Beko RSSA215K20W Instruction Manual

EN | DE | FR | NL | DA | SV | NO | FI
Instruction of use
Gebrauchsanweisung
Notice d'utilisation
Gebruiksaanwijzing
Brugsvejledning
Instruktionsmanual
Bruksanvisning
Käyttöohjekirja
Refrigerator
Kühlschrank
Réfrigérateur
Koelkast
Køleskab
Kylskåp
Kjøleskap
Jääkaappi
RSSA215K20W

Please read this user manual first
Dear Customer,
We hope that your product, which has been produced in modern plants
and checked under the most meticulous quality control procedures, will
provide you an effective service.
Therefore, read this entire user manual carefully before using the product
and keep it as a reference. If you handover the product to someone else, give
the user manual as well.
The user manual will help you use the product in a fast and safe way.
•Read the manual before installing and operating the product.
•Make sure you read the safety instructions.
•Keep the manual in an easily accessible place as you may need it later.
•Read the other documents given with the product.
Remember that this user manual is also applicable for several other models.
Differences between models will be identified in the manual.
Explanation of symbols
Throughout this user manual the following symbols are used:
C Important information or useful tips.
A Warning against dangerous conditions for life and property.
B Warning against electric voltage.
WARNING!
In order to ensure a normal operation of your refrigerating appliance, which uses
a completely environmentally friendly refrigerant the R600a (flammable only
under certain conditions) you must observe the following rules:
•Do not hinder the free circulation of the air around the appliance.
•Do not use mechanical devices in order to accelerate the defrosting,
others than the ones recommended by the manufacturer.
•Do not destroy the refrigerating circuit.
•Do not use electric appliances inside the food keeping compartment, other
than those that might have been recommended by the manufacturer.

2 EN
1 Your refrigerator 3
2 Important Safety
Warnings 4
Intended use .....................................4
General safety ...................................4
For products with a water dispenser...5
Child safety ........................................5
Compliance with the WEEE Regulation
and Disposing of the Waste Product ..6
Package information ..........................6
HCA warning .....................................6
Things to be done for energy saving ..6
3 Installation 7
Points to be paid attention to when the
relocation of the refrigerator ................7
Before you start the refrigerator ........ 7
Electrical connection ..........................7
Disposing of the packaging ...............8
Disposing of your old refrigerator ....... 8
Placing and Installation ......................8
Replacing the interior lamp..... ............8
Reversing the doors ..........................9
4 Preparation 10
5 Using your
refrigerator 11
Setting the operating temperature ...11
Cooling ............................................11
Defrost ............................................12
Stopping your product .....................12
6 Maintenance and
cleaning 13
Protection of plastic surfaces ..........13
7 Troubleshooting 14
CONTENTS
Using interior compartments ............11

3 EN
C Figures that take place in this instruction manual are schematic and may not
correspond exactly with your product. If the subject parts are not included in the
product you have purchased, then it is valid for other models.
1. Adjustable door shelves
2. Bottle shelf
3. Adjustable front feet
4. Crisper
5. Crisper cover
6. Defrost water collection channel -
drain tube
7. Movable shelves
8. Light bulb and thermostat box
1 Your refrigerator
1
5
4
3
6
7
1
1
2
7
7
7
8

4EN
Please review the following
information. Failure to observe this
information may cause injuries or
material damage. Otherwise, all
warranty and reliability commitments
will become invalid.
Original Spare parts will be provided
for 10 years, following the product
purchasing date.
Intended use
This product is intended to be used:
• indoors and in closed areas such as
homes;
• in closed working environments
such as stores and offices;
• in closed accommodation areas
such as farm houses, hotels,
pensions.
• It should not be used outdoors.
General safety
• When you want to dispose/scrap
the product, we recommend you to
consult the authorized service in
order to learn the required
information and authorized bodies.
• Consult your authorized service for
all your questions and problems
related to the refrigerator. Do not
intervene or let someone intervene
to the refrigerator without notifying
the authorised services.
• For products with a freezer
compartment; Do not eat cone ice
cream and ice cubes immediately
after you take them out of the
freezer compartment! (This may
cause frostbite in your mouth.)
•For products with a freezer
compartment; Do not put bottled
and canned liquid beverages in the
freezer compartment. Otherwise,
these may burst.
•Do not touch frozen food by hand;
they may stick to your hand.
•Unplug your refrigerator before
cleaning or defrosting.
• Vapor and vaporized cleaning materials
should never be used in cleaning and
defrosting processes of your
refrigerator. In such cases, the vapor
may get in contact with the electrical
parts and cause short circuit or electric
shock.
• Never use the parts on your refrigerator
such as the door as a means of support
or step.
• Do not use electrical devices inside the
refrigerator.
• Do not damage the parts, where the
refrigerant is circulating, with drilling or
cutting tools. The refrigerant that might
blow out when the gas channels of the
evaporator, pipe extensions or surface
coatings are punctured causes skin
irritations and eye injuries.
• Do not cover or block the ventilation
holes on your refrigerator with any
material.
• Electrical devices must be repaired by
only authorised persons. Repairs
performed by incompetent persons
create a risk for the user.
• In case of any failure or during
a maintenance or repair work,
disconnect your refrigerator’s mains
supply by either turning off the relevant
fuse or unplugging your appliance.
• Do not pull by the cable when pulling
off the plug.
• Place the beverage with higher proofs
tightly closed and vertically.
• Never store spray cans containing
flammable and explosive substances in
the refrigerator.
• Do not use mechanical devices
or other means to accelerate the
defrosting process, other than those
recommended by the manufacturer.
• This product is not intended to be
used by persons with physical,
sensory or mental disorders or
unlearned or inexperienced people
(including children) unless they are
attended by a person who will be
responsible for their safety or who will
instruct them accordingly for use of the
product.
2 Important Safety Warnings

5 EN
• Do not operate a damaged refrigerator.
Consult with t he service agent if you
have any concerns.
• Electrical safety of your refrigerator shall
be guaranteed only if the ea rth system
in your house complies with standards.
• Exposing the product to rain, snow, sun
and wind is dangerous with re spect to
electrical safety.
• C ontact authorized service when t here
is a power cable damage to avoid
d anger.
• Never plug the refrigerator into the wall
outlet during installation. Otherwise, risk
of death or serious injury may arise.
• This refrigerator is intended for only
storing food items. It must not be used
for any other purpose.
• L abel of technical specifications is
located on the left wall inside the
refrigerator.
• Never connect your refrigerator to
electricity-saving systems; they may
damage the refrigerator.
• I f there is a blue light on the refrigerator
do not look at the blue light with optical
tools.
• For manually controlled cooler/freezers,
w ait for at least 5 minutes to start the
refrigerator after power failure.
• This operation manual should be
handed in to the new owner of the
product when it is given to others.
• Avoid causing damage on power cable
when transporting the refrigerator.
Bending cable may cause fire. Never
place heavy objects on power cable.
• Do not touch the plug with wet hands
when plugging the product.
• Do not spray substances containing
inflammable gases such as propane gas
near the refrigerator to avoid fire and
explosion risk.
• Never place containers filled with water
on top of the refrigerator; in the event of
spillages, this may cause electric shock
or fire.
• Do not overload the refrigerator with
food. If overloaded, the food items may
fall down and hurt you and damage
refrigerator when you open the door.
• Never place objects on top of the
refrigerator; otherwise, these objects
may fall down when you open or close
the refrigerator's door.
• As they require a precise temperature,
vaccines, heat-sensitive medicine and
scientific materials and etc. should not
be kept in the refrigerator.
• If not to be used for a long time,
refrigerator should be unplugged. A
possible problem in power cable may
cause fire.
• The plug's tip should be cleaned
regularly with a dry cloth; otherwise, it
may cause fire.
• Refrigerator may move if adjustable
legs are not properly secured on the
floor. Properly securing adjustable legs
on the floor can prevent the refrigerator
to move.
• When carrying the refrigerator,
do not hold it from door handle.
Otherwise, it may be snapped.
• When you have to place your product
next to another refrigerator or freezer,
the distance between devices should
be at least 8 cm. Otherwise, adjacent
side walls may be humidified.
• Do not plug the refrigerator if the wall
outlet is loose.
• Water should not be sprayed on inner
or outer parts of the product for safety
purposes.
For products with a water
dispenser;
Pressure of water mains should be
minimum 1 bar. Pressure of water
mains should be maximum 8 bars.
• Use only potable water.
Child safety
• If the door has a lock, the key should
be kept away from reach of children.
• Children must be supervised to prevent
them from tampering with the product.

EN
6
• Do not leave the doors of your
refrigerator open for a long time.
• Do not put hot food or drinks in your
refrigerator.
• Do not overload your refrigerator so
that the air circulation inside of it is not
prevented.
• Do not install your refrigerator under
direct sunlight or near heat emitting
appliances such as ovens,
dishwashers or radiators. Keep your
refrigerator at least 30 cm away from
heat emitting sources and at least 5
cm from electrical ovens.
• Pay attention to keep your food in
closed containers.
• For products with a freezer
compartment; You can store
maximum amount of food items in the
freezer when you remove the shelf or
drawer of the freezer. Energy
consumption value stated for your
refrigerator has been determined by
removing freezer shelf or drawer and
under maximum load. There
is no harm to use a shelf or drawer
according to the shapes and size of
food to be frozen.
• Thawing frozen food in fridge
compartment will both provide energy
saving and preserve the food quality.
HCA warning
If your product's cooling system
contains R600a:
This gas is flammable. Therefore, pay
attention to not damaging the cooling
system and piping during usage and
transportation. In the event of damage,
keep your product away from potential
fire sources that can cause the product
catch a fire and ventilate the room in
which the unit is placed.
Ignore this warning if your product's
cooling system contains R134a.
Type of gas used in the product is
stated in the type label which is on the left
wall inside the refrigerator. Never throw
the product in fire for disposal.
Things to be done for energy
saving
Compliance with the WEEE
Regulation and Disposing of
the Waste Product
This product does not contain harmful
and forbidden materials described in
the "Regulation on the Control of the
Waste Electrical and Electronic
Equipment" issued by the T.R. Ministry
of Environment and City Planning.
Complies with the WEEE Regulation.
This product has been
manufactured with high
quality parts and
materials which can be
reused and are suitable
for recycling. Therefore,
do not dispose the product with
normal domestic waste at the end of its
service life. Take it to a collection point
for the recycling of electrical and
electronic equipment. Please consult
your local authorities to learn the nearest
collection point. Help protect the
environment and natural resources by
recycling used products. For children's
safety, cut the power cable and break
the locking mechanism of the door, if
any, so that it will be non-functional
before disposing of the product.
Package information
Packaging materials of the product are
manufactured from recyclable materials
in accordance with our National
Environment Regulations. Do not
dispose of the packaging materials
together with the domestic or other
wastes. Take them to the packaging
material collection points designated by
the local authorities.
Do not forget...
Any recycled substance is an
indispensable matter for nature and our
national asset wealth. If you want to
contribute to the reevaluation of the
packaging materials, you can consult to
your environmentalist organizations or
the municipalities where you are located.

7EN
3 Installation
B In case the information which are
given in the user manual are not taken
into account, manufacturer will not
assume any liability for this.
Points to be paid attention
to when the relocation of the
refrigerator
1. Your refrigerator should be
unplugged. Before transportation of
your refrigerator, it should be
emptied and cleaned.
2. Before it is re-packaged, shelves,
accessories, crisper, etc. inside
your refrigerator should be fixed
with adhesive tape and secured
against impacts. Package should
be bound with a thick tape or
sound ropes and the transportation
rules on the package should be
strictly observed.
3. Original packaging and foam
materials should be kept for future
transportations or moving.
Before you start the
refrigerator,
Check the following before you
start to use your refrigerator:
1. Is the interior of the refrigerator dry.
and can the air circulate freely in the
rear of it?
2. Attach 2 plastic wedges as
illustrated below. Plastic wedges are
intended to keep the distance which
will ensure the air circulation
between your refrigerator and the
wall. (The picture is drawn up as a
representation and it is not identical
with your product.)
3. Clean the interior of the refrigerator
as recommended in the
“Maintenance and cleaning” section.
4. Connect the plug of the refrigerator
to the wall socket. When the fridge
door is opened, fridge internal lamp
will turn on.
5. When the compressor starts to
operate, a sound will be heard. The
liquid and gases sealed within the
refrigeration system may also give rise
to noise, even if the compressor is not
running and this is quite normal.
6. Front edges of the refrigerator may
feel warm. This is normal. These
areas are designed to be warm to
avoid condensation.
Electrical connection
Connect your product to a grounded
socket which is being protected by a
fuse with the appropriate capacity.
Important:
The connection must be in compliance
with national regulations.
• The power plug must be easily
accessible after installation.
• Electrical safety of your refrigerator
shall be guaranteed only if the earth
system in your house complies with
standards.
• The voltage stated on the label
located at left inner side of your
product should be equal to your
network voltage.
• Extension cables and multi plugs
must not be used for connection.

EN
8
Disposing of the packaging
The packing materials may be
dangerous for children. Keep the
packing materials out of the reach of
children or dispose of them by
classifying them in accordance with
the waste instructions stated by your
local authorities. Do not throw away
with regular house waste, throw away
on packaging pick up spots
designated by the local authorities.
The packing of your refrigerator is
produced from recyclable materials.
Disposing of your old
refrigerator
Dispose of your old refrigerator
without giving any harm to the
environment.
• You may consult your authorized
dealer or waste collection center of
your municipality about the disposal
of your refrigerator.
Before disposing of your refrigerator,
cut out the electric plug and, if there
are any locks on the door, make
them inoperable in order to protect
children against any danger.
Placing and Installation
A If the entrance door of the room
where the refrigerator will be installed
is not wide enough for the refrigerator
to pass through, then call the
authorized service to have them
remove the doors of your refrigerator
and pass it sideways through the door.
1. Install your refrigerator to a place
that allows ease of use.
2. Keep your refrigerator away from
heat sources, humid places and
direct sunlight.
3. There must be appropriate air
ventilation around your refrigerator in
order to achieve an efficient
operation. If the refrigerator is to be
placed in a recess in the wall, there
must be at least 5 cm distance with
the ceiling and at least 5 cm with the
wall. Do not place your product on
the materials such as rug or carpet.
4. Place your refrigerator on an even
floor surface to prevent jolts.
5. Do not keep your refrigerator in
ambient temperatures under 10°C.
Replacing the interior lamp
To change the Bulb/LED used for
illumination of your refrigerator, call
your Authorised Service.
The lamp (s) used in this appliance is
not suitable for household room
illumination. The intended purpose of
this lamp is to assist the user to place
foodstuffs in the refrigerator/freezer in
a safe and comfortable way.
The lamps used in this appliance have
to withstand extreme physical
conditions such as temperatures
below -20°C.
B A damaged power cable must be
replaced by a qualified electrician.
B Product must not be operated before
it is repaired! There is the risk of
electric shock!

9EN
Reversing the doors
Proceed in numerical order.
3
7
8
1
12
11
9
13
10
4
2
5
14
15
45°
6

10 EN
4 Preparation
•Your refrigerator should be installed at
least 30 cm away from heat sources
such as hobs, ovens, central heater
and stoves and at least 5 cm away
from electrical ovens and should not
be located under direct sunlight.
•The ambient temperature of the room
where you install your refrigerator
should at least be 10°C. Operating
your refrigerator under cooler
conditions is not recommended with
regard to its efficiency.
•Please make sure that the interior
of your refrigerator is cleaned
thoroughly.
•If two cooler/freezers are to be
installed side by side, there should be
at least 2 cm distance between them.
•When you operate your refrigerator
for the firs time, please observe the
following instructions during the initial
six hours.
•The door should not be opened
frequently.
•It must be operated empty without
any food in it.
•Do not unplug your refrigerator.
If a power failure occurs out of your
control, please see the warnings in
the “Troubleshooting” section.
•Original packaging and foam
materials should be kept for future
transportations or moving.

11 EN
5 Using your refrigerator
Setting the operating
temperature
1 = Lowest cooling setting
(Warmest setting)
5 = Highest cooling setting
(Coldest setting)
(Or)
Min. = Lowest cooling setting
(Warmest setting)
Max. = Highest cooling setting
(Coldest setting)
The average temperature inside the
fridge should be around +5°C.
Please choose the setting according
to the desired temperature.
Please note that there will be different
temperatures in the cooling area. The
coldest region is immediately above the
vegetable compartment.
The interior temperature also depends
on ambient temperature, the frequency
with which the door is opened and the
amount of foods kept inside.
Frequently opening the door causes
the interior temperature to rise. For this
reason, it is recommended to close the
door again as soon as possible after
use.
Using interior compartments
Movable shelves: Distance between
the shelves can be adjusted when
necessary.
Vegetable drawer: Vegetables and
fruits can be stored in this
compartment for long periods without
decaying.
Bottle shelf: Bottles, jars and tins can
be placed in these shelves.
Cooling
Food storage
The fridge compartment is for the
short-term storage of fresh food and
drinks.
Store milk products in the intended
compartment in the refrigerator.
Bottles can be stored in the bottle
holder or in the bottle shelf of the door.
Raw meat is best kept in a
polyethylene bag in the compartment
at the very bottom of the refrigerator.
Allow hot foods and beverages to
cool to room temperature prior to
placing them in the refrigerator.
• Attention
Store concentrated alcohol only
standing upright and tightly closed.
• Attention
Do not store explosive substances or
containers with flammable propellant
gases (canned cream, spray cans etc.)
in the device. There is a danger of
explosion.
0
Warm Cold
1 2 3 4 5
(Or) Min. Max.
The operating temperature is regulated
by the temperature control.

12 EN
Defrost
The fridge compartment defrosts
automatically.
The thawing water flows through the
drain channel into a collection
container at the rear of the device.
During defrosting, water droplets
form at the back of the fridge due to
the evaporator.
If not all of the drops run down, they
may freeze again after defrosting
remove them with a cloth soaked in
warm water, but never with a hard or
sharp object.
Check the flow of the thawed water
from time to time. It may become
plugged occasionally.
Stopping your product
If your thermostat is equipped with
“0” position:
- Your product will stop operating
when you turn the thermostat button to
“0” (zero) position. Your product will not
start unless to you turn the thermostat
button to position “1” or one of the
other positions again.
If your thermostat is equipped
with “min” position:
- Unplug your product to stop it.

13 EN
6 Maintenance and cleaning
A Never use gasoline, benzene or similar
substances for cleaning purposes.
B We recommend that you unplug the
appliance before cleaning.
B Never use any sharp abrasive
instrument, soap, household cleaner,
detergent and wax polish for cleaning.
C Use lukewarm water to clean the
cabinet of your refrigerator and
wipe it dry.
C Use a damp cloth wrung out in
a solution of one teaspoon of
bicarbonate of soda to one pint of
water to clean the interior and wipe it
dry.
B Make sure that no water enters the
lamp housing and other electrical
items.
B If your refrigerator is not going to be
used for a long period of time, unplug
the power cable, remove all food,
clean it and leave the door ajar.
C Check door seals regularly to ensure
they are clean and free from food
particles.
A To remove door racks, remove all the
contents and then simply push the
door rack upwards from the base.
ANever use cleaning agents or water
that contain chlorine to clean the
outer surfaces and chromium coated
parts of the product. Chlorine causes
corrosion on such metal surfaces.
Protection of plastic surfaces
C Do not put the liquid oils or oil-cooked
meals in your refrigerator in unsealed
containers as they damage the
plastic surfaces of your refrigerator.
In case of spilling or smearing oil on
the plastic surfaces, clean and rinse
the relevant part of the surface at
once with warm water.

14 EN
7 Troubleshooting
Please review this list before calling the service. It will save your time and
money. This list includes frequent complaints that are not arising from defective
workmanship or material usage. Some of the features described here may not
exist in your product.
The refrigerator does not operate.
•The plug is not inserted into the socket correctly. >>>Insert the plug into the
socket securely.
•The fuse of the socket which your refrigerator is connected to or the main fuse
have blown out. >>>Check the fuse.
Condensation on the side wall of the fridge compartment (MULTIZONE, COOL
CONTROL and FLEXI ZONE).
•Ambient is very cold. >>>Do not install the refrigerator in places where the
temperature falls below 10°C.
•Door has been opened frequently. >>>Do not open and close the door of
refrigerator frequently.
•Ambient is very humid. >>>Do not install your refrigerator into highly humid
places.
•Food containing liquid is stored in open containers. >>>Do not store food with
liquid content in open containers.
•Door of the refrigerator is left ajar. >>>Close the door of the refrigerator.
•Thermostat is set to a very cold level. >>>Set the thermostat to a suitable level.
Compressor is not running.
• Protective thermic of the compressor will blow out during sudden power failures
or plug-out plug-ins as the refrigerant pressure in the cooling system of the
refrigerator has not been balanced yet. The refrigerator will start running
approximately after 6 minutes. Please call the service if the refrigerator does not
startup at the end of this period.
•The fridge is in defrost cycle. >>>This is normal for a full-automatically defrosting
refrigerator. Defrosting cycle occurs periodically.
•The refrigerator is not plugged into the socket. >>>Make sure that the plug is fit
in o the socket.
•Temperature settings are not made correctly. >>>Select the suitable
temperature value.
•There is a power outage. >>> Refrigerator returns to normal operation when the
power restores.

15 EN
The operation noise increases when the refrigerator is running.
•The operating performance of the refrigerator may change due to the changes
in the ambient temperature. It is normal and not a fault.
The refrigerator is running frequently or for a long time.
•New product may be wider than the previous one. Larger cooler/freezers
operate for a longer period of time.
•The room temperature may be high. >>>It is normal that the product operates
for longer periods in hot ambient.
•The refrigerator might be plugged in recently or might be loaded with food.
>>>When the refrigerator is plugged in or loaded with food recently, it will take
longer for it to attain the set temperature. This is normal.
•Large amounts of hot food might be put in the refrigerator recently. >>>Do not
put hot food into the refrigerator.
•Doors might be opened frequently or left ajar for a long time. >>>The warm air
that has entered into the refrigerator causes the refrigerator to run for longer
periods. Do not open the doors frequently.
• Freezer or fridge compartment door might be left ajar. >>>Check if the doors are
closed completely.
•The refrigerator is adjusted to a very low temperature. >>>Adjust the refrigerator
temperature to a warmer degree and wait until the temperature
is achieved.
•Door seal of the fridge or freezer may be soiled, worn out, broken or not
properly seated. >>>Clean or replace the seal. Damaged/broken seal causes
the refrigerator to run for a longer period of time in order to maintain the current
temperature.
Freezer temperature is very low while the fridge temperature is sufficient.
•The freezer temperature is adjusted to a very low value. >>>Adjust the freezer
temperature to a warmer degree and check.
Fridge temperature is very low while the freezer temperature is sufficient.
•The fridge temperature is adjusted to a very low value. >>>Adjust the fridge
temperature to a warmer degree and check.
Food kept in the fridge compartment drawers is frozen.
•The fridge temperature is adjusted to a very high value. >>>Adjust the fridge
temperature to a lower value and check.

16 EN
Temperature in the fridge or freezer is very high.
•The fridge temperature is adjusted to a very high value. >>>Fridge compartment
temperature setting has an effect on the temperature of the freezer. Change the
temperatures of the fridge or freezer and wait until the relevant compartments
attain a sufficient temperature.
• Doors are opened frequently or left ajar for a long time. >>>Do not open the
doors frequently.
• Door is ajar. >>>Close the door completely.
•The refrigerator is plugged in or loaded with food recently. >>>This is normal. When the
refrigerator is plugged in or loaded with food recently, it will take
longer for it to attain the set temperature.
• Large amounts of hot food might be put in the refrigerator recently. >>>Do not put hot food
into the refrigerator.
Vibrations or noise.
•The floor is not level or stable. >>> If the refrigerator rocks when moved slowly, balance it by
adjusting its feet. Also make sure that the floor is strong enough to carry the refrigerator,
and level.
•The items put onto the refrigerator may cause noise. >>>Remove the items on top of the
refrigerator.
There are noises coming from the refrigerator like liquid flowing, spraying,
etc.
•Liquid and gas flows occur in accordance with the operating principles of your
refrigerator. It is normal and not a fault.
Whistle comes from the refrigerator.
•Fans are used in order to cool the refrigerator. It is normal and not a fault.
Condensation on the inner walls of refrigerator.
•Hot and humid weather increases icing and condensation. It is normal and not
a fault.
•Doors are opened frequently or left ajar for a long time. >>>Do not open the doors
frequently. Close them if they are open.
•Door is ajar. >>>Close the door completely.
Humidity occurs on the outside of the refrigerator or between the doors.
•There might be humidity in the air; this is quite normal in humid weather. When the humidity
is less, condensation will disappear.
Bad odour inside the refrigerator.
• No regular cleaning is performed. >>>Clean the inside of the refrigerator regularly with a
sponge, lukewarm water or carbonate dissolved in water.
• Some containers or package materials may cause the smell. >>>Use a different container
or different brand packaging material.
• Food is put into the refrigerator in uncovered containers. >>>Keep the food in closed
containers. Microorganisms spreading out from uncovered containers can cause
unpleasant odours.
• Remove the foods that have expired best before dates and spoiled from the
refrigerator.
The door is not closing.
•Food packages are preventing the door from closing. >>>Replace the packages that are
obstructing the door.
•The refrigerator is not completely even on the floor. >>>Adjust the feet to balance the
refrigerator.
•The floor is not level or strong. >>>Make sure that the floor is level and capable to carry the
refrigerator.
Crispers are stuck.
•The food is touching the ceiling of the drawer. >>>Rearrange food in the drawer.

Bitte lesen Sie zuerst diese Anleitung!
Lieber Kunde,
Wir sind sicher, dass Ihnen dieses Produkt, das in modernsten Fertigungsstätten
hergestellt und den strengsten Qualitätsprüfungen unterzogen wurde, lange Zeit
gute Dienste leisten wird.
Wir empfehlen Ihnen, vor Inbetriebnahme des Gerätes das gesamte Handbuch
durchzulesen und es anschließend aufzubewahren.
Diese Anleitung...
• Hilft Ihnen, Ihr Gerät schnell und sicher zu bedienen.
• Lesen Sie die Anleitung, bevor Sie Ihr Gerät aufstellen und bedienen.
• Halten Sie sich an die Anweisungen, beachten Sie insbesondere die
Sicherheitshinweise.
• Bewahren Sie die Anleitung an einem leicht zugänglichen Ort auf, damit Sie
jederzeit darin nachschlagen können.
• Lesen Sie auch die weiteren Dokumente, die mit Ihrem Produkt geliefert wurden.
• Bitte beachten Sie, dass diese Anleitung eventuell auch für andere Geräte
eingesetzt werden kann.
Symbole und ihre Bedeutung
In dieser Anleitung finden Sie die folgenden Symbole:
C Wichtige Informationen oder nützliche Tipps.
A Warnung vor Verletzungen oder Sachschäden.
B Warnung vor elektrischem Strom.
Dieses Produkt ist mit dem selektiven Entsorgungssymbol für elektrische
und elektronische Altgeräte (WEEE) gekennzeichnet.
Das bedeutet, dass dieses Produkt gemäß der europäischen Direktive
2002/96/EC gehandhabt werden muss, um mit nur minimalen
umweltspezifischen Auswirkungen recycelt oder zerlegt werden zu können.
Weitere Informationen erhalten Sie von Ihren regionalen Behörden.
Elektronikprodukte, die nicht durch den selektiven Entsorgungsvorgang
erfasst werden, stellen durch das Vorhandensein potenziell gefährlicher
Substanzen umwelt- und gesundheitsrelevante Risiken dar.
Recycling
WARNUNG!
Ihr Gerät verwendet ein umweltverträgliches Kältemittel, R600a (nur unter
bestimmten Umständen brennbar). Um einen einwandfreien Betrieb Ihres
Gerätes sicherzustellen, beachten Sie bitte folgende Vorschriften:
•Die Luftzirkulation um das Gerät darf nicht behindert sein.
•Verwenden Sie außer der vom Hersteller empfohlenen, keine
mechanischen Hilfsmittel, um den Abtauprozess zu beschleunigen.
•Der Kältemittelkreislauf darf nicht beschädigt werden.
•Verwenden Sie im Lebensmittelaufbewahrungsbereich Ihres Gerätes
keine elektrischen Geräte, es sei denn, sie sind vom Hersteller empfohlen.

2DE
INHALT
1 Ihr Kühlschrank 3
2 Wichtige
Sicherheitshinweise 4
Bestimmungsgemäßer Einsatz...........4
Allgemeine Hinweise zu Ihrer
Sicherheit ..........................................4
Bei Geräten mit Wasserspender: .......6
Kinder – Sicherheit ............................6
HCA-Warnung ...................................6
Tipps zum Energiesparen ..................6
3 Installation 7
Was Sie bei einem weiteren Transport
Ihres Kühlschranks beachten müssen ..7
Bevor Sie Ihren Kühlschrank
einschalten ........................................7
Verpackungsmaterialien entsorgen ....8
Altgeräte entsorgen ...........................8
Aufstellung und Installation ................8
Austausch der Innenbeleuchtung ......8
Türanschlag umkehren .......................9
4 Vorbereitung 10
5 Nutzung des
Kühlschranks 11
Einstellen der Betriebstemperatur ....11
Innnenfächer verwenden ..................11
Kühlen .............................................11
Gerät stoppen .................................12
Abtauen ...........................................12
6 Wartung und Reinigung 13
Schutz der Kunststoffflächen ..........13
7 Empfehlungen zur
Problemlösung 14
Elektrischer Anschluss ...................... 7
