Belkin YourType Operating and safety instructions

YourType™Keyboard Case
for Kindle Fire HD 8.9"
Delivering the best typing experience. Enjoy!
1. Bluetooth®keyboard
2. Status LED
3. Charging port (micro-USB)
4. Bluetooth pair button
Product Overview To start, charge your keyboard by connecting the USB cable to an
appropriate USB power source (e.g. laptop, USB wall charger, etc.) and
the micro-USB to your keyboard.
When the battery is fully charged, the Status amber LED turns OFF.
Then pair it with your Kindle Fire HD. The Status LED light will flash
blue while the keyboard is not paired.
To initiate pairing between the keyboard and iPad, ensure that they are
in close proximity:
For Kindle Fire HD:
After creating a paired link, you do not need to repeat the pairing process;
the keyboard automatically links to the tablet or smartphone when both
devices are switched on. Pairing must be performed every time you want
to use the keyboard with a different tablet or smartphone. Note that
when the power switch is OFF and you plug the USB cable to charge the
keyboard, it’ll attempt to pair the device.
The keyboard is designed to prolong battery life and will enter into
battery-saving mode under prolonged inactivity. To wake the keyboard,
press any button. The Status LED will flash blue while the connection
is being reestablished, and will be solid blue for two seconds when the
connection is successfully established. The Status LED then turns off
during ongoing operation.
Go to the Home screen on your Kindle Fire HD and slide down the
settings menu on “Settings menu > Wireless > Bluetooth.”
Turn Bluetooth to “On.”
Turn on the keyboard and press and hold the “Pair” key. The Status
LED will flash blue on the keyboard and the keyboard will show up
under “Devices” on the tablet. Select “Belkin Bluetooth Keyboard.”
Note: When pairing and charging simultaneously, the amber
charging light will remain on while the blue pairing light flashes.
A code will appear on the Kindle Fire HD screen. Use the keyboard
to enter this code followed by the “Enter” key.
If, after 60 seconds, pairing fails, you will have to repeat the steps
above. You can view the status from the screen of the Kindle Fire HD.
Note: For other Bluetooth devices, follow device’s Bluetooth pairing
instructions.
Bluetooth Wireless Technology
Bluetooth wireless technology has revolutionized the personal
connectivity market by providing seamless freedom from wired
connections. It offers a small form factor and a low-cost radio solution,
providing links between mobile computers, mobile phones, and other
portable and handheld devices as well as connectivity to the Internet.
The Bluetooth Special Interest Group (SIG), composed of leaders in
the telecommunications, computing, and network industries, is driving
development of the technology and bringing it to market. The Bluetooth
SIG includes promoter companies 3Com®, Ericsson®, IBM®, Intel®,
Lucent®, Microsoft®, Motorola®, Nokia®, Toshiba®, and more than 2,000
adopter companies.
Safety Precautions
Please read the following carefully before using the product. Incorrect
use or incompatibility
with your device may result in reduced performance or damage to your
device.
• Do not attempt to disassemble product.
• Store and operate between 32° F–113° F.
• Do not allow this product to have contact with liquids.
• Do not place this product near a heat source or flame or it may explode.
• Do not throw or shake the Keyboard Case.
• Do not crush or puncture the Keyboard Case.
• Use soft cloth to clean the exterior. Do not use harsh chemicals or
strong cleaning solvents.
Recycling/Discarding
This product should be disposed of properly. Please do not dispose in
trash receptacles or incinerate. Recycling programs for this product/
packaging may not exist in your area.
FCC Statement
This device complies with Part 15 of the FCC Rules. Operation is subject
to the following two conditions: (1) This device may not cause harmful
interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation.
FCC Caution: Any changes or modifications not expressly approved by
the party responsible for compliance could void the user’s authority to
operate this equipment.
This equipment has been tested and found to comply with the limits for
a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits
are designed to provide reasonable protection against harmful
PAGE 1 PAGE 2FRONT COVER PAGE 3
4
3
1
2
1
3
2
5
4
PR# 35702
File name
QIG_F5L903Q-C00_8820-01304_RevB00_KIndLeFIRe_KeyBRdCase
SKU# F5L903Q-C00
P#/mKTG# 8820-01304 Rev. B00
DeSiGneR(S) aLLIson
DaTe 11/05/12 VeRSiOn 01

interference in a residential installation. This equipment generates, uses,
and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will
not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct
the interference by one of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that
to which the receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.
RSS-Gen & RSS-210 Statement:
This device complies with Industry Canada license-exempt RSS
standard(s).
Operation is subject to the following two conditions: (1) this device may
not cause interference, and (2) this device must accept any interference
received, including interference that may cause undesired operation.
RSS-102 Statement:
This equipment complies with Industry Canada radiation exposure limits
set forth for an uncontrolled environment.
Belkin International, Inc., Limited 1-Year Product Warranty
What this warranty covers:
Belkin International, Inc. (“Belkin”) warrants to the original purchaser of
this Belkin product that the product shall be free of defects in design,
assembly, material, or workmanship.
What the period of coverage is:
Belkin warrants the Belkin product for one year.
What will we do to correct problems?
Product Warranty.
Belkin will repair or replace, at its option, any defective product free of
charge (except for shipping charges for the product). Belkin reserves the
right to discontinue any of its products without notice, and disclaims any
limited warranty to repair or replace any such discontinued products. In the
event that Belkin is unable to repair or replace the product (for example,
because it has been discontinued), Belkin will offer either a refund or
a credit toward the purchase of another product from Belkin.com in an
amount equal to the purchase price of the product as evidenced on the
original purchase receipt as discounted by its natural use.
What is not covered by this warranty?
All above warranties are null and void if the Belkin product is not provided
to Belkin for inspection upon Belkin’s request at the sole expense of
the purchaser, or if Belkin determines that the Belkin product has been
improperly installed, altered in any way, or tampered with. The Belkin
Product Warranty does not protect against acts of God such as flood,
lightning, earthquake, war, vandalism, theft, normal-use wear and tear,
erosion, depletion, obsolescence, abuse, damage due to low voltage
disturbances (i.e. brownouts or sags), non-authorized program, or system
equipment modification or alteration.
How to get service:
To get service for your Belkin product you must take the following steps:
1. Contact Belkin International, Inc., at 12045 E. Waterfront Drive,
Playa Vista, CA 90094,
Attn: Customer Service, or call (800)-223-5546, within 15 days of
the Occurrence.
Be prepared to provide the following information:
a. The part number of the Belkin product.
b. Where you purchased the product.
c. When you purchased the product.
d. Copy of original receipt.
2. Your Belkin Customer Service Representative will then instruct you on
how to forward your receipt and Belkin product and how to proceed
with your claim.
Belkin reserves the right to review the damaged Belkin product. All costs
of shipping the Belkin product to Belkin for inspection shall be borne
solely by the purchaser. If Belkin determines, in its sole discretion, that
it is impractical to ship the damaged equipment to Belkin, Belkin may
designate, in its sole discretion, an equipment repair facility to inspect
and estimate the cost to repair such equipment. The cost, if any, of
shipping the equipment to and from such repair facility and of such
estimate shall be borne solely by the purchaser. Damaged equipment
must remain available for inspection until the claim is finalized. Whenever
claims are settled, Belkin reserves the right to be subrogated under any
existing insurance policies the purchaser may have.
How state law relates to the warranty.
THIS WARRANTY CONTAINS THE SOLE WARRANTY OF BELKIN.
THERE ARE NO OTHER WARRANTIES, EXPRESSED OR, EXCEPT AS
REQUIRED BY LAW, IMPLIED, INCLUDING THE IMPLIED WARRANTY
OR CONDITION OF QUALITY, MERCHANTABILITY OR FITNESS FOR A
PARTICULAR PURPOSE, AND SUCH IMPLIED WARRANTIES, IF ANY,
ARE LIMITED IN DURATION TO THE TERM OF THIS WARRANTY.
Some states do not allow limitations on how long an implied warranty
lasts, so the above limitations may not apply to you.
IN NO EVENT SHALL BELKIN BE LIABLE FOR INCIDENTAL, SPECIAL,
DIRECT, INDIRECT, CONSEQUENTIAL OR MULTIPLE DAMAGES SUCH
AS, BUT NOT LIMITED TO, LOST BUSINESS OR PROFITS ARISING OUT
OF THE SALE OR USE OF ANY BELKIN PRODUCT, EVEN IF ADVISED OF
THE POSSIBILITY OF SUCH DAMAGES.
This warranty gives you specific legal rights, and you may also have other
rights, which may vary from state to state. Some states do not allow the
exclusion or limitation of incidental, consequential, or other damages, so
the above limitations may not apply to you.
© 2012 Belkin International, Inc. All rights reserved. All trade names are
registered trademarks of respective manufacturers listed.
8820-01304 Rev. B00 • F5L903q-C00
PAGE 5 PAGE 6PAGE 4 BACK COVER
Belkin Tech Support
US
http://www.belkin.com/support.
