Belling platinum db3A Assembly Instructions

1
R
platinum db3A dual fuel cooker
Installation & User’s instructions
platinum db3A dual fuel - Natural Gas
(Liquid Petroleum gas convertible)
Note: This appliance is supplied for use with the category of gas
specified and can be converted to LP gas with the kit
provided.

2
Contents
Product Specification………………………………………………………………………………………….3
Introduction…………………………………………………………………………………………………..…4
Installation Instructions…………………………………………………………………………………….5-8
For Your Safety Never..……………………………………………………………………………………….9
For Your Safety Always………………………………………………………….…………………………..10
Know Your Cooker…………………………………………………………………………………………….11
Know Your Control Panel…………………………………………………………………………………….12
Timer Instructions………………………………………………………………………………………….13-17
Automatic Cooking (Large Oven)………………………………………………..…………………………18
Using the Hob……………………………………………………………………………………………….19-21
Main Multifunction Oven & Grill…………………………………………………………………………22-26
Small Conventional Oven / Storage & Reheating of Food……………………………………………..27
Main Multifunction Oven Cooking Guide………………………………………………………………28-29
Small Conventional Oven Cooking Guide…………………………………………………………………30
Temperature Conversion Scale………………………………………………………………………………31
Care & Cleaning……………………………………………………………………………………………..32-33
Is There Something Wrong With Your Cooker…………………………………………………………….34
Cooking Results…………………………………………………………………………………………………35
Service…………………………………………………………………………………………………………….36

3
Product Specification
Platinum db3A Technical Data
DIMENSIONS:- Height 900 – 915mm
Width 997mm
Depth 600mm (excluding door handles)
GENERAL
Gas connection Rp ½
Burner pressure Natural Gas – 1.0kPa
LPG Gas models – Propane 2.75kPa
Pressure test point Gas Regulator (Nat Gas) or Front Right Semi-Rapid hob burner
(see checking burner pressure)
Gas rate adjustment None
Aeration adjustment None
Electrical connection 4mm² cable 230 – 240V ac 50Hz
Total Heat Input (Gas) Natural Gas: 44.5 MJ/h
LPG – Propane: 38.4 MJ/h
Total Heat Input (Electric) 4.47 – 4.87kW
Multifunction Oven (Left Hand)
Oven Light Only 0.01 - 0.02kW
Fan Oven & Light 2.37 – 2.58kW
Conventional Oven & Light 2.04 – 2.22kW
Fan Grill (Closed Door) 2.43 – 2.65kW
Fan Only & Light (Defrost) 0.04 – 0.05kW
Grill (Full) (Closed Door) 2.41 – 2.62kW
Grill (Half) (Closed Door) 1.30 – 1.42kW
Conventional Oven (Right Hand) 2.04 – 2.22kW
NATURAL GAS LPG - PROPANE
BURNER
HEAT INPUT INJECTOR HEAT INPUT INJECTOR
Middle
(Ultra Rapid) / Wok
13.0 MJ/h 1.65mm 12.0 MJ/h 0.95mm
Front Left
(Rapid
12.0 MJ/h 1.55mm 10.0 MJ/h 0.87mm
Rear Left / Front Right
(Semi-Rapid)
7.7 MJ/h 1.25mm 6.3MJ/h 0.69mm
Rear Right
(Auxiliary)
4.1 MJ/h 0.90mm 3.8 MJ/h 0.53mm

4
Introduction
Your belling Cooker Thank you for purchasing a new belling platinum db3 cooker. Its stylish, practical
design will enhance your kitchen and make cooking a pleasure. It features a
large multifunction oven/Grill (Closed door), a small conventional oven, a storage
compartment, 5 gas hob burners and a utensil holder. There is also an electronic
clock/timer featuring a minute minder and automatic cooking facilities (large oven
only).
Even if you have used an electric or gas cooker before, it is important that
you read these instructions thoroughly before starting to cook, paying particular
attention to the installation and safety instructions.
Getting Help If you have any problems with installing, operating, or cooking with your belling
cooker, please check through these instructions thoroughly to make sure that
you have not missed anything. If you still need help, then please contact your
retailer or place of purchase.
Please quote the cooker model and serial number with all inquiries. This can be
found on the chassis behind the drop down storage compartment panel.
WARNING! For your own safety, make sure that these instructions on
installation, use and maintenance are followed.
We advise you to keep these instructions in a safe place for future reference.
If you sell or transfer ownership of this product, please pass on these Instructions
to the new owner.
Unpacking Unpack the components from inside the storage compartment.
Check that the following parts are present.
Meat / Grill pan with food support grid and detachable handle
Pan supports (3)
Pan Support Bridge
Multifunction oven shelves (2)
Conventional oven shelf
Baking Tray
Hob burners (5)
LP Gas Conversion kit
Literature
After unpacking your cooker, make sure that you remove all the packing from the
grill compartment / ovens and any stickers from the oven doors and hob.
Examine your cooker for any damage. If there is damage to your cooker or
anything is missing, please contact your supplier for advice.

5
F
OR COOKER TO SIT FLUSH WITH THE REAR WALL :-
G
AS PIPE MUST NOT BE MORE THAN 75mm ABOVE THE FLOOR (In either direction)
O
R PROJECT MORE THAN 40mm FROM THE REAR WALL
85
ELECTRICAL CONNECTION
75
MAX
T
Fig. 2
200
755
275
150
MAINS INLET ON APPLIANCE
250
150
1000
285
Installation Instructions
Gas Safety This appliance is TO BE INSTALLED ONLY BY AN AUTHORISED PERSON in
(Installation & accordance with the manufacturers installation instructions,
Use) Regulations local gas fitting regulations, the AGA Gas Installation Code, the Australian Gas
Installation code AG601/AS5601 and any other relevant statutory regulations.
Particular attention should be given to the relevant requirements regarding
ventilation.
Failure to install the cooker correctly could invalidate the warranty liability claims
and could lead to prosecution.
Where this appliance is installed in marine craft or in caravans, it shall NOT
be used as a space heater.
Space for Fixing Your cooker is heavy, so be careful when moving or positioning it. Do not try to
move the cooker by pulling on the doors or handles or control panel. The Belling
db92 is designed to 'slot-in' between 600mm deep cabinets, spaced at least
915mm apart. It can also be used freestanding, with a cabinet to one side, in a
corner setting or with its back to a wall. However it must not be situated with
either side closer than 50mm to a combustible wall or cupboard that is higher
than the cooker.
The wall behind the cooker and 450mm above and across the width of the
cooker, should be of an incombustible material or easy clean surface such as
ceramic tiles. Please note, when positioning your cooker against a wall, ensure
there is sufficient clearance for the screw heads on the back panel.
This appliance is designed not to project in front of standard 600mm worktops
(excluding handles). To achieve the best fit the cooker must be pushed against the
wall. If the wall mounted adapter back-plate (Fig.1) is to be fitted behind the
appliance then the suitable area for this fitting is shown as the area in (Fig.2).
Fig. 1
NOTE: The adaptor backplate requires chasing into the wall if it protrudes more than 40mm. This is to
allow the cooker to be pushed back to the wall.
VERTICAL PIPEWORK OPTION
HORIZONTAL PIPEWORK OPTION
(Natural Gas Only
GAS REGULATOR
(Natural Gas Only
GAS REGULATOR

6
Installation Instructions
Any overhanging surface or cooker hood should be at least 760mm (30") above
the cooker hob. We do not recommend positioning the cooker below wall
cupboards, as the heat and steam from the cooker may cause damage to the
cupboard and its contents.
Excess steam from the oven, vents out at the top back edge of the cooker, so
make sure that the walls behind and near the cooker are resistant to heat, steam
and condensation.
Levelling Your cooker must stand on a flat surface so that when it is in position the hob is
level. The cooker is fitted with rear wheels and will slide into position easily.
Movement of your cooker is most easily achieved by lifting the front, as follows.
Open the oven doors sufficiently to allow a comfortable grip on the underside front
edge of the oven roofs, avoiding grill elements or oven furniture.
Adjust the cooker at the rear to the required height, using the 2 jacking screws
situated behind the rear access cover and secure with the lock-nuts. Position the
cooker and adjust the height at the front with the 2 jacking screws situated at the
front underside. Check that the cooker is level by using a spirit level (adjusting the
jacking screws if necessary). It is important that the cooker is stable and level for
the overall cooking performance.
Caution NOTE: This appliance should not be installed on a platform.
Stability Chain The cooker must be fitted with a stability device such as a proprietary stability
chain (supplied) as shown in Figure 3 and firmly secured to the fabric of the
building. Any leaflet included with the chain should be read in conjunction with the
following instructions.
Whatever the position, remember to leave enough room for the cooker to be pulled
out for cleaning and service.
Fig.3

7
Installation Instructions
Connect to Gas Supply Means of isolation shall be provided at the supply point by either an approved
quick connect device or a type1 manual shut off valve. The outlet of the quick
connect device shall be at, or below, the horizontal position.
Connection to the cooker should be made using the supplied AGA certified hose
assembly and regulator (Natural Gas only).
Note: Max length of hose = 900mm
The temperature rise of areas at the rear of the cooker that are likely to come
into contact with the flexible hose do not exceed 70°C.
A Rp 1/2elbow is fitted to the cooker.
If the position of the wall connection is within 250mm of the oven inlet, the loop of
hose will give maximum movement to the cooker.
A restraining chain or wire of adequate strength is to be fixed to the appliance and
the wall within 50mm of each connection point. The length of the chain or wire is
not to exceed 80% of the length of the hose assembly. The restraining chain or
wire is to prevent stress being imparted onto the hose assembly when the cooker
is moved out of its normal operating position.
After installation, check for soundness.
The burner pressure is tested at the hob burner situated rear/left.
With reference to the user instructions:
1 Check that the hotplate burners ignite correctly and burn with a steady flame.
2 Check for a steady flame at the low (small flame symbol) setting.
3 Instruct the user on the operation of the cooker.
Checking Burner Pressure The burner pressure of the appliance can be checked at the Gas regulator
(Nat Gas), or the front Right Semi-Rapid hob burner (the adaptor supplied will be
required).
When checking at the front right Semi-Rapid burner, remove the burner jet and
screw in the adaptor. Connect the test equipment and ignite the Rapid burner
(Front left) on maximum setting. Pressure should be as stated on the data badge
(adjust the pressure if required). Remove the adaptor and replace the jet in the
burner (Rapid).
IMPORTANT:
Ensure the pressure adaptor is retained by the householder for use by future
authorized service personnel.
Bypass Adjustment The appliance is factory set for Natural Gas. All bypass screws are preset to suit
and should only require adjustment, by an authorized person, when the appliance
is being converted to Propane gas (Refer to Conversion Instructions). If
adjustment is required, the adjusting screw is situated down the center of each gas
tap spindle and is adjusted, only by an authorized person, with the aid of a small
flat-headed screwdriver.
Clockwise = Reduce rate
Anti-clockwise = Increase rate
If the appliance cannot be adjusted to perform correctly, then please contact your
sales agent shown at the rear of these instructions or your local gas authority.

8
Installation Instructions
Connecting to Electrical For your own safety, we recommend that your cooker is installed by a
Supply competent person. The cooker should be installed in accordance with
AS/NZS 3000:2000
WARNING: THIS APPLIANCE MUST BE EARTHED!
The cooker must be connected to the correct electrical supply as stated on the
rating plate, through a suitable cooker control unit incorporating a double pole
switch having a contact separation of at least 3mm in all poles, adjacent to (but not
above) the cooker. We recommend that the cooker circuit is rated to 30 Amps.
We also recommend that 4mm² P.V.C. (minimum 2.5mm² - maximum 6.0mm²)
Insulated twin and earth cable is used to connect the cooker control unit.
IMPORTANT:
For access to the mains terminal block and for supply cable connection, it is
necessary to remove the access cover situated at the bottom of the back panel.
No part of the appliance will operate unless the main control unit is switched ON.
The live and neutral positions are marked with the letters L and N respectively,
marked in front of the terminal block. The earth terminal is marked by the earth
symbol.
Allow sufficient cable length for the cooker to be pulled out for cleaning, but do not
let it hang closer than 25mm (1”) to the floor. The cable can be looped if
necessary, but make sure that it is not kinked or trapped when the cooker is in
position. Secure the mains cable using the cable clamp.
Connect the mains cable as follows:-
Live to terminal L.
Neutral to terminal N
Earth to the earth stud.
Before Cooking Before you cook for the first time, we recommend that you switch on each element
in turn to burn off any odours remaining from manufacture.
Additional Protective An additional protective means to avoid contact with high temperatures on the
Means oven doors is available. An extra inner door glass is provided to make the door
assembly triple glazed, thus reducing temperatures on the door front. This part
should be fitted when young children are likely to be present.
The kit is available as an optional extra from the Belling Agent as listed at the
rear of the instructions.
Quote Reference: DK0001
Screw (2) Grubscrews into the base of the extrusions
into the channels as shown
Inner door glass slides into position

9
For Your Own Safety
When used properly your Belling Cooker is completely safe, but as with any cooker there are some precautions
you must take in its use.
NEVER
• Never allow anyone except an authorized Belling Service Agent to service or
repair your cooker.
• Never remove any part of the cooker other than those intended in normal use, or
attempt to modify the cooker in any way.
• Never use the cooker for commercial catering. It is designed for domestic use.
• Never allow young children to operate or play with the cooker.
• Never use a chip pan or deep fat fryer more than 1/3full of oil, or use a lid while
frying and do not leave a fryer unattended while cooking.
• Never line the shelves, floor, or sides of the ovens or grill with aluminum foil as
overheating and damage may result.
• Never place anything which might catch fire, such as towels or tea towels, near to
the burners or over the flue outlet even when the cooker is not in use.
• Never use an asbestos mat, trivet or rack of any kind under pans on any hotplate.
• Never store anything which might catch fire in the oven, grill compartment or
storage compartment.
• Never allow aluminum foil or plastic to touch any hotplate when it is hot.
• Never store flammable liquids, aerosols, etc. in adjacent cabinetry.
• Never dry clothes or place other items over or near to the hotplate or oven or grill
doors.
• Never use large preserving pans or fish kettles across two hotplates as this will
damage the hob.
• Never use cooker as a room heater.
• Never wear garments with long flowing sleeves whilst cooking.
• Never leave burners lit when not in use.
• Never use the hotplates with the burner caps removed.
• Never use badly designed or misshapen pans which may be unstable.
• Never allow pan handles to stick out beyond the hotplate (where they can be
knocked) or over another burner.
• Never store flammable materials in the storage drawer
MPORTANT! DO NOT SPRAY AEROSOLS IN THE VICINITY OF THIS COOKER WHILE IT IS
IN OPERATION
IF YOU SMELL GAS turn off all gas controls on the hob, open windows and turn
off gas supply at the mains. Do not operate any electrical switches and contact
your local gas supplier immediately.

10
For Your Own Safety
ALWAYS
• Always make sure you understand the controls prior to use.
• Always take care when touching any part of the cooker that may be hot. Use good
quality dry oven gloves when removing or replacing food or dishes.
• Always stand back when opening the oven door to allow any build-up of heat or
steam to disperse.
• Always keep the oven and grill doors closed when not in use to prevent accidents.
• Always make sure that the roof, side and back panels, and shelves are fitted
correctly before using the oven or grill.
• Always keep your cooker clean, as a build-up of grease or fat from cooking may
be a fire hazard.
• Always switch off at the mains supply before cleaning your cooker.
• Always supervise children and pets, particularly when grilling, as exposed parts of
the grill may become hot.
• Always place pans centrally over the hotplate burners and make sure that they are
stable.
• Always keep handles away from the edge of the hob and any other burners. For
added safety you should consider using a suitable hob guard.
• Always make sure that all the controls are switched off when you finish cooking.
• Always remember that your cooker may stay hot for a time even after you have
finished cooking.
• Always keep ventilation slots at the rear of the cooker clear of obstructions.

11
Know Your Cooker
Rear left hotplate
(Semi-Rapide)
Front left hotplate
(Rapide) Front right hotplate
(Semi-Rapide)
Rear right hotplate
(Auxiliary)
Large Timed Electric Multifunction Oven
Small electric
2 Oven shelves
Cookclean side panels
(Wok-Triple Ring)
Centre hotplate
Control panel
Cookclean side & rear panels
1 Oven shelf
Baking tray
Meat/grill pan c/w
Drop down storage panel
Electric grill
(Closed door)
Utensil holder
Rating label on chassis
(Behind storage panel)
Electronic digital timer &
Cookclean roof liner
PLinth
large oven programmer
food support grid &
Easyfit small oven glass door
Easyfit
main oven
glass door
detachable handle
(Not shown)
conventional oven
multi-function
Pan Bridge Support

12
Know Your Control Panel
Control Knobs & Switches The hob (Gas hotplates) control knobs can only be rotated anti-clockwise
from the off position.
The ovens thermostat control knobs can only be rotated clockwise from the
off position.
The multifunction selector switch knob can be rotated in either direction from
the off position.
The spark ignition switch is operated as follows.
Depress and hold in the push-button. This will provide a repetitive spark to
the burners.
(5) Gas Hotplate Controls
Main Oven Neon
Multifunction Selector
(Programmable Timing Option)
Large Elec Multifunction Oven Thermostat
Switch (Main Oven)
200
230
150
100
70
200
230
m
100
150
and Large Elec Oven Timer
Electronic Digital Clock, Minute Minder
Spark Ignition Switch
stop
Small Oven Neon
Small Conventional Elec Oven Thermostat

13
Timer Instructions
The oven timer offers you the following features:
1. Time of day
2. Automatic cooking (Large oven only)
3. Minute minder
The large oven can be controlled by the automatic timer. When the timer has been
set, the small oven remains functional.
Hints on Automatic 1. Select foods which will take the same amount of time to cook and require
Cooking approximately the same temperature.
2. Set the oven timer so that the food has just finished or about to finish cooking
on your return to the oven. This will ensure the food has not cooled down and
does not require re-heating before serving.
3. Food should be as cold as possible when it goes into the oven, ideally straight
from the refrigerator. Frozen meat and poultry should be thawed thoroughly
before being placed into the oven.
4. We advise that warm food should never be placed in the oven if there is to be a
delay period. Stews prepared by frying the meat and vegetables should be
cooked as soon as possible.
5. We advise dishes containing left over cooked poultry or meat (eg. Shepherds
pie) should not be cooked automatically if there is to be a delay period.
6. Stews and joints should be cooked by the long slow method, so that the delay
start is kept to a minimum.
7. On warm days, to prevent harmful bacterial growth in certain foods (eg. Poultry,
joints etc.) the delay start should be kept to a minimum.
8. Wine or beer may ferment and cream may curdle during the delay period, so it
is best that these ingredients are added just before serving.
9. Foods that discolour should be protected by coating in fat or tossing in water (to
which lemon juice has just been added) prior to placing the food into the oven.
10. Dishes containing liquid should not be overfilled. This will prevent boiling over.
11. Foods should be well sealed (but not airtight) in a container to prevent the loss
of liquid during cooling. Aluminium foil gives a good seal.
12. Ensure food is cooked thoroughly before serving.

14
Timer Instructions
To set the Time of Day Step 1 Make sure all the oven controls are turned off.
Step 2 Check that the electricity supply to the oven is switched on.
Step 3 When switched on the display will show 0.00 and
Auto flashing intermittently.
Step 4 Press and hold the and buttons together (the
display shows 0.00). At the same time press either the “+” or “-
“ button to set the correct time of day.
RELEASE AND THE TIME OF DAY IS NOW SET.
To set Timer to switch (This allows you to cook immediately for a chosen period of time OFF
Automatically before the oven switches OFF Automatically)
Step 1 Ensure the time of day is set correctly.
Step 2 Place food onto the correct shelf position in the oven.
Step 3 Turn the oven control to the required temperature (The oven
Cookpot Symbol should now be operating).
Step 4
Press and release the button. The display will read 0.00 with the
cookpot lit.
Within 2 seconds press and hold the “ +” or “ -“ button until the
required cooking period is set.
(Adjustment can be made by pressing the “ -“ button)
The timer display will revert to the time of day with the Auto symbol
Cookpot Symbol Disappears and Cookpot lit.
At the end of the cooking period the Auto symbol will flash and an
intermittent bleeping sound will be heard. This will continue for
approximately 2 minutes unless the timer is reset within this period
(See step 6).
The oven will no longer operate until the timer has been reset to
manual operation (See steps 5 & 6 on the next page).

15
Timer Instructions
To set Timer to switch OFF Step 5 Turn off the oven control
Automatically (Continued)
Step 6 Press the button to cancel the bleeping (If 2 minutes has
not elapsed)
Press button again to return to manual operation.
To set Timer to switch ON (This allows you to cook at a specified time for a chosen period
& OFF Automatically before the oven switches OFF Automatically)
Step 1 Ensure the time of day is set correctly.
Step 2 Place food onto the correct shelf position in the oven.
Step 3 Press and release the “ “ button. The display will read
0.00 with the cook-pot lit. Within 2 seconds press and hold the
“ + ” button until the required cooking period is set.
(Adjustment can be made by pressing the “ -“ button).
The timer display will revert to the time of day with the Auto
symbol and cook-pot lit.
Step 4 Press and release the “ “ button. The display will
read the earliest possible end time with the cook-pot and Auto
symbol lit.
Within 2 seconds press and hold the “ +” to set the time
you require the food to be ready, with only the Auto symbol lit.
(Adjustment can be made by pressing the “ -“ button).
Step 5 Turn the oven control to the required temperature.
(The oven will now switch on later at the designated time, cook for the required period and switch off
automatically at the stop setting).
At the end of the cooking period the Auto symbol will flash and an intermittent bleeping sound will be heard.
This will continue for approximately 2 minutes unless the timer is reset within this period (See Step 7).
The oven will no longer operate until the timer has been reset to manual operation (See steps 6 & 7 on
the next page).

16
Timer Instructions
To set Timer to switch ON & Step 6 Turn off the oven control
OFF Automatically (Continued)
Step 7 Press the button to cancel the bleeping
(If 2 minutes has not elapsed)
Press button again to return to manual operation.
Other Notes On Timer 1. When cooking Automatically the cook period can be checked at
Operation any time simply by pressing the “ “ button.
2. When cooking Automatically the stop time can be checked at any
time simply by pressing the “ “ button. (This also can be
altered at any time by following Step 4 previously).
3. Having set a cooking period and stop time an electronic device stores the information. The device within
the timer will switch the oven on at the required start time.
4. If a mistake is made, alter the display to show 0.00 by pressing and holding the “ “and “-“ buttons.
Release and then press the “ “ button (See step 7 above).
Restart the programming sequence.
5. After an automatic sequence the bleeping sound can be switched off by pressing any of the following three
buttons.
However, the large oven cannot be operated until the timer has been set to manual. Press the button
(See Step 7 above).
6. If at any time the display shows three flashing zeros 0.00. It is likely
that the electricity supply to the oven has been interrupted. Reset
the timer to the correct time of day. If there is any food in the oven,
make sure that it has been cooked thoroughly before serving.
7. To give yourself more time to set each function press and hold the
required function button and at the same time press “ +“ or “ -“
button.
Note: Between the hours of 10.00 p.m. and 6.00 a.m. the intensity of the display reduces.

17
Timer Instructions
To Set the Minute Minder Step 1 Ensure the time of day is set correctly
Step 2 Press and release the “ “ button. Within 5 seconds
press and hold the “ +” button until the required time is set
(A bell symbol will light).
This can be adjusted by pressing the “ -“ button.
On releasing the buttons the timer will revert
back to the time of day.
At the end of the set time a bleeping sound will be heard and the bell
symbol will flash.
This can be cancelled by pressing the “ “.
Note: If necessary the Minute Minder can be cancelled before the tone
sounds by pressing the “ “ button and then press the “-“ button
until 0.00 appears in the display window.
Key Lock This timer is fitted with a locking function. This function overrides the
relays and allows operation of the timer without switching on the
elements. A “ “ key symbol will appear in the display when this
function is set.
NOTE: THE TIMED LARGE OVEN WILL NOT OPERATE IN THIS MODE.
If you require this safety feature, ensure timer is in manual mode and
cancel any active programs. Press and hold the “ “ and “ “
buttons simultaneously for approximately 8 seconds. The display will
read “On”. Release the two pressed buttons and immediately press the
“+” button. The display now reads “Of” and the key symbol appears.
After approx 5 seconds the time of day will show next to the key symbol.
THE KEY LOCK IS NOW ACTIVATED.
To return the timer to manual mode, repeat the setting procedure so
that “Of” is displayed. Press and release the “+” button so that “On” is
displayed and the key symbol has disappeared.
The timer will revert to the time of day after approximately 5 seconds.

18
Automatic Cooking (Large Oven)
Rules to follow when When planning your meal, remember that the oven control setting
cooking automatically refers to the center of the oven - it is warmer above and cooler below.
1. Food should be as cold as possible when it goes into the oven, ideally
straight from the refrigerator.
2. Frozen meat and poultry should be thawed thoroughly before it is put into
the oven.
3 The automatic timer should not be used in hot weather because of the
possible growth of food poisoning organisms.
4.NEVER use the automatic timer to re-heat Cook-Chill dishes.
5. Never leave food in the oven to cool slowly after cooking.
Serve immediately or refrigerate.
6. Dishes containing left over cooked meat or poultry, for example shepherds
pie, dishes containing eggs, cooked rice or seafood should not be cooked
automatically if there is to be a delay period.
7. Warm food should never be placed in the oven if there is to be a delay
period. Stews prepared by frying the meat and vegetables should be cooked
as soon as possible or refrigerated until loading the oven.
8. Try to set the stop time for a period beyond your anticipated return.
9. DO NOT leave food for an automatic program in a warm oven, i.e. one that
has just been used manually.
10. It is advisable to cover dishes where possible either with a lid or foil to
prevent the transfer of odours. If the food is to be served golden brown, it
may be uncovered or have the lid removed for a quick browning before
serving.
11. Dishes containing liquid should not be filled too full to prevent boiling over.
12. To prevent discoloration of certain fruit and vegetables such as apples,
pears, turnips and parsnips, a little lemon juice should be added to the
cooking liquid.
13. Potatoes should be par-boiled or brushed with fat to prevent discoloration
during delay time.
14. Wine or beer may ferment and cream may curdle during the delay period,
so it is best to add these ingredients just before serving.

19
Using The Hob
Description of The hob is made of enamelled mild steel and fitted with five gas
Hotplate Burners hotplate burners.
The left front hotplate burner (Rapide) is rated at 12.0MJ/h.
The left rear and right front hotplate burners (Semi – Rapide) are rated at 7.7MJ/h.
The centre hotplate burner (Wok – Triple Ring) is rated at 13.0MJ/h.
The right rear hotplate burner (Auxiliary) is rated at 4.1MJ/h.
Use of Hotplates Check that the electricity supply is switched on. Select the burner to be used.
Push in and turn the control knob anti-clockwise to the large flame symbol:-
Press the ignition button until the burner lights. Turn the control knob to the
required setting. A simmer position is achieved when the control knob is turned
fully anti-clockwise.
To turn off, turn the control knob fully clockwise to the ‘0’ symbol.
Under certain conditions a slight ‘popping’ noise can be heard from the
hotplates. This is perfectly normal and will not affect the performance of the
appliance.
Control Setting Guide There are four sizes of hotplate burners on the hob and all are easily
Hotplates adjusted to any rate of cooking required.
The chart given below is provided as a guide only and personal experience will
soon familiarise you with the correct burner and setting to use. This depends
on the size, thickness, material of saucepans and the quantity and type of
ingredients being cooked.
Cooking Chart
Burner Control Knob Position Uses Type of Food
SMALL FLAME
Simmering Stews of fish, poultry and meat
Milk puddings-steamed puddings.
Soups, scrambled egg, sauces.
Boiled joints of meat e.g. Ham, mutton, beef etc.
LARGE FLAME
Steady Boiling
Shallow Frying
Fast Boiling
Vegetables
Boiling jam after the sugar has been added
Burgers, Pancakes, omelettes, bacon, eggs and
raw fish.
Bringing vegetables to the boil, stir frying,
battered fruits, fish and pasta.

20
Using The Hob
Choosing Your Utensils Any type of flat based kettle or pan from 100mm (4in.) to 230mm (9in.) base
diameter may be used. Do not use pans which are unstable when placed on a
flat work-top. The use of split pans, i.e. those comprising two or more pans
designed to fit together over a single burner, is not recommended as these can
be unstable on the hotplate. Asbestos mats should not be used on the pan
supports because they may impede burner performance or damage the pan
support.
In order to get best value out of your hob, the following economy tip is
recommended. Choose the correct burner for the size of pan.
Pan Bridge Support A wire ‘Pan Bridge Support’ is supplied for use with the pan support above the
auxiliary burner. This allows a more stable support for the 100mm pan.
Energy Saving Tips 1 Do use saucepans with lids
2 Place pans centrally over burner.
3 Do not allow flames to lick up the sides of the pan.
4 Only fill kettles or pans with the amount of liquid needed.
5 Turn down the gas as soon as the contents of the pan boil.
6 Do not light the burner until the pan is in position and turn off before
removing the pan.
7 Cut vegetables into smaller pieces so that they cook quicker and cook more
than one vegetable in the same pan, e.g. carrots and potatoes.
8 In hard water areas descale kettles regularly.
9 Consider using a pressure cooker.
