Belkin AC1000 DB User manual

User Manual
F9J1104 V1 8820nt01137uk Rev. A00
WiFi® DUALBAND AC+ MODEM ROUTER
AC 1000 DB
ENGLISH
FRANÇAIS
DEUTSCH
NEDERLANDS
ESPAÑOL
ITALIANO
PORTUGUÊS
POLSKI







TÜRKÇE

TABLE OF CONTENTS
Getting Started ........................................... 1
What’s in the Box ............................................. 1
Initial Setup.................................................. 1
How to Set It Up ............................................. 2
Run the Installer Software ..................................... 4
Advanced Tools & Settings..................................... 7
The Belkin Router Manager .................................... 8
Adding Computers to Your Network ............................. 9
Connect Your Wireless Devices................................ 17
Adding USB Devices ......................................... 20
 ..............................30
Router .....................................................30
Front Panel .................................................30
Back Panel ................................................. 31
 .............................. 32
Power Modem .............................................. 32
Technical Details ........................................33
Technical Features ..........................................33
System Requirements........................................ 34
....................................35
Enabling Auto Update on Your Belkin Router.....................35
Updating Your Router via Your System Tray (Windows) or Menu Bar
(Mac) ...................................................... 37
Updating the Router’s Firmware via the Web Interface ............38
Resetting the Router ......................................... 42
Restoring Your Router to Factory Defaults....................... 42
Restoring the Router to Default Settings Using the Web Interface ...43
Resetting the Power Modem .................................. 46
Restoring Your Power Modem to Factory Defaults ................ 46
 ................... 47
Troubleshooting ............................................. 47
Technical Support ...........................................56
Belkin International, Inc., Limited 2-Year Product Warranty......... 57
 .........................60
Declaration of Conformity with electromagnetic compatibility and
electromagnetic interference ..................................60
Europe – EU Declaration of Conformity ......................... 61
General Safety Information: ................................... 61

1
What’s in the Box
AC1000 DB Wi-Fi Dual-Band AC+ Modem Router
Power Modem --- Combined power supply and ADSL Modem with
built-in bundled power and Ethernet cable (attached to router)
RJ11 telephone cable (attached to router)
Network information card (attached to router)
Belkin Setup CD with User Manual
Quick Setup Guide
Initial Setup
Where to Place Your Modem Router
For the best results, place the Router next to the master phone
socket (the first one where the phone line comes into the dwelling
from outside) in an open location away from large metal objects
and magnets such as those found in speakers. Raising the Router
above floor level can improve the strength of your wireless signal.
GETTING STARTED

2
GETTING STARTED
How to Set It Up
Connect Your AC1000 DB Modem Router
1. Take the Router out of the box before removing
the Power Modem.
1
2
2. Plug the Power Modem into a socket
near your ADSL telephone line.

3
GETTING STARTED
3. Unravel the bundle and connect the
ADSL telephone cable. (ADSL filter may be required)
4. Insert CD to run the installer software.
If CD does not launch automatically,
find the setup program and open it.
The setup software will configure your
Internet connection and let you know
when things are working
3
4

4
GETTING STARTED
1. Click the Setup icon on the CD menu.
Run the Installer Software
If you have DSL, you may need a
username and password from your Internet provider

5
GETTING STARTED
2. After a brief installation, the setup software will ask you for the
network name and password from the network information card that
is stored in the foot of your new Belkin Router. Store the card under
the base of your Router for future reference.

6
GETTING STARTED
3. A progress screen will appear while additional software is
installed. This may take a few minutes to complete. Once
finished, a “Success” message will appear indicating that you
are connected to the Internet via your new Belkin Router.
During setup you may be asked for additional information.
You may need to enter a username and password provided by your ISP.
This username and password is likely to be found on materials that
came from your ISP when you signed up for service. If necessary, you
may need to contact your ISP to retrieve your username and password.
If you have a static IP address, you may need to enter
additional information also provided by your ISP.
If your computer doesn’t have a wireless adapter, or the setup
software is unable to control it, you may be asked to connect
your computer to the Router with a network cable.

7
GETTING STARTED
Advanced Tools & Settings
After the initial setup is complete, you have the option to change settings
like your network name, security type, and password. To make these
changes and others, click on the Advanced Tools icon at the CD Setup menu
and select one of the following settings that you would like to change:
Network Name & Security – Personalize your network name
(SSID), password, and strength of wireless security.
Internet Service Provider & Login Settings – Have you moved or
changed Internet Service Providers? If you’d like to change these settings
without running through the setup process again, this is the place.

8
GETTING STARTED
The Belkin Router Manager
The Belkin Router Manager appears in your system tray (Windows) or
menu bar (Mac). Its icon indicates the current status of your Router and
also allows you to access your Router’s settings to make changes. It also
provides quick access to software that came bundled with your Router.
To access the Router settings, click on the icon
and select from the menu that appears.
The status of your Router is shown by the Belkin Router Manager
icon, which closely mimics the light on the front of the Router.
Blue: You are connected to your Belkin Router
and it is connected to the Internet.
Amber: You are connected to your Belkin Router,
but it is not connected to the Internet.
Router Settings
User Manual
Network problem detected…
Networked USB Devices
Backup your les and folders
Video Mover
Check for Updates
Options
Exit

9
GETTING STARTED
Adding Computers to Your Network
Wireless devices such as computers, network printers, and gaming
systems can connect to your Router with a few simple steps.
Using the CD
1. Put the Setup CD into your computer. If the CD
doesn’t open automatically, browse to your CD
drive and open the Belkin Setup CD icon.
2. Click the Setup icon on the CD menu.
3. After a brief installation, the setup software will ask you for the
network name and password from the network information card
that came with your Router. This card is most likely now located
underneath the foot of your Router in the provided card slot.
4. A progress screen will appear while additional software is
installed. This may take a few minutes to complete. Once
finished, a “Success” message will appear indicating that you
are connected to the Internet via your new Belkin Router.
Note: The setup software runs only on Windows and Mac OS X systems.

10
GETTING STARTED
able baker
belkin.###
zebranet
Manual Setup
If you know what sort of Internet service you have, you
might try a manual setup. For this you will need a Wi-
Fi-enabled smartphone, tablet, or computer.
Connect to Your Router
Retrieve the network ID card from the foot of your new Belkin Router. When requested, please enter the password
(security key) provided on the card.
Take a moment to look at the light on the front of the Router. If it is solid
blue, your Router was able to connect to the Internet automatically.
Can’t find the card? The default network name and
password are also printed on the foot of the Router.
Use your computer, tablet, or smartphone to connect to
the wireless network shown on the network ID card. If not, please proceed to “Manually Set Up
Your Internet Connection” on page 12.

11
GETTING STARTED
Using the WPS Button
1. Start WPS Push Button Connection (WPS PBC) on your
computer or other Wi-Fi device that you would like to connect
wirelessly to your Router. Often there will be a button for this
purpose in software that came with the device, or a physical
“WPS,” “PBC,” or “Security” button on the device itself.
2. Within two minutes, press the WPS button on your Router.
The WPS light (small light above WPS button) will blink blue while
it listens for your Wi-Fi device. Once a connection is established, the
light will turn blue and then go out. If a connection is not established,
the light will blink amber. You may repeat the process to try again.
You can repeat this process for each WPS-enabled
device you’d like to add to your network.

12
GETTING STARTED
Manually Set Up Your Internet Connection
Use a browser to visit http://router/
The router homepage should appear.
You can also try visiting http://192.168.2.1/
The status of your Internet connection is shown in the
upper right corner of the router homepage.
If after a few moments it says “Connected,”
you’re done! You can surf the Internet.
http://router/
Internet Status: Connected

13
GETTING STARTED
If not, select “Connection Type” from the menu on the left. If a password screen appears, press “Submit.”
Internet Status: Not Connected
g
DHCP Client List
Static Route
Internet WAN
Connection Type
DNS
MAC Address
Wireless
Channel and SSID

14
GETTING STARTED
Dynamic/Fixed IP (1483 Bridge)
Select “Dynamic/Fixed IP (1483 Bridge)” from the
menu that appears and press “Next.” In most cases the IP address is dynamic, in which case all you need to do is
enter the correct VPI and VCI values and select the correct encapsulation
mode (check with your ISP if you are unsure), then click “Apply Changes.”
If your connection uses a static IP address change the “IP Assigned
by ISP” option to “No” and enter the address details supplied by
your ISP. Then enter the above values, and click “Apply Changes.”

15
GETTING STARTED
If after a few minutes your Internet Status says “Connected,”
you’re done! You can surf the Internet. PPPoE/PPPoA Connection
Some ADSL providers require a PPPoE or PPPoA connection.
Select either PPPoE or PPPoA (check with your ISP if you
are unsure of which you need) and press “Next.”
If these steps do not work, try restarting the
Modem Router and repeating the process.
Internet Status: Connected

16
GETTING STARTED
Enter the username and password supplied by your Internet
provider, enter the correct VPI and VCI values, and select the
correct encapsulation mode (check with your ISP if you are unsure
of what VPI/VCI and encapsulation values to use). Then click “Apply
Changes.” Ignore the other fields. The Router will restart.
If after a few minutes your Internet Status says “Connected,”
you’re done! You can surf the Internet.
If these steps do not work, try restarting your
Power Modem and repeating the process.
Internet Status: Connected

17
GETTING STARTED
Android
(phones and tablets)
1. Open the Settings app and select Wireless and Network.
2. From there, select Wi-Fi to see the list of available networks.
3. Select your wireless network from the list. If asked
to do so, enter your network password.
Connect Your Wireless Devices
iOS
(iPhone, iPad, and iPod touch)
1. Open the Settings app and select the Wi-Fi menu item.
2.Select your wireless network from the list that appears
there. If asked to do so, enter the network password.
Mac OS®X
Your Mac®provides a menu of available wireless networks
at the right end of the menu bar.
1. Click on the icon showing wireless waves.
2. Select your wireless network from the list that appears
there. If asked to do so, enter the network password.

18
GETTING STARTED
Windows®7
Your computer provides a menu of available wireless
networks at the right end of the task bar.
1. Left-click on the icon that looks like signal strength bars.
2. Select your wireless network from the list. If asked,
enter your network password (network key).
Windows Vista®and Windows XP
Your device provides a menu of available wireless
networks at the right end of the task bar.
1. Right-click on the icon that shows a computer with wireless
waves (XP) or two computers (Windows Vista).
2. Choose “View Available Wireless Networks (XP)” or
“Connect to a network (Vista)” from the menu.
3. Select your wireless network from the list. If asked,
enter your network password (network key).
