Bematech S303D Operating instructions

Advanced Handheld High-Speed Laser Scanner

2D Imaging

Barcode Scanner

Programming Guide

S303D

S303D 2D Imaging Barcode Scanner

PROGRAMMING GUIDE

Important Notice

No warranty of any kind is made in regard to this material, including, but not limited to,

implied warranties of merchantability or fitness for any particular purpose. We are not

liable for any errors contained herein nor for incidental or consequential damages in

connection with furnishing, performance or use of this material. We shall be under no

liability in respect of any defect arising from fair wear and tear, willful damage,

negligence, abnormal working conditions, failure to follow the instructions and warnings,

or misuse or alteration or repair of the products without written approval. No part of this

document may be reproduced, transmitted, stored in a retrieval system, transcribed, or

translated into any human or computer or other language in any form or by any means

electronic, mechanical, magnetic, optical, chemical, biological, manual or otherwise,

except for brief passages which may be quoted for purposes of scholastic or literary

review, without express written consent and authorization. We reserve the right to make

changes in product design without reservation and without notification. The material in

this guide is for information only and is subject to change without notice. All trademarks

mentioned herein, registered or otherwise, are the properties of their various, ill,

assorted owners.

General Handling Precautions

Do not dispose the scanner in fire.

Do not put the scanner directly in the sun or by any heat source.

Do not use or store the scanner in a very humid place.

Do not drop the scanner or allow it to collide violently with other objects.

Do not take the scanner apart without authorization

Guidance for Printing

This manual is in A5 size. Please double check your printer setting before printing it out.

When the barcodes are to be printed out for programming, the use of a high-resolution

laser printer is strongly suggested for the best scan result.

Firmware Notice

To use all functions in this guide please update to the latest firmware.

Advanced 2D Image Scanner

PROGRAMMING GUIDE
