FP785
LCD Color Monitor
17.0" LCD Panel Size
User’s Manual
Welcome

2
Copyright
Copyright © 2004 by BENQ Corporation. All rights reserved. No part of this publication may be
reproduced, transmitted, transcribed, stored in a retrieval system or translated into any language
or computer language, in any form or by any means, electronic, mechanical, magnetic, optical,
chemical, manual or otherwise, without the prior written permission of BENQ Corporation.
Disclaimer
BENQ Corporation makes no representations or warranties, either expressed or implied, with
respect to the contents hereof and specifically disclaims any warranties, merchantability or fitness
for any particular purpose. Further, BENQ Corporation reserves the right to revise this
publication and to make changes from time to time in the contents hereof without obligation of
BENQ Corporation to notify any person of such revision or changes.
Please follow these safety instructions for best
performance, and long life for your monitor
Power Safety
•The AC plug isolates this equipment from the AC supply.
•The power supply cord serves as a power disconnect device for pluggable equipment. The socket
outlet should be installed near the equipment and be easily accessible.
•This product should be operated from the type of power indicated on the marked label. If you are
not sure of the type of power available, consult your dealer or local power company.
Care And Cleaning
•Cleaning. Always unplug your monitor from the wall outlet before cleaning. Clean the LCD
monitor surface with a lint-free, non-abrasive cloth. Avoid using any liquid, aerosol or glass
cleaners.
•Slots and openings on the back or top of the cabinet are for ventilation. They must not be blocked
or covered. Your monitor should never be placed near or over a radiator or heat source, or in a
built-in installation unless proper ventilation is provided.
•Never push objects or spill liquid of any kind into this product.
Servicing
•Do not attempt to service this product yourself, as opening or removing covers may expose you to
dangerous voltages or other risks. If any of the above mentioned misuse or other accident such as
dropping or mishandling occurs, contact qualified service personnel for servicing.
i
ii
iii

Table of Contents 3
Table of Contents
Getting started ...................................................................................................................... 5
Getting to know your Monitor ............................................................................................ 7
Front View ..................................................................................................................7
Back View (1) ...............................................................................................................7
Back View (2): Locations of plugs & sockets ..............................................................8
How to install your monitor hardware ............................................................................... 9
Using the Monitor Mounting Kit (Optional) ..........................................................11
Adjusting the viewing angle ......................................................................................12
How to install your monitor’s software ............................................................................ 13
Choosing the best picture resolution ................................................................................. 36
How to choose the right Refresh Rate ............................................................................... 38
How to set the Picture Optimization ................................................................................ 41
How to adjust your Monitor .............................................................................................. 42
A Look at the Control Panel .....................................................................................42
Hot Key Mode ...........................................................................................................42
Main Menu Mode ......................................................................................................43
Troubleshooting ................................................................................................................. 52
Frequently Asked Questions (FAQ) .........................................................................52
Need More Help? .......................................................................................................53
Supported operating modes ............................................................................................... 54
Specifications ...................................................................................................................... 55
i

Table of Contents4

5Getting started
Getting started
When unpacking please check you have the following items. If they are missing or are damaged,
please immediately contact the dealer at which you purchased the goods.
1
BenQ LCD Monitor
Quick Start Guide
CD-ROM Disk
Power Cord
Power Adapter
Signal Cable: D-Sub

6 Getting started
Signal Cable: DVI-D
Audio Cable

7Getting to know your Monitor
Getting to know your Monitor
Front View
1. “Mode” key
2. X(Right) key
3. "Enter" key
4. “Exit” key
5. W(Left) key
6. “ iKey ”
For more information about these keys, please refer to Chapter 8 - “How to adjust your monitor.”
Back View (1)
2

8 Getting to know your Monitor
Back View (2): Locations of plugs & sockets
1. Audio Connector
2. Power AC Input Jack
3. DVI-D Connector
4. D-Sub Connector

9How to install your monitor hardware
How to install your monitor hardware
Please go along with the following steps to install your LCD monitor.
3
1. Unpack the monitor and remove the stuff filling in
the seams. Then place the monitor face down on a
stable surface and release the locks to detach the back
cover.
Note: Place the foam packing sheet from the monitor on
the flat surface to prevent damage to the bezel.
2. Connect the signal cables (D-Sub and DVI-D) to the monitor as shown.
3. Connect the other end of the signal cable to your
computer as shown.

10 How to install your monitor hardware
4. Connect the power adaptor plug to your monitor as
shown.
5. Connet your monitor and computer with the audio
cable.
6. Put the back cover back and then separate the legs of
the stand and place the monitor on a stable surface.
7. Connect the Power Cord to the power adaptor then
plug the other end into a nearby wall socket. (Use
only power supplies listed in the user’s manual)

11How to install your monitor hardware
Using the Monitor Mounting Kit (Optional)
Your FP785 allows "Location Free" installation. You may wish to mount your LCD monitor to the
wall after completing the installtion procedures above. Before starting to install a monitor
mounting kit, please read the precautions carefully.
Note: This funtion is available for PC application only.
Precautions
•Install your monitor and monitor mounting kit on a wall with flat surface.
•Ensure that the wall material is stable to support the weight of the monitor. It is recommended
that you consult a qualified tradesman prior to mounting the device.
•To avoid the possiblity of damage, use the provided materials to complete the installation.
Installing the Pivot software
1. Execute "START_PIVOT.EXE" from the folder named "Pivot" on the provided CD.
2. Follow the on-screen instructions to install the software.
3. After restarting your sytem, you will see a Pivot Software Control icon, , appearing in the
system tray. Click on the icon and choose "Rotate 180 degrees", , to pivot the display. To
cancel this action, choose "Rotate 0 degree" , .
4. Turn the power off and keep following the steps below..
8. Press the Power button on the side panel of the
monitor. The power indicator will light up.

12 How to install your monitor hardware
Installing the monitor mounting kit
1. Adhere the mounting position reference chart to the wall.
2. Use a suitable drill and bit to drill two holes inon the wall according to the reference chart.
3. Insert the supplied screws into the holes and then attach the monitor mounting kit to the wall.
4. Mount the LCD panel to the fixed monitor mounting kit. Now you may turn the monitor
power on.
Adjusting the viewing angle
Your LCD monitor is designed with a tilt feature that allows you to achieve your optimal viewing
angle.
1
23
4

13How to install your monitor’s software
How to install your monitor’s software
You need to set up the correct monitor driver to suit your operating system.
Windows 98, turn to page 13.
Windows 2000, turn to page 19.
Windows ME, turn to page 26.
Windows XP, turn to page 32.
Windows 98. To manually install or update the driver, perform the following steps:
1. Open the control panel and double-click “Display” icon.
4

14 How to install your monitor’s software
2. From the “Display Properties” window, select the “Settings” tab. Click the “Advanced...” button in
the bottom right corner.

15How to install your monitor’s software
3. Select the “Monitor” tab. Click the “Change” button in the top right corner.
4. The “Update Device Driver Wizard” opens. Confirm by clicking “Next”.

16 How to install your monitor’s software
5. Select “Display a list of all drivers in a specific location, so you can select the driver you want.” and
press “Next”.
6. Now click the “Have Disk” button in the bottom right corner. Another window appears. Select the
“Browse” button.

17How to install your monitor’s software
7. Insert the supplied CD into your computer. Select the CD-drive from the drop-down menu.
8. By pressing “OK” again in the next window you will be given a list of compatible devices. Select
“FP785” from the list and press “Next” again.

18 How to install your monitor’s software
9. An “Insert Disk” dialogue box appears. Click “OK”, and then click “Skip File”.
10. Close “Update Device Driver Wizard” by clicking “Finish” to complete the installation.

19How to install your monitor’s software
Windows 2000. The first time you start Windows with a new monitor, the system will detect it and
automatically start the “Add New Hardware Wizard”. Carry out the instructions beginning at step
4.
1. Insert “BenQ LCD Monitor” CD-ROM into your CD-ROM Driver.
2. Click “Start” then “Settings”.
3. Open the Control Panel and double click on the “Display” icon.

20 How to install your monitor’s software
4. From the “Display Properties” window, select the “Settings” tab. Click the “Advanced Properties”
button in the bottom right corner.
