and down
buttons to select the feature you
wish to change and use the Volume
up and down buttons to adjust this
feature.
Picture menu (Green button)
The picture menu allows you to set up the
following:
BRIGHTNESS
CONTRAST
COLOUR
SHARPNESS
SMART CONTROL
and NOISE REDUCTION
To change, for example, the colour,
select it using Program up and down
buttons.
Use the Volume up and Volume
down buttons to change the setting.
To save your settings, select STORE
and press the OK button. STORED
will be displayed.
These settings are stored as USER
picture type.
You can change the picture type whilst
watching the TV using the picture Smart to
control.
Press the picture Smart control to
scroll through the different picture
types and select the one you want:
SOFT, NATURAL, RICH or USER.
NOISE REDUCTION: You can reduce the noise
effects in the pictures by selecting ON.
To save your settings, select STORE
and press the OK button. STORED
will be displayed. Press the Menu
button to go back to the previous
menu.
MENU
OK
OK
OK
MENU
OK
USER
ON
BRIGHTNESS
CONTRAST
COLOUR
SHARPNESS
SMART CONTROL
NOISE REDUCTION
FEATURES
CHILD LOCK
CLOCK
TIMER
BACKGROUND
LANGUAGE
OFF
03 14
ON

-18-
Language: You can select one of the 16
languages by pressing the OK button in
the language selection.
Timer: Use Program up and down buttons
to select Timer in the features menu. Using
the Timer fuction, you can switch to a
specific programme at a pre-programmed
time or you can turn your TV off at the
time you want your TV to be turned off.
Press OK to access the Timer menu.
ON TIMER: Use the numeric buttons to set
the time that you want your TV to be turned
on and programme number.
Switch the TV to Stand-by mode.
OFF TIMER: Use the numeric buttons to set
the time that you want your TV to be turned
off into Stand-by mode.
Note: It is not possible to switch to TV On
and Off at predetermined times using the
timer.
Picture format
4:3, conventional TV picture format.
16:9, this is the screen format of your
TV set
The TV will automatically switch to this
format if it detects 16:9 format from the
SCART inputs.
Child Lock :Using the Child Lock,
you can lock any Program you
want so that adult channels
cannot be watched by children.
You can cancel child lock any
time you want. To cancel Child
Lock, select Child Lock as OFF,
ON that program.
Clock: Use the numeric buttons
to set the real time.
Note: If you enter any channel
with teletext transmission, clock
will automatically set to real time.
Background: You can adjust the
menu background as ON or
OFF.
MAGYAR
ROMENESTE
LANGUAGE
TIMER
P 00PROGRAM NO
ON TIMER
OFF TIMER
To exit the sub-menu press the
Menu button and return to the
main menu.
MENU
Press the 16:9 button to page
through the different picture formats
and select the one you want. The
selected format will appear on the
lower right side of the screen for
a short while.
Once you have switched the TV off
the picture format will revert to 16:9.
16:9

-19-
No on screen display is available in text mode.
The contrast, brightness and colour cannot be
changed but the volume control is still available.
Make sure the TV channel you are watching
transmits teletext. If not NO TEXT sign will
be shown on the screen.
Press the TV/TEXT button. The text
page will appear, normally the index
page.
Press the TV/TXT button. The screen
will return to the channel you were
watching.
Find the number of the page in the
index and enter it using the Numeric
buttons. The number of the page will
appear in the top left hand corner of
the screen.
The page counter will search for your
page. When it finds it, the page will
be displayed.
To move to the next page of text press
the Program up button.
To move to the previous page press
the Program down button.
To return to the index page press the
P100 button.
To view a TV programme whilst in
text mode, press the MIX button.
The text will be superimposed over
the TV programme.
Press the MIX button again to return
to the text page.
If you have difficulty reading the
text on the TV you can double the
height of the text.
Press the Double height button.
The top half of the page will be
displayed in double height text.
Press the Double height button
again. The bottom half of the page
will be displayed in double height
text.
Press the Double height button
again to return to the full page.
Using Teletext
Please Note
To enter Text mode
Please Note
To exit Text mode
To select a page of text
TV/text mix
Page search whilst watching TV
Double height text
0
9
0
9
P100
UPDATE
UPDATE
Teletext is an information system that displays
text on your TV screen. Using the teletext
control buttons you can view pages of
information that are listed in the teletext index.
In Text mode press the Update
button. The TV will return to TV
mode with the text page number
in the top left hand corner of the
screen.
Enter the page number you want
using the Numeric buttons.
The top line of the text page will
appear whilst the text searches for
your page. When the page is
found the number will remain in
the top left hand corner of the
screen.
Press the Update button to view
your selected page of text.
MIX
MIX
TV/TX
TV/TX
DOUBLE
DOUBLE
TV/PC
TV/PC

-20-
Page Stop
If the page of text you have selected
contains sub pages, these sub pages
will automatically be displayed in
order with a delay to allow you to
read the page.
To stop the move to the next sub page
press the STOP button. STOP will
appear in the top left hand corner.
To continue moving through the sub
pages press the STOP button again.
To select a sub page
If the page of text you are viewing
contains sub pages, the number of
the sub page you are on and the total
number of sub pages is displayed on
the right of the screen i.e. 1/7.
To select a sub page press the SUB
button. Press the green button to select
next sub-page or press the red button
to select the previous sub-page.
Enter the number of the sub page,
using the Numeric buttons in the
format S0001 for sub page 1.
The teletext will search for the sub
page. This may take some time. To
return to the TV whilst the teletext is
searching press the Update button.
When the page number is found it
will appear in the top left hand corner
of the screen.
Press the Update button again to view
the text page.
To reveal information
Press the Rev button to reveal
concealed information (quiz
answers etc.).
Press the Rev button again to
conceal the information again.
Clock
Press the Sub button, whilst
watching a TV program , to
display the time.
Press sub button again to cancel
time display.
Fast text
At the bottom of the teletext screen is a
row of subject headings in red, green
yellow and blue.
The remote control has a row of coloured
buttons corresponding to the row of
coloured subjects on the screen.
Pressing one of the coloured buttons will
take you directly to the page
corresponding to the subject heading.
HOLD
HOLD
SUB
REVEAL
REVEAL
SUB
5
UPDATE

-21-
You can connect a wide range of audio and video equipment
to your TV.
Connecting external
equipment
Connecting a video recorder
Make sure the TV and video recorder are both
switched off.
Plug one end of the SCART lead (not supplied)
into the back of the video recorder and the
other end into one of the SCART sockets on the
back of the TV.
Switch on the video recorder and the TV.
Please note:
You can connect RGB external equipment
via Scart. It is necessary to you use a full Scart
cable for this purpose.
Select the video output of the external device
by referring to its operation instructions.
Make sure the TV and video recorder are
both switched off.
Plug one end of the Phono lead into the
video and audio out sockets on the back of
the video recorder and plug the other end
into the video and audio in sockets of the
TV.
If the sound is mono, use the Audio Input L.
and in the SOUND menu select the MONO
feature.
Press the AV button on the remote
control to select AV1 or AV2 to
correspond with the SCART socket
you are using on the back of the TV.
AV
Via Phono lead (optional)
Via SCART
SOUND
VOLUME
BALANCE
SOUND TYPE
SOUND MODE
AVL
EQUALISER
HEADPHONE
STORE
MONO
SPATIAL
ON
