Bend-Pak MDS-6EXT User manual

BendPak, Inc. Corporate Oce
1645 Lemonwood Drive
Santa Paula, CA 93060 USA
Toll Free US/Canada: 1-800-253-2363
Fax: [phone]
[email protected]om
Customer Service Desk / Warranty
Customer Service Representatives
Oce Tel: [phone]
Toll Free US/Canada: 1-800-253-2363
Fax: [phone]
customerservic[email protected]
Parts Orders
Customer Service Representatives
Oce Tel: [phone]
Toll Free US/Canada: 1-800-253-2363
Fax: [phone]
[email protected]om
Domestic Sales & Service
USA Sales Representatives
Oce Tel: [phone]
Toll Free US/Canada: 1-800-253-2363
Fax: [phone]
[email protected]om
International Sales & Service
Oce Tel: [phone]
Exports Dept: 1-805-933-9970 EXT. 192
Ext. Toll Free US/Canada: 1-800-253-2363
Fax: [phone]
bpkex[email protected]om
Service Manual
SERVICE PARTS & DIAGRAMS
This guide is a troubleshooting reference used for maintaining and
servicing your Bend Pak product. It provides comprehensive information
on identifying serviceable parts and components and assists in
troubleshooting problems and performing assembly /disassembly
procedures.
BENDPAK
MDS-6EXT
PRODUCT SKU
5175192
DRAWING Nº
5260675
CATEGORY
Mid-Rise Scissor Li
REV
Version A
DATE
04.28.2022

DIMENSIONS ARE IN MM
☺
6
5
1
3
2
4
ITEM
NO
PART
NUMBER
DESCRIPTION QTY REV
1 5245045 XPR-10AXLS LIFT SUPERSTRUCTURE 1 L
2 5250236 XPR-10AXLS EXTENDED PARTS BOX 1 F
3 5215278 XPR-10AS-LP LONG ARM ASSEMBLY, R.H. 1 L
4 5215277 XPR-10AS-LP LONG ARM ASSEMBLY, L.H. 1 L
5 5215276 XPR-10AS-LP SHORT ARM ASSEMBLY 2 L
6 5210269 XPR-10 POST EXTENSION WELDMENT 2 E
- 5905109 WARNING ALI/WL 101 1 A
- 5905131 2 POST DECAL KIT, LESS ALI 1 E
- 5905403 MAX CAPACITY 10K DANGER LABEL, ENGLISH-FRENCH 1 D
- 5905465 MANUFACTURER LABEL 1 C
- 5905940 PRODUCT DATA LABEL 1 C
- 5905951 SERIAL TAG B 1 B
- 5905653 LABEL; ALI-ALCTV-2017 GOLD LABEL, US; MET LABS 1 A
- 5905414 GP/XPR LOCK-RELEASE LABEL 1 B
- 5905285 SERIALTAG EXTERIOR PEEL OFF INVENTORY LABEL 1 A
- 5905655 MAX CAPACITY NTRL 10K LABEL, ENGLISH-FRENCH 1 C
- 5905377 NOTICE LABEL, ALI/WLSIA01 1 A
REVISION
REV DESCRIPTION DATE EDITED BY ECO#
H UPDATED BOM REVISION 11/03/2020 TM 01226
J UPDATED BOM REVISION 03/29/2021 TM 01291
K UPDATED BOM REVISION 06/23/2021 TM 01310
SHEET 1 OF 3
REV
DWG. NO.
A
SIZE
TITLE:
NAME
DATE
CHECKED
DRAWN
K
1645 LEMONWOOD DR.
SANTA PAULA, CA 93060
PROPRIETARY AND CONFIDENTIAL
THE INFORMATION CONTAINED IN THIS DRAWING IS
THE SOLE PROPERTY OF BENDPAK INC. ANY
REPRODUCTION IN PART OR AS A WHOLE WITHOUT
THE WRITTEN PERMISSION OF BENDPAK INC. IS
PROHIBITED.
NOTE: UNLESS OTHERWISE SPECIFIED .
TM
5260245
XPR-10AXLS-181-LP
PRODUCTION LIFT VER F
09/28/2018
DO NOT SCALE DRAWING
1:35
SCALE:
THIRD ANGLE PROJECTION
OR 07/07/2021
REFER TO MODEL FOR ADDITIONAL INFORMATION 1.
SEE SHIPPING INSTRUCTIONS FOR FINAL PACKAGING 2.

2700.0- 2903 mm
[106.299-114.280in]
4589.0mm
180.669in
[5.295-80.295in]
134.5-2039.5mm
[9.941-84.941in]
252.5-2157.5mm
WITH 63mm [2.5in] ADAPTER
AND MAX ADJUSTMENT
[133.307-141.343in]
3386.0-3590.1mm
B B
2382.0- 2585.0 mm
DRIVE THRU
[93.780-101.772in]
3480.0- 3683.9 mm
[137.008-145.035in]
[23.835-38.315in]
605.4-973.2mm
[34.882-54.134in]
886-1375mm
SECTION B-B
SCALE 1 : 35
SHEET 2 OF 3
REV
DWG. NO.
A
SIZE
TITLE:
K
1645 LEMONWOOD DR.
SANTA PAULA, CA 93060
5260245
XPR-10AXLS-181-LP
PRODUCTION LIFT VER F
1:45
SCALE:

DIMENSIONS ARE IN MM
☺
3
2
1
ISOMETRIC VIEW
FOR REFERENCE ONLY
DO NOT SCALE
NEXT ASSEMBLY
5260120
5260234
5260244
5260245
ITEM NO PART NUMBER DESCRIPTION QTY REV
1 5215442 XPR-10XLS/AXLS POWER SIDE POST ASSEMBLY 1 K
2 5215440 XPR-10XLS/AXLS OFF SIDE POST ASSEMBLY 1 K
3 5210211 XPR-10A TOP TROUGH ASSEMBLY 1 D
REVISION
REV DESCRIPTION DATE EDITED BY ECO#
J UPDATED BOM REVISION 02/21/2020 TM 01107
K UPDATED BOM REVISION 11/03/2020 TM 01226
L UPDATED BOM REVISION 03/29/2021 TM 01291
WHERE USED
XPR-10AXLS
XPR-10AXLS-181
XPR-10AXLS-LP
XPR-10AXLS-181-LP
SHEET 1 OF 1
REV
DWG. NO.
A
SIZE
TITLE:
NAME
DATE
CHECKED
DRAWN
L
1645 LEMONWOOD DR.
SANTA PAULA, CA 93060
PROPRIETARY AND CONFIDENTIAL
THE INFORMATION CONTAINED IN THIS DRAWING IS
THE SOLE PROPERTY OF BENDPAK INC. ANY
REPRODUCTION IN PART OR AS A WHOLE WITHOUT
THE WRITTEN PERMISSION OF BENDPAK INC. IS
PROHIBITED.
NOTE: UNLESS OTHERWISE SPECIFIED .
HG
5245045
XPR-10AXLS LIFT
SUPERSTRUCTURE
10/07/2015
DO NOT SCALE DRAWING
1:35
SCALE:
THIRD ANGLE PROJECTION
OR 03/31/2021
REFER TO MODEL FOR ADDITIONAL INFORMATION 1.
SEE SHIPPING INSTRUCTIONS FOR FINAL PACKAGING 2.
ASSEMBLE ITEMS AS SHOWN 3.

DIMENSIONS ARE IN MM
☺
E
1
2
3
8
9
10
11
ISOMETRIC VIEW
FOR REFERENCE ONLY
DO NOT SCALE
DETAIL E
SCALE 2 : 5
6
5
4
7
ITEM NO PART NUMBER DESCRIPTION QTY REV
1 5600922 XPR-10XLS/AXLS OFF SIDE POST WELDMENT 1 G
2 5575111 XPR-9S/10 SHEAVE ASSEMBLY 1 G
3 5620141 XPR-9/10 CABLE SHEAVE PIN WELDMENT 1 F
4 5575112 D2/GP/PCL/0XPR/PL-7000 SAFETY SHEAVE 1 C
5 5565350
D2/GP/PCL/XPR/PL-7000 SAFETY SHEAVE
SPACER
1 C
6 5535357 NUT M6 x 1.0 NL 1 -
7 5530756 HHB M6 x 1 x 25 1 -
8 5530030 HHB M6 x 1 x 8 1 -
9 5215441 XPR-10XLS/AXLS LIFT HEAD ASSEMBLY 1 G
10 5502013 CYLINDER ASSEMBLY Ø2.0 X 75" 1 D
11 5701242 CYLINDER CLAMP ASSY 1 -
REVISION
REV DESCRIPTION DATE EDITED BY ECO#
H UPDATED BOM REVISION 05/14/2019 TS 01086
J UPDATED BOM REVISION 02/21/2020 TM 01107
K UPDATED BOM REVISION 11/03/2020 TM 01226
NEXT ASSEMBLY
5245045
5245049
WHERE USED
XPR-10XLS SERIES
XPR-10AXLS SERIES
SHEET 1 OF 1
REV
DWG. NO.
A
SIZE
TITLE:
NAME
DATE
CHECKED
DRAWN
K
1645 LEMONWOOD DR.
SANTA PAULA, CA 93060
PROPRIETARY AND CONFIDENTIAL
THE INFORMATION CONTAINED IN THIS DRAWING IS
THE SOLE PROPERTY OF BENDPAK INC. ANY
REPRODUCTION IN PART OR AS A WHOLE WITHOUT
THE WRITTEN PERMISSION OF BENDPAK INC. IS
PROHIBITED.
NOTE: UNLESS OTHERWISE SPECIFIED .
HG
5215440
XPR-10XLS/AXLS OFF
SIDE POST ASSEMBLY
10/08/2015
DO NOT SCALE DRAWING
1:25
SCALE:
THIRD ANGLE PROJECTION
OR
11/04/2020
REFER TO MODEL FOR ADDITIONAL INFORMATION 1.
SEE SHIPPING INSTRUCTIONS FOR FINAL PACKAGING 2.
ASSEMBLE ITEMS AS SHOWN 3.

DIMENSIONS ARE IN MM
☺
2
1
7
6
4
8
3
5
9
100.0
NEXT ASSEMBLY
5215440
5215442
ITEM NO PART NUMBER DESCRIPTION QTY REV
1 5601040 XPR-10XLS/AXLS LIFT HEAD WELDMENT 1 D
2 5716001 2 POST GUIDE BLOCK 8 G
3 5746098 GP/XPR-9/10 Ø25mm GEAR SHAFT 2 F
4 5701052 GP/XPR ARM INTERNAL GEAR STOP 2 F
5 5540133 GP-7, XPR-9/10 LIFT HEAD SPRING 2 D
6 5505106 SPRING PIN M6 x 50 2 -
7 5540006 SNAP RING TRUARC 5103-100 2 -
8 5580219 KEYRING 56mm x 3mm 2 -
9 5930183 XPR-9/10 LIFT HEAD GUSSET COVER 1 E
REVISION
REV DESCRIPTION DATE EDITED BY ECO#
E
UPDATED TITLE TO REFLECT WHERE USED,
UPDATED BOM REVISIONS
05/11/2018 TM 00946
F UPDATED BOM REVISION 05/14/2019 TS 01086
G UPDATED BOM REVISION 02/21/2020 TM 01107
WHERE USED
XPR-10XLS SERIES
XPR-10AXL SERIES
SHEET 1 OF 1
REV
DWG. NO.
A
SIZE
TITLE:
NAME
DATE
CHECKED
DRAWN
G
1645 LEMONWOOD DR.
SANTA PAULA, CA 93060
PROPRIETARY AND CONFIDENTIAL
THE INFORMATION CONTAINED IN THIS DRAWING IS
THE SOLE PROPERTY OF BENDPAK INC. ANY
REPRODUCTION IN PART OR AS A WHOLE WITHOUT
THE WRITTEN PERMISSION OF BENDPAK INC. IS
PROHIBITED.
NOTE: UNLESS OTHERWISE SPECIFIED .
HG
5215441
XPR-10XLS/AXLS LIFT
HEAD ASSEMBLY
10/09/2015
DO NOT SCALE DRAWING
1:12
SCALE:
THIRD ANGLE PROJECTION
OR 04/15/2020
REFER TO MODEL FOR ADDITIONAL INFORMATION 1.
SEE SHIPPING INSTRUCTIONS FOR FINAL PACKAGING 2.
ASSEMBLE ITEMS AS SHOWN 3.

DIMENSIONS ARE IN MM
☺
C
1
2
3
8
10
11
12
ISOMETRIC VIEW
FOR REFERENCE ONLY
DO NOT SCALE
DETAIL C
SCALE 1 : 5
9
6
5
4
7
NEXT ASSEMBLY
5245045
5245049
ITEM NO PART NUMBER DESCRIPTION QTY REV
1 5601041 XPR-10XLS/AXLS POWER SIDE POST WELDMENT 1 F
2 5575111 XPR-9S/10 SHEAVE ASSEMBLY 1 G
3 5620141 XPR-9/10 CABLE SHEAVE PIN WELDMENT 1 F
4 5575112 D2/GP/PCL/0XPR/PL-7000 SAFETY SHEAVE 1 C
5 5565350
D2/GP/PCL/XPR/PL-7000 SAFETY SHEAVE
SPACER
1 C
6 5535357 NUT M6 x 1.0 NL 1 -
7 5530756 HHB M6 x 1 x 25 1 -
8 5530030 HHB M6 x 1 x 8 1 -
9 5520001 RUBBER GROMMET, 3/4 I.D. 1 -
10 5215441 XPR-10XLS/AXLS LIFT HEAD ASSEMBLY 1 G
11 5502013 CYLINDER ASSEMBLY Ø2.0 X 75" 1 D
12 5701242 CYLINDER CLAMP ASSY 1 -
REVISION
REV DESCRIPTION DATE EDITED BY ECO#
H UPDATED BOM REVISION 05/14/2019 TS 01086
J UPDATED BOM REVISION 02/21/2020 TM 01107
K UPDATED BOM REVISION 11/03/2020 TM 01226
WHERE USED
XPR-10XLS SERIES
XPR-10AXLS SERIES
SHEET 1 OF 1
REV
DWG. NO.
A
SIZE
TITLE:
NAME
DATE
CHECKED
DRAWN
K
1645 LEMONWOOD DR.
SANTA PAULA, CA 93060
PROPRIETARY AND CONFIDENTIAL
THE INFORMATION CONTAINED IN THIS DRAWING IS
THE SOLE PROPERTY OF BENDPAK INC. ANY
REPRODUCTION IN PART OR AS A WHOLE WITHOUT
THE WRITTEN PERMISSION OF BENDPAK INC. IS
PROHIBITED.
NOTE: UNLESS OTHERWISE SPECIFIED .
HG
5215442
XPR-10XLS/AXLS POWER
SIDE POST ASSEMBLY
10/08/2015
DO NOT SCALE DRAWING
1:25
SCALE:
THIRD ANGLE PROJECTION
OR 11/04/2020
REFER TO MODEL FOR ADDITIONAL INFORMATION 1.
SEE SHIPPING INSTRUCTIONS FOR FINAL PACKAGING 2.
ASSEMBLE ITEMS AS SHOWN 3.

DIMENSIONS ARE IN MM
☺
A
2
12
15
18
13
6
11
4
1
5
3
8
17
19
7
DETAIL A
SCALE 1 : 6
9
16
10
14
ISOMETRIC VIEW
FOR REFERENCE ONLY
DO NOT SCALE
ITEM
NO
PART NUMBER DESCRIPTION QTY REV
1 5600926 XPR-10A INNER TOP TROUGH WELDMENT 1 C
2 5600925 XPR-10A OUTER TOP TROUGH WELDMENT 1 C
3 5565350 D2/GP/PCL/XPR/PL-7000 SAFETY SHEAVE SPACER 2 C
4 5575112 D2/GP/PCL/0XPR/PL-7000 SAFETY SHEAVE 2 C
5 5575111 D2-8F, XPR-9/10 SHEAVE ASSEMBLY 4 G
6 5620141 XPR-9/10 CABLE SHEAVE PIN WELDMENT 4 F
7 5530030 HHB M6 x 1 x 8 4 -
8 5530756 HHB M6 x 1 x 25 2 -
9 5530738 HHB M10 x 1.5 x 25 6 -
10 5535013 NUT M10 x 1.5 NL 2 -
11 5535357 NUT M6 x 1.0 NL 2 -
12 5545341 WASHER M10 x Ø20 FLAT 6 -
13 5580211 STEEL HOLE PLUG 1 1/4" 1 -
14 5620445 XPR TRIP STOP BAR SLIDER WELDMENT 1 C
15 5300815 10AP/D2/XPR STOP BAR CUSHION 1 D
16 5530055 SSS M6x1x10 2 -
17 5545200 WASHER M10 x Ø18 SL 4 -
18 5535998 NUT M10 x 1.5 4 -
19 5600501 XPR-10/10A MICROSWITCH STOP BAR WELDMENT 1 B
NEXT ASSEMBLY
5245044
5245045
REVISION
REV DESCRIPTION DATE EDITED BY ECO#
B
UPDATED TITLE TO REFLECT MARKETING,
UPDATED BOM REVISION
11/23/2015 TM 00738
C UPDATED BOM REVISION 11/02/2017 TM 00900
D UPDATED BOM REVISION 03/29/2021 TM 01291
WHERE USED
XPR-10A
SERIES
SHEET 1 OF 2
REV
DWG. NO.
A
SIZE
TITLE:
NAME
DATE
CHECKED
DRAWN
D
1645 LEMONWOOD DR.
SANTA PAULA, CA 93060
PROPRIETARY AND CONFIDENTIAL
THE INFORMATION CONTAINED IN THIS DRAWING IS
THE SOLE PROPERTY OF BENDPAK INC. ANY
REPRODUCTION IN PART OR AS A WHOLE WITHOUT
THE WRITTEN PERMISSION OF BENDPAK INC. IS
PROHIBITED.
NOTE: UNLESS OTHERWISE SPECIFIED .
TM
5210211
XPR-10A TOP TROUGH
ASSEMBLY
10/07/2014
DO NOT SCALE DRAWING
1:18
SCALE:
THIRD ANGLE PROJECTION
OR 03/31/2021
SEE SHIPPING INSTRUCTIONS FOR FINAL PACKAGING 1.
ASSEMBLE ITEMS AS SHOWN 2.

3368
3571
EXTENDED
COLLAPSED
SHEET 2 OF 2
REV
DWG. NO.
A
SIZE
TITLE:
D
1645 LEMONWOOD DR.
SANTA PAULA, CA 93060
5210211
XPR-10A TOP
TROUGH ASSEMBLY
1:15
SCALE:

DIMENSIONS ARE IN MM
☺
1
2
3
4
ITEM NO PART NUMBER DESCRIPTION QTY REV
1 5600989 XPR-10S-LP SHORT ARM WELDMENT 1 L
2 5545341 WASHER M10 x Ø20 FLAT 3 -
3 5545200 WASHER M10 x Ø18 SL 3 -
4 5530302 HHB M10 x 1.5 x 40 FULLY THREAD 3 -
REVISION
REV DESCRIPTION DATE EDITED BY ECO#
J UPDATED BOM REVISION 04/02/2018 TM 00930
K UPDATED BOM REVISION 05/30/2018 TM 00953
L UPDATED BOM REVISION 02/20/2020 TM 01107
NEXT ASSEMBLY
5260444
5260445
5260559
5260560
WHERE USED
XPR-10AS-168-LP
XPR-10AS-LP
XPR-10AXLS-181-LP
XPR-10AXLS-LP
SHEET 1 OF 1
REV
DWG. NO.
A
SIZE
TITLE:
NAME
DATE
CHECKED
DRAWN
L
1645 LEMONWOOD DR.
SANTA PAULA, CA 93060
PROPRIETARY AND CONFIDENTIAL
THE INFORMATION CONTAINED IN THIS DRAWING IS
THE SOLE PROPERTY OF BENDPAK INC. ANY
REPRODUCTION IN PART OR AS A WHOLE WITHOUT
THE WRITTEN PERMISSION OF BENDPAK INC. IS
PROHIBITED.
NOTE: UNLESS OTHERWISE SPECIFIED .
JM
5215276
XPR-10AS-LP SHORT
ARM ASSEMBLY
06/22/2015
DO NOT SCALE DRAWING
1:5
SCALE:
THIRD ANGLE PROJECTION
OR 04/15/2020
REFER TO MODEL FOR ADDITIONAL INFORMATION 1.
SEE SHIPPING INSTRUCTIONS FOR FINAL PACKAGING 2.
ASSEMBLE ITEMS AS SHOWN 3.

DIMENSIONS ARE IN MM
☺
1
2
3
4
ITEM NO PART NUMBER DESCRIPTION QTY REV
1 5600981 XPR-10AS-LP LONG ARM WELDMENT, L.H. 1 L
2 5545341 WASHER M10 x Ø20 FLAT 3 -
3 5545200 WASHER M10 x Ø18 SL 3 -
4 5530302 HHB M10 x 1.5 x 40 FULLY THREAD 3 -
REVISION
REV DESCRIPTION DATE EDITED BY ECO#
J UPDATED BOM REVISION 03/30/2018 TM 00930
K UPDATED BOM REVISION 05/30/2018 TM 00953
L UPDATED BOM REVISION 02/20/2020 TM 01107
NEXT ASSEMBLY
5260244
5260245
5260559
5260560
WHERE USED
XPR-10AS-168-LP
XPR-10AS-LP
XPR-10AXLS-181-LP
XPR-10AXLS-LP
SHEET 1 OF 1
REV
DWG. NO.
A
SIZE
TITLE:
NAME
DATE
CHECKED
DRAWN
L
1645 LEMONWOOD DR.
SANTA PAULA, CA 93060
PROPRIETARY AND CONFIDENTIAL
THE INFORMATION CONTAINED IN THIS DRAWING IS
THE SOLE PROPERTY OF BENDPAK INC. ANY
REPRODUCTION IN PART OR AS A WHOLE WITHOUT
THE WRITTEN PERMISSION OF BENDPAK INC. IS
PROHIBITED.
NOTE: UNLESS OTHERWISE SPECIFIED .
JM
5215277
XPR-10AS-LP LONG ARM
ASSEMBLY, L.H.
06/22/2015
DO NOT SCALE DRAWING
1:5
SCALE:
THIRD ANGLE PROJECTION
OR 04/15/2020
REFER TO MODEL FOR ADDITIONAL INFORMATION 1.
SEE SHIPPING INSTRUCTIONS FOR FINAL PACKAGING 2.
ASSEMBLE ITEMS AS SHOWN 3.

DIMENSIONS ARE IN MM
☺
1
2
3
4
ITEM NO PART NUMBER DESCRIPTION QTY REV
1 5600990 XPR-10AS-LP LONG ARM WELDMENT, R.H. 1 L
2 5545341 WASHER M10 x Ø20 FLAT 3 -
3 5545200 WASHER M10 x Ø18 SL 3 -
4 5530302 HHB M10 x 1.5 x 40 FULLY THREAD 3 -
NEXT ASSEMBLY
5260244
5260245
5260559
5260560
REVISION
REV DESCRIPTION DATE EDITED BY ECO#
J UPDATED BOM REVISION 04/02/2018 TM 00930
K UPDATED BOM REVISION 05/30/2018 TM 00953
L UPDATED BOM REVISION 02/20/2020 TM 01107
WHERE USED
XPR-10AS-168-LP
XPR-10AS-LP
XPR-10AXLS-181-LP
XPR-10AXLS-LP
SHEET 1 OF 1
REV
DWG. NO.
A
SIZE
TITLE:
NAME
DATE
CHECKED
DRAWN
L
1645 LEMONWOOD DR.
SANTA PAULA, CA 93060
PROPRIETARY AND CONFIDENTIAL
THE INFORMATION CONTAINED IN THIS DRAWING IS
THE SOLE PROPERTY OF BENDPAK INC. ANY
REPRODUCTION IN PART OR AS A WHOLE WITHOUT
THE WRITTEN PERMISSION OF BENDPAK INC. IS
PROHIBITED.
NOTE: UNLESS OTHERWISE SPECIFIED .
JM
5215278
XPR-10AS-LP LONG ARM
ASSEMBLY, R.H.
06/22/2015
DO NOT SCALE DRAWING
1:5
SCALE:
THIRD ANGLE PROJECTION
OR
04/15/2020
REFER TO MODEL FOR ADDITIONAL INFORMATION 1.
SEE SHIPPING INSTRUCTIONS FOR FINAL PACKAGING 2.
ASSEMBLE ITEMS AS SHOWN 3.

DIMENSIONS ARE IN MM
☺
NEXT ASSEMBLY
5260234
5260245
ITEM
NO
PART
NUMBER
DESCRIPTION QTY REV
1 5174218 XPR CLEARFLOOR EXTENDED PARTS BAG 1 N
2 5505116 D2-8F, XPR-9/10 LIFT HEAD PIN WELDMENT 4 D
3 5595556 CABLE ASSEMBLY Ø10 x 11675mm DBST 1 B
4 5595557 CABLE ASSEMBLY Ø10 x 11791mm DBST 1 B
5 5570065 HYDRAULIC HOSE ASSEMBLY Ø6.35 x 203mm DS 1 D
6 5570075 HYDRAULIC HOSE ASSEMBLY Ø6.35 x 2451mm SB 1 D
7 5570076 HYDRAULIC HOSE ASSEMBLY Ø10 x 1371mm SB 1 D
8 5595553
XPR-10XLS/10AXLS EXTENDED Ø2.4 x 9296mm
SAFETY CABLE
1 A
9 5570097 HYDRAULIC HOSE ASSEMBLY Ø6.35 x 9766mm SB 1 B
10 5210196 D2/XPR POWER SIDE INCLINED SAFETY ASSEMBLY 1 C
11 5210010 D2/XPR OFF SIDE SAFETY WELDMENT 1 F
12 5715003 POWER UNIT VIBRATION DAMPENER 1 B
13 5215704 ROUND ADJUSTABLE LIFT PAD ASSEMBLY 4 H
14 5701631 XPR-10 POST ASSEMBLY LIFT HEAD FOOT GUARD 2 B
15 5736604
TWO POST LIGHT DUTY BOLT ON ARM RESTRAINT GEAR
4 E
16 5716173
D2-8/12/15, GP/XPR POWER SIDE PLASTIC SAFETY COVER
1 B
17 5716174
D2-8/12/15, GP/XPR OFF SIDE PLASTIC SAFETY
COVER
1 B
18 5746192 ARM ADAPTER, MEDIUM 4 E
19 5540281 C RING Ø38mm OD 5103-150 4 --
20 5746167 DOUBLE THREADED ROD M10 x 1.5 x 275 2 B
21 5716634 D2/10AP/XPR MICROSWITCH COVER, PLASTIC 1 B
22 5550095 FTG NPL -04 JIC x -04 JIC 1 --
23 5530337 AB 3/4" x 6.3" 12 --
24 5900951 XPR-10S SERIES INSTALLATION MANUAL 1 --
25 5525150 SPDT MICRO SWITCH;25A@125VAC 1 --
26 5525112 MICRO SWITCH COVER-5PA2 1 --
27 5520116 14-4 SJO UL 62 CABLE 300vac 4550mm* --
28 5701660 10AP/D2-12/15/XPR HEIGHT ADAPTER HOLDER 2 B
REVISION
REV DESCRIPTION DATE EDITED BY ECO#
D
ADDED 5701660, REMOVED 5535358 AND
5545342, UPDATED BOM REVISIONS
02/25/2020 TM 01107
E UPDATED BOM REVISION 10/02/2020 TM 01215
F UPDATED BOM REVISION 06/22/2021 TM 01310
WHERE USED
XPR-10AXLS-181
XPR-10AXLS-181-LP
SHEET 1 OF 2
REV
DWG. NO.
A
SIZE
TITLE:
NAME
DATE
CHECKED
DRAWN
F
1645 LEMONWOOD DR.
SANTA PAULA, CA 93060
PROPRIETARY AND CONFIDENTIAL
THE INFORMATION CONTAINED IN THIS DRAWING IS
THE SOLE PROPERTY OF BENDPAK INC. ANY
REPRODUCTION IN PART OR AS A WHOLE WITHOUT
THE WRITTEN PERMISSION OF BENDPAK INC. IS
PROHIBITED.
TM
5250236
XPR-10AXLS
EXTENDED PARTS BOX
10/15/2018
DO NOT SCALE DRAWING
1:30
SCALE:
THIRD ANGLE PROJECTION
OR 07/01/2021
SEE SHIPPING INSTRUCTIONS FOR FINAL PACKAGING 1.
HOSES AND CABLES IN REPRESENTATIONAL FORM 2.
FOR 5220116 SPECIFICATIONS REFER TO PART SPECIFICATION FORM 3.
(*)5520116 QTY FOR REFERENCE ONLY
NOTE: UNLESS OTHERWISE SPECIFIED .

1
17
11
13
3
8
6
7
9
15
2
12
10
4
20
21
5
22
19
23
24
25
26
27
18
16
14
28
SHEET 2 OF 2
REV
DWG. NO.
A
SIZE
TITLE:
F
1645 LEMONWOOD DR.
SANTA PAULA, CA 93060
5250236
XPR-10AXLS
EXTENDED PARTS BOX
1:25
SCALE:

DIMENSIONS ARE IN MM
☺
12
13
14
22 17
20
25
26
15
16
18
23
10
8
24
19
4
2
21
7
1
11
27
9
3
6
28
31
30
29
REVISION
REV DESCRIPTION DATE EDITED BY ECO#
L REMOVED 5520001, UPDATED NEXT ASSEMBLIES 10/12/2018 TM 01011
M
ADDED 5535357, 5530093, 5545005, AND
5580012, REPLACED 5530750 WITH 5530799
02/20/2020 TM 01107
N
REPLACED 5505001 WITH 5505113, REMOVED
(2) 5540075
10/02/2020 TM 01215
NEXT ASSEMBLY
5250087
5250089
5250236
5250252
5250264
5250267
5250269
ITEM NO PART NUMBER DESCRIPTION QTY REV
1 5505113 2 POST SAFETY CLEVIS PIN 2 H
2 5715196 D2/XPR POLYETHYLENE COVER BLOCK 105 x 80 2 D
3 5535022 NUT 9/16"-18 JN 1 -
4 5550113 FTG ELB -04 NPT L x -04 JIC 2 -
5 5550183 FTG ELB -06 JIC -06L ORB 1 -
6 5550003 FTG TEE -04JIC -04JIC -06JIC 1 -
7 5505350 MODEL#211 HAIR PIN/ LARGE 2 -
8 5530261 PHPS M6 x 1 x 10 4 -
9 5545347 WASHER, M12 FLAT WASHER 2 -
10 5535354 NUT M12 x1.75 10 -
11 5535001 NUT M8 x 1.25 NL 4 -
12 5530010 HHB M8 x 1.25 x 25 4 -
13 5545200 WASHER M10 x Ø18 SL 4 -
14 5535998 NUT M10 x 1.5 4 -
15 5530760 HHB M10 x 1.5 x 38 4 -
16 5545201 WASHER, M12 SPRING LOCK 8 -
17 5545027 WASHER M12 x Ø37 x 3mm 16 -
18 5530076 HHB M12 x 1.75 x 35mm 8 -
19 5540075 R.H., 2.5 WIRE DIA., Ø20.5 x 75 LG 2 B
20 5530799 HSDS M4.2 x 1.41 x 20 2 -
21 5545535 C WASHER SHIM FOR LIFTS 20 -
22 5535013 NUT M10 x 1.5 NL 4 -
23 5545341 WASHER M10 x Ø20 FLAT 4 -
24 5505031 ROTOR CLIP 12mm SS 1 -
25 5530115 BHS 6-32 x 1.25 2 -
26 5535190 HN 6-32 2 -
27 5520140 ROMEX CONNECTOR 3/8 #6623 2 -
28 5580012 LIQUID PTFE THREAD SEALANT 50ml 1 -
29 5530093 HHB M6 x 1 x 20 4 -
30 5545005 M6 FLAT WASHER 8 -
31 5535357 NUT M6 x 1.0 NL 4 -
WHERE USED
XPR-10AXLS-181
XPR-10AS-168
XPR-10S-168
XPR-10XLS-181
XPR-12CL-192
XPR-12CL-LTA-192
XPR- 15CL-192
XPR-18CL-192
SHEET 1 OF 1
REV
DWG. NO.
A
SIZE
TITLE:
NAME
DATE
CHECKED
DRAWN
N
1645 LEMONWOOD DR.
SANTA PAULA, CA 93060
PROPRIETARY AND CONFIDENTIAL
THE INFORMATION CONTAINED IN THIS DRAWING IS
THE SOLE PROPERTY OF BENDPAK INC. ANY
REPRODUCTION IN PART OR AS A WHOLE WITHOUT
THE WRITTEN PERMISSION OF BENDPAK INC. IS
PROHIBITED.
NOTE: UNLESS OTHERWISE SPECIFIED .
TM
5174218
XPR CLEARFLOOR
EXTENDED PARTS BAG
01/26/2010
DO NOT SCALE DRAWING
1:18
SCALE:
THIRD ANGLE PROJECTION
OR 10/15/2020
SEE SHIPPING INSTRUCTIONS FOR FINAL PACKAGING 1.

DIMENSIONS ARE IN MM
☺
3
4
1
6
2
5
REVISION
REV DESCRIPTION DATE EDITED BY ECO#
F UPDATED BOM REVISION 09/21/2016 DB 00780
G
G-001
UPDATED BOM REVISION
UPDATED NEXT ASSEMBLY
02/05/2018
05/14/2018
TS
TM
00922
00946
H
H-001
UPDATED BOM REVISION
UPDATED NEXT ASSEMBLIES
05/30/2018
06/25/2018
TM
TM
00953
00964
WHERE USED
10AP SERIES
XPR-9 SERIES
XPR-10 SERIES
ITEM NO. PART NUMBER DESCRIPTION QTY REV
1 5715017
ROUND LIFT PAD ADAPTER POLYURETHANE
PAD
1 E
2 5540025 S RING Ø35mm 1 --
3 5746692 INNER SCREW 1 C
4 5540026 S RING Ø45mm 2 --
5 5746693 ROUND LIFT PAD SCREW ADAPTOR 1 D
6 5601001 ROUND LIFT PAD ADAPTOR WELDMENT 1 D
NEXT ASSEMBLY
5250037
5250083
5250084
5250087
5250088
5250089
5250203
5250236
5250252
5250296
5250299
5250312
5250313
5250329
SHEET 1 OF 1
REV
DWG. NO.
A
SIZE
TITLE:
NAME
DATE
CHECKED
DRAWN
H
1645 LEMONWOOD DR.
SANTA PAULA, CA 93060
PROPRIETARY AND CONFIDENTIAL
THE INFORMATION CONTAINED IN THIS DRAWING IS
THE SOLE PROPERTY OF BENDPAK INC. ANY
REPRODUCTION IN PART OR AS A WHOLE WITHOUT
THE WRITTEN PERMISSION OF BENDPAK INC. IS
PROHIBITED.
NOTE: UNLESS OTHERWISE SPECIFIED .
CHY
5215704
ROUND ADJUSTABLE LIFT
PAD ASSEMBLY
06/14/2015
DO NOT SCALE DRAWING
1:3
SCALE:
THIRD ANGLE PROJECTION
CA 06/29/2018
SEE SHIPPING INSTRUCTIONS FOR FINAL PACKAGING 1.
ASSEMBLE ITEMS AS SHOWN 2.

203
1 2
ITEM NO PART NUMBER DESCRIPTION QTY REV
1 5570129 Ø6.4 ID HYDRAULIC HOSE 137mm* --
2 5550325 FTG NPL Ø1/4 CRIMP x -04 JIC 2 --
REVISION
REV DESCRIPTION DATE EDITED BY ECO#
B
REPLACED 5570110 WITH 5570129 TO REFLECT
INVENTORY
11/21/2014 TM 00673
C
C-001
UPDATED TITLE TO REFLECT MARKETING,
UPDATED NEXT ASSEMBLIES
UPDATED NEXT ASSEMBLIES
11/25/2015
06/25/2018
TM
TM
00738
00964
D UPDATED TITLE TO REFLECT STANDARD 03/03/2020 TM 01148
NEXT ASSEMBLY
5240020
5240021
5240052
5240806
5250083
5250084
5250087
5250236
5250277
5250296
5250299
5250312
5250313
WHERE USED
10AP SERIS
A6W SERIES
XPR-10A SERIES
SHEET 1 OF 1
REV
DWG. NO.
A
SIZE
TITLE:
NAME
DATE
CHECKED
DRAWN
D
1645 LEMONWOOD DR.
SANTA PAULA, CA 93060
PROPRIETARY AND CONFIDENTIAL
THE INFORMATION CONTAINED IN THIS DRAWING IS
THE SOLE PROPERTY OF BENDPAK INC. ANY
REPRODUCTION IN PART OR AS A WHOLE WITHOUT
THE WRITTEN PERMISSION OF BENDPAK INC. IS
PROHIBITED.
TM
5570065
HYDRAULIC HOSE ASSEMBLY
Ø6.35 x 203mm DS
10/07/2014
DO NOT SCALE DRAWING
1:2
SCALE:
THIRD ANGLE PROJECTION
OR 03/11/2020
DIMENSIONS ARE IN MM
TOLERANCES:
0. = ±1.5
0.0 = ±1.0
0.00 = ±0.25
0.000 = ±0.13
SURFACE FINISH 1.6 ISO Ra µm
FOR MACHINED SURFACES
UNLESS OTHERWISE SPECIFIED
NOTE: UNLESS OTHERWISE SPECIFIED.
FOR ITEM 1 SPECIFICATIONS REFER TO PART SPECIFICATION FORM 1.
(*)ITEM 1 QTY FOR REFERENCE ONLY 2.

2451.0
3
1 2
REVISION
REV DESCRIPTION DATE EDITED BY ECO#
B UPDATED TITLE TO REFLECT MARKETING 12/23/2015 TM 00738
C
C-001
UPDATED TITLE TO REFLECT WHERE USED,
UPDATED NEXT ASSEMBLY
UPDATED NEXT ASSEMBLIES
05/14/2018
06/26/2018
TM
TM
00946
00964
D UPDATED TITLE TO REFLECT STANDARD 02/24/2020 TM 01107
NEXT ASSEMBLY
5250083
5250203
5250236
5250252
5250312
5250313
ITEM NO PART NUMBER DESCRIPTION QTY REV
1 5570129 Ø6.4 ID HYDRAULIC HOSE 2401mm* --
2 5550325 FTG NPL Ø1/4 CRIMP x -04 JIC 1 --
3 5550345 FTG ELB Ø1/4 CRIMP x -04 JIC 1 --
WHERE USED
10APX SEIRES
XPR-10AXLS SERIES
XPR-10XLS SERIES
SHEET 1 OF 1
REV
DWG. NO.
A
SIZE
TITLE:
NAME
DATE
CHECKED
DRAWN
D
1645 LEMONWOOD DR.
SANTA PAULA, CA 93060
PROPRIETARY AND CONFIDENTIAL
THE INFORMATION CONTAINED IN THIS DRAWING IS
THE SOLE PROPERTY OF BENDPAK INC. ANY
REPRODUCTION IN PART OR AS A WHOLE WITHOUT
THE WRITTEN PERMISSION OF BENDPAK INC. IS
PROHIBITED.
JM
5570075
HYDRAULIC HOSE ASSEMBLY
Ø6.35 x 2451mm SB
11/18/2015
DO NOT SCALE DRAWING
1:2
SCALE:
THIRD ANGLE PROJECTION
OR 04/17/2020
DIMENSIONS ARE IN MM
TOLERANCES:
0. = ±1.5
0.0 = ±1.0
0.00 = ±0.25
0.000 = ±0.13
SURFACE FINISH 1.6 ISO Ra µm
FOR MACHINED SURFACES
UNLESS OTHERWISE SPECIFIED
NOTE: UNLESS OTHERWISE SPECIFIED.
FOR ITEM 1 SPECIFICATIONS REFER TO PART SPECIFICATION FORM 1.
(*)ITEM 1 QTY FOR REFERENCE ONLY 2.

1371
13 2
REVISION
REV DESCRIPTION DATE EDITED BY ECO#
B UPDATED TITLE TO REFLECT MARKETING 12/23/2015 TM 00738
C
C-001
UPDATED TITLE TO REFLECT WHERE USED,
UPDATED NEXT ASSEMBLY
UPDATED NEXT ASSEMBLIES
05/14/2018
06/26/018
TM
TM
00946
00964
D UPDATED TITLE TO REFLECT STANDARD 02/25/2020 TM 01107
NEXT ASSEMBLY
5250083
5250203
5250236
5250252
5250312
5250313
ITEM NO PART NUMBER DESCRIPTION QTY REV
1 5570116 Ø10 ID HYDRAULIC HOSE 1296mm* -
2 5550337 FTG ELB -06 CRIMP x -06 JIC 1 -
3 5550336 FTG NPL -06 CRIMP x -06 JIC 1 -
WHERE USED
10APX SERIES
XPR-10AXLS SERIES
XPR-10XLS SERIES
SHEET 1 OF 1
REV
DWG. NO.
A
SIZE
TITLE:
NAME
DATE
CHECKED
DRAWN
D
1645 LEMONWOOD DR.
SANTA PAULA, CA 93060
PROPRIETARY AND CONFIDENTIAL
THE INFORMATION CONTAINED IN THIS DRAWING IS
THE SOLE PROPERTY OF BENDPAK INC. ANY
REPRODUCTION IN PART OR AS A WHOLE WITHOUT
THE WRITTEN PERMISSION OF BENDPAK INC. IS
PROHIBITED.
JM
5570076
HYDRAULIC HOSE ASSEMBLY
Ø10 x 1371mm SB
11/18/2015
DO NOT SCALE DRAWING
1:2
SCALE:
THIRD ANGLE PROJECTION
OR 04/17/2020
DIMENSIONS ARE IN MM
TOLERANCES:
0. = ±1.5
0.0 = ±1.0
0.00 = ±0.25
0.000 = ±0.13
SURFACE FINISH 1.6 ISO Ra µm
FOR MACHINED SURFACES
UNLESS OTHERWISE SPECIFIED
NOTE: UNLESS OTHERWISE SPECIFIED.
FOR ITEM 1 SPECIFICATIONS REFER TO PART SPECIFICATION FORM 1.
(*)ITEM 1 QTY FOR REFERENCE ONLY 2.

9766
2
3
1
NEXT ASSEMBLY
5240052
5250236
ITEM NO PART NUMBER DESCRIPTION QTY REV
1 5570129 Ø6.4 ID HYDRAULIC HOSE 9716mm* --
2 5550325 FTG NPL Ø1/4 CRIMP x -04 JIC 1 --
3 5550345 FTG ELB Ø1/4 CRIMP x -04 JIC 1 --
REVISION
REV DESCRIPTION DATE EDITED BY ECO#
A PRODUCTION RELEASE, DERIVED FROM 5570059 06/22/2018 TM 00964
B UPDATED TITLE TO REFLECT STANDARD 02/25/2020 TM 01107
WHERE USED
XPR-10AXLS-181
XPR-10AXLS-181-LP
SHEET 1 OF 1
REV
DWG. NO.
A
SIZE
TITLE:
NAME
DATE
CHECKED
DRAWN
B
1645 LEMONWOOD DR.
SANTA PAULA, CA 93060
PROPRIETARY AND CONFIDENTIAL
THE INFORMATION CONTAINED IN THIS DRAWING IS
THE SOLE PROPERTY OF BENDPAK INC. ANY
REPRODUCTION IN PART OR AS A WHOLE WITHOUT
THE WRITTEN PERMISSION OF BENDPAK INC. IS
PROHIBITED.
TM
5570097
HYDRAULIC HOSE ASSEMBLY
Ø6.35 x 9766mm SB
06/22/2018
DO NOT SCALE DRAWING
1:2
SCALE:
THIRD ANGLE PROJECTION
OR 04/10/2020
DIMENSIONS ARE IN MM
TOLERANCES:
0. = ±1.5
0.0 = ±1.0
0.00 = ±0.25
0.000 = ±0.13
SURFACE FINISH 1.6 ISO Ra µm
FOR MACHINED SURFACES
UNLESS OTHERWISE SPECIFIED
NOTE: UNLESS OTHERWISE SPECIFIED.
FOR ITEM 1 SPECIFICATIONS REFER TO PART SPECIFICATION FORM 1.
(*)ITEM 1 QTY FOR REFERENCE ONLY 2.
