Belling 900Ei User manual

USER
GUIDE
A commitment to:
Belling Range Ei AU Part Number: 083758801 Date: 14/11/18

To contact Belling about your appliance, please call:
Calls are charged at the basic rate, please check with your telephone service provider for exact charges
AU - Glen Dimplex Australia PTY LTD, 1340 Ferntree Gully Rd, Scoresby VIC 3179
NZ - Glen Dimplex New Zealand Ltd, 38 Harris Road, East Tamaki, Auckland, New Zealand
Warranty Registration
AU - 1300 556 816
NZ - 09 274 8265
Customer Care Helpline
AU - 1 800 444 357
NZ - 09 274 8265
To contact us by email:
AU - [email protected]
NZ - [email protected]
For spare parts and service information, please contact our Customer Care Department shown above
To register your appliance by mail:
Please complete the warranty card
and return to theaddress supplied
To register your appliance online:
AU - www.belling.com.au
NZ - www.belling.co.nz
During the 2 year guarantee period, your appliance, as specied on your warranty registration card,
your appliance is protected against electrical and mechanical breakdown. To register your
appliance, please call the number shown above, register online or complete the registration card
included.
Please ensure that you have available your appliance model number and serial number. For full
terms & conditions of the manufacturer’s guarantee, refer to the website.
Our policy is one of constant development and improvement, therefore we cannot guarantee the
strict accuracy of all of our illustrations and specications. Changes may have been made
subsequent to publishing.
GB - Great Britain
IE - Ireland
DE - Germany
ES - Spain
FR - France
IT - Italy
PL - Poland
NL - Netherlands
SE - Sweden
CN - China
NZ - New Zealand þ
AU - Australia þ
Countries of destination:

Thank you for buying this British-built appliance from us.
This user guide book is designed to help you through each step of owning your new product.
Please read it carefully before you start using your appliance, as we have endeavored to answer as
many questions as possible, and provide you with as much support as we can.
General information and User Guides are available from our website.
If you should nd something missing from your product or have any questions that are not covered in
this user guide, please contact us (see contact information inside the front cover).
This unit must be installed by a competent electrician / qualied technician. In regions where applicable,
please retain your Certicate of Compliance.
Disposal of Packaging Material
The packaging materials used with this appliance can be recycled. Please dispose of the packaging
materials in the correct manner.
GAS WARNING:
If you smell gas, Do not try to light any appliance. Do not touch any electrical switch.
Call the gas emergency helpline
INTRODUCTION

WARNING
• If the hob surface is cracked, broken or shattered, switch o󰀨 the
appliance to avoid the possibility of electric shock and call for a
service engineer’s visit.
• During use the appliance becomes hot. Care should be taken to
avoid touching heating elements.
• Children less than 8 years of age shall be kept away unless
continuously supervised. This appliance can be used by children
aged from 8 years and above and persons with reduced
physical sensory or mental capabilities or lack of experience and
knowledge if they have been given supervision or instruction
concerning the use of the appliance in a safe way and understand
the hazards involved. Children shall not play with the appliance.
Cleaning and user maintenance shall not be made by children
without supervision.
• Do not use harsh abrasive cleaners or sharp metal scrapers to
clean the oven door glass or the hob, since they can scratch the
surface, which may result in shattering of the glass.
• Do not use a steam cleaner on any cooking range, hob or oven
appliance.
• Metallic objects such as knives, forks, spoons and lids should not
be placed on the hob surface since they can get hot.
• If your appliance is tted with a lid, any spillage should be removed
from the lid before opening. The hob surface should be allowed to
cool before closing the lid (if tted).
• After use, switch o󰀨 the hob element by its control and do not rely
on the pan detector.
• To avoid electric shock, ensure that the appliance is switched o󰀨
before replacing the lamp.
• The appliance is not intended to be operated by means of an
external timer or separate control system.
• Unattended cooking on a hob with fat or oil can be dangerous and
may result in re.
• NEVER try to extinguish a re with water, but switch o󰀨 the
appliance and then cover the ame with a lid or damp cloth.
SAFETY

• Danger of re: Do not store items on the cooking surfaces.
• Only use hob guards designed by the manufacturer of the cooking
appliance or indicated by the manufacturer of the appliance in
the instructions for use as suitable or hob guards incorporated in
the appliance. The use of inappropriate hob guards can cause
accidents.
• If the cooker is placed on a base, measures have to be taken to
prevent the appliance slipping from the base.
• Never put items directly on the base of the oven or cover the oven
with foil, as this can cause the base element to overheat.
• This induction hob complies with the applicable EMC and EMF
standards. Therefore it should not interfere with other electronic
units. Persons tted with a pacemaker or any other electrical
implant should clarify with their doctor or the producer of the
implant, whether there implant is adequate and fail-safe. Please
place pans centrally on the cooking zones. The British Heart
Foundation provide additional advice regarding using induction
hobs when a pacemaker is tted.
• Do not place articles on or against the appliance
• Always switch o󰀨 your appliance and allow it to cool down before
you clean any part of it.
• Although every care has been taken to ensure this appliance has
no sharp edges, we recommend that you wear protective gloves
when installing and moving this appliance. This will prevent injury.
• This appliance must be tted to a switch providing all pole
disconnection with a minimum contact separation of 3mm.
• Connection should be made with a suitable exible cable with a
minimum temperature of 70oC.
CAUTION
• The cooking process has to be supervised. A short term cooking
process has to be supervised continuously.
• This appliance must not be installed behind a decorative door in
order to avoid overheating.
• Ensure shelving is correctly installed. See the sections on the shelf
runners and shelf location within this book.
SAFETY

• Fire Safety Advice
If you do have a re in the kitchen, don’t take any risks - get every-
one out of your home and call the Fire Brigade.
If you have an electrical re in the kitchen:
• Pull the plug out, or switch o󰀨 the power at the fuse box - this may
be enough to stop the re immediately
• Smother the re with a re blanket, or use a dry powder or carbon
dioxide extinguisher
• Remember: never use water on an electrical or cooking oil re.
• Other Safety Advice
• Servicing should be carried out only by authorised personnel.
• Do not operate the appliance without the glass panel correctly
tted.
• Do not modify the outer panels of this appliance in any way.
• This appliance must be earthed.
• The appliance must never be disconnected from the mains supply
during use, as this will seriously a󰀨ect the safety and performance,
particularly in relation to surface temperatures becoming hot and
gas operated parts not working e󰀩ciently. The cooling fan (if tted)
is designed to run on after the control knob has been switched o󰀨.
• GAS WARNING! - If you smell gas: Do not try to light any
appliance, Do not touch any electrical switch. Contact your local
gas supplier immediately.
SAFETY

Getting to know your product
Note: Your appliance layout may di󰀨er depending on the model.
Hob 90/110cm
Hob control panel
Control Panel 90cm
USING YOUR APPLIANCE
Oven controls
Oven controls Oven
Top Oven/Grill Split Cavity
Oven Top Oven/Grill
Oven Selector Control
Clock/Programmer
Thermostat indicator
Thermostat indicator
Thermostat indicator

Control Panel 110cm
Fascia Fascia
90cm 110cm
Top Oven
Multifunction
Oven
Fanned
Oven with
Splitter
Top Oven
Multifunction
Oven
Fanned
Oven
Slow
Cook
USING YOUR APPLIANCE
Oven
Oven Selector Control
Grill
Clock/Programmer
Oven Oven
Oven controlsOven controls
Thermostat indicator Thermostat indicator
Thermostat indicator
Top Oven/Grill

Appliance functions
Note: Your oven may not have all of the functions shown here. We recommend for best cooking results,
please preheat your oven for 15 minutes and 3-5 minutes for grilling.
Only slow cook using the dedicated function. When using the multifunction oven, rstly select the
fanned oven feature.
Intense Baking Defrost
Base Heat with Fan Conventional Oven
SSlow Cook Fanned Oven
Fanned Grill Low Grill
Oven Selector Control Single Grill
Conventional Grill Dual Grill
Top Heat Base Heat
Lights Only Pizza Function
Bread Proving Keep Warm
Oven Selector Control Electric oven
OFF
OFF
S
120
140
160
180
200
220
240
260
USING YOUR APPLIANCE

Ovens and Grill
When using the top oven or main oven, the white thermostat indicator light will come on until the
selected temperature is reached.
When the Top oven/grill or grill is switched on, the cooling fans come on to keep the fascia and control
knobs cool during cooking/grilling. The cooling fans may operate when the main ovens are in use,
depending on the temperature setting. The fans may continue to operate for a period after the oven/grill
has been switched o󰀨. During use the fan may cycle on and o󰀨, this is normal.
Important: Never put items directly on top the base of the oven, or cover the oven base with foil, as
this may cause the element to overheat. Always position items on the shelf.
The left hand main oven will not operate if the programmer is set to Auto, see clock/programmer
section.
Top Oven - Grill
THE DOOR MUST BE OPEN WHEN THE GRILL IS USED.
Main Oven - Grill
THE DOOR MUST BE CLOSED WHEN THE GRILL IS USED FOR FANNED AND CONVENTIONAL
GRILLING.
Tall Oven - Grill (90cm only)
THE DOOR MUST BE OPEN WHEN THE GRILL IS USED.
USING YOUR APPLIANCE

USING YOUR APPLIANCE
Grill pan and trivet
The grill trivet (inside the grill pan) can be inverted to give a high or low position, or it may be removed.
The speed of grilling can be controlled by selecting a higher or lower shelf position, or adjusting the grill
setting.
Inverted

USING THE HOBUSING THE HOB
USING THE HOTPLATE
• Commercial simmering aids should
not be used as they create excessive
temperatures that can damage the
surface and may cause a hazard.
• Do not place aluminium foil or plastic
utensils on the ceramic glass, as they
may melt and damage the surface.
• Do not use the ceramic glass hotplate
surface for storage.
• When cooking with fat or oil, never
leave unattended.
• Turn pan handles to a safe position,
so they are out of reach of children,
not overhanging the appliance, and
cannot be caught accidentally.
• Position pans over the centre of the
hotplate elements.
• Do not use the hob as a chopping
board or a storage area, as this
increases the likelihood of it be-
ing damaged - e.g.; plastic utensils
placed on a warm hob may melt onto
it, and damage the ceramic glass
surface.
• Be careful when cooking foods in
salted water, or foods containing
large amounts of sugar, syrup or jam
- if they are spilled onto hot areas of
the hob they may damage it.
• Liftpansontoandothesurface,
rather than sliding them across the
surface, to avoid marks and scratch-
es.
• If you use a wet paper towel to
remove spills from a warm heating
area of the hob, be careful to avoid
steam burns.
• Do not use abrasive powder cleaners,
metal wire wool pads, impregnated
plastic pads, detergents, bleaches,
bath stain removers, or chemical
oven cleaners; all these types of
products will damage the ceramic
glass.
The functions of the hob comply with
the applicable standards on electro-
magnetic interference
Your induction cooking hob thus com-
plies fully with the statutory require-
ments (Directive 2004/108/EC). It
is designed to not interfere with the
functioning of other electrical equip-
ment as long as these also comply
with the same regulations.
Your induction hob generates magnetic
eldsinitsimmediatevicinity.
So that there is no interference
between your cooking hob and a
pacemaker, the pacemaker must be
designed in compliance with the ap-
propriate regulations.
In this respect we can only guarantee
the compliance of our own product.
You can ask the manufacturer or your
doctor about the compliance or any
incompatibilities of your pacemaker.
Once you have powered on the
induction hob, you have 10 sec-
onds to set the power or use the
timer, before the induction hob is
automatically switched o.

USING THE HOBUSING THE HOB
Feature Symbol Description
Eco power InductionPoweristhemostenergyecientmeansof
cooking food, provides fast heat up and boiling times
Slide Control Slideyourngeralongthegraphicorsimplytouchthe
graphic at the power level you require.
Digital display Secret till “lit” hob display
No. of power
levels 13 Precise and repeatable control settings
Special Functions
Three preset temperature controls set at 42oC, 70oC, and
94oC. Ideal for Melting chocolate, Warming and Rapid
Simmer respectively
Central Power
On/O PowerOn/OfortheInductionhob
Power Boost Temporarily boost the power to a cook zone by a mas-
sive 60%
Pause/un-pause This button pauses cooking with one touch. (cuts power)
Minute Minder To a maximum time of 9 hours 99 minutes, you can time
anything
Auto Time
Switch’sOall5
zones
Yes Allvezonescanbesimultaneouslytimedtoturno
automatically
Key Lock To prevent accidentally changing settings, press the key
graphic to lock the controls
Pan Detection
Lets you know if the correct pans are being used and
helpstosaveenergy.Whenapanisliftedothezone,
the power is automatically cut.
Overheat Pan
Detection Yes
Helps prevent cookware from overheating providing an
additional level of safety not available on other types of
hobs
Child lock Yes Prevents unintentional operation of the hob
Residual Heat
Indictions
Warns you against hot surfaces but also indicates that
the residual heat which can be used as a temporary
warm zone
Holiday Shutdown Yes Nooperationisrequired-thehobwillturnitsselfoif
left

USING THE HOBUSING THE HOB
About the induction hob
The induction hob provides the most en-
ergyecienthobtechnologyavailable.
The induction system provides superior
heat up and cool down times for pans -
you get fast, precise, repeatable power
control.
As induction only heats up the pan, there
is no lost heat from the cooking process,
which in turn, limits the heat generated in
the kitchen.
Auto Power Tuning
Induction hobs have a unique power
tuning system that automatically tunes
the power to the size of the pan base this
ensures energy isn’t wasted.
Touch Controls
The touch controls for your induction have
beendesignedtoprovideyouwithnger
touch control of your hob, providing ac-
curate and repeatable power settings for
cooking and an easy clean surface that
can be easily wiped over.
Each cook zone displays it’s individual
power setting.
Using the Touch Controls
To select a cook zone or the timer, simply
touchthegraphicslider,usingtheat
ofyournger,notthetip,Thecontrols
respond to touch, so you don’t need to
apply any pressure.
Once you have powered on the induc-
tion hob, you have 10 seconds to set the
power or use the timer.
If the red displays disappear, simply press
the power button again.
Always ensure the control area is clean,
dry and free from of any objects (e.g.
utensils, tea towels and cloths). Spillages
andwatermaymakethecontrolsdicult
to operate.
Basic Hob Function
Turning on the hob.
•Usetheon/obutton.
Activating a cook zone.
Select the slider and operate by sliding
yourngeracrossthegraphicortouch-
ing the graphic at the desired power level
(0-9).
Modifying the power setting whilst
cooking
Turning o individual cooking zones.
1) Decrease the power setting until the
display shows 0. If the cook zone surface
is hot to touch, Hwill replace 0in the
display.
Small Pan
Large Pan

USING THE HOBUSING THE HOB
Induction controls
Power Boost
The power boost is a function that can
be used to temporally boost the normal
maximum power for a cook zone by bor-
rowing the available power from a “paired
zone”.
All the cook zones have this function.
The Power Boost is activated by sliding or
touching the P.
Note The Power Boost function will only
operate for a limited time and is also
under thermal control. This means the
power boost will deactivate automati-
cally if the product is hot, to protect the
internal electronic components of the
hob and to prevent the cookware from
overheating.
145mm
145mm
145mm
145mm 120mm
Smallest recommended pan diameter

USING THE HOBUSING THE HOB
Special Function Key
Touch once for Function 1 94 oC -
Ideal for a Rapid Simmering.
Touch twice for Function 2
70 oC - Ideal for keeping warm
Touch three times for Function 3
42 oC - Ideal for melting or sauces
Pan detection
When a zone has been activated but no
pan has been placed on the cook zone,
the zone will recognise that there is no
pan in position. It also means the hob
only uses power when a suitable pan is
placed on the zone. This reduces the en-
ergy used during the cooking process, i.e.
whenyoutakeyourpanothezonethe
hob automatically reduces the power, and
only switches back on when you replace
the pan.
Note If the symbol does not disap-
pear when a pan is placed on the zone it
indicates that the pan is not suitable for
induction cooking.
SPECIAL HOB FUNCTIONS
On/O switch
Thecentralon/oswitchenablesallof
thecookingzonestobeswitchedon/o
simultaneously at a touch of a button, so
whenyouhavenishedcookingorare
called away from the kitchen for any rea-
son you can be safe in the knowledge that
everything is under control and safe.
To Operate
1)Selecttheon/okey.Thekeyneedsto
be pressed for at least 1 second to acti-
vate, this is to ensure that the hob cannot
be activated unintentionally.
Note:
All other keys only need to be pressed for
0.3 seconds to be activated/deactivated.
Note:
“H” will appear on any cook zone display
that is still hot to touch.
Using the Timer
min
The timer has up to
7 timers. 6 timers to
be assigned to the
cooking zones and
one independent
timer called egg-
timer.
The displays show
the remaining time
until the alarm is
activated.
All timers work as count down timers. The
operation range is between 1 min to 2h
59min.Fortimeslessthan59mins,the
display is exact to the second.
Before activating a timer the control has
to be switched on. Switching the con-
trolodeactivatescookingzonerelated
timers. The egg timer stays active after
switchingthecontrolo.
A symbol next to the zone will be lit when
a timer is set to that zone
Activating Cooking Zone Timer
To activate the timer, press both the plus
(+) and minus (-) keys together.
A timer can be activated for each active
cooking zone. After selecting the timer the
cooking zone related luminous symbol is
fully lit and the timer display shows 0.00.
For the following 10 sec it is now pos-
sible to assign a timer value to the active
cooking zone. After 10sec without input,
the timer function is deactivated and the
displayisswitchedoagain.Usingthe

USING THE HOBUSING THE HOB
timer selection key again (as long as no
value was set) the next active cooking
zone can be selected.
Setting a timer value
•Bypressingthetimerkeys,atimer
value can be set. If the timer-plus-key is
pressedrstthedisplaystartswith1min
and can be increased in 1min steps. If the
timer-minus-keyispressedrstthetimer
startswith15minandcanbedecreased
in 1 min steps.
•Pressingthekeypermanentlyspeedsup
the timer adjustment. The speed will also
increase while the key is held. (the time
between two time steps reduces).
•Ifatimerhasexpiredthetimeralarmis
activated and the assigned cooking zone is
immediatelyswitchedo.
•Thecookingzonedisplayshows0orH.
If no user input stops the alarm
signal it will be on for maximum 2
minutes.
The alarm can be deactivated
byswitchingothecontrol
using the main switch or by
pressing the two timer keys or
it will be deactivated automatically after 2
minutes.
Switching o a timer or changing the
time setting
Thetimervaluecanbemodiedatany
time by selecting the timer and then by
pressing the (+ or -) timer key.
To stop an active timer the value can be
set to 0. Pressing Plus and Minus simul-
taneously for 2 seconds also resets the
timer value to 0.00.
Minute Minder
The minute minder buzzes when the time
sethasexpired.Itdoesnotswitchoany
zone.
To operate:
1)Turnonthehob,usingtheon/okey.
2) Select the timer by pressing the + and
- keys together (do not activate any cook
zone).
3) Set the right hand digit up to 9 minutes
(Single Minutes Units) and wait a couple
of seconds.
4) The display will now indicate for you to
set the left hand digit, up to 90 minutes
(10 Minute Units).
5)Thetimerisnowsetandbeginscount-
ing down. (No zone indicator light should
be set).
6) You can now use the hob as normal.
When the time is up.
1) The corresponding indicator in the
timerdisplaywillash,thetimerwillbeep.
2) Touch any control to stop the beeping.
Warning!
Never leave the hob unattended when in
use, even when you have set the timer to
turnothecookzone.
Additional timer information
To modify or cancel a timer setting follow
steps1)to5)above.
To set the timer for additional zones follow
steps1)to5)above.
If multiple zones have been set for timed
operation , the timer display will always
display the time for the cook zone with
the shortest time remaining.
Tocheckthetimersettingforadierent
cook zone, simply select the required cook
zone,theremainingtimewillbrieyap-
pear in the timer display.
min

USING THE HOBUSING THE HOB
Pause key
Warning!
Don’t leave pans on the hob when you’re
notaround-takethemotheheatifyou
have to leave the kitchen (even if you
think it will only be for a moment, while
you answer the door or phone) or you can
use the Pause Key.
The Pause key is ideal for unexpected
interruptions when cooking. With this
button you can pause all cooking settings
(Cuts power) with one touch.
To Operate
1) Press the pause key.
Note:-
All cook zones functions will pause (no
power) and will be displayed for each cook
zone.
2) To restart, press the pause button and
then within 10sec use the cooking zone
slider left to the timer (slide from low to
higher levels).
Note:- All cook zones will automatically
resume to the previous settings.
Cookware for the induction hobs
Cookware for the induction cooking zones must be made of metal and have magnetic
properties. The base must also be the correct diameter.
Suitable Cookware for Induction Hobs Unsuitable Cookware
Enamelled steel pots with a thick base
Pots made of copper, stainless steel,
aluminium, oven-proof glass, wood,
ceramic and terra-cotta.
Cast iron pots with an enamelled base
Pots made of multi layer stainless steel,
rustproof ferrite steel or aluminium with
a special base
Pans marked for use with induction
How to establish the suitability of a pan
Check your pans with a magnet. If it sticks and it’s the correct diameter, it’s suitable for
use with induction. Also with pans that bear the symbol for suitability for cooking with
induction.
Note - when using certain pans, you may get various noises from the pans. This is due
tothedesignofthepansanddoesnoteecttheperformanceorsafetyofthehob.
Pans should not be allowed to come into contact with coloured trims during use as this
may cause discolouration of the surface

USING THE HOBUSING THE HOB
Child Lock
This feature is to help prevent accidental
switching on of the hob, especially by
young children.
To activate:
Press the key lock button and pause
button together, and then release them.
Complete activation by pressing the key
lock button again.
To deactivate:
Press the key lock button and pause
button together, and then release them.
Complete activation by pressing the pause
button again.
Residual Heat indicators
Ifwhenthecookzoneisswitchedothe
glass surface is above 60°C , H will be dis-
played in the cook zone display until the
glass surface drops below approximately
55°C.
This feature not only warns you against
hot surfaces but also indicates that there
is residual heat which can be used as
temporary warm zone.
Note - The cook zone itself does not heat
up, but the ceramic glass does get hot
because of the hot pan conducting heat
back onto the hob glass.
Overheat Pan Protection
The hob is equipped with additional safety
systems that help to prevent cookware
from overheating, providing an additional
level of safety not available on conven-
tional hobs (such as gas and ceramic
hobs).
Approximate
Glass
Surface
Temperature
(oC)
Intelligent hob
safety system
200 Reduces Power Boost
setting to Power Level 9
250 Reduces power to 60%
of power level setting
270 Switchescookzoneo
300 Switches whole appli-
anceo
Note - The safety temperature control
of the pans is only possible with quality
atbottomedpanssuitableforinduction
cooking. Poor quality pans can create
air gaps between the glass and the pan,
whichaectstheaccuracyofthetem-
perature control.
Auto Stand by (Holiday Shut Down)
Thehobwillautomaticallyswitchitselfo
if left unattended.
Cooking guide
For best cooking results, follow the
examples in the guide below, bearing in
mind that settings 8 and 9 are maximum
positions and should only be used for
deep frying and bringing up to the boil
quickly.

USING THE HOBUSING THE HOB
Preparation
Very fast
frying
Fast Medium Slow Simmering,
re-heating
Keeping
warm
9 8 7 6 54 3 2 1
Soup
Thin soup
Thick soup


Fish
Court-Bouillon
Deep fried


Sauces
Thick,ourbased
Buttery, containing eggs


Vegetables
Spinach
Pulses
Boiled potatoes
Carrots
Saute potatoes
Frozen vegetables









Meat
Thin cuts of meat
Fried steak


Other types of cooking
Deep frying: frozen chips
Deep frying: fresh chips
Pressure cooking
Stewed fruit
Pancakes
Custard
To melt chocolate
Jam
Milk
Fried eggs
Pasta
Re-heating baby food
Rice pudding
Keeping food warm
Stews

















