BenQ Joybook Lite U122 Eco User manual

Joybook Lite
U122 Eco Series
User Manual
JBL_U122_Eco_UM_EN.book Page i Monday, October 12, 2009 2:39 PM

Copyright and trademark
Copyright 2009 by BenQ Corporation. All rights reserved. No
part of this publication may be reproduced, transmitted,
transcribed, stored in a retrieval system or translated into any
language or computer language, in any form or by any means,
electronic, mechanical, magnetic, optical, chemical, manual or
otherwise, without the prior written permission of this
company.
For the latest user manual, visit
http://www.BenQ.com.
All other logos, products, or company names mentioned in this
manual may be the registered trademarks or copyrights of their
respective companies, and are used for informational purposes
only.
Windows, Internet Explorer, and Windows Mail are trademarks
of Microsoft Corporation. Others are copyrights of their
respective companies or organizations.
is a trademark of SRS Labs, Inc. TruSurround
HD and CS Headphone technologies are
incorporated under license from SRS Labs, Inc.
Disclaimer
BenQ Corporation makes no representations or warranties,
either expressed or implied, with respect to the contents hereof
and specifically disclaims any warranties, merchantability, or
fitness for any particular purpose. Further, BenQ Corporation
reserves the right to revise this publication and to make changes
from time to time in the contents hereof without obligation of
this company to notify any person of such revision or changes.
It is the sole responsibility of the user if problems (such as data
loss and system failure) occurred due to non-factory installed
software, parts, and/or non-original accessories.
Joybook Lite models covered
by this manual
This manual contains the information about the following
Joybook Lite model:
• Joybook Lite U122 Eco Series (DH1200)
Please note that the actual hardware or software capabilities will
vary according to the model you purchased. To determine your
Joybook Lite model, refer to the label on the packing box, or the
printing on your Joybook Lite.
Ver.: 10/12/2009
JBL_U122_Eco_UM_EN.book Page ii Monday, October 12, 2009 2:39 PM

Table of Contents iii
Table of Contents
Overview ......................................................................................... 1
About this book...........................................................................1
Typographics...............................................................................2
Getting started................................................................................ 3
Package contents.........................................................................3
Getting your Joybook Lite ready for use....................................3
Saving power of your Joybook Lite......................................5
Expanding the capabilities of your Joybook Lite.......................6
Touring your Joybook Lite ............................................................ 8
Front view ................................................................................8
Left side view ...............................................................................9
Right side view ..........................................................................10
Bottom view ..............................................................................12
Indicators...................................................................................13
Getting started with Windows 7.................................................. 15
Turning off Joybook Lite properly or selecting other options15
Using Windows Mobility Center .............................................16
Using your Joybook Lite .............................................................. 17
Using the touchpad...................................................................17
Using the keyboard ...................................................................19
Function hotkeys ................................................................19
Windows key shortcuts and other keys .............................21
Using built-in wireless connectivity (select models only) ......23
Connecting to a wireless network......................................23
Using Bluetooth (optional accessory)......................................25
Connecting to a Bluetooth device......................................25
Sending a file to a Bluetooth device .................................. 28
Using the built-in webcam....................................................... 30
Activating WebCam Companion 3................................... 30
Using WebCam Companion 3 .......................................... 31
Switching to different modules ................................... 31
Capturing still images or recording videos................. 31
Using the Masque function ......................................... 32
Photo Booth ................................................................. 32
Video chat........................................................................... 32
Adjusting the screen........................................................... 32
Using Magic-i Visual Effects.............................................. 33
Adjusting resolution .................................................... 33
Using SRS.................................................................................. 34
Recovering your system using QDataTrove............................... 36
Introduction to QDataTrove ................................................... 36
How to launch QDataTrove .................................................... 37
Using QDataTrove in Windows 7 ........................................... 37
Backing up your system ..................................................... 37
Backing up your system into a single file.................... 37
Backing up your system into a disc............................. 38
Creating a restore point ............................................... 38
Restoring your system........................................................ 39
Restoring your system to factory default settings....... 39
Restoring your system to your own backup system
image............................................................................. 39
Restoring your system from a restore point ............... 39
JBL_U122_Eco_UM_EN.book Page iii Monday, October 12, 2009 2:39 PM

Table of Contentsiv
Reinstalling bundled applications and drivers............40
Creating recovery discs or Application and Driver DVD .40
Creating a Factory Recovery CD/DVD........................40
Creating a User Recovery CD/DVD ............................41
Creating an Application and Driver DVD ..................41
Creating bootable USB flash disk.................................42
Protecting your Joybook Lite from viruses and other security
threats ........................................................................................43
Using BIOS setup ......................................................................... 44
When and how to use BIOS setup............................................44
Navigating the BIOS setup screen ............................................45
Information menu ..............................................................46
The Information menu contains information about BIOS
version, CPU data, memory status, etc..............................46
Main menu..........................................................................46
Security menu .....................................................................46
Boot menu...........................................................................47
Exit menu ............................................................................47
Replacing the memory ................................................................. 48
FAQ and troubleshooting............................................................ 52
Battery and power .....................................................................52
Connection ................................................................................53
System ........................................................................................54
Display .......................................................................................58
Cleaning and battery maintenance ............................................. 60
Battery maintenance .................................................................60
Cleaning your Joybook Lite......................................................60
Service and support...................................................................... 61
BenQ Joybook Lite Global Online Service...............................61
Joybook/Joybook Lite Overseas Regional Warranty (ORW)
online registration..................................................................... 61
Appendix....................................................................................... 62
General safety information....................................................... 62
Safety information about the battery....................................... 62
Safety information about the power adapter .......................... 63
Disposal of Waste Electrical and Electronic Equipment by users
in private households in the European Union........................ 63
Declaration of Conformity ...................................................... 64
Safety instructions for Poland, Romania, Slovenia, Bulgaria,
Latvia, and Croatia.................................................................... 65
BenQ Authorized Distributors in Turkey ............................... 68
JBL_U122_Eco_UM_EN.book Page iv Monday, October 12, 2009 2:39 PM

Overview 1
Overview
About this book
This book provides you the main information about various
components in your Joybook Lite and demonstrates how to use
them. The following are the major chapters of this book.
Chapter title Description
Overview Introduction to this book
Getting started Information about beginning to
use your Joybook Lite
Touring your Joybook
Lite
Introduction to the hardware
components of your Joybook
Lite
Getting started with
Windows 7
Basic information about
Windows 7
Using your Joybook
Lite
Information about operating
your Joybook Lite
Using BIOS setup Information about how to use
the BIOS setup utility
Recovering your
system using
QDataTrove
Information about using system
backup and restore tools
Replacing the
memory
Information about how to
replace RAM memory
FAQ and
troubleshooting
Information about frequently
asked questions and
troubleshooting
Cleaning and battery
maintenance
Information about cleaning and
battery maintenance
Service and support Information about Joybook Lite
service and support
Appendix Important safety information
JBL_U122_Eco_UM_EN.book Page 1 Monday, October 12, 2009 2:39 PM

Overview2
Typographics
The usage of notes, tips, and warnings in this manual is
specifically for different purposes, which are described as
follows:
When you first set up your Joybook Lite, you may want to find
more information on setups. Refer to the user manual that is
supplied with your operating system, or search from Help and
Support in the Start menu in Windows 7.
In this book, the steps needed to reach a menu are shown in
condensed form, for example: Start > Help and Support. The
Control Panel options mentioned are organized by the default
category view.
Icon/
Symbol
Item Meaning
Warning Information mainly to
prevent the damage to
components, data, or
personal injury caused by
misuse and improper
operation or behavior.
Tip Useful information for
completing a task.
Note Supplementary information.
< > or [ ] Keys on the
keyboard; User
Interface (UI)
on the screen
Indicates a key on the
keyboard, or the UI on the
screen. Do not actually type
the symbols together with
the enclosed letters.
JBL_U122_Eco_UM_EN.book Page 2 Monday, October 12, 2009 2:39 PM

Getting started 3
Getting started
Package contents
Before using your Joybook Lite for the first time, please check if
you have all the items with you. For details about what should
be included in the package, refer to the Product Specification
label on the product carton. If any of the items are missing or
appear damaged, contact your dealer immediately. Save the
packaging in case you need to ship your Joybook Lite for
service.
Getting your Joybook Lite
ready for use
1. Installing the battery pack
Close the lid of your Joybook Lite (if open). Turn your Joybook
Lite upside down and place it on a soft clean cloth. With the
label side of the battery pack facing down, slide it gently into the
battery compartment until it snaps into place (1). Move
“Battery retainer A” to the right as shown to lock the battery
pack into place (2).
Depending on the model of your Joybook Lite, the appearance
may be different from the illustrations shown in this manual.
Battery retainer A
JBL_U122_Eco_UM_EN.book Page 3 Monday, October 12, 2009 2:39 PM

Getting started4
2. Connecting the power
a. Connect the power cord to the power adapter.
b. Connect the power adapter to the power jack on your
Joybook Lite.
c. Connect the power cord to a power outlet. The
Joybook Lite will automatically start charging the
battery.
3. Opening your Joybook Lite
Gently lift up the latchless lid that allows you to open the case
easily.
• The battery pack is shipped with low charge from the factory.
You can still use your Joybook Lite while the battery is
charging.
• Power systems and plug types may vary depending on your
country/region.
• When the battery is charging, the battery indicator lights up in
amber. When the battery is fully charged, the light goes off.
• For details about the colors and meanings of the indicators,
refer to "Indicators" on page 13.
JBL_U122_Eco_UM_EN.book Page 4 Monday, October 12, 2009 2:39 PM

Getting started 5
4. Performing initial setup
Press the Power button to start up your Joybook Lite, the Power
button indicator then lights up in white. And then follow the
on-screen instructions to complete the initial Windows 7 setup.
Saving power of your Joybook Lite
Your Joybook Lite features a Power Save mode that allows you
to save power by decreasing backlight brightness and switching
off certain functions and devices quickly.
To activ a te the Power Save mode, press the <Fn> + <F12>
hotkey combination. By default, the following functions and
devices will be switched off immediately.
• Wireless LAN (WLAN)
• Bluetooth
• 3G connection
• Webcam
In addition, the following settings will be changed at the same
time as preset in BIOS setup menu.
• Backlight brightness
• CPU throttling (which decides the frequency scaling of the
CPU and conserves power if the percentage is decreased)
If you intend to keep some functions or devices on during
Power Save mode, do one of the following:
• Press the hotkey combinations to activate the designated
functions manually. Refer to "Function hotkeys" on page 19
for details. The enabled functions remain on after the Power
Save mode is deactivated. Yet they will be off if the Power
Save mode is activated again.
• In BIOS setup menu, go to Advanced > Power save. Select
to enable the desired function. For more information on
BIOS, refer to "Using BIOS setup" on page 44.
• Your Joybook Lite U122 Eco Series works best with the
operating system pre-installed for you. Installing other
operating systems that have not been tested is not
recommended, and may not only void your warranty but also
affect the functionality of your Joybook Lite.
• The actual operating system that comes with your Joybook
Lite may vary. For details, refer to the Product Specification
label on the product carton
Important:
It is strongly recommended to create Factory Recovery DVD
immediately once your Joybook Lite is ready for use. Refer to
"Creating a Factory Recovery CD/DVD" on page 40 for details.
JBL_U122_Eco_UM_EN.book Page 5 Monday, October 12, 2009 2:39 PM

Getting started6
Expanding the capabilities of your Joybook Lite
Connect an external display device (such as a monitor or
projector) to the 15-pin D-sub video jack of your Joybook Lite
with a VGA cable.
Connect USB peripherals to the USB ports of your Joybook Lite.
Insert a Memory Stick, Memory Stick Pro, MMC, and SD
memory card following the direction indicated on the card to
exchange files.
Pay attention to the plug direction when making the following
connections. Incorrect direction may cause damage to the
device.
To switch to the external display device or simultaneous
display, press the <Fn> + <F3> hotkey combination.
JBL_U122_Eco_UM_EN.book Page 6 Monday, October 12, 2009 2:39 PM

Getting started 7
Connect an earphone to the audio output jack to output
sounds.
Connect a microphone to the microphone input jack to record
sounds.
Access local area network (LAN) by connecting a network cable
to the LAN port of your Joybook Lite.
JBL_U122_Eco_UM_EN.book Page 7 Monday, October 12, 2009 2:39 PM

Touring your Joybook Lite8
Touring your Joybook Lite
Front view
(1)
(3)
(6)(5)
(4)
(2)
(7)
No. Front components
(1) Built-in webcam
A built-in webcam that allows you to capture still
images, record videos, and chat online. For
details, refer to "Using the built-in webcam" on
page 28.
(2) Built-in microphone
Receives sounds and voices for recording.
(3) LCD (Liquid Crystal Display) panel
(4) Keyboard
(5) Indicators
Refer to "Indicators" on page 13 for details.
(6) Touchpad
Refer to "Using the touchpad" on page 17 for
details.
(7) Power button
Turns your Joybook Lite on or off.
JBL_U122_Eco_UM_EN.book Page 8 Monday, October 12, 2009 2:39 PM

Touring your Joybook Lite 9
Left side view
(1) (2) (3) (4)
No. Left-side components
(1) Power jack
Connects AC power supply to power the Joybook
Lite and charge the battery.
(2) Vents
Dissipate heat and keep your Joybook Lite at an
optimal temperature.
To prevent overheating, do not obstruct the vents. For
example, do not use the Joybook Lite in bed where a
blanket may inadvertently cover the vents and block
the airflow.
(3) 15-pin D-sub video jack
Connects external display devices, such as
monitors and projectors.
(4) USB port
Connects peripherals such as mice, digital
cameras and MP3 players that use the USB 2.0
interface.
JBL_U122_Eco_UM_EN.book Page 9 Monday, October 12, 2009 2:39 PM

Touring your Joybook Lite10
Right side view
(2)(1) (3) (4) (5) (6)
No. Right-side components
(1) Four-in-One memory card slot
For a Memory Stick, Memory Stick Pro, SD or
MMC memory card.
(2) Audio output jack
Connects to an earphone/headset or external
speaker for playing the Joybook Lite audio.
(3) Microphone input jack
Connects to a microphone for recording sounds.
This jack is for 3.5mm analog audio plugs. It accepts
both mono and stereo plugs.
(4) USB port
Connects peripherals such as mice, digital
cameras and MP3 players that use the USB 2.0
interface.
(5) LAN (Local Area Network) port (RJ-45
connector)
Allows the Joybook Lite to connect to a 10/
100Mbps fast Ethernet 100BASE-T network.
Please be careful to avoid plugging a RJ-11 phone
cable connector in the RJ-45 port. This will damage
the LAN port. They look similar, but the RJ-45
connector is wider than the RJ-11 connector, and has
more conductors.
JBL_U122_Eco_UM_EN.book Page 10 Monday, October 12, 2009 2:39 PM

Touring your Joybook Lite 11
(6) Anti-theft Kensington lock slot
Attaches to an anti-theft Kensington lock and
cable to help prevent possible theft.
JBL_U122_Eco_UM_EN.book Page 11 Monday, October 12, 2009 2:39 PM

Touring your Joybook Lite12
Bottom view
No. Bottom components
(1) Battery pack
Supplies power to the Joybook Lite when external
power is not connected.
(2) Battery retainers
Secure the battery in place.
(1)
(2)
(3)
(4)
(3) Memory expansion slot cover
Inside the cover, you can find the memory slot of
the Joybook Lite. You can replace the existing
memory module of your Joybook Lite from here.
• To remove the cover, a small Phillips head
screwdriver is required.
• For more information about replacing the memory
module, the limit of maximum memory, or the types
of BenQ certified memory modules for your Joybook
Lite, refer to "Replacing the memory" on page 48.
(4) Speakers
JBL_U122_Eco_UM_EN.book Page 12 Monday, October 12, 2009 2:39 PM

Touring your Joybook Lite 13
Indicators
No. Indicators
(1) Power button indicator
• When the system is on, it lights up in blue.
• When the system is in Sleep mode, it lights up in
amber.
• When the system is off or in Hibernation mode,
the light goes off.
(1)
No. Indicators
(2) Wireless LAN (WLAN)/Bluetooth indicator
• When WLAN is turned on, it lights in blue.
• When Bluetooth is turned on, it lights up in
amber.
• When both WLAN and Bluetooth are turned on,
it lights up in purple.
• When both WLAN and Bluetooth are turned off,
the light goes off.
(3) System status indicator
• When the system is on, it lights up in blue.
• When the system is in Sleep mode, it lights up in
amber.
• When the system is off for Hibernation, the light
goes off.
(2) (3) (4) (5) (7)(6)
JBL_U122_Eco_UM_EN.book Page 13 Monday, October 12, 2009 2:39 PM

Touring your Joybook Lite14
(4) Battery indicator
• When the battery is charging, it lights up in
amber.
• When the battery is fully charged, the light goes
off.
• When the battery is in use, it lights up in blue.
• When the battery is running low, it blinks in blue.
• When the battery is not working properly, it
flashes in amber.
(5) Hard disk/SSD activity indicator
Flashes in blue when the Joybook Lite is
accessing data in the hard disk or/and SSD.
(6) Caps Lock indicator
Lights up in blue when the <Caps Lock> key is
enabled.
(7) Num Lock indicator
Lights up in blue when the <Num Lk> key is
enabled.
JBL_U122_Eco_UM_EN.book Page 14 Monday, October 12, 2009 2:39 PM

Getting started with Windows 7 15
Getting started with Windows 7
If you are using Windows 7 on your Joybook Lite, you may want
to find information about the following topics. Refer to the user
manual that is supplied with your operating system, or search
from Help and Support in the Start menu.
• How to set the system region settings, date, and time.
• How to set system administrator and user security logins and
settings.
• How to install, setup and run anti-virus software.
• How to name the computer for network identification.
• How to connect to a local network wirelessly or by cable.
• How to connect to another computer over a network and share
files.
• How to connect with a network or shared printer.
• How to connect to the Internet.
• How to register Windows and other packaged software.
• How to update Windows with the latest service packs and
security patches.
• How to synchronize the system clock with an Internet time
server.
• How to locate, download, and install latest system device
drivers.
• How to setup scheduled events for system maintenance.
Turning off Joybook Lite
properly or selecting other
options
To turn off Joybook Lite, click Start > . You can also
click to the right of and choose other options
as shown below:
Alternatively, you can customize power settings using the steps
below:
1. Right-click the battery meter icon ( or ) in the
notification area located in the lower right corner of the
desktop, and then click Power Options.
2. On the Select a power plan screen, click Change plan
settings under the selected plan.
3. Click Change advanced power settings.
JBL_U122_Eco_UM_EN.book Page 15 Monday, October 12, 2009 2:39 PM

Getting started with Windows 716
4. On the Advanced settings tab, double-click Power
buttons and lid to expand this category.
5. Double-click Lid close action and Power button action
to expand these items.
6. To specify the action to take when you close the lid of your
Joybook Lite or press the Power button, click On battery or
Plugged in, and then select the desired setting from the
drop-down list.
Using Windows Mobility
Center
Windows Mobility Center is a convenient location where you
can quickly access your Joybook Lite's settings, such as volume,
battery status, and wireless network, etc.
To open Windows Mobility Center, press the + <X>
hotkey combination, or do one of the following:
• Click Start > Control Panel > Adjust commonly used
mobility settings (under Hardware and Sound).
• Right-click the battery meter icon ( or ) in the
notification area located in the lower right corner of the
desktop, and then click Windows Mobility Center.
JBL_U122_Eco_UM_EN.book Page 16 Monday, October 12, 2009 2:39 PM
