Bematech I-150 Operating instructions

Advanced Handheld High-Speed Laser Scanner
1
Linear Imaging
Barcode Scanner
Programming Guide
I-150

I-150 Imaging Barcode Scanner
i
I-150 PROGRAMMING GUIDE
Important Notice
No warranty of any kind is made in regard to this material, including, but not limited to,
implied warranties of merchantability or fitness for any particular purpose. We are not
liable for any errors contained herein nor for incidental or consequential damages in
connection with furnishing, performance or use of this material. We shall be under no
liability in respect of any defect arising from fair wear and tear, willful damage,
negligence, abnormal working conditions, failure to follow the instructions and warnings,
or misuse or alteration or repair of the products without written approval. No part of this
document may be reproduced, transmitted, stored in a retrieval system, transcribed, or
translated into any human or computer or other language in any form or by any means
electronic, mechanical, magnetic, optical, chemical, biological, manual or otherwise,
except for brief passages which may be quoted for purposes of scholastic or literary
review, without express written consent and authorization. We reserve the right to make
changes in product design without reservation and without notification. The material in
this guide is for information only and is subject to change without notice. All trademarks
mentioned herein, registered or otherwise, are the properties of their various, ill,
assorted owners.
General Handling Precautions
Do not dispose the scanner in fire.
Do not put the scanner directly in the sun or by any heat source.
Do not use or store the scanner in a very humid place.
Do not drop the scanner or allow it to collide violently with other objects.
Do not take the scanner apart without authorization
Guidance for Printing
This manual is in A5 size. Please double check your printer setting before printing it out.
When the barcodes are to be printed out for programming, the use of a high-resolution
laser printer is strongly suggested for the best scan result.
Copyright © 2018. All rights reserved.

I-150 Imaging Barcode Scanner
ii
I-150 PROGRAMMING GUIDE
Table of Contents
Important Notice ................................................................................... i
General Handling Precautions ............................................................................................ i
Guidance for Printing.......................................................................................................... i
Using the Scanner ................................................................................. 1
Settings and Programming .................................................................... 2
Programming operation steps ...........................................................................................2
1. System Settings...................................................................................................3
Show Version .....................................................................................................................3
Set Factory Default ............................................................................................................3
2. System Configurations ........................................................................................4
2.1 Interface Selection...............................................................................................4
2.2 Keyboard Language .............................................................................................5
2.3 Message Terminator............................................................................................6
2.4 Scanner Operation Mode ....................................................................................7
2.5 Buzzer Setup........................................................................................................8
3. Barcode Symbologies Configuration....................................................................9
3.1 UPC-A ..................................................................................................................9
3.2 UPC-E................................................................................................................... 9
3.3 EAN-13............................................................................................................... 10
3.4 EAN-8.................................................................................................................10
3.5 Code 39 ............................................................................................................. 10
3.6 Codabar .............................................................................................................11
3.7 Code 93 ............................................................................................................. 11
3.8 Code 128 ...........................................................................................................11
3.9 Interleaved 2 of 5............................................................................................... 11
3.10 Industrial 2 of 5 .................................................................................................12
3.11 Matrix 2 of 5 ......................................................................................................12
3.12 MSI / Plessey .....................................................................................................12
3.13 Code 32 ............................................................................................................. 13
3.14 Code 11 ............................................................................................................. 13

Start Configuration
End Configuration
1
I-150 PROGRAMMING GUIDE
Using the Scanner
1. Ensure that the scanner is connected to the host computer correctly.
2. Hold down the trigger button to activate the red aiming line and the white
illumination pattern. The illumination pattern is used to illuminate the barcode. The
aiming line is used to aim at the barcode and help to find the best reading distance.
Keep red aiming line in the center of a bar code.
3. On a successful scan, there’ll be a beep sound, illumination & aiming pattern will turn
off. The scanner then transmits barcode message to the host computer.
NOTE: After scanning the same barcode a few times, it will be able to find a certain
scanning distance range with higher successful reading rate. This range is the optimum
reading distance.

Start Configuration
End Configuration
2
I-150 PROGRAMMING GUIDE
Settings and Programming
Scan selected barcodes in this manual to perform setup and programming of the
handheld imaging barcode scanner. Decoding options and interface protocols can be
tailored to a specific application.
Setup parameters are stored in non-volatile memory in the scanner and are retained
even when power is off. Setup parameters change only when you reset them. You may
need to hide adjacent code patches with your hand when scanning.
Programming operation steps
To program each scanner parameter, scan the setup barcodes in the following sequence.
1. Scan "Start Configuration" barcode to initiate set up.
2. Scan the barcodes for desired configuration.
3. Scan "End Configuration" barcode to confirm the setup.

Start Configuration
End Configuration
3
I-150 PROGRAMMING GUIDE
1. System Settings
Show Version
Scan this barcode to display firmware version.
Read device firmware version
Set Factory Default
Scan this barcode to return all parameters to the factory default values.
Factory default settings

Start Configuration
End Configuration
4
I-150 PROGRAMMING GUIDE
2. System Configurations
2.1 Interface Selection
<USB Keyboard>
USB_COM

Start Configuration
End Configuration
5
I-150 PROGRAMMING GUIDE
2.2 Keyboard Language
<U.S.A>
Italian
Spanish
French
Germany
Turkey
Portugal
Brazil
Hungary
Global Mode

Start Configuration
End Configuration
6
I-150 PROGRAMMING GUIDE
2.3 Message Terminator
None
<CR>
Tab
ESC

Start Configuration
End Configuration
7
I-150 PROGRAMMING GUIDE
2.4 Scanner Operation Mode
<Trigger On/Off>
Trigger On/Good read off
Continuous/Trigger Off
Presentation Mode
