Belleze 014-HG-17025 User manual

4 Piece Patio Sofa Sets
item no. 014-HG-17025
www.bellezefurniture.com
[email protected]
1-800-682-6376
@bellezefurniture
FOLLOW US: CONTACT INFO: NOTE:
The instruction booklet contains IMPORTANT safety
information Please read and keep for future reference.

2
OUR BRAND
LB
Estimated Time for Assembly
Weight Limitation
Tools Needed
80:00
All necessary tools are included in the package.
Since 2013, Belleze has been dedicated to providing customers with quality products and
exceptional service and has prospered into one of the nation’s largest retailers of indoor and
outdoor home décor. Every Belleze product is carefully selected to ensure they meet our
standards as well as your standards. We believe quality should never be determined by price
which is why Belleze is committed to providing high end merchandise at the absolute lowest cost.
PLEASE LIKE, COMMENT AND FOLLOW.
@bellezefurniture
705 lb Loveseat
881 lb 3 Seater
165 lb Table

3
PACKAGE CONTENT
Backrest
Table Top
Table Front
Table Base
Table Side
Seat
A1
C1
B
B
Leg Set
Cushion
BOX A
BOX A
A4
C4
B2
I1

4
PACKAGE CONTENT
M6x20 Bolt
4X
M6x35 Bolt
16X
M6x40 Bolt
47X
Washer
63X
M6x 20 Washer
4X
Allen Key
BOX B
BOX B
A2
B
C2
A3
B1
I
C3
Backrest
Seat
Leg Set
Cushion
Table Top
Table FrontTable Base
Table Side

5
1
2
Attach seat to the leg set.
Attach the leg set to the backrest.
A1
B
B
C1
Do not fully tighten the bolts until all parts are assembled.

6
4
3
Secure the seat to the leg set and backrest.
Make sure the unit is leveled on the ground,
then tighten all bolt and put on the cushion.

7
5
6
Attach the table sides to the base.
Attach the table front to the assembly.
B2
I1
I1
C4
Do not fully tighten the bolts until all parts are assembled.

8
8
7
Attach the table top and back assembly.
Secure the gas spring to the table sides.
A4

9
9
10
Attach the leg set to the backrest.
A2
B
B
Make sure the unit is leveled on the ground,
then tighten all bolt and attach the lining to
the velcro inside the table.
Do not fully tighten the bolts until all parts are assembled.

10
11
12
Attach seat to the leg set.
Secure the seat to the leg set and backrest.
C2
