Bematech BR800BT User manual

Advanced Handheld High-Speed Laser Scanner
1
BR800BT
User Manual

Wireless Handheld Gun Type Scanner
i
USER MANUAL
Important Notice
This User Manual is a description of the bar code scanners BR800BT and S-800BT,
including information regarding installation and operation.
No warranty of any kind is made in regard to this material, including, but not limited to,
implied warranties of merchantability or fitness for any particular purpose. We are not
liable for any errors contained herein nor for incidental or consequential damages in
connection with furnishing, performance or use of this material. We shall be under no
liability in respect of any defect arising from fair wear and tear, willful damage,
negligence, abnormal working conditions, failure to follow the instructions and warnings,
or misuse or alteration or repair of the products without written approval. No part of this
document may be reproduced, transmitted, stored in a retrieval system, transcribed, or
translated into any human or computer or other language in any form or by any means
electronic, mechanical, magnetic, optical, chemical, biological, manual or otherwise,
except for brief passages which may be quoted for purposes of scholastic or literary
review, without express written consent and authorization. We reserve the right to make
changes in product design without reservation and without notification. The material in
this guide is for information only and is subject to change without notice. All trademarks
mentioned herein, registered or otherwise, are the properties of their various, ill,
assorted owners.
General Handling Precautions
Do not dispose the scanner in fire.
Do not put the scanner directly in the sun or by any heat source.
Do not use or store the scanner in a very humid place.
Do not drop the scanner or allow it to collide violently with other objects.
Do not take the scanner apart without authorization
Copyright © 2014. All rights reserved.
Radio Notice
This equipment generates uses and can radiate radio frequency energy. If not installed
and used in accordance with the instructions in this manual, it may cause interference to
radio communications. The equipment has been tested and found to comply with the
limits for a Class A computing device pursuant to EN55022 and 47 CFR, Part 2 and Part 15
of the FCC rules. These specifications are designed to provide reasonable protection
against interference when operated in a commercial environment.
Radio and Television Interference

Wireless Handheld Gun Type Scanner
ii
USER MANUAL
Operation of this equipment in a residential area can cause interference to radio or
television reception. This can be determined by turning the equipment off and on.
The user is encouraged to try to correct the interference by one or more of the following
measures:
- Reorient the receiving antenna.
- Relocate the device with respect to the receiver.
- Move the device away from the receiver.
- Plug the device into a different outlet so that the device and the receiver are on
different branch circuits.
If necessary the user may consult the manufacturer, and authorized dealer, or
experienced radio/television technician for additional suggestions. The user may find
the following booklet prepared by the Federal Communications Commission helpful:
“How to Identify and Resolve Radio-TV Interference Problems.”This booklet is available
from the U.S. Government Printing Office, Washington, DC 20402 U.S.A., Stock No.
004000003454.
For CE-Countries
This scanner is in conformity with CE standards. Please note that an approved, CE-marked
power supply unit should be used in order to maintain CE conformance.
Power Supply
Use only the type of battery and the charging equipments that came with your
scanner.
Using any other type of battery and charging equipment may damage the scanner
and invalidate the warranty.
Do not short the battery terminals. The battery could overheat.
Do not attempt to split or peel the outer casing.
Remove the battery if the scanner is not going to be used for a long time. If the
battery is left unused for more than 3 months, you need to charge the battery
before use.

Wireless Handheld Gun Type Scanner
iii
USER MANUAL
Wireless Communication
Wireless technology operates 100M / 75M with communication cradle. Maximum communication range
may vary depending on obstacles (person, metal, wall, etc.) or electromagnetic environment.
The following conditions may affect the sensitivity of wireless communication.
There is an obstacle such as a person, metal, or wall between this unit and wireless device.
A device using 2.4 GHz frequency, such as a wireless LAN device, cordless telephone, or
microwave oven, is in use near this unit.
Because wireless devices and wireless LAN (IEEE802.11b/g) use the same frequency, microwave
interference may occur and resulting in communication speed deterioration, noise, or invalid connection
if this unit is used near a wireless LAN device. In such a case, perform the following.
Use this unit at least 10 m (about 30 ft) away from the wireless LAN device.
If this unit is used within 10 m (about 30 ft) of a wireless LAN device, turn off the wireless LAN
device.
Install this unit and wireless device as near to each other as possible.
Microwaves emitting from a wireless device may affect the operation of electronic medical devices. Turn
off this unit and other wireless devices in the following locations, as it may cause an accident.
Where inflammable gas is present, in a hospital, train, airplane, or a petrol station
Near automatic doors or a fire alarm
This unit supports security capabilities that comply with the wireless standard to provide a secure
connection when the wireless technology is used, but security may not be enough depending on the
setting. Be careful when communicating using wireless technology.
We do not take any responsibility for the leakage of information during wireless communication.
Connection with all wireless devices cannot be guaranteed.
A device featuring wireless function is required to conform to the wireless standard specified by
wireless SIG, and be authenticated.
Even if the connected device conforms to the above mentioned wireless standard, some devices
may not be connected or work correctly, depending on the features or specifications of the
device.
Depending on the device to be connected, it may require some time to start communication.
Tips to help improve your wireless network
1. Position the access point (host/cradle) in a relatively empty space at central location.
When possible, place the access point in a central location on the high ground (1m or above). If your access
point is against an outside wall, the signal will be weak on the other side of the room.
XBad host placement
OGood host placement

Wireless Handheld Gun Type Scanner
iv
USER MANUAL
2. Move the access point (host/cradle) off the floor and away from walls and metal objects (such as metal file
cabinets). Metal objects, walls, and floors will interfere with your wireless signals. The closer your access
point is to these obstructions, the more severe the interference, and the weaker your connection will be.
3. Reduce wireless interference.
The most common wireless technology, 802.11g (wireless-G), operates at a frequency of 2.4 gigahertz (GHz).
Many cordless phones, microwave ovens, hospital equipments, refrigerator, LED, and other wireless
electronics also use this frequency. If you use these wireless devices in your office, your device might not be
able to "hear" the signals over the noise coming from them.
If your network uses wireless-G, you can quiet the noise by avoiding wireless electronics that use the 2.4
GHz frequency. Instead, look for cordless phones and other devices that use the 5.8 GHz or 900 megahertz
(MHz) frequencies. Because 802.11n (wireless-N) operates at both 2.4 GHz and the less frequently used 5.0
GHz frequency, you may experience less interference on your network if you use this technology.
4. Update the firmware or driver of your wireless dongle.
If you are using a wireless dongle or other similar devices to make the connection, getting the latest
firmware or driver updates may improve the performance. Visit your manufacturer’s website for the
updates.
At least 1 m
Avoid possible wireless interference
XBad host placement
OGood host placement

Wireless Handheld Gun Type Scanner
v
USER MANUAL
Table of Contents
Important Notice ..............................................................................................i
General Handling Precautions ...........................................................................i
For CE-Countries..............................................................................................ii
Power Supply...................................................................................................ii
Wireless Communication ................................................................................iii
Introduction....................................................................................................................1
Product Overview....................................................................................................2
Scanner ...........................................................................................................2
Cradle (Optional) .............................................................................................2
Scanner and Accessories..........................................................................................3
Battery Installation ..................................................................................................4
Installing Cable Clip .................................................................................................5
Connecting the Cradle .............................................................................................7
Charging the Battery................................................................................................8
Power on the Scanner..............................................................................................9
How to Scan ..........................................................................................................10
Radio Communication Host Type ...........................................................................11
Cradle Host Mode..........................................................................................11
SPP Mater/SPP Slave Mode............................................................................11
HID Mode......................................................................................................11
Paging the Scanner................................................................................................12
Scanner USB online to Host ...................................................................................12
USB Online Mode ..........................................................................................12
Visible Indicators ...................................................................................................12
Scanner .........................................................................................................12
Cradle............................................................................................................13
Sound Indicators....................................................................................................14
ACK/NAK Protocol or Frame Packing ......................................................................14
Scanner to Remote Application..............................................................................16
Pin-out Configuration ............................................................................................18
Cable Pin-out.........................................................................................................19
Programming Guide ......................................................................................................20
Connecting to a Host .............................................................................................24
Cradle Host Mode..........................................................................................25
Wireless Mode...............................................................................................26
Data Transnit Method ....................................................................................31
System Function Settings.......................................................................................34
Data Editing ...................................................................................................81
Appendix 1: USB Virtual COM Driver Installation ............................................89
Appendix 2: Barcode Length Setting ...............................................................90

Wireless Handheld Gun Type Scanner
1
USER MANUAL
Introduction
This scanner is a gun type rugged wireless CCD/Laser barcode scanner with a state of
the art scan engine. Featuring a superb scanning speed and able to withstand 1.5
meter drop, it is ideal for manufacturing and logistics sectors.
The cradle, a dongle, or devices with wireless technology can be the host of this
scanner. All scanned data are instantly transferred to the connected host in a 100-
meter connection range in open space or 75-meter range in indoor environments (the
actual communication range may vary due to different indoor placement). This feature
eliminates hazardous cables and creates a safer work environment.
Either scanning in the handheld or hands-free mode, this scanner always offers a high-
accuracy and reliable scanning ability. This scanner would be your trusted tool
scanning partner.
Key Features:
Superb scanning ability
Proprietary hardware decoding technology
100M long-range wireless connection
Rugged and ergonomic form factor
Flexible communications

Wireless Handheld Gun Type Scanner
2
USER MANUAL
Metal Charging
Contacts
Product Overview
Scanner
Cradle (Optional)
Function
Trigger/LED
indicator
Charging
Contacts
Host
Connector
DC Power
Connector
LED Indicator
Buzzer
Trigger
Cable Connector
Exit Window
Strap Hole
Bluetooth
Address Label
