Beko CXFG3790S User manual

Refrigerator
User manual
EN /
CXFG3790S - CXFG3790G
58 4590 0000/AB

Please read these instructions first before using your appliance
Thank you for choosing a Beko appliance.
Please take some time to read this user manual before using your appliance, to
ensure you know how to safely operate the controls and functions.
Carefully follow all unpacking and installation instructions to ensure the
appliance is correctly connected and fitted prior to use.
Please write your product model and serial number on the last page of this
user manual, and store in a safe location close to the appliance for easy future
reference.
This user manual may also be applicable for several other models. Differences
between models will be listed.
If you have any questions or concerns, please call our contact centre or find
help and information online at www.beko.co.uk
Symbols and their descriptions
This instruction manual contains the following symbols:
CImportant information or useful usage tips.
AWarning against dangerous conditions for life and property.
BWarning against electric voltage.
A
A
A
C
SUPPLIER’S NAME MODEL IDENTIFIER (*)
INFORMATION
C
The model information as stored in the product data base
can be reached by entering following website and searching
for your model identifier (*) found on energy label.
https://eprel.ec.europa.eu/

EN
3
1 Your refrigerator 4
2 Warnings 5
Electrical requirements...........................6
Warning! This appliance must be
earthed..........................................................6
Energy saving tips..................................... 7
Compliance with WEEE Directive and
Disposing of the Waste Product: .......8
Compliance with rohs directive: .........8
Package information................................8
3 Installation 9
Transportation Instructions..................9
Changing the illumination lamp .......10
Installation Instructions .......................10
4 Before operating 13
Final Check .................................................13
5 Using your refrigerator 14
Fridge Compartment Storage
Advice...........................................................15
Placing the food.......................................15
Defrosting of the appliance ................15
Defrosting ..................................................17
A) Fridge Compartment ........................17
B) Freezer Compartment......................18
Icematic and ice storage container..18
Using the water dispenser..................19
Filling the water dispenser's tank ....19
Drip tray.......................................................21
6 Maintenance and
cleaning 22
7 Do's and Don'ts 23
Problem Solvıng ...................................... 24

EN
4
1Your refrigerator
CFigures that take place in this instruction manual are schematic and may not
correspond exactly with your product. If the subject parts are not included in
the product you have purchased, then it is valid for other models.
Congratulations on your choice of a Beko quality Appliance which has been
designed to give you service for many years.
1
2
6
*
9
10
11
12*
7
13
14
15
8
*3
5*
4
1. Door Shelves (Small bottles,cans,
tubes)
2. Egg Tray
3. Water dispenser filling tank
4. Water dispenser reservoir
5. Bottle shelf
6. Adjustable Front Feet
7. Freezing and Storage (store fresh
food to be frozen lower down)
8. Twist & Serve ice cube trays and
ice cube storage tray (Make and store ice
cubes)
9. Crisper bins (for fresh fruit and
vegetables)
10. Crisper cover
11. Adjustable Shelves
12. Wine rack
13. Thermostat knob
14. Fridge compartment
15. Freezer compartment
* May not be available in all models

EN
5
2Warnings
• Do not connect your
appliance to the electricity
supply until all packing and
transit protectors have been
removed.
• If transported horizontally
leave to stand upright for at
least 4 hours before switching
on to allow compressor oil to
settle
• If you are discarding an old
refrigerator with a lock or latch
fitted to the door, disable the
lock/latch, ensure that it is left
in a safe condition to prevent
the entrapment of young
children.
• This fridge/freezer must
only be used for its intended
purpose i.e the storing and
freezing of edible foodstuff.
• Do not dispose of the
appliance on a fire. At Beko,
the care and protection
of our environment is an
ongoing commitment. This
appliance which is among
the latest range introduced
is particularly environment
friendly. Your appliance
contains non CFC / HFC
natural substances in the
cooling system (Called
R600a) and in the insulation
(Called cyclopentane) which
are potentially flammable if
exposed to fire. Therefore,
take care not to damage, the
cooling circuit / pipes of the
appliance in transportation
and in use. In case of damage
do not expose the appliance
to fire or potential ignition
source and immediately
ventilate the room where the
appliance is situated.
• We suggest you contact your
local authority for disposal
information and facilities
available.
• To obtain the best possible
performance and trouble free
operation from your appliance
it is very important to carefully
read these instructions.
• On delivery, check to make
sure that the product is not
damaged and that all the parts
and accessories are in perfect
condition.
• Ensure that the plug remains
readily accessible. Do not use
multiple adapter or extension
cable.
• Failure to observe these
instructions may invalidate
your right to free service
during the guarantee period.
• Keep ventilation openings, in
the appliance enclosure or in
the built-in structure, clear of
obstruction.
• Do not damage the refrigerant
circuit.
• Do not use electrical
appliances inside the food
storage compartments of the
appliance, unless they are of
the type recommended by the
manufacturer.

EN
6
• We suggest you keep these
instructions in a safe place for
easy reference.
• This appliance can be used
by children aged from 8 years
and above and persons with
reduced physical, sensory
or mental capabilities or
lack of experience and
knowledge if they have
been given supervision or
instruction concerning use
of the appliance in a safe
way and understand the
hazards involved. Children
shall not play with the
appliance. Cleaning and user
maintenance shall not be
made by children without
supervision.
• Children should be supervised
to ensure that they do not
play with the appliance.
Electrical requirements
Before you insert the plug into
the wall socket make sure that
the voltage and the frequency
shown on the rating plate inside
the appliance corresponds to
your electricity supply.
Rating label is on the left hand
side of fridge inner liner.
We recommend that this
appliance be connected to the
mains supply via a suitable
switched and fused socket. The
appliance must be positioned
so that the plug is accessible.
WARNING:
When positioning the
appliance ensure the supply
cord is not trapped or damaged.
Should the mains lead of the
appliance become damaged or
should it need replacing at any
time, it must be replaced by a
special purpose made mains
lead which can only be obtained
from a Beko authorised service
agent.
Warning! This appliance
must be earthed
If the fitted moulded plug is
not suitable for your socket,
then the plug should be cut
off and an appropriate plug
fitted. Destroy the old plug
which is cut off as a plug with
bared cord could cause a shock
hazard if inserted into a socket
elsewhere in the house.
The moulded plug on this
appliance incorporates a 13
A fuse. Should the fuse need
to be replaced an ASTABEAB
approved BS 1362 fuse of the
same rating must be used. Do
not forget to refit the fuse
cover. In the event of losing the
fuse cover the plug must not be
used until a replacement fuse
cover has been fitted.
Colour of the replacement
fuse cover must be the same
colour as that visible on the pin
face of the plug. Fuse covers
are available from any good
electrical store.

EN
7
FITTED WITH
BS 1362 13A FUSE ALWAYS
FIT BS 1362 REPLACEMENT
CARTRIDGE FUSE
GREEN &
YELLOW
OR
GREEN
N
BLUE
OR
BLACK
L
BROWN
OR
RED
22mm.
6mm.
6mm.
6mm. 32mm.
12mm.
FUSE
CORD GRIP
Important! Fitting A
Different Plug
1. As the colours of the wires
in the mains lead of this
appliance may not correspond
with the coloured markings
identifying the terminals in
your plug proceed as follows:
(See diagram).
2.Connect the green-yellow
or green (Earth) wire to the
terminal in the plug marked
‘E’ or with the symbol or
coloured green and yellow or
green.
3.Connect the blue (Neutral)
wire to the terminal in the
plug marked ‘N’ or coloured
black.
4.Connect the brown (Live) wire
to the terminal in the plug
marked ‘L’ or coloured red.
5. With alternative plugs a 13
A fuse must be fitted either
in the plug or adaptor or in
the main fuse box. If in doubt
contact a qualified electrician.
Energy saving tips
1. Ensure your appliance is
installed in a well ventilated
area.
2.Ensure the time between
buying chilled/frozen food
and placing them in your
appliance is kept at minimum,
particularly in summer. We
recommend you use a cool
bag or a special carrier bag to
carry perishable food.
3.Do not leave the door (s) of
your appliance open longer
than necessary and ensure
they are closed properly after
each opening.
4.Defrost frozen food in the
fridge compartment, so that
frozen food acts as an ice pack
to assist cooling in the fridge.
5. Energy consumption of this
appliance is measured while
freezer compartment is
loaded without use of top
shelf lid and the drawers
except the bottom drawer.
It is advised that freezer
compartment is loaded
without use of drawers except
the bottom drawer in order
to achieve maximum loading
capacity.

EN
8
Compliance with WEEE
Directive and Disposing of
the Waste Product:
This product complies
with EU WEEE
Directive (2012/19/
EU). This product
bears a classification
symbol for waste
electrical and electronic
equipment (WEEE).This product
has been manufactured with
high quality parts and materials
which can be reused and are
suitable for recycling. Do not
dispose of the waste product
with normal domestic and other
wastes at the end of its service
life. Take it to the collection
center for the recycling of
electrical and electronic
equipment. Please consult your
local authorities to learn about
these collection centers.
Compliance with rohs
directive:
The product you have
purchased complies with EU
RoHS Directive (2011/65/EU).
It does not contain harmful and
prohibited materials specified
in the Directive.
Package information
Packaging materials of the
product are manufactured
from recyclable materials in
accordance with our National
Environment Regulations. Do
not dispose of the packaging
materials together with the
domestic or other wastes. Take
them to the packaging material
collection points designated by
the local authorities.

EN
9
3Installation
Transportation
Instructions
1. The appliance should be
transported only in a vertical upright
position. The packing as supplied
must be intact during transportation.
2. If during the course of
transport the appliance has to be
transported horizontally, it must only
be laid on its right hand side when
standing in the frontof the appliance.
After bringing it to upright position,it
must not be operated for at least 4
hours to allow the system to settle.
3. Failure to comply with the
above instructions could result in
damage occuring to the appliance.
The manufacturer will not be held
responsible if these instructions are
disregarded.
4. The appliance must be
protected against rain, moisture and
other atmospheric influences.
5. When positioning your
appliance take care not to damage
your flooring, pipes, wall coverings
etc. Do not move the appliance by
pulling by the door or handle.
6. Empty any water in the drain
tray before moving. See section
‘Defrosting’ and ‘Care & cleaning’ for
further information.
7. Make sure that the defrost
water pipe at the back of the product
is fixed to the plastic evaporating pan
on the top of the compressor, to avoid
defrost water spillage on the floor.
8. The appliance must be
protected against rain, moisture and
other atmospheric influences.
“Important: Care must be taken
whle cleanng / carryng the
applance to avod touchng the
bottom of the condenser metal wres
at the back of theapplance as you
mght njure your fngers and hands.
“Important: Ths applance s not
desgned for stackng wth any
otherapplance.When postonng
your applance, take care not to
damage your floorng, ppes,wall
coverngs etc.
“Important: Care must be taken
whle cleanng / carryng the applance
to avod touchng the bottom of the
condenser metal wres at the back of
the applance as you mght njure your
fngers and hands.
Do not attempt to st or stand on top
of your applance as t s not desgned
for such use. You could njure yourself
or damage the applance.
“Important: Make sure that mans
cablesnot caughtundertheapplance
durng and after carryng / movng
the applance, to avod the mans
cable becomng cut or damaged.”Do
not allow chldren to play wth the
applance or tamper wth the controls.
Beko declnes to accept any lablty
should the nstructons not be
followed.
WARNING:
Do not locate extension
sockets or charging
transformers/power supplies or
Lithium-Iron battery operated
products adjacent to the compressor
as they could overheat.

EN
10
Installation Instructions
1. Fitted the two plastic wall
spacers supplied onto the condenser
at the back of the appliance by
rotating 1/4 turn.
5. The space in the room where
the appliance is installed must not be
smaller than 10 cubic metres.
Plug receptacle
2. Locate the appliance on a
smooth surface.
3. To ensure it is standing upright
adjust the two front feet by turning
clockwise or anti-clockwise, until it is
in firm contact with the floor. Correct
adjustment of feet avoids excessive
vibration and noise.
4. A special receptacle is supplied
to store the mains plug during transit.
The receptacle is fixed at the back
of the cabinet on the side of the
compressor. Gently remove the plug
from the receptacle. Never pull the
mains cord, you may damage the
appliance. In case of transportation,
ensure you locate the plug in the
receptacle provided to avoid transit
damage.
Changing the illumination
lamp
To change the Bulb/LED used for
illumination of your refrigerator, call
your AuthorisedService.
The lamp(s) used in this appliance
is not suitable for household room
illumination. The intended purpose
of this lamp is to assist the user to
place foodstuffs in the refrigerator/
freezer in a safe and comfortable
way.The lamps used in this appliance
have to withstand extreme physical
conditions such as temperatures
below -20 °C.
(only chest and upright freezer)

EN
11
1
1
7
1
20
11
13 9
2
10
5
3
20
20
8
18
17
19
14
12
16
21
21
45 °
180
8 13
6
4
15

EN
12
45
11
10
3
9
9
2
1
5
6
7
8
12
13
14
15
17
18
19
16
21
4
20
20

EN
13
4Before operating
Final Check
Before you start using the fridge/
freezer check that:
1. For a freestanding appliance;
‘this refrigerating appliance is not
intended to be used as a built-in
appliance.
2. The feet have been adjusted
for perfect levelling.
3. The interior is dry and air can
circulate freely at the rear of the
cabinet.
4. Clean the interior as
recommended under “CLEANING AND
CARE.”
5. Insert the plug into the wall
socket and switch on the electricity
supply.
6. When the door is open the
fridge interior light will come on.
7. You will hear a noise as the
compressor starts up. The liquid and
gases sealed within the refrigeration
system may also give rise to noise,
whether the compressor is running
or not which is quite normal.“Due
to operation of the fan inside the
frost free freezer compartment,
overall noise level is slightly higher
in comparison to non-frost free
appliances. This is quite normal and is
not a fault.”
8. Set the setting knob half way
between min and max.
9. Front edges of the cabinet may
feel warm. This is normal. These areas
are designed to be warm to avoid
condensation.
10. “Do not load the appliance
immediately it is switched on. Wait
until the correct storage temperature
has been reached. We recommend
that you check the temperature
with an accurate thermometer
(see; Temperature Control and
Adjustment)”
11. When the freezer reaches the
desired temperature the freezer fan
will stop. When the freezer fan is on,
the noise will be louder when the
freezer door is opened.
12. Avoid spillage of food
particularly small items like rice,
peas, beans through the fan guard as
they may cause the cooling system
to block and therefore operate less
efficiently.
13. Since hot and humid air will not
directly penetrate into your product
when the doors are not opened,
your product will optimize itself in
conditions sufficient to protect your
food. In this energy saving function,
functions and components such as
compressor, fan, heater, defrost,
lighting, display and so on will operate
according to the needs to consume
minimum energy while maintaining
the freshness of your foodstuff.

EN
14
5Using your refrigerator
The operating temperature is
regulated by the temperature control.
Warm Cold
1 2 3 4 5
(Or) Min. Max.
0=System cooling is off.
1=Lowest cooling setting
(Warmest setting).
5=Highest cooling setting
(Coldest setting).
The average temperature inside the
fridge should be around +5°C.
Please choose the setting according
to the desired temperature.
Please note that there will be
different temperatures in the cooling
area.
The coldest region is immediately
above the vegetable compartment.
The interior temperature also
depends on ambient temperature,
the frequency with which the door is
opened and the amount of foods kept
inside.
Frequently opening the door causes
the interior temperature to rise.
For this reason, it is recommended
to close the door again as soon as
possible after use.
The interior temperature of your
refrigerator changes for the following
reasons;
• Seasonal temperatures,
• Frequent opening of the door and
leaving the door open for long
periods,
• Food put into the refrigerator
without cooling down to the room
temperature,
• The location of the refrigerator in
the room (e.g. exposing to sunlight).
• You may adjust the varying interior
temperature due to such reasons
by using the thermostat.
Cooling
Food storage
The frdge compartment s for the
short-term storage of fresh food and
drnks.
Store mlk products n the ntended
compartment n the cooler/freezer.
Bottles can be stored n the bottle
holder or n the bottle shelf of the
door.
Raw meat s best kept n a
polyethylene bag n the compartment
at the very bottom of the cooler/
freezer.
Allow hot foods and beverages to
cool to room temperature pror to
placng them n the cooler/freezer.

EN
15
Wrap raw meat and poultry loosely
in polythene bags or aluminium foil.
This prevents drying.
Wrap fish and offal in polythene bags
and place on the lowest shelf.
Dairy: Wrap Cheese firstly in
greaseproof paper and then in
polythene bag excluding as much air
as possible. For best results take out
of the fridge
compartment an hour before eating.
Wrap bread well to keep it fresh.
Fruit & Vegetables: Take off any
unusable leaves on vegetables and
wipe off any soil.
Leave lettuce, cabbage, parsley and
cauliflower on the stem.
Wrap pineapples, melons,
cucumbers, tomatoes and similar
produce in polythene bags as these
types of produce may suffer damage
if kept at very low temperatures.
Wrap food, which has a strong odour,
or can dry out, in polythene bags,
aluminium foil, or place in an airtight
container.
Fridge Compartment
Storage Advice
Fruit & vegetables
Don’t store bananas.Don’t store
melon - it can be chilled for short
periods as long as it is wrapped to
avoid it flavouring other food.
Wrap food affected by
temperatures near 0°C (pineapples,
cucumbers,tomatoes etc.) in
polythene bags.
• Attenton
Store concentrated alcohol only
standng uprght and tghtly closed.
• Attenton
Do not store explosve substances or
contaners wth flammable propellant
gases (canned cream, spray cans etc.)
n the freezer. There s a danger of
exploson.
Placing the food
Egg tray Egg
Fridge
compartment
shelves
Food in pans,
covered plates
and closed
containers
Fridge
compartment
door shelves
Small and
packaged food
or drinks (such
as milk, fruit juice
and beer)
Crisper Vegetables and
fruits
Defrosting of the appliance
Theapplancedefrostsautomatcally.
Check regularly to see if the drain
pipe is clogged or not and clear it with
the stick in the hole when necessary.

EN
16
Meat & poultry
Store raw meat and poultry below
cooked food and dairy products.
Do not allow raw meat to come into
contact with cooked food to avoid
contamination. For safety, only store
raw meat for two to three days.
General
Cooked dishes must be stored in
airtight covered containers.Don’t store
cooked and fresh food together in the
same container.Always allow hot food
and beverages to cool first.Leftover
canned food should not be stored in
the can.
Place chilled cooked food and similar
food near the rear of the fridge where
it is coldest.
Keep food for as short a time as
possible and adhere to ‘best before’
and ‘use by’ dates.
Don’t let defrosting food or food
juices drip onto other food.Do not
fill water tank with any liquid other
than drinking water; beverages such
as fruit juice, carbonated fizzy soda
drinks, alcoholic drinks are not suitable
for use with water dispenser. If such
liquids are used, water dispenser will
malfunction and may be damaged
beyond repair. Guarantee does not
cover such uses. Some chemical
ingredients and additives in such
drinks / beverages may also attack and
damage water tank material. Only use
clean pure drinking water.Capacity of
water dispenser tank is 2.2 litres [3.8
pints], do not overfill.
Push the water dispenser lever with
a rigid cup. If you are using a plastic
disposable cup, then push the lever
with your fingers from behind the
cup. Safety Locking knob is supplied
for your convenience when filling the
water tank and also to avoid small
children tampering with the water
dispenser.
Storing pre-frozen food
Take special care not to mix with
fresh food.
The recommendation for
storage as stated on the food
packaging must always be followed.
Pre-packed frozen food should
be stored in accordance with the
food manufacturer’s instructions
for a frozen food storage
compartment.To ensure that
the high quality achieved by the
food manufacturer and retailer is
maintained:
1. Wrap packets when you buy
them.
2. Put packets in the freezer as
quickly as possible after purchase.
3. Ensure that contents are
labelled and dated.
4. Do not exceed ‘use by’ and ‘best
before’ dates.
Freezing fresh food
Take special care not to mix with
already frozen food.
Always choose high quality fresh
food and be sure it is thoroughly clean.
Prepare fresh food in small portions
to ensure rapid freezing. Do not freeze
too large a quantity at any one time.
The quality is best preserved when
the food is frozen right through to the
core as quickly as possible.
Do not exceed the freezing capacity
which in a 24 hour period is 6 kg (13
lbs).
When freezing the maximum
amount, turn the setting knob to MAX.

EN
17
When freezing average amounts, the
setting knob can be kept at medium
position. i.e. 2 kg (5lbs)
When freezing small quantities, up
to 1/2 kg (1 lb), the setting knob will
not need adjusting.
Preparation
Wrap food in aluminium foil or freezer
quality polythene bags.Wrap fish and
offal in polythene bags.
Wrap food which has a strong odour
or can dry out, in polythene bags,
aluminium foil, or place in airtight
containers.
Make sure all air is excluded from foil
wrapping or bags.
Freezer compartment storage
info/advice
Do not leave frozen food at room
temperature to thaw; the best way to
defrost food is to put it in the fridge
to thaw slowly. Make sure you avoid
defrosting food or food juices drip
onto other food.
The freezer compartment is
rated and suitable for freezing food
and the storage of pre-frozen food.
Don’t freeze filled bottles or sealed
cans containing fizzy (carbonated)
drinks as they may burst.
Check contents of the freezer every
so often.Don’t close the freezer door
unless all drawers/flaps are closed.
Don’t try to keep frozen food which
has thawed, it should be eaten within
24 hours or cooked and re-frozen.If
there is a power failure do not open
the door. Frozen food should not be
affected if the failure lasts for less
than 18 hours. If the failure is longer,
then the food should be checked and
either eaten immediately or cooked
and then re-frozen.Placing warm
food into the freezer compartment
causes the compressor to operate
continuously until the food is frozen
solid. This can temporarily lead to
excessive cooling of the refrigeration
compartment.
"The wire shelf between the two full
depth plastic drawers can be removed
temporarily if you want to store a
turkey. After you remove the drawers,
pull out the wire shelf as shown in the
diagram. Reverse the sequence of
operations when you re-fit the wire
shelf back in to its position. Make sure
you fit it properly otherwise operation
of drawers will be affected."
Defrosting
A) Fridge Compartment
The fridge compartment defrosts
automatically.
The defrosting water runs to the
drain tube via a collection container
at the back of the appliance (1). (see
diagram) During defrosting water
droplets may form at the back of the
fridge compartment where concealed
evaporator is located. Some droplets
may remain on the liner and refreeze
when defrosting is completed. Do not
use pointed or sharp edged objects
such as knives, forks to remove the
droplets which have frozen.

EN
18
If at any time the defrost water does
not drain from the collection channel,
check to ensure that no food particles
have blocked the drain tube. The drain
tube can be cleared by pushing the
special plastic plunger provided down
the drain tube (2). If the frost layer
reaches about 1/4”(7 mm), reduce
the setting (i.e. from 4 to 1) to restart
automatic defrosting.
B) Freezer Compartment
The freezer compartment operation
is frost free and does not need
defrosting.
Icematic and ice storage
container
*May not be available in all
models
Using the Icematic
Fill the Icematic with water and place
it into its seat. Your ice will be ready
approximately in two hours. Do not
remove the Icematic from its seating
to take ice.
Turn the knobs on the ice reservoirs
clockwise by 90 degrees.
Ice cubes in the reservoirs will fall
down into the ice storage container
below.
You may take out the ice storage
container and serve the ice cubes.
If you wish, you may keep the ice
cubes in the ice storage container.
Ice storage container
Ice storage container is only intended
for accumulating the ice cubes. Do not
put water in it. Otherwise, it will break.

EN
19
Using the water dispenser
* May not be available in all
models
CIt is normal for the first few
glasses of water taken from
the dispenser to be warm.
CIf the water dispenser is
not used for a long period
of time, dispose of first few
glasses of water to obtain
fresh water.
1. Push in the lever of the water
dispenser with your glass. If you are
using a soft plastic cup, pushing the
lever with your hand will be easier.
2. After filling the cup up to the level
you want, release the lever.
CPlease note, how much
water flows from the
dispenser depends on how
far you depress the lever. As
the level of water in your cup
/ glass rises, gently reduce
the amount of pressure on
the lever to avoid overflow.
If you slightly press the
arm, the water will drip; this
is quite normal and not a
failure.
Filling the water dispenser's
tank
Water tank filling reservoir is located
inside the door rack.
1. Open the cover of the tank.
2. Fill the tank with fresh drinking water.
3. Close the cover.
CDo not fill the water tank
with any other liquid except
for water such as fruit juices,
carbonated beverages or
alcoholic drinks which are
not suitable to use in the
water dispenser. Water
dispenser will be irreparably
damaged if these kinds of
liquids are used. Warranty
does not cover such usages.
Some chemical substances
and additives contained in
these kinds of drinks/liquids
may damage the water tank.
CUse clean drinking water
only.
CCapacity of the water tank
is 3 litres; do not overfill.

EN
20
Cleaning the water tank
1. Remove the water filling
reservoir inside the door rack.
2. Remove the door rack by
holding from both sides.
3. Grab the water tank from both
sides and remove it with an angle of
45°C.
4. Remove the cover of the water
tank and clean the tank.
CComponents of the water
tank and water dispenser
should not be washed in
dishwasher.
