Beko 01M-8891883200-2223-07 User manual

HCA 92641 WH - HCA92641BH
EN - DE - FR
01M-8891883200-2223-07
01M-8891893200-2223-07
User Manual
Cooker Hood

2 / EN Cooker Hood / User Manual
CONTENTS
ENGLISH 3-17
DEUTSCH 18-34
FRANÇAIS 35-50

Please read this user manual first!
Dear Valued Customer,
Thank you for preferring this Beko appliance. We hope that you get the best results
from your appliance which has been manufactured with high quality and state-of-
the-art technology. For this reason, please read this entire user manual and all other
accompanying documents carefully before using the appliance and keep it as a
reference for future use. If you handover the appliance to someone else, give the user
manual as well. Follow the instructions by paying attention to all the information and
warnings in the user manual.
Remember that this user manual may also apply to other models. Differences between
models are explicitly described in the manual.
Meanings of the Symbols
Following symbols are used in various sections of this user manual:
CImportant information and useful hints about
usage.
AWARNING: Warnings against dangerous situa-
tions concerning the security of life and property.
WARNING: Warning for danger of fire.
BWARNING: Warning for electric shock.

4 / EN Cooker Hood / User Manual
1 Important safety and environmental instructions
1.1 General safety
Important Safety Instructions Read
Carefully And Keep For Future
Reference This section contains
safety instructions that will help
protect from risk of fire, electric
shock, exposure to leak micro-
wave energy, personal injury or
property damage. Failure to follow
these instructions shall void any
warranty.
•Beko products comply with the
applicable safety standards;
therefore, in case of any damage
on the appliance or power cable,
it should be repaired or replaced
by the dealer, service center or a
specialist and authorized service
alike to avoid any danger. Faulty
or unqualified repair work may
be dangerous and cause risk to
the user.
•This appliance is intended to be
used in household and similar
applications such as:
– Staff kitchen areas in shops,
offices and other working en-
vironments;
– Farm houses
– By clients in hotels, and other
residential type environments;
– Bed and Breakfast type envi-
ronments.
•Operate the appliance for its
intended purpose only as de-
scribed in this manual.
•The manufacturer cannot be held
liable for damages resulting from
improper installation or misuse of
the product.
•This appliance can be used by
children aged from 8 years and
above and persons with reduced
physical, sensory or mental ca-
pabilities or lack of experience
and knowledge if they have been
given supervision or instruction
concerning use of the appliance
in a safe way and understand the
hazards involved.
•Children shall not be allowed
play with the appliance. Cleaning
and user maintenance shall not
be made by children without su-
pervision.
•The minimum distance between
the supporting surface for the
cooking vessels on the hob and
the lowest part of your product
must be at least 50 cm.

Cooker Hood / User Manual 5 / EN
1 Important safety and environmental instructions
•If the instructions for installation
for the gas hob specify a greater
distance, this has to be taken
into account.
•Make sure that your mains
power supply complies with the
information supplied on the rat-
ing plate of the appliance.
•Never use the appliance if the
power cable or the appliance it-
self is damaged.
•Prevent damage to the power
cable by not squeezing, bending,
or rubbing it on sharp edges.
Keep the power cable away from
hot surfaces and naked flame.
•Use the appliance with a
grounded outlet only.
WARNING: Do not connect the
appliance to the mains until the
installation is fully complete.
•Place the appliance in a way so
that the plug is always accessible.
•Do not touch the lamps if they
have operated for a long time.
They can burn your hands since
they will be hot.
•Follow the regulations set out by
competent authorities on dis-
charge of the exhaust air (this
warning is not applicable for use
without flue).
•Operate your appliance after put-
ting a pot, pan etc. on the hob.
Otherwise, high heat may cause
deformation in some parts of
your product.
•Turn off the hob before taking the
pot, pan etc. from it.
•Do not leave hot oil on the hob.
Pans with hot oil may cause self
combustion.
•Pay attention to your curtains
and covers since oil may catch
fire while cooking food such as
fries.
•Grease filter must be cleaned
at least monthly. Carbon filter
must be replaced at least every
3 months.
•Product shall be cleaned ac-
cordance with user manual. If
cleaning was not carried out in
accordance with user manual,
there may be fire risk.
•Do not use non-fire-resistant
filtering materials instead of the
current filter.
•Only use the original parts or
parts recommended by the man-

6 / EN Cooker Hood / User Manual
1 Important safety and environmental instructions
ufacturer.
•Do not operate the product with-
out the filter and do not remove
the filters while the product is
running.
•In the event of be started any
flame, de-energize your product
and cooking appliances.
•In the event of be started any
flame, cover the flame and never
use water to extinguish.
•Unplug the appliance before
each cleaning and when the ap-
pliance is not in use.
•The negative pressure in the envi-
ronment should not exceed 4 Pa
(4x10 bar) while the hood for elec-
tric hob and appliances running on
another type of energy but electric-
ity operate simultaneously.
•In the environment where the
appliance is being used, the ex-
haust of devices running on fuel
oil or gas, such as room heater
must be absolutely isolated or
device must be hermetical type.
•When connecting the flue, use
pipes with a diameter of 120 or
150 mm. Pipe connection must
be as short as possible and have
as few elbows as possible.
•Danger of choking! Keep all the
packaging materials away from
children.
CAUTION: Accessible parts may
become hot when used with cook-
ing appliances.
•The product outlet must not be
connected to air channels that
include other smoke.
•The ventilation in the room may
be insufficient when the hood for
electric hob is used simultane-
ously with the devices operating
on gas or other fuels (this may
not apply to appliances that only
discharge the air back into the
room).
•Objects placed on the product
may fall. Do not place any ob-
jects on the product.
•Do not flambe under the your
product.
WARNING: Before installing the
Hood, remove the protective films.
•Never leave high naked flames
under the hood when it is in op-
eration
•Deep fat fryers must be contin-
uously monitored during use:

Cooker Hood / User Manual 7 / EN
1 Important safety and environmental instructions
overheated oil can burst into
flames.
1.2 Compliance with the WEEE
Directive and Disposing of the Waste
Product:
This product complies with EU WEEE Directive
(2012/19/EU). This product bears a classification
symbol for waste electrical and electronic equip-
ment (WEEE).
This symbol indicates that this product
shall not be disposed with other
household wastes at the end of its ser-
vice life. Used device must be returned
to offical collection point for recycling
of electrical and electronic devices. To find these
collection systems please contact to your local au-
thorities or retailer where the product was pu-
chased. Each household performs important role
in recovering and recycling of old appliance.
Appropriate disposal of used appliance helps pre-
vent potential negative consequences for the envi-
ronment and human health.
1.3 Compliance with RoHS Directive
The product you have purchased complies with EU
RoHS Directive (2011/65/EU). It does not contain
harmful and prohibited materials specified in the
Directive.
1.4 Package Information
Packaging materials of the product are
manufactured from recyclable materials
in accordance with our National
Environment Regulations. Do not dis-
pose of the packaging materials together with the
domestic or other wastes. Take them to the pack-
aging material collection points designated by the
local authorities.

8 / EN Cooker Hood / User Manual
400
400
20
350
262
250
20
80
393
896
365
M n:750 Max:1130
1
2
3
4
5
6
1. Inner chimney
2. Outer chimney
3. Grease filter (Behind glass cover)
4. Glass cover
5. Control panel
6. Lighting
2.2 Technical Data
Model HCA92641WH
HCA92641BH
Supply voltage & Frequency 220-240V ~ 50 Hz
Lamp Power 2 x 3 W
Motor Power 210 W
Flow rate – 3. Level 648 m³/h
Insulation Class of Motor Class F
Insulation Class Class I
2.1 Overview
2 General appearance

Cooker Hood / User Manual 9 / EN
3.1 Controlling the Appliance
KEY FUNCTION
A : Light On
/ Off
You may illuminate the cooking
area by pressing this button. Re-
press the button to turn off the
lamp.
B : 1. Stage
Button
Operates the appliance on 1st
speed. When you press this button
again to turn off the appliance, the
screen speed stage turns off.
C : 2. Stage
Button
Operates the appliance on 2nd
speed. When you press this button
again to turn off the appliance, the
screen speed stage turns off.
D : 3rd Stage
Button
Operates the appliance on 3rd
speed. When you press this button
again to turn off the appliance, the
screen speed stage turns off.
3.2 Energy efficient usage
•When using your appliance, adjust the speed
settings according to vapour and odour intensity,
in order to save energy.
•Use low speeds (1-2) under normal conditions,
and high speed (3) for intense odour and vapour.
•The lamps on the hood are placed for illuminat-
ing the cooking area.
•Using them for environmental lighting shall
cause unnecessary energy expenditure and in-
sufficient lighting.
3.3 Operating the hood
•Your appliance contains a motor that has various
speeds.
•For better performance, we recommend using
low speeds under normal conditions and high
speeds in cases of strong odours and intense
vapour.
3 Operation of the appliance
•You can start your appliance by pressing on the
desired speed setting button. (B, C, D).
•You may illuminate the cooking area by pressing
the lamp (A).
3.4 Automatic stop
Your appliance has Automatic Stop feature, ena-
bling it to ventilate for a bit more and remove the
unwanted odours and vapour inside the environ-
ment and turn off automatically after the cooking
is done. To enable Automatic Stop feature, press
the any speed stage button (B, C, D) on the control
panel for longer than 2 seconds; the 15-minute
timer function shall be activated. When the au-
tomatic stop feature is active, pressing the same
speed button shall disable the automatic stop
function and the appliance’s motor shall stop. This
feature is disables when you switch between dif-
ferent speed stages. If you want the appliance to
stop automatically, you need to enable the auto-
matic stop feature again.
3.5 Replacement of Lamp
MAX 3 W
Make the electrical connections of the appliance.
Your appliance uses 3W spot LED lamp. For re-
placing the lamps, push downwards on the holder
from its behind, turn it counter-clockwise, and take
it out downwards. Apply the above operation in re-
verse to install new lamps.

10 / EN Cooker Hood / User Manual
Bulb
Bulb Power 3 W
Holder / Socket GZ 10
Bulb Voltage 220 - 240 V
Size 53 x 50 mm
ILCOS Code DR/F3-220-240-GZ10-50-53
Luminous flux 260 lm
Correlated colour
temperature
3000 K
This product contains a light source of energy ef-
ficiency class “F”.
3.6 Operation with chimney
connection
•Vapour is extracted through the
flue duct, which is fastened to
the connection head on the
hood.
•The diameter of the flue duct must be the same
as the connection ring. In horizontal settings, the
pipe has to have a slight upward slope (around
10º) so that the air can exit the room easily.
3.7 Operation without chimney
connection
•Air is filtered through the carbon
filter and recirculated in the
room. Carbon filter is used
when it is impossible to use a
flue in the house.
•In flueless use, remove the flaps inside the flue
adapter.
•Remove the Grease filter. To install the carbon
filter, fit the filter to the tabs by centring it on
the plastic piece on both sides of the fan body.
tighten it by turning right or left.
•Replace grease filter.
3 Operation of the appliance

Cooker Hood / User Manual 11 / EN
CBefore cleaning and maintenance,
unplug the product or turn off the
switch.
4.1 Cleaning of the grease filter
This filter retains the oil particles in the air. Grease
filter may change colour as they are washed; this
is normal and does not require replacing your
grease filter.
•Push the grease filter lock forward.
•Then pull it slightly down and pull it out. Oth-
erwise, you can bend the filter. Wash and rinse
Grease filter with liquid detergent and replace
grease filter to their sockets by by carrying out
the steps specified above in reverse order. This
filter retains the oil particles in the air.
CYou may wash your grease filter in
the dishwasher.
ACAUTION: In case of normal use,
clean your filter once in a month.
4.2 Replacement of carbon filters
Odour removing filters contain charcoal (Active
carbon). Grease filter must be installed in the prod-
uct, regardless of whether or not carbon filters are
used.
•Remove the grease filter.
•To remove the carbon filter, remove the car-
bon filter from its housing by rotating it coun-
ter-clockwise from the tab.
•Install the new carbon filter.
•Install the grease filter.
A
CAUTION
•Carbon filter shall never be
washed.
•Replace carbon filters once every
3 months.
•You can obtain the carbon filter
from the authorized services.
4 Cleaing and maintenance

12 / EN Cooker Hood / User Manual
AWARNING: Before starting the in-
stallation, read the safety informa-
tion on user manual.
BWARNING: Failure to install with
screws and stabilizers in accordance
with these instructions may result in
electric shock.
For the installation of the hood, please contact the
nearest Authorized Service.
It is the customer’s responsibility to prepare the
location and electrical installation of the hood.
5.1 Position of the appliance
•In all cooker hood types, the installation distance
on Gas hob and Electric hob is min 650 mm. For
inclined cooker hoods only, the installation
distance on the electric hob is min 500 mm.
•Distance must be measured from the surface of
grate for gas cookers, from surface of glass for
electric cookers.
5.2 Installation Accessories
11 12 13 14 1615
HCA62641BH- HCA62641WH
EN- DE - FR
01M-8891873200-5021-04
01M-8891863200-5021-04
UserManual
CookerHood
1. Product
2. Outer chimney
3. Inner chimney
4. Flue Connection Plate
5. Ø150/120mm Flue Adapter
6. User Manual
7. Assembly Pattern
8. 4x Ø8mm Plastic Dowel
9. 6x Ø6mm Plastic Dowel
10.4x 4.8x50 Wall Mount Screw
11.6x 3.9x22 Flue Connection Plate Screw
12.4x 3.5x9.5 Flue Connection Screw
13.Ø120mm Flue Adapter
14.Ø150mm Plastic Flue Adapter (Option)
15.Metal Chimney Clamp
16.Air Baffle
The information required to make the location suit-
able for the installation of the hood is given below.
5 Installation of appliance

Cooker Hood / User Manual 13 / EN
Chimney connection plate will be mounted with
the help of a pen (Figure 1/a).
Drill the marked points with Ø6mm drill and insert
2 plastic dowels in the drilled holes (Figure 1/a).
Fix the chimney connection plate to the wall with
3,9x22 screws (Figure 1/a).
To assemble the hood body,you can use the Ø8mm
drill bit to drill points A, B, C, D on the assembly
template, and insert 4.8x50mm plastic dowels at
these points. (Figure 1/b). 2 piece 4.8x50 suspen-
sion screw with a clearance of 5 mm between the
screw head and the wall (Figure 1/b).
(Figure 2)
1. Hanger Plate
2. Hanging Plate Connection Screw
In order to install your hood to the wall, loosen the
screws on the hanger plates mounted on the mo-
tor cabin and pull them up, and then fasten again
(Figure 2/A).
Turn on the suction glass of the hood and remove
the grease filter.
(Figure 3)
If the air outlet is to be connected to the air dis-
charge duct smaller than 150mm, install the 150 /
120mm plastic flue adapter (Figure 3).
5 Installation of appliance
5.3 Wall Mounting
•Wall must be flat, straight and have the suffi-
cient bearing capacity.
•Depth of drilling holes must comply with the
length of bolts.
•The bolts and dowels provided are suitable for
brick walls. For other construction material (e.g.
drywall, plate, porous concrete), suitable fixing
dowels and nuts shall be used.
(Figure 1)
ACAUTION: Before drilling, ensure
that there are no power, gas or wa-
ter pipes in the close proximity of the
drilling locations.
Draw a mid location line from the ceiling perpen-
dicular to the lower edge of the hood.
Paste the installing template provided within the
accessories on the surface where the hood is to
be mounted. In doing this operation, observe the
mounting height of the hood.
There is a tab in the middle of the Chimney con-
nection plate. Place the middle point of this tab on
the line that is drawn perpendicular to the wall. In
doing this operation, adjust the hood according to
the maximum height. Mark the holes where the

14 / EN Cooker Hood / User Manual
(Figure 4)
Hold the cooker hood by its body and place it on
the mounting screws on the wall and tighten the
screws (Figure 4).
Secure the cooker hood with two 4.8x50 screws to
the wall through the mounting hole on the interior
of the appliance (Figure 4).
5.4 Connecting to Chimney
(Figure 5)
1. Flap Pin Socket
2. Flap Pin
Insert the plastic pin (Figure 5/area no. 2) on the
pin socket on the motor exhaust (Figure 5/area
no.1). Then bend the flap lightly to insert the other
pin on the flap and insert the other pin to its socket
(Figure 5).
If you are going to use the Ø 120/150 mm plastic
Chimney adapter, connect one end of the pipe to
this adapter, if you are not going to use it, to the
direct output on the product. Connect the other
end of the pipe to your chimney. Check that these
two connections are tight enough so they will not
come out when the appliance runs on full pow-
er. Ensure that the flaps inside the chimney work
when tightened with clamp. Connect the chimney
connection duct outside the adapter (Figure 6/a).
If the connection duct is fitted inside the adapter,
suction of air shall not occur as the Chimney flap
that prevents the return of air will remain closed
(Figure 6/b). The length of the pipe connection as
well as the number of elbows must be as mini-
mum as possible.
A : Chimney exit pipe
B : Chimney Clamps
C: Plastic Chimney
The valves are closed then the appliance is not
operating and prevent possible outside odour and
dust from entering inside.
Ok Not Ok
(a) (b)
(Figure 6)
5.5 Installation of the Hood to the
chimney
Make the electrical connection of your hood before
starting the installation of the chimney. Slip the
chimney plates around the body. Screw the chim-
ney to the chimney fastening plates available on
the motor cabin (Figure 7).
5 Installation of appliance

Cooker Hood / User Manual 15 / EN
Install the chimney to the chimney fastening plate
that is secured to the wall from its upper outer
edges (Figure 7).
(Figure 7)
5.6 Installation of air baffle
While using with the carbon filter, air baffle is pro-
vided with your appliance with the aim of re-re-
leasing the air which is cleaned with carbon fil-
ter from the perforated located on the chimney.
Assemble the air baffle as below.
(Figure 8)
There is a tab in the middle of the chimney con-
nection plate. Place the middle point of this tab on
the line that is drawn perpendicular to the wall.
Align horizontally and mark the holes where the
connection plate will be mounted via a pen (Figure
8/A, B).
5 Installation of appliance
Drill the marked points with Ø6mm drill and in-
sert two Ø6mm plastic dowels in the drilled holes
(Figure 8/A, B).
Fix the chimney connection plate to the wall with
3.9x22 screws (Figure 8/A, B).
For the assembly air baffle, drill points C, D, E, F
with a Ø6mm drill bit and tap the Ø6mm plastic
dowels (Figure 8).
Assemble cooker hood's body (Figure 4).
(Figure 9)
1. Flap Pin Socket
2. Flap Pin
Attach the flue flaps to the plastic flue adapter in
the package content as follows. Insert the plastic
pin (Figure 9/area no. 2) on the pin socket on the
motor exhaust (Figure 9/area no.1). Then bend the
flap lightly to insert the other pin on the flap and
insert the other pin to its socket (Figure 9).
1
2
(Figure 10)
1. Air Baffle
2. Plastic Chimney

16 / EN Cooker Hood / User Manual
Attach the plastic chimney adapter, which is in-
cluded in the package, in the direction of the air
baffle. Lock the chimney adapter by turning it in
the direction of the arrow (Figure 10).
(Figure 11)
Assemble the air baffle group with 3.9 x 22
screws from point C, D, E, F that you have already
prepared (Figure 11).
(Figure 12)
1. Aluminium Air Outlet Pipe
Make the air outlet pipe assembly (Figure 12).
C
Since twists and bends in the alu-
minium pipe will lead to reduction
in the air suction power, avoid using
twists and bends as much as pos-
sible.
Install the chimney plates of the hood (Figure 7)
5 Installation of appliance

Cooker Hood / User Manual 17 / EN
6 Troubleshooting
Troubleshooting Root cause Help
Appliance is not working. Check your fuses. Fuse may be blown, inspect and restore it.
Appliance is not working. Check the electrical connection. Mains voltage shall be between 220 and 240 V.
Appliance is not working. Check the electrical connection. Check if other appliance in your kitchen
operate.
Illumination light does
not operate.
Check the electrical connection. Mains voltage shall be between 220 and 240 V.
Illumination light does
not operate.
Inspect the lamp switch. Lamp switch shall be at “on” position.
Illumination light does
not operate.
Inspect the lamps. The lamps of the appliance shall illuminate.
Air inlet of the appliance
is inadequate.
Inspect the aluminium filter. Under normal operating conditions, Grease filter
shall be cleaned at least once in a month.
Air inlet of the appliance
is inadequate.
Check the air discharge chimney. The air discharge chimney shall be at “on” po-
sition.
Air inlet of the appliance
is inadequate.
Inspect the carbon filter. The filters of the appliances with carbon filters
shall be replaced once in every 3 months under
normal conditions.

Bitte lesen Sie zunächst diese Anleitung!
Sehr geehrte Kundin, sehr geehrter Kunde,
Vielen Dank,dass Sie sich für dieses Gerät der Marke Beko entschieden haben.Wir sind
überzeugt, dass Sie mit diesem Gerät, das mit den höchsten Qualitätsanforderungen
und modernster Technologie hergestellt wurde, beste Ergebnisse erzielen werden.
Bitte lesen Sie die gesamte Bedienungsanleitung und alle anderen Begleitdokumente
aufmerksam, bevor Sie das Gerät verwenden; bewahren Sie sie zum künftigen
Nachschlagen sicher auf. Wenn Sie das Gerät an jemanden weitergeben, händigen
Sie ihm bitte auch diese Anleitung aus. Befolgen Sie die Anweisungen, indem Sie alle
Informationen und Warnhinweise in der Bedienungsanleitung beachten.
Bitte denken Sie daran, dass diese Bedienungsanleitung eventuell für mehrere Modelle
geschrieben wurde. Unterschiede zwischen den Modellen werden in der Anleitung klar
und deutlich beschrieben.
Bedeutung der Symbole
Folgende Symbole werden in den verschiedenen Abschnitten dieser Anleitung
verwendet:
CWichtige Informationen und nützliche Hinweise zur
Verwendung.
AWARNUNG: Warnhinweise zu gefährlichen
Situationen im Hinblick auf die Sicherheit von Leib,
Leben und Eigentum.
Warnung vor Brandgefahr.
BWarnung vor Stromschlägen.

Dunstabzugshaube / Bedienungsanleitung 19 / DE
1.1 Allgemeine Sicherheit
Wichtige Sicherheitsanweisungen
sorgfältig lesen und zum künftigen
Nachschlagen aufbewahren
Dieser Abschnitt enthält
Sicherheitsanweisungen, die
beim Schutz vor Personen-
und Sachschäden, Bränden,
Stromschlägen und dem
Austreten von Mikrowellenenergie
helfen. Bei Nichtbeachtung dies-
er Anweisungen erlischt die
Gewährleistung.
•Beko-Produkte stimmen mit
geltenden Sicherheitsstandards
überein; daher sollten Gerät oder
Netzkabel zur Vermeidung von
Gefahren im Falle von Schäden
durch den Händler, ein Kunden-
center oder einen spezialisierten,
autorisierten Serviceanbieter
repariert oder ersetzt werden.
Fehlerhafte oder unqualifizierte
Reparaturen können Gefahren
und Risiken für den Benutzer
verursachen.
•Dieses Gerät ist für den Einsatz
in Haushalten und ähnlichen
Bereichen vorgesehen, wie:
– In Betriebsküchen, Läden,
Büros und anderen Arbeit-
sumgebungen;
– Bauernhöfen;
– Von Gästen in Hotels und an-
deren Wohnumgebungen;
– Pensionen und Jugendher-
bergen.
•Das Gerät darf nur für seinen in
dieser Anleitung beschriebenen
vorgesehenen Zweck verwendet
werden.
•Der Hersteller haftet nicht für
Schäden, die auf unsachgemäße
Installation oder fehlerhaften Ge-
brauch zurückzuführen sind.
•Das Gerät darf nur dann von
Kindern ab 8 Jahren und Perso-
nen mit körperlichen oder geis-
tigen Einschränkungen genutzt
werden, wenn diese beaufsichtigt
werden oder gründlich über den
richtigen und sicheren Umgang
mit dem Gerät aufgeklärt wurden
und sich sämtlicher möglicher
Gefahren bewusst sind.
•Kinder dürfen nicht mit dem
Gerät spielen. Reinigungs- und
Wartungsarbeiten dürfen nicht
unbeaufsichtigt von Kindern aus-
1 Wichtige Sicherheits- und Umweltanweisungen

20 / DE Dunstabzugshaube / Bedienungsanleitung
geführt werden.
•Der Abstand zwischen der Stütz-
fläche für Kochgeschirr auf dem
Kochfeld und dem niedrigsten
Teil der Abzugshaube muss
mindestens 50 cm betragen.
•Falls die Anweisungen zur In-
stallation eines Gasherdes einen
größeren Abstand angeben, ist
dieser einzuhalten.
•Stellen Sie sicher, dass Ihre
Stromversorgung mit den Anga-
ben am Typenschild des Gerätes
übereinstimmt.
•Benutzen Sie das Gerät niemals,
wenn das Netzkabel oder das
Gerät selbst beschädigt ist.
•Vermeiden Sie Schäden am
Netzkabel, indem Sie es nicht
quetschen, knicken oder über
scharfe Kanten ziehen. Halten
Sie das Netzkabel von heißen
Oberflächen und offener Flamme
fern.
•Verwenden Sie das Gerät nur mit
einer geerdeten Steckdose.
WARNUNG: Schließen Sie das
Gerät erst nach vollständig ab-
geschlossener Installation an das
Stromnetz an.
•Stellen Sie das Gerät so auf,
dass der Netzstecker immer
zugänglich ist.
•Berühren Sie die Lampen nicht,
falls sie lange Zeit in Betrieb
waren. Sie könnten sich die Fin-
ger verbrennen, da die Lampen
heiß werden.
•Befolgen Sie die von zuständigen
Behörden festgelegten Richt-
linien zum Abführen von Abluft
(diese Warnung ist bei Einsatz
ohne Abzug nicht zutreffend).
•Nehmen Sie Ihr Gerät erst in
Betrieb, nachdem Sie ein Koch-
geschirr auf das Kochfeld gestellt
haben. Andernfalls könnte hohe
Hitze zur Verformung von Teilen
Ihres Geräts führen.
•Schalten Sie die Kochfelder
ab, bevor Sie das Kochgeschirr
herunternehmen.
•Lassen Sie kein heißes Öl auf das
Kochfeld gelangen. Kochgeschirr
mit heißem Öl kann sich selbst
entzünden.
•Achten Sie auf Vorhänge und
Abdeckungen, da Öl beim Zu-
bereiten von Lebensmitteln, wie
Pommes frites, Feuer fangen
1 Wichtige Sicherheits- und Umweltanweisungen
