Beko HTX851436A-IT User manual

Washer-Dryer
User Manual
HTX851436A-IT
2820531086_EN/ 07-03-23.(12:59)
Document Number :

Please read these instructions
first before using your appliance
Dear Customer,
Thank you for choosing a Beko appliance.
Please take some time to read this user manual
before using your appliance, to ensure you know
how to safely operate the controls and functions.
Carefully follow all unpacking and installation
instructions to ensure the appliance is correctly
connected and fitted prior to use. Please write
your product model and serial number on the
last page of this user manual, and store in a
safe location close to the appliance for easy
future reference. This user manual may also be
applicable for several other models. Differences
between models will be listed. If you have any
questions or concerns, please call our contact
centre or find help and information online at
www.beko.co.uk
Explanation of symbols used throughout this
User Manual
B
DANGER!
• Warning for electric shock.
DANGER!
• Product weight warning
DANGER!
• Fire risk warning.
A
CAUTION!
• Warning for hazardous situations with
regard to life and property.
A
PRECAUTION!
• Precautions that need to be taken.
C
INFORMATION
• Important information or useful hints about
usage.
• Read user manual.
• Packaging materials of the
product are manufactured
from recyclable materials in
accordance with regulations.
• Do not dispose of the
Packaging materials together
with the domestic or other
wastes. Take them to the
packaging material collection
points designated by the local
authorities.
• Allergy UK, is the brand of
British Allergy Association. Their
main endorsement is the ‚Seal
of Approval‘. When you see
a product with this logo on it,
you have the reassurance the
product has been scientifically
tested to prove it is efficient at
reducing/removing allergens
from the environment of allergy
and asthma sufferers or the
products have significantly
reduced allergen/chemical
content.

3 / EN Washer-Dryer / User Manual
1 Important instructions for safety and environment
This section contains safety instructions
that will help protect from risk of personal
injury or property damage. Failure to follow
these instructions shall void any warranty.
1.1 General safety
A
CAUTION!
• This product can be used by
children at and above 8 years old
and by persons whose physical,
sensory or mental capabilities are
not fully developed or who lack
experience and knowledge provided
that they are supervised or trained
on the safe use of the product and
the risks involved. Children should
not play with the product. Cleaning
and maintenance works should not
be performed by children unless
they are supervised by someone.
Children under the age of 3 must be
kept away from the product unless
they are continuously supervised.
A
WARNING!
• Never place the product on a carpet-
covered floor. Otherwise, lack of
airflow beneath the product will cause
electrical parts to overheat. This will
cause problems with your product.
C
INFORMATION
• Always have the installation
procedures carried out by
authorised persons. The
manufacturer shall not be held
liable for damages that may arise
from procedures carried out by
unauthorised persons.
1.1.1 Electrical safety
B
DANGER!
• If the product has a failure, it should
not be operated unless it is repaired
by the Authorised Service Agent.
There is risk of electric shock!
• Never wash the product by
spreading or pouring water onto it!
There is risk of electric shock!
A
CAUTION!
• If the power cable is damaged, it must
be replaced by the manufacturer, after
sales service or a similarly qualified
person (preferably an electrician) or
someone designated by the importer
in order to avoid possible risks.
A
WARNING!
• Unplug the product when it is not
in use.
• Never touch the plug with wet hands!
Never unplug by pulling on the cable,
always pull out by grabbing the plug.
• Unplug the product during installation,
maintenance, cleaning and repair.
• Do not make connections via
extension cables or multi-plugs.
C
INFORMATION
• This product is designed to resume
operating in the event of powering
on after a power interruption. If you
wish to cancel the programme, see
"Cancelling the programme" section.

4 / EN Washer-Dryer / User Manual
1.1.2 Product safety
B
DANGER!
• Never open the loading door or remove
the filter while there is still water in the
drum. Otherwise, risk of flooding and
injury from hot water will occur.
A
CAUTION!
• The water supply and draining
hoses must be securely fastened
and remain undamaged. Otherwise,
there is the risk of water leakage.
C
INFORMATION
• Do not force open the locked loading
door. The door will open immediately
after the washing cycle has ended. If
the machine is not cooled enough at
the end of the programme, the loading
door cannot be opened. Wait for the
product to cool down. If the door still
does not open, apply the solutions
provided for "Loading door cannot
be opened" in the Troubleshooting
section. Do not force the loading door
to open. The loading door and the lock
mechanism may get damaged.
• In the location where this product is
going to be installed, there must be
no doors with a lock, bolt or hinge
that will prevent the loading door
from opening completely.
• Follow the instructions on the textile
tags and on the detergent package.
• Use detergents, softeners and
supplements suitable for washing
machines only.
C
INFORMATION
• Do not install or leave the product in
places where it might be exposed to
outdoor conditions.
• Do not play with control elements of
the product.
• If a non-self-resetting thermal cut-out
is required in order to comply with
the standard then the instructions for
appliances incorporating a non-self-
resetting thermal cutout that is reset
by disconnection of the supply mains
shall contain the substance of the
following:
CAUTION: In order to avoid a hazard
due to inadvertent resetting of the
thermal cut-out, this appliance must
not be supplied through an external
switching device, such as a timer, or
connected to a circuit that is regularly
switched on and off by the utility.
1.1.3 Warnings about drying
DANGER!
• Laundry that has previously been
washed, cleaned, soiled or stained
with petrol/gas, dry cleaning solvents
or other inflammable/combustive
substances must not be dried in the
machine since they emit inflammable/
combustive vapour. Otherwise, there
will be the risk of fire.
• Laundry soiled with vegetable
oil, alcohol, petrol, gas oil, stain
remover, turpentine, wax or wax
remover must be washed with
hot water and a great amount of
detergent before drying. Otherwise,
there will be the risk of fire.

5 / EN Washer-Dryer / User Manual
DANGER!
• Rubber (latex) foam, shower caps,
waterproof fabrics, clothes and
rubber-reinforced/rubber-foam
pillows must not be dried with the
drying function. Otherwise, there will
be the risk of fire.
• If you use laundry balls, measuring
scoops or laundry cage in your
machine, these products might melt
during the drying process. If you are
going to select the drying function, do
not use these products. Otherwise,
there will be the risk of fire.
• If you are using industrial chemicals
for cleaning, do not use the drying
function. Otherwise, there will be the
risk of fire.
B
DANGER!
• Do not touch the glass of the
loading door with bare hands after
drying. There is the risk of burning.
• There is a final step, which is
cooling, to keep the laundry at a
certain temperature to ensure that
it is not damaged. You may be
exposed to hot steam if you open
the door before cooling is complete.
There is the risk of scalding.
• If the drying programmes are
interrupted (due to programme
cancellation or power failure), the
laundry in the machine might be
hot. Be careful.
A
CAUTION!
• Do not stop the machine before the
drying programme is completed.
If you have to do so, remove all
laundry, place it at an appropriate
place and wait for it to cool down.
• Your product is designed to work at
temperatures between 0°C and +35°C.
• Ambient temperatures between
15°C and +25°C are suitable for
your product.
• Do not let pets enter the product. Check
inside of the product before using it.
• Do not overload the machine to dry
laundry. Observe the maximum load
levels stated for drying.
A
WARNING!
• Do not use the machine to dry
leather clothes or clothes that contain
leather (such as leather labels on
jeans). The colour of the leather parts
might affect other fabrics.
• If there is a problem you cannot solve
by using the information given in the
safety instructions section, switch off
and unplug the machine and call the
Authorised Service Agent.
• You can use your washer-dryer to
only wash, only dry or both wash and
dry laundry. The machine must not
be used to dry wet laundry only for a
long time. When using the machine
only for drying purposes, run a
washing programme with the machine
unloaded after every 15 drying cycles.

6 / EN Washer-Dryer / User Manual
A
WARNING!
• Before loading the machine, check
each laundry item and make sure
that there is no lighter, change,
metal objects, needles etc. inside
them or in their pockets.
• Underwear with metal supports
must not be dried in the machine.
Metal supports might come off
during the drying process and
damage the machine. Place them in
a bag or a pillowcase.
• Do not use the machine to dry large
laundry such as tulle, curtains,
sheets/bedding, blanket or rugs.
Your laundry might get damaged.
C
INFORMATION
• Do not dry unwashed laundry in the
machine.
• Do not use softeners or antistatic
agents unless recommended by the
manufacturer.
• Products such as softeners must
be used in accordance with the
manufacturer’s instructions.
• Do not use the machine to dry silk,
wool and similar delicate clothes.
Otherwise, woollen clothes may
shrink, and other delicate clothes
might get damaged.
• Check the symbols on the label of the
clothes before washing and drying.
• The water supply pressure required
to run the product is between 1 to
10 bars (0.1 – 1 MPa).
• Do not use old or used water inlet
hoses on the new product. It may
cause stains on your laundry.
1.2 Intended use
C
INFORMATION
• This product has been designed for
domestic use. It is not suitable for
commercial use and it must not be
used out of its intended use.
• The product must be used to wash,
rinse and dry only the textile products
that have the relevant marking.
• The manufacturer waives any
responsibility arisen from incorrect
usage or transportation.
• The service life of your product is
10 years. During this period, original
spare parts will be available for the
product to operate properly.
• This appliance is intended to be
used in household and similar
applications such as:
– staff kitchen areas in shops, offices
and other working environments;
– farm houses;
– by clients in hotels, motels and
other residential type environments;
– bed and breakfast type
environments;
– areas for communal use in blocks
of flats or in launderettes.

7 / EN Washer-Dryer / User Manual
1.3 Children's safety
A
CAUTION!
• Children under the age of 3 must be
kept away from the product unless
they are continuously supervised.
• Packaging materials are dangerous
to children. Keep packaging
materials in a safe place away from
reach of the children.
• Electrical products are dangerous for
children. Keep children away from
the product when it is in use. Do not
allow them to play with the product.
Use child lock to prevent children
from intervening with the product.
• Do not forget to close the loading
door when leaving the room where
the product is located.
• Store all detergents and additives in
a safe place away from the reach of
the children by closing the cover of
the detergent container or sealing
the detergent package.
1.4 Compliance with the
WEEE Directive and disposing
of the waste product
This product does not contain the harmful and
prohibited materials described in the “Directive
on the Management of Waste Electrical and
Electronic Equipment”. It complies with the
WEEE Directive.
This product has been
manufactured with high quality parts
and materials which can be reused
and are suitable for recycling.
Therefore, do not dispose of the
product with normal domestic
waste at the end of its service life.
Take it to a collection point for the
recycling of electrical and electronic
equipment. Please consult your
local authorities to learn about the
nearest collection point.
2 Your washer-dryer
2.1 Overview
1
2
3
4
5
6
7
8
1- Power cable 5- Loading door
2- Top panel 6- Filter cover
3- Control panel 7- Adjustable feet
4- Water discharge
hose
8- Detergent drawer
Help protect the environment and natural
resources by recycling used products. For
children’s safety, cut the power cable and
break the lock mechanism of the loading door
to make the product non-functional before
disposal.
Compliance with the RoHS Directive
This product complies with the RoHS Directive
No. 2011/65/EU. It does not contain harmful or
prohibited materials stated in the directive.
1.5 Package information
Packaging materials of the product are
manufactured from recyclable materials in
accordance with our National Environment
Regulations. Do not dispose of the packaging
together with normal domestic waste. Take
them to the packaging material collection points
designated by local authorities.

8 / EN Washer-Dryer / User Manual
2.2 Package contents
Power cable
Water discharge hose
Transit bolts
Mains water inlet hose
Liquid detergent container (*)
User manual
Plastic plug group
C
INFORMATION
• Figures in this manual are schematic and may not match the product exactly.
(*) This may be supplied with the machine depending on the model of your product.

9 / EN Washer-Dryer / User Manual
2.3 Technical specifications
A
WARNING!
• Consumption values are applicable for cases where the wireless network connection is off.
C
INFORMATION
SUPPLIER’S NAME MODEL IDENTIFIER
A
A
(*)
• The model information as stored in the product
database can be reached by entering following
website and searching for your model identifier (*)
found on energy label.
https://eprel.ec.europa.eu/
Supplier name or trademark Beko
Model name HTX851436A-IT
7165146800
Maximum spin speed (rpm) 1400
Washing capacity (cotton) (kg) 8
Drying capacity (cotton) (kg) 5
Built-in No
Height (cm) 84
Width (cm) 60
Depth (cm) 59
Single Water inlet / Double Water inlet • / -
• Available
Electrical input (V/Hz) 230 V / 50Hz
Total current (A) 10
Total power (W) 2200
Main model code 1420
Rinse Spin+Drain
Prewash Fast Fast+ Extra
Rinse
Extra
Water
Anti
Crease
Pet Hair
Removal
Rinse
Hold
No
Water
Drain
Soaking
Spin No
Spin
Tap
Water
(Cold)
Steam
Time
Delay
Night
Modu
Temperature Door
Lock
Child
Lock
On/Off Start /
Pause
Soil Level Add
Garment
AutoDose Liquid
Detergent
Selection
Softener
Selection
Wash
Downloaded
Program
Steeping
Ok
(End)
Cancel AntiCrease+ Iron
Dry
Cupboard
Dry
Extra
Dry
Timed
Drying
Clean&
Wear
Symbols Table
Drying

10 / EN Washer-Dryer / User Manual
3 Installation
C
INFORMATION
• Your washing machine automatically
detects the amount of laundry placed inside
when selecting a program.
• While installing the product, before the first
use, calibration should be done to ensure
that the laundry amount is detected in the
most accurate way.
• To do this, select the Drum Cleaning*
program and cancel the spin function. Start
the program without laundry. Wait for the
program to finish, which will take about 15
minutes.
*The program name may vary depending on the
model. For the appropriate program selection,
review the program descriptions section.
To make the product ready for use, review the
information in the user manual and make sure
that the electricity, tap water supply and water
drainage systems are appropriate. If they are
not, call a qualified technician and plumber to
have any necessary arrangements carried out.
B
DANGER!
• Make sure that the installation and
electrical connections of the product
are performed by competent persons.
Manufacturer shall not be held liable for
damages that may arise from procedures
carried out by unauthorised persons.
DANGER!
• Your product is too heavy for one person
to carry.
A
CAUTION!
• Prior to installation, visually check if the
product has any defects on it. If so, do not
have it installed. Damaged products cause
risks for your safety.
A
PRECAUTION!
• Preparation of the location and electrical,
tap water and waste water installations at
the place of installation is under customer’s
responsibility.
• Make sure that the water inlet and
discharge hoses as well as the power
cable are not folded, pinched or crushed
while pushing the product into its place
after installation or cleaning procedures.
3.1 Appropriate
installation location
• Place the product on a solid and level
floor. Do not place it onto a carpet with
high pile or other similar surfaces.
• Do not place the product close to the
edge if the floor contains steps. Do not
also place the product on a platform.
• Do not place the product on the power cable.
• Do not install the product in environments
where the temperature falls below
0 ºC.(See. Warnings for Drying)
• Leaving a gap at the sides of the machine
is suggested to reduce vibration and noise
• In the area where this product is
installed, there must not be a lockable,
sliding or hinged door that will restrict
the full opening of loading door.
• Operate the product in a well ventilated
and dust free environment.
• Do not place heat sources such as Hobs,
Irons, Ovens, etc. on the washing machine
and do not use them on the product.
3.2 Removing packaging
reinforcement
Tilt the machine
backwards to remove
the packaging
reinforcement.
Remove the
packaging
reinforcement
attached to the
ribbon.

11 / EN Washer-Dryer / User Manual
DANGER!
• Your product is heavy. Remove packaging
reinforcement as displayed in the figure.
• Be careful not to get your hand caught
under the machine during this procedure.
3.3 Removing the transit bolts
A
PRECAUTION!
• Do not remove the transit bolts before
removing the packaging reinforcement.
• Remove the transit bolts before operating
the washing machine! Otherwise, the
product will get damaged.
3
2
1
1 Use a tool to
loosen all bolts until
they rotate freely.
3
2
1
2 Remove the transit
bolts by turning
them slightly.
3
2
1
3 Attach the plastic
covers supplied in
the user manual
bag into the holes
on the rear panel.
C
INFORMATION
• Keep the transit bolts in a safe place to
reuse when the product needs to be
moved again in the future.
• Never move the product without the transit
bolts properly fixed in place!
3.4 Connecting water supply
C
INFORMATION
• It is necessary to have 10 – 80 liters of
water flowing from the fully open tap in one
minute to have your product run smoothly.
Attach a pressure reducing valve if water
pressure is higher.
C
INFORMATION
• It is also recommended to attach a
pressure reducing valve if you experience
overflow from the detergent dispenser
during water fill between 3.5 to 10 bars
(0.35 to 1 MPa).
A
CAUTION!
• Models with a single water inlet should not
be connected to the hot water tap. In such
a case the laundry will get damaged or the
product will switch to protection mode and
will not operate.
1 2 3
1 Connect the special
hose supplied
with the product
to the water inlet
on the product.
A
CAUTION!
• Ensure that the cold water connection is
made correctly when installing the product.
Otherwise, your laundry will come out hot
at the end of the washing process and
wear out.
1 2 3
2 Tighten the hose
nuts securely
by hand. Never
use a tool when
tightening the nuts.

12 / EN Washer-Dryer / User Manual
1 2 3
3 Open the taps
completely after
making the hose
connection to
check for water
leaks at the
connection points.
If any leak occurs, turn off the tap and remove
the nut. Retighten the nut carefully after
checking the seal. In order to prevent the
water leaks, keep the taps closed when you
do not use the product.
3.5 Connecting to the drain
• Attach the end of the drain hose directly
to waste water drain, sink or bathtub.
A
CAUTION!
• Your house will be flooded if the
hose comes out of its housing during
water discharge. Moreover, there is
risk of scalding due to high washing
temperatures! To prevent such situations
and to ensure smooth water intake and
discharge of the machine, fix the end of
the discharge hose tightly so that it cannot
displace.
90 cm
90
40
90
40
90 cm
90 cm
min.40
90 cm
90
40
90
40
90 cm
90 cm
min.40
90 cm
90
40
90
40
90 cm
90 cm
min.40
• Connect the hose to a minimum height of
40 cm and a maximum height of 90 cm.
• If the hose is run along the floor (or at less
than 40 cm above it) and raised later on,
water drain becomes difficult and laundry
may come out extremely wet. Therefore,
observe the heights described in the figure.
• To prevent flowing of dirty water back into
the machine and to allow for easy discharge,
do not immerse the hose end into the dirty
water or do not drive it in the drain more
than 15 cm. If it is too long, cut it short.
• The end of the hose should not be
bent, it should not be stepped on
and the hose must not be pinched
between the drain and the machine.
• If the length of the hose is too short, add an
original extension hose. Length of the hose
may not be longer than 3.2 m. To avoid water
leak failures, the connection between the
extension hose and the drain hose of the
product must be fitted well with an appropriate
clamp as not to come off and leak.
3.6 Adjusting the feet
A
CAUTION!
• Adjust feet so that the product will be
balanced in the location it will be used.
• Balance the machine by adjusting the feet.
• Check for any play by pressing the product
from upper diagonal edges.
• Otherwise, the product may move from
its place and cause crushing, noise and
vibration problems.
• Do not use any tools to loosen the lock nuts.
Otherwise, the lock nuts may get damaged.
a) Loosen the lock nuts on the feet by hand.
b) Adjust the feet until the product stands level
and balanced.
c) Tighten all lock nuts again by hand.

13 / EN Washer-Dryer / User Manual
3.7 Electrical connection
Connect the product to a grounded outlet
protected by a 16 A fuse. Our company shall
not be liable for any damages that will arise
when the product is used without grounding in
accordance with the local regulations.
• Connection must comply with
national regulations.
• The wiring for the electrical outlet circuit
must be sufficient to meet the appliance
requirements. Use of a Ground Fault Circuit
Interrupter (GFCI) is recommended.
• Power cable plug must be within
easy reach after installation.
• If the current value of the fuse or breaker
in the house is less than 16 Amps, have a
qualified electrician install a 16 Amp fuse.
• The voltage specified in the “Technical
specifications” section must be
equal to your mains voltage.
B
DANGER!
• Damaged power cables must be replaced
by the Authorised Service Agent.
3.8 Transportation of the product
1 Unplug the product before transporting it.
2 Remove water drain and water
supply connections.
3 Drain all water that has remained
in the product. See 6.5
4 Install the transit bolts in reverse order of
the disassembly procedure. See 3.3
DANGER!
• Your product is too heavy for one person
to carry.
• Your product is heavy; two persons must
carry it and extra precaution taken on
stairs. If your product falls on you, it may
cause injuries.
A
CAUTION!
• Packaging materials are dangerous to
children. Keep packaging materials in a
safe place away from reach of the children.
C
INFORMATION
• Never move the product without the transit
bolts properly fixed in place!

14 / EN Washer-Dryer / User Manual
C
INFORMATION
• Laundry that are subjected to materials
such as flour, lime dust, milk powder, etc.
intensely must be shaken off before being
placed into the machine. Such dusts and
powders on the laundry may build up on the
inner parts of the product in time and can
cause damage.
• Keep laundry items made of Angora wool in
a plastic bag in the freezer for a few hours
before washing. This can reduce piling.
• Wash trousers and delicate laundry turned
inside out.
• Tough stains must be treated properly
before washing.
• Take out all substances in the pockets such
as coins, pens and paper clips, and turn
pockets inside out and brush if possible.
Such objects may damage the product or
cause noise problem.
4.3 Tips for energy and water saving
Following information will help you use the product
in an ecological and energy/water-efficient manner.
• Operate the product in the highest load
capacity allowed for the programme you
have selected, but do not overload. See,
“Programme and consumption table”.
• Observe the temperature instructions
on the detergent packaging.
• Wash slightly soiled laundry at low temperatures.
• Use faster programmes for small
quantities of lightly soiled laundry.
• Do not use prewash and high temperatures
for laundry that is not heavily soiled or stained.
• If you plan to dry your laundry in a
dryer, select the highest spin speed
recommended during washing process.
• Do not use more detergent than the
recommended on the detergent packaging.
4.4 First use
Before starting to use
the product make sure
that all preparations are
made in accordance
with the “Important
safety and environment
instructions” and the
instructions in the
“Installation” section.
4 Preparation
4.1 Sorting the laundry
* Sort laundry according to type of
fabric, colour, degree of soiling and
the suitable water temperature.
* Always obey the instructions
given on the garment tags.
4.2 Preparing the laundry for washing
• Underwire bras and clothes with metal pieces
such as buckles or buttons damage the
machine. Remove the metal pieces or wash
such clothes after putting them in a cotton
laundry bag or cotton pillow case. Moreover,
this type of clothes may overheat during the
drying process and damage other clothes.
Do not use the machine to dry such clothes.
• Put small size clothes such as infant's
socks and nylon stockings in cotton a
laundry bag or cotton pillow case.
• Place curtains in without compressing
them. Remove curtain attachment items.
Do not dry tulle curtains in your machine.
• Fasten zippers, sew loose buttons
and mend rips and tears.
• Wash “Machine washable” or “Hand
washable” labelled products only with
an appropriate programme. Dry them by
hanging them or laying them flat. Do not
use the machine to dry such clothes.
• Do not wash colours and whites together.
New, dark coloured cottons release a
lot of dye. Wash them separately.
• Only use the dyes / colour changers and
descaling agents which are appropriate
to machine wash. Always follow the
instructions on the package.

15 / EN Washer-Dryer / User Manual
To prepare the product for washing laundry,
perform first operation in Drum Cleaning
programme. If this programme is not available
on your machine, apply the method described
in section 6.2.
C
INFORMATION
• Use an anti-limescale agent suitable for
washing machines.
• Some water has remained in the product
due to the quality control processes in the
production. It is not harmful for the product.
4.5 Correct load capacity
The maximum load capacity depends on the
type of laundry, the degree of soiling and the
selected washing programme.
The product automatically adjusts the water
amount according to the weight of the laundry
put inside it.
A
CAUTION!
• Follow the information in the “Programme
and consumption table”. When overloaded,
machine's washing performance will drop.
Moreover, noise and vibration problems
may occur. For a good drying performance,
do not load the machine with more laundry
than recommended.
Laundry
type
Weight
(g)
Laundry
type
Weight
(g)
Bathrobe 1200 Hand towel 100
Fabric napkin 100 Nightgown 200
Bed sheet 700 Underclothing 100
Bed sheet 500 Men’s work shirts 600
Pillowcase 200 Men’s shirt 200
Tablecloth 250 Men’s pyjamas 500
Towel 200 Blouses 100
4.6 Loading the laundry
1. Open the loading door.
2. Place the laundry loosely in the product.
3. Push the loading door to close it until
you hear a locking sound. Ensure that
no items are caught in the door.
C
INFORMATION
• The loading door is locked while a programme
is running. The door lock will open
immediately after the washing programme has
ended. If the inner part of the machine is too
hot at the end of the programme, the loading
door will not open until the temperature drops.
If the door does not open, apply the solutions
provided for "Loading Door Cannot be
Opened." error in the Troubleshooting section.
A
CAUTION!
• If the laundry is misplaced, noise and
vibration problems may occur in the machine.
4.7 Using detergent and softener
C
INFORMATION
• When using detergent, softener, starch,
fabric dye, bleach or limescale remover,
read the manufacturer's instructions on the
package carefully and follow the suggested
dosage values. Use measuring cup if any.
4.7.1 Detergent drawer
The detergent drawer is composed of three
compartments:
1
3
2
– (1) for prewash
– (2) for main wash
– (3) for softener
–( ) in addition, there
is a siphon part in the
softener compartment.
4.7.2 Detergent, softener
and other cleaning agents
• Add detergent and softener before
starting the washing programme.
• Never leave the detergent drawer open
while the washing programme is running!
• When using a programme without prewash,
do not put liquid detergent into the prewash
compartment (compartment no. "1").
• If you are using a program with prewash,
start the machine after adding powder
detergent to the prewash and main wash

16 / EN Washer-Dryer / User Manual
compartments (compartments 1 and 2).
• Do not select a programme with prewash if
you are using a detergent bag or dispensing
ball. Place the detergent bag or the
dispensing ball directly among the laundry
in the machine. Remove them after drying.
• If you are using liquid detergent, do not forget
to place the liquid detergent container into the
main wash compartment (compartment no. 2).
• When the machine is in Drying step,
do not add any washing chemicals
(Liquid detergent, Softener, etc.).
4.7.3 Choosing the detergent type
Detergent type to be used depends on the
washing programme, fabric type and colour.
• Use different detergents for
coloured and white laundry.
• Wash your delicate clothes only with
special detergents (liquid detergent, wool
shampoo, etc.) intended solely for delicate
clothes and at suggested programmes.
• When washing dark coloured clothes and quilts,
it is recommended to use liquid detergent.
• Wash woollens at suggested programme with
special detergent made specifically for woollens
• Please review the programme descriptions part
for suggested programme for different textiles.
• All recommendations about detergents are valid
for selectable temperature range of programmes.
A
CAUTION!
• Use only detergents manufactured
specifically for washing machines.
• Do not use soap powder.
4.7.4 Adjusting the
amount of detergent
The amount of washing detergent to be used
depends on the amount of laundry, the degree
of soiling and water hardness.
• Do not use amounts exceeding the dosage
quantities recommended on the detergent
package to avoid problems of excessive
foam, poor rinsing, financial savings
and finally, environmental protection.
• Use less detergent for small loads,
lightly soiled clothes and short duration
programmes, especially in soft water areas.
4.7.5 Using softeners
Pour the softener into the softener compartment
of the detergent drawer.
• Do not exceed the (>max<) level marking
in the softener compartment.
• If the softener has lost its fluidity or if it is
concentrated, dilute it with water before
putting it in the detergent drawer.
4.7.6 Using liquid detergents
4.7.6.1 If the product contains
a liquid detergent container
• Place the liquid detergent container
in compartment no. “2”.
• If the liquid detergent has lost its fluidity, dilute it
with water before putting in the compartment.
2
4.7.6.2 If the product is equipped
with a liquid detergent apparatus:
• When you want to use liquid detergent,
press on the point shown to rotate the
apparatus. The part that falls off will function
as a barrier for the liquid detergent.
• If required, clean the apparatus with water
when it is in place or by removing it.
• If you will use powder detergent, the apparatus
must be secured at top position. The fan that
you would see in this position will mix the
powder detergent and help it to dissolve.

17 / EN Washer-Dryer / User Manual
4.7.6.3 If the product does not
contain a liquid detergent container
• Do not use liquid detergent for the
prewash in a programme with prewash.
• Liquid detergent stains your clothes
when used with Delayed Start function.
If you are going to use the Delayed Start
function, do not use liquid detergent.
4.7.7 Using gel and tablet detergent
• If the gel detergent thickness is fluidal and
your machine does not contain a special
liquid detergent container, put the gel
detergent into the main wash detergent
compartment during first water intake. If
your machine contains a liquid detergent
container, fill the detergent into this
container before starting the programme.
• If the gel detergent thickness is not fluidal
or in the shape of capsule liquid tablet, put
it directly into the drum before washing.
• Put tablet detergents into the main wash
compartment (compartment no. "2") or
directly into the drum before washing.
C
INFORMATION
• Tablet detergents may leave residues in the
detergent compartment. If you encounter
such residues, place the tablet detergent
between the laundry, close to the lower part
of the drum in future washings.
• Use the tablet or gel detergent without
selecting the prewash function.
C
INFORMATION
• Before drying, remember to remove objects
such as the plastic detergent container from
the drum.
4.7.8 Using laundry starch
• Add liquid starch, powder starch or the
fabric dye into the softener compartment.
• Do not use softener and starch
together in a washing cycle.
• Wipe the inside of the machine with a
damp and clean cloth after using starch.
4.7.9 Using bleach
• Select a programme with prewash and add the
bleach at the beginning of the prewash. Do not
put detergent in the prewash compartment.
Alternatively, select a programme with an
extra drying step, add the bleach to the empty
detergent compartment and once you see the
rinsing step on the display for the first time, add
1 glass of water into the same compartment.
• Do not use bleach and detergent
by mixing them.
• Use just a little amount (approximately
50 ml) of bleach and rinse the clothes
very well as it causes skin irritation. Do
not pour the bleach onto the laundry and
do not use it with the coloured items.
• When using oxygen-based bleaches,
select a programme that washes the
laundry at a low temperature.
• You can use oxygen-based bleaches
together with the detergent. However, if it
has a different consistency, first add the
detergent into the detergent compartment
no “2” and wait for the machine to take in
the detergent together with water. While
the product continues taking in water,
add bleach in the same compartment.
4.7.10 Using limescale remover
• When required, use limescale
removers manufactured specifically
for washing machines only.

18 / EN Washer-Dryer / User Manual
4.8 Tips for efficient washing
Clothes
Light Colours and
Whites Colours Black/Dark Colours
Delicates/
Woollens/Silks
(Recommended temperature range
based on soiling level: 40-90˚C)
(Recommended temperature range
based on soiling level: cold -40˚C)
(Recommended
temperature range based
on soiling level: cold -40˚C)
(Recommended temperature
range based on soiling level:
cold -30˚C)
Soiling Level
Heavily Soiled
(difficult stains such as grass,
coffee, fruits and blood.)
It may be necessary to pre-treat the
stains or perform prewash. Powder
and liquid detergents recommended
for whites can be used at dosages
recommended for heavily soiled
clothes. It is recommended to use
powder detergents to clean clay and
soil stains and the stains that are
sensitive to bleaches.
Powder and liquid detergents
recommended for coloured
laundry can be used at dosages
recommended for heavily soiled
clothes. It is recommended to use
powder detergents to clean clay and
soil stains and the stains that are
sensitive to bleaches. Detergents
which do not contain bleach should
be used.
Liquid detergents suitable
for colours and dark
colours can be used at
dosages recommended for
heavily soiled clothes.
Prefer liquid detergents
produced for delicate clothes.
Woollen and silk clothes
must be washed with special
woollen detergents.
Normally
Soiled
(For example, stains
caused by body on
collars and cuffs)
Powder and liquid detergents
recommended for whites can be
used at dosages recommended for
normally soiled clothes.
Powder and liquid detergents
recommended for colours can be
used at dosages recommended for
normally soiled clothes. Detergents
which do not contain bleach should
be used.
Liquid detergents suitable
for colours and dark
colours can be used at
dosages recommended for
normally soiled clothes.
Prefer liquid detergents
produced for delicate clothes.
Woollen and silk clothes
must be washed with special
woollen detergents.
Lightly
Soiled
(No visible stains
exist.)
Powder and liquid detergents
recommended for whites can be
used at dosages recommended for
lightly soiled clothes.
Powder and liquid detergents
recommended for colours can be
used at dosages recommended for
lightly soiled clothes. Detergents
which do not contain bleach should
be used.
Liquid detergents suitable
for colours and dark
colours can be used at
dosages recommended for
lightly soiled clothes.
Prefer liquid detergents
produced for delicate clothes.
Woollen and silk clothes
must be washed with special
woollen detergents.

19 / EN Washer-Dryer / User Manual
4.9 Tips for correct drying
Programmes
Cottons Drying Synthetics Drying Babyprotect + Washing and Drying Wash&Wear
Types of Clothes
Durable Clothes with Cotton-Content
Sheet, bedding, baby
clothes, t-shirts, sweatshirts,
durable knit clothing, jeans,
canvas trousers, shirts,
cotton socks etc.
Not recommended!
Washes and dries
respectively! Sheet,
bedding, baby clothes,
t-shirts, sweatshirts,
durable knit clothing,
jeans, canvas trousers,
shirts, cotton socks etc.
Washes and dries respectively!
Sheet, bedding, baby clothes,
t-shirts, sweatshirts, durable
knit clothing, jeans, canvas
trousers, shirts, cotton socks
etc.
Stainless clothes that has
been worn for a short time
such as shirts, t-shirts,
sweatshirts A very small
amount of laundry must
be loaded.
Synthetics Clothes (Polyester, nylon, etc.)
Not recommended!
It is recommended for the
polyester, nylon, polyacetate,
acrylic-content clothes. Drying
is not recommended for the
viscose-content clothes. Drying
explanations in the maintenance
label should be taken into
account.
It is recommended
for polyester, nylon,
polyacetate, acrylic
content clothes at low
temperatures, taking into
account the washing and
drying warnings on the
care label.
It is recommended for
polyester, nylon, polyacetate,
acrylic content clothes at low
temperatures, taking into
account the washing and
drying warnings on the care
label.
Lightly soiled and stainless
shirts, t-shirts and
synthetic-content clothes.
A very small amount of
laundry should be loaded.
Delicate (Silk, Woollens, Cashmere, Angora wool, etc. content) Clothes
Not recommended! Not recommended! Not recommended! Not recommended! Not recommended!
Bulky laundry such as blankets, coats, curtains etc.
Not recommended! It is
not appropriate to dry bulky
laundry in the washer. Dry
them by hanging them or
laying them flat.
Not recommended! It is not
appropriate to dry bulky laundry
in the washer. Dry them by
hanging them or laying them flat.
Not recommended! It
is not appropriate to
dry bulky laundry in the
washer. Dry them by
hanging them or laying
them flat.
Not recommended! It is
not appropriate to dry bulky
laundry in the washer. Dry
them by hanging them or
laying them flat.
Not recommended! It is
not appropriate to dry bulky
laundry in the washer. Dry
them by hanging them or
laying them flat.
4.10 Displayed Programme Time
You can see the programme duration on
the display of your machine while selecting
a programme. Depending on the amount of
laundry you have loaded into your machine,
foaming, unbalanced load conditions,
fluctuations in power supply, water pressure
and programme settings, the programme
duration is automatically adjusted while the
programme is running.
SPECIAL CASE: At programme start of
Cottons and Cotton Eco programmes, display
shows the duration of half load, which is the
most common use case. After programme
starts, in 20-25 minutes actual load is detected
by the machine. And if the detected load is
higher than half load; washing programme
will be adjusted accordingly and programme
duration increased automatically. You may follow
this change on the display.

20 / EN Washer-Dryer / User Manual
5 Operating the product
5.1 Control panel
12 3 4
79 8101112 6 5
1 - Programme selection knob
2 - Temperature level lights
3 - Spin speed level lights
4 - Display
5 - Start/Pause button
6 - Remote Control button
7 - End Time Adjustment button
8 - Drying Level Adjustment Button
9 - Auxiliary function button 2
10 - Auxiliary function button 1
11 - Spin speed adjustment button
12 - Temperature adjustment button
5.2 Display Symbols
1400
1200
800
600
90
˚
60
˚
40
˚
30
˚
20
˚
a b c d e
f
h
g
ikl jno mpr
a - Temperature indicator
b - Spin speed indicator
c - Duration information
d - Door lock engaged symbol
e - Programme follow-up indicator
f - No water indicator
g - Add laundry indicator
h - Bluetooth connection indicator
i - Remote Control indicator
j - Delayed Start enabled indicator
k - Drying level indicator
l - Child lock enabled symbol
m - Auxiliary function indicators 2
n - Auxiliary function indicators 1
o - No spin indicator
p - Rinse hold indicator
r - Cold water indicator
5.3 Preparing the Machine
1. Check if the hoses are connected tightly.
2. Plug in your machine.
3. Turn the tap on completely.
4. Place the laundry in the machine.
5. Add detergent and fabric softener.
5.4 Selecting a washing
programme
1. In accordance with the “Programme
and consumption table”, select a
suitable programme for the amount
and soiling level of the laundry.
2. Select the desired programme with
the Programme Selection knob.
C
INFORMATION
• Programmes are limited to the highest spin
speed appropriate for that particular type of
fabric.
• When selecting a programme, always
consider the type of fabric, colour, soiling
level and permissible water temperature.
5.5 Washing programmes
Depending on the type of fabric, use the
following main programmes.
C
INFORMATION
• After selecting a washing programme suitable
for your laundry, you can press the Drying
button to set the machine to perform drying
after the washing programme. Each time you
press the button, info line shows at which
step the drying process will take place and
the relevant symbol will turn on. If you want,
you can keep pressing the button to perform
drying for the maximum period allowed.
• The symbols shown on the display are
schematic and may not match the product
exactly.
• When you will perform washing and
drying by using the Drying function of your
machine, load maximum 5 kg of laundry
into the machine. If you exceed the capacity
of the machine, your laundry will not dry
and the machine will work longer, which will
result in more energy consumption.
