Bend-Pak HDS-18E User manual

BendPak, Inc. Corporate Oce
1645 Lemonwood Drive
Santa Paula, CA 93060 USA
Toll Free US/Canada: 1-800-253-2363
Fax: [phone]
[email protected]om
Customer Service Desk / Warranty
Customer Service Representatives
Oce Tel: [phone]
Toll Free US/Canada: 1-800-253-2363
Fax: [phone]
customerservic[email protected]
Parts Orders
Customer Service Representatives
Oce Tel: [phone]
Toll Free US/Canada: 1-800-253-2363
Fax: [phone]
[email protected]om
Domestic Sales & Service
USA Sales Representatives
Oce Tel: [phone]
Toll Free US/Canada: 1-800-253-2363
Fax: [phone]
[email protected]om
International Sales & Service
Oce Tel: [phone]
Exports Dept: 1-805-933-9970 EXT. 192
Ext. Toll Free US/Canada: 1-800-253-2363
Fax: [phone]
bpkex[email protected]om
Service Manual
SERVICE PARTS & DIAGRAMS
This guide is a troubleshooting reference used for maintaining and
servicing your Bend Pak product. It provides comprehensive information
on identifying serviceable parts and components and assists in
troubleshooting problems and performing assembly /disassembly
procedures.
BENDPAK
HDS18E
PRODUCT SKU
5175968
DRAWING Nº
5260604
CATEGORY
Four Post Li
REV
Version J
DATE
08.29.2022

DIMENSIONS ARE IN MM
☺
2
1
ITEM NO PART NUMBER DESCRIPTION QTY REV
1 5245088 HDS-18E LIFT SUPERSTRUCTURE 1 G
2 5250172 HDS-18E/27 PARTS BOX 1 M
REVISION
REV DESCRIPTION DATE EDITED BY ECO#
G UPDATED BOM REVISION 01/11/2022 TM 01378
H UPDATED BOM REVISIONS 05/25/2022 TM 01414
J WAS 107.3 NOW 108.7, UPDATED BOM REVISION 08/08/2022 TM 01436
SHEET 1 OF 3
REV
DWG. NO.
A
SIZE
TITLE:
NAME
DATE
CHECKED
DRAWN
J
1645 LEMONWOOD DR.
SANTA PAULA, CA 93060
PROPRIETARY AND CONFIDENTIAL
THE INFORMATION CONTAINED IN THIS DRAWING IS
THE SOLE PROPERTY OF BENDPAK INC. ANY
REPRODUCTION IN PART OR AS A WHOLE WITHOUT
THE WRITTEN PERMISSION OF BENDPAK INC. IS
PROHIBITED.
NOTE: UNLESS OTHERWISE SPECIFIED .
TM
5260604
HDS-18E PRODUCTION
LIFT VER D (CE CERT)
12/12/2019
DO NOT SCALE DRAWING
1:45
SCALE:
THIRD ANGLE PROJECTION
OR 08/16/2022
REFER TO MODEL FOR ADDITIONAL INFORMATION 1.
SEE SHIPPING INSTRUCTIONS FOR FINAL PACKAGING 2.
SEE COLORS & GRAPHICS FOR LABEL PLACEMENT 3.

4.026in
102.3mm
8.150in
207.0mm
69.528in
1766.0mm
3.969in MAX
100.8mm MAX
91.260in
2318.0mm
30.558in
776.2mm
61.378in
1559.0mm
A
B
[40.04 MIN - 45.315in MAX]
1017.0 MIN - 1151.0mm MAX
133.504in
3391.0mm
312.730in
7943.3mm
22.047in
560.0mm
20.976in
532.8mm
153.504in
3899.0mm
257.008in
6528.0mm
257.371in
6537.2mm
58.134in
1476.6mm
DRIVE THRU
FRONT VIEW
5.000in
127.0mm
DETAIL A
SCALE 1 : 10
4.279in
108.7mm
DETAIL B
SCALE 1 : 10
SHEET 2 OF 3
REV
DWG. NO.
A
SIZE
TITLE:
J
1645 LEMONWOOD DR.
SANTA PAULA, CA 93060
5260604
HDS-18E PRODUCTION
LIFT VER D (CE CERT)
1:45
SCALE:

69.528in
1766.0mm
RAISED
67.583in
1716.6mm
TOP LOCK
20.339in
516.6mm
LOWEST LOCK
9.528in
242.0mm
LOWERED
SHEET 3 OF 3
REV
DWG. NO.
A
SIZE
TITLE:
J
1645 LEMONWOOD DR.
SANTA PAULA, CA 93060
5260604
HDS-18E PRODUCTION
LIFT VER D (CE CERT)
1:40
SCALE:
DIMENSIONS ARE WITH THE LOCK LADDER ADJUSTED ALL THE WAY UP 1.

DIMENSIONS ARE IN MM
☺
A
B
8
4
3
7
1
5
2
6
DETAIL A
SCALE 1 : 5
10
11
9
DETAIL B
SCALE 1 : 20
12
15
13
15
14
ITEM
NO
PART
NUMBER
DESCRIPTION QTY REV
1 5601143 HDS-18/27/40 POWER POST WELDMENT 1 B
2 5601141 HDS-18/27/40 POST WELDMENT 3 B
3 5215164 HDS-18E/27 POWER SIDE RAMP ASSEMBLY 1 AA
4 5601441 HDS-18E/27 OFF SIDE RAMP WELDMENT 1 B
5 5216168 HDS-18/27 CROSSTUBE ASSEMBLY, LARGE WINDOW 1 A
6 5216167 HDS-18/27 CROSSTUBE ASSEMBLY, SMALL WINDOW 1 A
7 5215161 HDS-18/27 EXTENDED DRIVE UP RAMP ASSEMBLY 2 K
8 5600875 HDS-18/27 SAFETY LADDER WELDMENT 4 C
9 5535211 NUT M27 x 3.0 NL 4 --
10 5535210 NUT M27 x 3.0 4 --
11 5545103 WASHER M27 x 50mm 4 --
12 5530046 HHB M10 x 1.5 x 65mm 4 --
13 5746088 HDS-18/27 SPACER, SAFETY LADDER, 31mm LG 4 B
14 5535013 NUT M10 x 1.5 NL 4 --
15 5545341 WASHER M10 x Ø20 FLAT 8 --
NEXT ASSEMBLY
5260604
WHERE USED
HDS-18E
REVISION
REV DESCRIPTION DATE EDITED BY ECO#
E UPDATED BOM REVISION 01/11/2022 TM 01378
F
REPLACED 5215891 WITH 5216168, 5215890
WITH 5216167
05/23/2022 TM 01414
G UPDATED BOM REVISION 08/08/2022 TM 01436
SHEET 1 OF 1
REV
DWG. NO.
A
SIZE
TITLE:
NAME
DATE
CHECKED
DRAWN
G
1645 LEMONWOOD DR.
SANTA PAULA, CA 93060
PROPRIETARY AND CONFIDENTIAL
THE INFORMATION CONTAINED IN THIS DRAWING IS
THE SOLE PROPERTY OF BENDPAK INC. ANY
REPRODUCTION IN PART OR AS A WHOLE WITHOUT
THE WRITTEN PERMISSION OF BENDPAK INC. IS
PROHIBITED.
TM
5245088
HDS-18E LIFT
SUPERSTRUCTURE
12/12/2019
DO NOT SCALE DRAWING
1:55
SCALE:
THIRD ANGLE PROJECTION
OR 08/16/2022
REFER TO MODEL FOR ADDITIONAL INFORMATION 1.
FASTEN NUTS AND WASHERS TO SAFETY LADDERS IN 2.
ORDER SHOWN FOR SHIPMENT
SEE SHIPPING INSTRUCTIONS FOR FINAL PACKAGING 3.
NOTE: UNLESS OTHERWISE SPECIFIED .

DIMENSIONS ARE IN MM
☺
3
1
2
4
6
5
7
9
8
10
ISOMETRIC VIEW
FOR REFERENCE ONLY
DO NOT SCALE
ITEM
NO
PART
NUMBER
DESCRIPTION QTY REV
1 5600142 HDS-18E/27 POWER SIDE RAMP WELDMENT 1 K
2 5215160 HDS-18E/27 SERIES RAMP SHEAVE ROLLER ASSEMBLY 6 D
3 5620242 HDS-18E/27 SHEAVE PIN WELDMENT 2 C
4 5716016 HDS-18E/27 SERIES SHEAVE SPACER 6 C
5 5746089 HDS-18/27/40 SERIES SHEAVE SHAFT PIN 2 D
6 5755113 HD-18/27 SPACER, RAMP SHEAVE 2 B
7 5505335 HAIR PIN 3/32” x 1 5/8” 4 -
8 5215159 HDS-18/27 SERIES CYLINDER FLANGE ARM ASSEMBLY 1 H
9 5502161 PULL CYLINDER ASSEMBLY Ø5.0 x 60 1 N
10 5731025 HDS-18/27 SERIES CABLE RETAINER PLATE 1 B
NEXT ASSEMBLY
5245088
5245090
REVISION
REV DESCRIPTION DATE EDITED BY ECO#
Y UPDATED BOM REVISION 11/05/2020 CA 01227
Z
REPLACED (1) 5620197 WITH 5620242,
UPDATED BOM REVISION
08/26/2021 CA 01322
AA UPDATED BOM REVISION 01/10/2022 TM 01378
WHERE USED
HDS-18E
HDS-27
SHEET 1 OF 2
REV
DWG. NO.
A
SIZE
TITLE:
NAME
DATE
CHECKED
DRAWN
AA
1645 LEMONWOOD DR.
SANTA PAULA, CA 93060
PROPRIETARY AND CONFIDENTIAL
THE INFORMATION CONTAINED IN THIS DRAWING IS
THE SOLE PROPERTY OF BENDPAK INC. ANY
REPRODUCTION IN PART OR AS A WHOLE WITHOUT
THE WRITTEN PERMISSION OF BENDPAK INC. IS
PROHIBITED.
NOTE: UNLESS OTHERWISE SPECIFIED .
GJZ
5215164
HDS-18E/27 POWER SIDE
RAMP ASSEMBLY
10/23/2008
DO NOT SCALE DRAWING
1:32
SCALE:
THIRD ANGLE PROJECTION
OR 01/11/2022
REFER TO MODEL FOR ADDITIONAL INFORMATION 1.
SEE SHIPPING INSTRUCTIONS FOR FINAL PACKAGING 2.
ASSEMBLE ITEMS AS SHOWN 3.
VERIFY CYLINDER PORTS ARE CAPPED OFF WITH 3/8" NPT STEEL PLUG 4.

24.606in
625.0mm
265.236in
6737.0mm
PORTS MUST BE
ON THIS SIDE
10.394in
264.0mm
SHEET 2 OF 2
REV
DWG. NO.
A
SIZE
TITLE:
AA
1645 LEMONWOOD DR.
SANTA PAULA, CA 93060
5215164
HDS-18E/27 POWER SIDE
RAMP ASSEMBLY
1:20
SCALE:

DIMENSIONS ARE IN MM
☺
1
20
22
21
DETAIL A
SCALE 1 : 10
6
13
3
12
5
7
8
15
14
17
94
10
2
16
18
19
11
ITEM
NO
PART
NUMBER
DESCRIPTION QTY REV
1 5601832 HDS-18/27 CROSSTUBE WELDMENT, SMALL WINDOW 1 A
2 5215166 HDS-18/27 CROSSTUBE SHEAVE ASSEMBLY 2 D
3 5215169 HDS-18/27 SAFETY ROLLER ASSEMBLY 2 D
4 5505124 HDS-18/27/40 CROSSTUBE SHEAVE SHAFT WELDMENT 2 G
5 5505125 HDS-18/27/40 SAFETY PIN 2 E
6 5716152 HDS-18/27 POLYETHYLENE SLIDE BLOCK 8 G
7 5210359 HDS-18/27/40 SAFETY WELDMENT #1 2 D
8 5210358 HDS-18/27/40 SAFETY WELDMENT #2 2 E
9 5502335 AIR CYLINDER, Ø.75 x 4.0" STROKE 2 -
10 5505030 PUSH-ON CLIP Ø10mm SS 4 -
11 5505031 ROTOR CLIP Ø12mm SS 6 -
12 5505033 PUSH-ON CLIP Ø16mm SS 4 -
13 5540002 E RING Ø1.375" OD TRUARC X5133-137 8 -
14 5540060 SPRING Ø29 x 178mm, SLACK SAFETY 2 A
15 5540112 SNAP RING; TRUARC 5103-175 2 -
16 5550087 FTG ELB -04 COMP x -02 NPT 2 -
17 5535101 3/8-16 HEX NUT JAM 2 -
18 5550376 HDS-18/27/40 ADAPTER, 1" AIR CYLINDER 2 D
19 5545108 WASHER M45 x 80 FLAT 2 -
20 5530317 HHB M6 x 1 x 136 2 -
21 5535357 NUT M6 x 1.0 NL 2 -
22 5755158 HD-18/27/40 CROSSTUBE SPACER Ø16 x Ø10 x 102 2 B
WHERE USED
HDS-18 SERIES
HDS-27 SERIES
NEXT ASSEMBLY
5245086
5245087
5245088
5245089
5245090
REVISION
REV DESCRIPTION DATE EDITED BY ECO#
A PRODUCTION RELEASE, DERIVED FROM 5215890 05/02/2022 TM 01414
SHEET 1 OF 1
REV
DWG. NO.
A
SIZE
TITLE:
NAME
DATE
CHECKED
DRAWN
A
1645 LEMONWOOD DR.
SANTA PAULA, CA 93060
PROPRIETARY AND CONFIDENTIAL
THE INFORMATION CONTAINED IN THIS DRAWING IS
THE SOLE PROPERTY OF BENDPAK INC. ANY
REPRODUCTION IN PART OR AS A WHOLE WITHOUT
THE WRITTEN PERMISSION OF BENDPAK INC. IS
PROHIBITED.
NOTE: UNLESS OTHERWISE SPECIFIED .
TM
5216167
HDS-18/27 CROSSTUBE
ASSEMBLY, SMALL WINDOW
05/02/2022
DO NOT SCALE DRAWING
1:20
SCALE:
THIRD ANGLE PROJECTION
REFER TO MODEL FOR ADDITIONAL INFORMATION 1.
SEE SHIPPING INSTRUCTIONS FOR FINAL PACKAGING 2.
ASSEMBLE ITEMS AS SHOWN 3.

DIMENSIONS ARE IN MM
☺
1
20 21
22
DETAIL A
SCALE 1 : 10
13
5
7
9
17
18
12
3
8
15
19
2
14
11
16
4
6
10
ITEM
NO
PART
NUMBER
DESCRIPTION QTY REV
1 5601831 HDS-18/27 CROSSTUBE WELDMENT, LARGE WINDOW 1 A
2 5215166 HDS-18/27 SERIES CROSSTUBE SHEAVE ASSEMBLY 2 D
3 5215169 HDS-18/27 SAFETY ROLLER ASSEMBLY 2 D
4 5505124 HDS-18/27/40 CROSSTUBE SHEAVE SHAFT WELDMENT 2 G
5 5505125 HDS-18/27/40 SAFETY PIN 2 E
6 5716152 HDS-18/27 POLYETHYLENE SLIDE BLOCK 8 G
7 5210359 HDS-18/27/40 SAFETY WELDMENT #1 2 D
8 5210358 HDS-18/27/40 SAFETY WELDMENT #2 2 E
9 5502335 AIR CYLINDER, Ø.75 x 4.0" STROKE 2 -
10 5505030 PUSH-ON CLIP Ø10mm SS 4 -
11 5505031 ROTOR CLIP Ø12mm SS 6 -
12 5505033 PUSH-ON CLIP Ø16mm SS 4 -
13 5540002 E RING Ø1.375" OD TRUARC X5133-137 8 -
14 5540060 SPRING Ø29 x 178mm, SLACK SAFETY 2 A
15 5540112 SNAP RING; TRUARC 5103-175 2 -
16 5550087 FTG ELB -04 COMP x -02 NPT 2 -
17 5535101 3/8-16 HEX NUT JAM 2 -
18 5550376 HDS-18/27/40 ADAPTER, 1" AIR CYLINDER 2 D
19 5545108 WASHER M45 x 80 FLAT 2 -
20 5530317 HHB M6 x 1 x 136 2 -
21 5535357 NUT M6 x 1.0 NL 2 -
22 5755158 HD-18/27/40 CROSSTUBE SPACER Ø16 x Ø10 x 102 2 B
NEXT ASSEMBLY
5245086
5245087
5245088
5245089
5245090
WHERE USED
HDS-18 SERIES
HDS-27 SERIES
REVISION
REV DESCRIPTION DATE EDITED BY ECO#
A PRODUCTION RELEASE, DERIVED FROM 5215891 05/02/2022 TM 01414
SHEET 1 OF 1
REV
DWG. NO.
A
SIZE
TITLE:
NAME
DATE
CHECKED
DRAWN
A
1645 LEMONWOOD DR.
SANTA PAULA, CA 93060
PROPRIETARY AND CONFIDENTIAL
THE INFORMATION CONTAINED IN THIS DRAWING IS
THE SOLE PROPERTY OF BENDPAK INC. ANY
REPRODUCTION IN PART OR AS A WHOLE WITHOUT
THE WRITTEN PERMISSION OF BENDPAK INC. IS
PROHIBITED.
TM
5216168
HDS-18/27 CROSSTUBE
ASSEMBLY, LARGE WINDOW
05/02/2022
DO NOT SCALE DRAWING
1:20
SCALE:
THIRD ANGLE PROJECTION
REFER TO MODEL FOR ADDITIONAL INFORMATION 1.
SEE SHIPPING INSTRUCTIONS FOR FINAL PACKAGING 2.
ASSEMBLE ITEMS AS SHOWN 3.
NOTE: UNLESS OTHERWISE SPECIFIED .

DIMENSIONS ARE IN MM
☺
12
15 19
1
17
20
16
18
11
8
7
6
9
13
14
4
3
2
5
10
21
NEXT ASSEMBLY
5260604
5260606
ITEM
NO
PART
NUMBER
DESCRIPTION QTY. REV
1 5174600 HDS-18E/27/40 PARTS BAG 1 H
2 5700029 HD-SERIES FLEX TUBE BRACKET PLATE 1 F
3 5700033 HD-SERIES FLEX TUBE ANGLE 1 E
4 5216139 FLEX TUBE KIT, UP TO 2000mm 1 A
5 5715003 POWER UNIT VIBRATION DAMPENER 1 B
6 5595835
HDS-18E/18EA/27 CABLE ASSEMBLY Ø16 x 4127mm ST
1 E
7 5595807 HDS-18/27 CABLE ASSEMBLY Ø16 x 12215mm ST 1 J
8 5595806 HDS-18/27 CABLE ASSEMBLY Ø16 x 10483mm ST 1 H
9 5595836
HDS-18E/18EA/27 CABLE ASSEMBLY Ø16 x 5855mm ST
1 E
10 5215096 PUSH BUTTON AIR ASSEMBLY 1 G
11 5620194 HDS-18E/27/40 TIRE STOP WELDMENT 2 C
12 5600409 HDS-18/27 TOP PLATE WELDMENT 4 D
13 5570901 HDS-27 HYDRAULIC HOSE ASSY Ø10 x 5385mm 1 C
14 5570795 1/4" POLY-FLO TUBING 24000mm* -
15 5505123 HDS-27 SERIES HINGE PIN 2 B
16 5530456 AB 3/4" x 4 - 3/4" 16 -
17 5900160 HDS TRUCK SERIES INSTALLATION MANUAL 1 -
18 5716633 HDS-18/27/40 SERIES CROSSTUBE COVER, PLASTIC 4 C
19 5700246 WHEEL CHOCK 2 B
20 5210242 4 POST HEAVY DUTY CE PARTS BAG 1 A
21 5930195 ANTI-SLIP TAPE, 6” x 24ft 1 --
REVISION
REV DESCRIPTION DATE EDITED BY ECO#
K
ADDED 5210242, REMOVED 5535104 AND
5545415, UPDATED BOM REVISIONS
07/21/2020 TM 01174
L UPDATED BOM REVISION 08/25/2021 CA 01322
M
ADDED 5930195, REPLACED 5570050 WITH
5216139
05/04/2022 TM
01414
PRE A
WHERE USED
HDS-18E
HDS-27
SHEET 1 OF 1
REV
DWG. NO.
A
SIZE
TITLE:
NAME
DATE
CHECKED
DRAWN
M
1645 LEMONWOOD DR.
SANTA PAULA, CA 93060
PROPRIETARY AND CONFIDENTIAL
THE INFORMATION CONTAINED IN THIS DRAWING IS
THE SOLE PROPERTY OF BENDPAK INC. ANY
REPRODUCTION IN PART OR AS A WHOLE WITHOUT
THE WRITTEN PERMISSION OF BENDPAK INC. IS
PROHIBITED.
NOTE: UNLESS OTHERWISE SPECIFIED .
TM
5250172
HDS-18E/27 PARTS BOX
05/08/2013
DO NOT SCALE DRAWING
1:25
SCALE:
THIRD ANGLE PROJECTION
REFER TO MODEL FOR ADDITIONAL INFORMATION 1.
SEE SHIPPING INSTRUCTIONS FOR FINAL PACKAGING 2.
HOSES AND CABLES IN REPRESENTATIONAL FORM 3.
(*) LENGTH FOR REFERENCE ONLY 4.

DIMENSIONS ARE IN MM
☺
22
23
DETAIL A
SCALE 1 : 5
2
DETAIL B
SCALE 1 : 5
20 18
19
DETAIL C
SCALE 1 : 5
6
10
3
7
DETAIL D
SCALE 1 : 10
4
21
11
12
9
8
5
16
DETAIL E
SCALE 1 : 5
17 1
DETAIL F
SCALE 1 : 2
14 15
13
REVISION
REV DESCRIPTION DATE EDITED BY ECO#
F
UPDATED TITLE TO REFLECT WHERE USED,
UPDATED NEXT ASSEMBLY
05/15/2018 TS 00945
G
ADDED (4) 5530200,(4) 5545342,(4) 5545350,
(4) 5535106, 5550026 AND 5580012
12/13/2019 TM 01120
H REMOVED 5550026 08/25/2021 CA 01322
ITEM NO PART NUMBER DESCRIPTION QTY REV
1 5550550 FTG ELB -06 JIC -06 NPT 1 --
2 5505032 ROTOR CLIP 18mm SS 4 --
3 5535001 NUT M8 x 1.25 NL 4 --
4 5530743 HHB M20 x 2.5 x 80 4 --
5 5530200 HHB M18 x 2.5 x 150mm 8 --
6 5530010 HHB M8 x 1.25 x 25 4 --
7 5550183 FTG ELB -06 JIC -06L ORB 1 --
8 5545342 WASHER M18 FLAT 8 --
9 5545350 WASHER M18 x 28 SL 8 --
10 5545340 WASHER M8 x24 FLAT 4 --
11 5535017 NUT M20 x 2.5 NL 4 --
12 5535106 HEX NUT M18 x 2.5 8 --
13 5535010 NUT M4 X 0.7 NL 2 --
14 5530008 SHCS M4 x 0.7 x 12 BOC 2 --
15 5545009 WASHER, Ø4.3 x Ø9mm x 0.8mm 2 --
16 5550395 FTG TEE -04 COMP x -04 COMP x -04 COMP 3 --
17 5550089 FTG ELB -04 COMP x -06 NPT 2 --
18 5545341 WASHER M10 x Ø20 FLAT 8 --
19 5530738 HHB M10 x 1.5 x 25 8 --
20 5535013 NUT M10 x 1.5 NL 8 --
21 5545343 WASHER, M20 FLAT 4 --
22 5545535 C WASHER SHIM FOR LIFTS 20 --
23 5580012 LIQUID PTFE THREAD SEALANT 50ml 1 --
NEXT ASSEMBLY
5250079
5250082
5250172
5250175
5250364
WHERE USED
HDS-18E
HDS-27 SERIES
HDS-40 SERIES
SHEET 1 OF 1
REV
DWG. NO.
A
SIZE
TITLE:
NAME
DATE
CHECKED
DRAWN
H
1645 LEMONWOOD DR.
SANTA PAULA, CA 93060
PROPRIETARY AND CONFIDENTIAL
THE INFORMATION CONTAINED IN THIS DRAWING IS
THE SOLE PROPERTY OF BENDPAK INC. ANY
REPRODUCTION IN PART OR AS A WHOLE WITHOUT
THE WRITTEN PERMISSION OF BENDPAK INC. IS
PROHIBITED.
NOTE: UNLESS OTHERWISE SPECIFIED .
AC
5174600
HDS-18E/27/40
PARTS BAG
05/06/2009
DO NOT SCALE DRAWING
1:50
SCALE:
THIRD ANGLE PROJECTION
OR 09/15/2021
SEE SHIPPING INSTRUCTIONS FOR FINAL PACKAGING 1.

DIMENSIONS ARE IN MM
☺
1
3
2
ISOMETRIC VIEW
FOR REFERENCE ONLY
DO NOT SCALE
REVISION
REV DESCRIPTION DATE EDITED BY ECO#
A
PRODUCTION RELEASE, DERIVED FROM
5570050, 5570052, 5570239
05/05/2022 TM
01414
PRE A
ITEM NO PART NUMBER DESCRIPTION QTY REV
1 5570053 PE FLEX TUBE Ø34.5xØ29 2100mm* -
2 5555555 WQG1-M36/AD34.5 CONNECTOR 2 -
3 5535050 PLASTIC NUT M36 x 2 2 -
WHERE USED
D4-12 SERIES
HD-14T
HD-7500 SERIES
HD-7W
HD-7P
HD-9 SERIES
HD-973 SERIES
HDS-14 SERIES
HDSO-14 SERIES
HDS-18/27/40 SERIES
NEXT ASSEMBLY
5250058 5250175 5250289
5250059 5250184 5250290
5250079 5250185 5250294
5250081 5250187 5250295
5250082 5250188 5250336
5250143 5250189 5250337
5250144 5250191 5250338
5250164 5250193 5250349
5250167 5250194 5250364
5250168 5250195
5250169 5250278
5250172 5250286
SHEET 1 OF 1
REV
DWG. NO.
A
SIZE
TITLE:
NAME
DATE
CHECKED
DRAWN
A
1645 LEMONWOOD DR.
SANTA PAULA, CA 93060
PROPRIETARY AND CONFIDENTIAL
THE INFORMATION CONTAINED IN THIS DRAWING IS
THE SOLE PROPERTY OF BENDPAK INC. ANY
REPRODUCTION IN PART OR AS A WHOLE WITHOUT
THE WRITTEN PERMISSION OF BENDPAK INC. IS
PROHIBITED.
NOTE: UNLESS OTHERWISE SPECIFIED .
TM
5216139
FLEX TUBE KIT,
UP TO 2000mm
05/05/2022
DO NOT SCALE DRAWING
1:3
SCALE:
THIRD ANGLE PROJECTION
OR 05/10/2022
SEE SHIPPING INSTRUCTIONS FOR FINAL PACKAGING 1.
SHOWN IN REPRESENTATIONAL FORM ONLY 2.
(*)LENGTH FOR REFERENCE ONLY

DIMENSIONS ARE IN MM
☺
3
1
6
2
5
4
7
ISOMETRIC VIEW
FOR REFERENCE ONLY
DO NOT SCALE
REVISION
REV DESCRIPTION DATE EDITED BY ECO#
E REPLACED 5550481 WITH 5550087 10/29/2013 TM 00593
F
REPLACED 5590240 WITH 5590175, UPDATED
NEXT ASSEMBLIES
05/05/2015 MR 00683
G
SWITCHED POSITIONS OF 5550087 AND
5550486, UPDATED NEXT ASSEMBLY
06/16/2016 TS 00765
ITEM NO PART NUMBER DESCRIPTION QTY REV
1 5700031 ZERO ANGLE MOUNTING BRACKET 1 C
2 5590175 PUSH BUTTON AIR VALVE 1 -
3 5530043 SHCS M3 x 0.5 x 30 2 -
4 5545024 WASHER, M3 x 9mm FLAT 2 -
5 5535020 NUT M3 x 0.5, NL CL8 2 -
6 5550087 FTG ELB -04 COMP x -02 NPT 1 -
7 5550486 FTG NPL -02 NPT x -04 F NPT 1 -
NEXT ASSEMBLY
D4-12 SERIES
HD SERIES
HDS SERIES
HDSO SERIES
PL-12000DP
SHEET 1 OF 1
REV
DWG. NO.
A
SIZE
TITLE:
NAME
DATE
CHECKED
DRAWN
G
1645 LEMONWOOD DR.
SANTA PAULA, CA 93060
PROPRIETARY AND CONFIDENTIAL
THE INFORMATION CONTAINED IN THIS DRAWING IS
THE SOLE PROPERTY OF BENDPAK INC. ANY
REPRODUCTION IN PART OR AS A WHOLE WITHOUT
THE WRITTEN PERMISSION OF BENDPAK INC. IS
PROHIBITED.
NOTE: UNLESS OTHERWISE SPECIFIED .
AC
5215096
PUSH BUTTON AIR
ASSEMBLY
03/14/2008
DO NOT SCALE DRAWING
2:3
SCALE:
THIRD ANGLE PROJECTION
CA 09/02/2015
SEE SHIPPING INSTRUCTIONS FOR FINAL PACKAGING 1.
ASSEMBLE ITEMS AS SHOWN 2.

DIMENSIONS ARE IN MM
☺
3
2
1
4
REVISION
REV DESCRIPTION DATE EDITED BY ECO#
F UPDATED BOM REVISIONS 05/10/2017 TS 00829
G UPDATED BOM REVISION AND NEXT ASSEMBLY 12/28/2017 TM 00909
H UPDATED BOM REVISION 10/10/2018 CA 00945
ITEM
NO
PART
NUMBER
DESCRIPTION QTY REV
1 5620202 HDS-18/27 CYLINDER FLANGE ARM WELDMENT 1 E
2 5716153 HDS-18/27/40 SERIES ALIGNMENT BLOCK 2 E
3 5530095 BHPS M6 x 1 x 30mmL 4 -
4 5535357 NUT M6 x 1.0 NL 4 -
NEXT ASSEMBLY
5215157
5215164
5215657
5215689
SHEET 1 OF 1
REV
DWG. NO.
A
SIZE
TITLE:
NAME
DATE
CHECKED
DRAWN
H
1645 LEMONWOOD DR.
SANTA PAULA, CA 93060
PROPRIETARY AND CONFIDENTIAL
THE INFORMATION CONTAINED IN THIS DRAWING IS
THE SOLE PROPERTY OF BENDPAK INC. ANY
REPRODUCTION IN PART OR AS A WHOLE WITHOUT
THE WRITTEN PERMISSION OF BENDPAK INC. IS
PROHIBITED.
NOTE: UNLESS OTHERWISE SPECIFIED .
GJZ
5215159
HDS-18/27 SERIES CYLINDER
FLANGE ARM ASSEMBLY
10/21/2008
DO NOT SCALE DRAWING
1:4
SCALE:
THIRD ANGLE PROJECTION
CA 10/30/2018
SEE SHIPPING INSTRUCTIONS FOR FINAL PACKAGING 1.
ASSEMBLE ITEMS AS SHOWN 2.

DIMENSIONS ARE IN MM
☺
1
3
2
ISOMETRIC VIEW
FOR REFERENCE ONLY
DO NOT SCALE
REVISION
REV DESCRIPTION DATE EDITED BY ECO#
H UPDATED BOM REVISIONS AND NEXT ASSEMBLY 06/14/2018 TS 00945
J UPDATED BOM REVISION AND NEXT ASSEMBLIES 10/03/2019 TS 01120
K
REPLACED 5575663, WITH 5716088, REPLACED
5530012, AND 5530035 WITH 5530464, UPDATED
BOM REVISION
08/09/2022 TM 01436
ITEM NO
PART
NUMBER
DESCRIPTION QTY REV
1 5600196 HDS-18/27 EXTENDED DRIVE UP RAMP WELDMENT 1 K
2 5716088 HDS-18/27 APPROACH RAMP EDGE GUARD 1 A
3 5530464 BBSS M10 x 1.5 x 24mm 3 --
NEXT ASSEMBLY
5245086
5245087
5245088
5245089
5245090
WHERE USED
HDS-18 SERIES
HDS-27 SERIES
SHEET 1 OF 1
REV
DWG. NO.
A
SIZE
TITLE:
NAME
DATE
CHECKED
DRAWN
K
1645 LEMONWOOD DR.
SANTA PAULA, CA 93060
PROPRIETARY AND CONFIDENTIAL
THE INFORMATION CONTAINED IN THIS DRAWING IS
THE SOLE PROPERTY OF BENDPAK INC. ANY
REPRODUCTION IN PART OR AS A WHOLE WITHOUT
THE WRITTEN PERMISSION OF BENDPAK INC. IS
PROHIBITED.
NOTE: UNLESS OTHERWISE SPECIFIED .
AC
5215161
HDS-18/27 EXTENDED
DRIVE UP RAMP ASSEMBLY
05/06/2009
DO NOT SCALE DRAWING
1:10
SCALE:
THIRD ANGLE PROJECTION
OR
08/16/2022
REFER TO MODEL FOR ADDITIONAL INFORMATION 1.
SEE COLORS & GRAPHICS FOR LABEL PLACEMENT 2.
SEE SHIPPING INSTRUCTIONS FOR FINAL PACKAGING 3.
ASSEMBLE ITEMS AS SHOWN 4.

5385
3 1 2
REVISION
REV DESCRIPTION DATE EDITED BY ECO#
A PRODUCTION RELEASE 08/27/2008 AC 00235
B
B-001
UNOBSOLETE DUE TO USE IN HDS-27/27A,
CHANGED LENGTH WAS 3385 NOW 5385,
UPDATED TITLE AND NEXT ASSEMBLY TO
REFLECT WHERE USED
UPDATED NEXT ASSEMBLIES
06/11/2010
05/21/2013
TM
TM
00371
00593
C UPDATED TITLE TO REFLECT WHERE USED 09/18/2015 TM 00724
NEXT ASSEMBLY
5250172
5250173
ITEM NO PART NUMBER DESCRIPTION QTY. REV
1 5570116 Ø10 ID HYDRAULIC HOSE 5325*mm -
2 5550337 FTG ELB -06 CRIMP x -06 JIC 1 -
3 5550336 FTG NPL -06 CRIMP x -06 JIC 1 -
SHEET 1 OF 1
REV
DWG. NO.
A
SIZE
TITLE:
NAME
DATE
CHECKED
DRAWN
C
1645 LEMONWOOD DR.
SANTA PAULA, CA 93060
PROPRIETARY AND CONFIDENTIAL
THE INFORMATION CONTAINED IN THIS DRAWING IS
THE SOLE PROPERTY OF BENDPAK INC. ANY
REPRODUCTION IN PART OR AS A WHOLE WITHOUT
THE WRITTEN PERMISSION OF BENDPAK INC. IS
PROHIBITED.
AC
5570901
HDS-27 HYDRAULIC HOSE
ASSY Ø10 x 5385mm
08/27/2008
DO NOT SCALE DRAWING
1:2
SCALE:
THIRD ANGLE PROJECTION
CA 02/02/2016
DIMENSIONS ARE IN MM
TOLERANCES:
0. = ±1.5
0.0 = ±1.0
0.00 = ±0.25
0.000 = ±0.13
SURFACE FINISH 1.6 ISO Ra µm
FOR MACHINED SURFACES
UNLESS OTHERWISE SPECIFIED
NOTE: UNLESS OTHERWISE SPECIFIED.
FOR ITEM 1 SPECIFICATIONS REFER TO PART SPECIFICATION FORM 1.
(*)ITEM 1 QTY FOR REFERENCE ONLY 2.

29.4
36.0
73.0
10483
10410
2
135
4
REVISION
REV DESCRIPTION DATE EDITED BY ECO#
F
UPDATED TITLE TO REFLECT WHERE USED,
UPDATED NEXT ASSEMBLY
09/18/2015 TM 00724
G UPDATED BOM REVISION 12/28/2017 TM 00909
H
ADDED 5535104 AND 5545415, UPDATED TITLE
AND NEXT ASSEMBLY
07/21/2020 TM 01174
ITEM NO PART NUMBER DESCRIPTION QTY. REV
1 5595190 CABLE, LIFTING 16mm 10330mm* -
2 5746061 Ø16 CABLE BUTTON 1 C
3 5746060 Ø16 THREADED CABLE CONNECTOR 1 A
4 5535104 NUT M30 x 3.5 NL 1 -
5 5545415 WASHER M30 x 56 FLAT 1 -
NEXT ASSEMBLY
5250172
5250286
WHERE USED
HDS-18 SERIES
HDS-27
SHEET 1 OF 1
REV
DWG. NO.
A
SIZE
TITLE:
NAME
DATE
CHECKED
DRAWN
H
1645 LEMONWOOD DR.
SANTA PAULA, CA 93060
PROPRIETARY AND CONFIDENTIAL
THE INFORMATION CONTAINED IN THIS DRAWING IS
THE SOLE PROPERTY OF BENDPAK INC. ANY
REPRODUCTION IN PART OR AS A WHOLE WITHOUT
THE WRITTEN PERMISSION OF BENDPAK INC. IS
PROHIBITED.
AC
5595806
HDS-18/27 CABLE ASSEMBLY
Ø16 x 10483mm ST
05/16/2008
DO NOT SCALE DRAWING
1:2
SCALE:
THIRD ANGLE PROJECTION
DIMENSIONS ARE IN MM
TOLERANCES:
0. = ±1.5
0.0 = ±0.5
SURFACE FINISH 1.6 ISO Ra µm
FOR MACHINED SURFACES
UNLESS OTHERWISE SPECIFIED
NOTE: UNLESS OTHERWISE SPECIFIED .
FOR ITEM 1 SPECIFICATIONS REFER TO PART SPECIFICATION FORM 1.
LENGTH SHOWN IS AFTER SWAGING 2.
ITEM 1 QTY FOR REFERENCE ONLY 3.
THREAD 5535104 WITH 5545415 ONTO CABLES FOR SHIPMENT 4.

29.4
36.0
73.0
12215
12142
2
13
5
4
REVISION
REV DESCRIPTION DATE EDITED BY ECO#
G
UPDATED TITLE TO REFLECT WHERE USED,
UPDATED NEXT ASSEMBLY
09/18/2015 TM 00724
H
WAS 12100 NOW 12142, WAS 12023 NOW
12118, UPDATED BOM REVISION
12/28/2017 TM 00909
J
ADDED 5535104 AND 5545415, UPDATED TITLE
AND NEXT ASSEMBLY
07/21/2020 TM 01174
ITEM NO PART NUMBER DESCRIPTION QTY. REV
1 5595190 CABLE, LIFTING 16mm 12118mm* -
2 5746061 Ø16 CABLE BUTTON 1 C
3 5746060 Ø16 THREADED CABLE CONNECTOR 1 A
4 5535104 NUT M30 x 3.5 NL 1 -
5 5545415 WASHER M30 x 56 FLAT 1 -
NEXT ASSEMBLY
5250172
5250286
WHERE USED
HDS-18 SERIES
HDS-27
SHEET 1 OF 1
REV
DWG. NO.
A
SIZE
TITLE:
NAME
DATE
CHECKED
DRAWN
J
1645 LEMONWOOD DR.
SANTA PAULA, CA 93060
PROPRIETARY AND CONFIDENTIAL
THE INFORMATION CONTAINED IN THIS DRAWING IS
THE SOLE PROPERTY OF BENDPAK INC. ANY
REPRODUCTION IN PART OR AS A WHOLE WITHOUT
THE WRITTEN PERMISSION OF BENDPAK INC. IS
PROHIBITED.
AC
5595807
HDS-18/27 CABLE ASSEMBLY
Ø16 x 12215mm ST
05/16/2008
DO NOT SCALE DRAWING
1:2
SCALE:
THIRD ANGLE PROJECTION
DIMENSIONS ARE IN MM
TOLERANCES:
0. = ±1.5
0.0 = ±0.5
SURFACE FINISH 1.6 ISO Ra µm
FOR MACHINED SURFACES
UNLESS OTHERWISE SPECIFIED
NOTE: UNLESS OTHERWISE SPECIFIED .
FOR ITEM 1 SPECIFICATIONS REFER TO PART SPECIFICATION FORM 1.
LENGTH SHOWN IS AFTER SWAGING 2.
ITEM 1 QTY FOR REFERENCE ONLY 3.
THREAD 5535104 WITH 5545415 ONTO CABLES FOR SHIPMENT 4.

29.4
36.0
73.0
4127
4054
2
1 3 5
4
ITEM NO PART NUMBER DESCRIPTION QTY. REV
1 5595190 CABLE, LIFTING 16mm 3977mm* -
2 5746061 Ø16 CABLE BUTTON 1 C
3 5746060
Ø16mm THREADED CABLE
CONNECTOR
1 A
4 5535104 NUT M30 x 3.5 NL 1 -
5 5545415 WASHER M30 x 56 FLAT 1 -
NEXT ASSEMBLY
5250172
5250175
5250286
REVISION
REV DESCRIPTION DATE EDITED BY ECO#
C
C-001
UPDATED TITLE TO REFELCT WHERE USED AND
NEXT ASSEMBLIES
UPDATED NEXT ASSEMBLIES
08/04/2015
09/18/2015
TM
TM
00683
00724
D
UPDATED TITLE TO REFLECT WHERE USED,
UPDATED BOM REVISION
12/20/2017 TM 00909
E ADDED 5535104 AND 5545415 07/21/2020 TM 01174
WHERE USED
HDS-18 SERIES
HDS-27
HDS-27X
SHEET 1 OF 1
REV
DWG. NO.
A
SIZE
TITLE:
NAME
DATE
CHECKED
DRAWN
E
1645 LEMONWOOD DR.
SANTA PAULA, CA 93060
PROPRIETARY AND CONFIDENTIAL
THE INFORMATION CONTAINED IN THIS DRAWING IS
THE SOLE PROPERTY OF BENDPAK INC. ANY
REPRODUCTION IN PART OR AS A WHOLE WITHOUT
THE WRITTEN PERMISSION OF BENDPAK INC. IS
PROHIBITED.
MT
5595835
HDS-18E/18EA/27 CABLE
ASSEMBLY Ø16 x 4127mm ST
04/19/2011
DO NOT SCALE DRAWING
1:2
SCALE:
THIRD ANGLE PROJECTION
OR 08/28/2020
DIMENSIONS ARE IN MM
TOLERANCES:
0. = ±1.5
0.0 = ±0.5
SURFACE FINISH 1.6 ISO Ra µm
FOR MACHINED SURFACES
UNLESS OTHERWISE SPECIFIED
NOTE: UNLESS OTHERWISE SPECIFIED .
FOR ITEM 1 SPECIFICATIONS REFER TO PART SPECIFICATION FORM 1.
LENGTH SHOWN IS AFTER SWAGING 2.
ITEM 1 QTY FOR REFERENCE ONLY 3.
THREAD 5535104 WITH 5545415 ONTO CABLES FOR SHIPMENT 4.

29.4
36.0
73.0
5855
5782
2
13 5
4
ITEM NO PART NUMBER DESCRIPTION QTY. REV
1 5595190 CABLE, LIFTING 16mm 5702mm* -
2 5746061 Ø16 CABLE BUTTON 1 C
3 5746060
Ø16mm THREADED CABLE
CONNECTOR
1 A
4 5535104 NUT M30 x 3.5 NL 1 -
5 5545415 WASHER M30 x 56 FLAT 1 -
REVISION
REV. DESCRIPTION DATE EDITED BY ECO#
C
C-001
UPDATED TITLE TO REFELCT WHERE USED AND
NEXT ASSEMBLIES
UPDATED NEXT ASSEMBLIES
08/04/2015
09/18/2015
TM
TM
00683
00724
D
UPDATED TITLE TO REFLECT WHERE USED,
UPDATED BOM REVISION
12/20/2017 TM 00909
E
ADDED 5535104 AND 5545415, UPDATED NEXT
ASSEMBLY
07/21/2020 TM 01174
NEXT ASSEMBLY
5250172
5250175
5250286
WHERE USED
HDS-18 SERIES
HDS-27
HDS-27X
SHEET 1 OF 1
REV
DWG. NO.
A
SIZE
TITLE:
NAME
DATE
CHECKED
DRAWN
E
1645 LEMONWOOD DR.
SANTA PAULA, CA 93060
PROPRIETARY AND CONFIDENTIAL
THE INFORMATION CONTAINED IN THIS DRAWING IS
THE SOLE PROPERTY OF BENDPAK INC. ANY
REPRODUCTION IN PART OR AS A WHOLE WITHOUT
THE WRITTEN PERMISSION OF BENDPAK INC. IS
PROHIBITED.
MT
5595836
HDS-18E/18EA/27 CABLE
ASSEMBLY Ø16 x 5855mm ST
04/19/2011
DO NOT SCALE DRAWING
1:2
SCALE:
THIRD ANGLE PROJECTION
OR 08/28/2020
DIMENSIONS ARE IN MM
TOLERANCES:
0. = ±1.5
0.0 = ±0.5
SURFACE FINISH 1.6 ISO Ra µm
FOR MACHINED SURFACES
UNLESS OTHERWISE SPECIFIED
NOTE: UNLESS OTHERWISE SPECIFIED .
FOR ITEM 1 SPECIFICATIONS REFER TO PART SPECIFICATION FORM 1.
LENGTH SHOWN IS AFTER SWAGING 2.
ITEM 1 QTY FOR REFERENCE ONLY 3.
THREAD 5535104 WITH 5545415 ONTO CABLES FOR SHIPMENT 4.
