BenQ MX720 User manual

BenQ America Corp.
15375 Barranca Parkway. Suite A-205. Irvine, CA 92618 Tel: [phone] www.BenQ.us
BenQ is a registered trademark of BenQ Corp. DLP®is a registered trademark of Texas Instruments. All rights reserved.
Product names, logos, brands, and other trademarks featured or referred to in this materials are the property of their respective trademark holders.
Specifications subject to change without notice.
1
2
3
4
5
6
7
RS232 (DB-9pin)
LAN (RJ45)
USB (Type Mini B)
HDMI
Audio Out (Mini Jack)
Monitor Out (D-sub 15pin)
Computer In 1 & 2 (D-sub 15pin)
S-Video In (Mini DIN 4pin)
Audio In L/R (RCA)
Audio In (Mini Jack)
Composite Video In (RCA)
Microphone in
123456789
11
10
12
8
9
10
11
12
I
MX720
DIGITAL
PROJECTOR
Features Specications
Native XGA (1024 x 768) Resolution
3,500 ANSI Lumens, 13,000:1 Contrast Ratio
Up to 6,000 Hours Long Lamp Life
SmartEco™ Power Saving Technology
LAN control and LAN display function
Projection System
Native Resolution
Brightness
Contrast Ratio
Display Color
Lens
Aspect Ratio
Throw Ratio
Image Size (Diagonal)
Zoom Ratio
Lamp Type
Lamp Life
Keystone Adjustment
Projection Offset
Resolution Support
Horizontal Frequency
Vertical Scan Rate
Compatibility
Interface
Dimensions (WxHxD)
Weight
Power Supply
Power Consumption
Audible Noise
On-Screen Display
Languages
Picture Modes
Accessories (Standard)
Accessories (Optional)
UPC Code
Limited Warranty
DLP®
XGA(1024x768 )
3,500AL
13,000:1
1.07 Billion Colors
F2.54~2.73, f=18.18~21.84
Native 4:3 (5 aspect ratio selectable)
1.64-1.97(60”@ 2m)
37’’- 300’’
1.2:1
240W
3500/5000/6000 hours (Normal/Eco/SmartEco)
1D, Vertical +/- 40 degrees
110%±5%
VGA(640 x 480) to UXGA(1600 x 1200)
15-102KHz
23-120Hz
HDTV Compatibility: 480i, 480p, 576i, 576p, 720p, 1080i, 1080p
Video Compatibility: NTSC, PAL, SECAM
Computer in (D-sub 15pin) x 2(Share with component)
Monitor out (D-sub 15pin) x 1
Composite Video in (RCA) x 1
S-Video in (Mini DIN 4pin) x 1
HDMI x 1
Audio in (Mini Jack) x 2
Audio in (L/R) x 1
Audio out (Mini Jack) x 1
Microphone in (Mini Jack) x 1
Speaker 10W x 1
USB (Type mini B) x1 (Download & page/down)
RJ45 x 1 (LAN Control & LAN Display)
RS232 (DB-9pin) x 1
IR Receiver x 2 (Front + Real)
12.24” x 4.09” x 9.6”
6.41 lbs (2.9 kgs)
AC100 to 240V, 3.5A, 50 to 60 Hz
375W(Max), Standby<0.5W
33/30 dBA (Normal/Economic mode)
Arabic/Bulgarian/ Croatian/ Czech/ Danish/ Dutch/ English/ Finnish/
French/ German/ Greek/ Hindi/ Hungarian/ Italian/ Indonesian/
Japanese/ Korean/ Norwegian/ Polish/ Portuguese/ Romanian/
Russian/ Simplied Chinese/Spanish/ Swedish/ Turkish/ Thai/
Traditional Chinese (28 Languages)
Dynamic/Presentation/sRGB/Cinema/User 1/User 2
Lens Cover, Remote Control w/ Battery, Power Cord, User Manual CD,
Quick Start Guide, Warranty Card, Carry bag, VGA(D-sub 15pin) Cable
Spare Lamp Kit 5J.J6E05.001
Ceiling Mount 5J.J4N10.001
3D glasses 5J.J7K25.001
Case 5J.J3T09.001
8400460-2497-0
3-Years Parts & Labor / 1-Year or 2000 hours of lamp life
MX720 02-06-13-BQus
*Lamp life results will vary depending on environmental conditions and usage. Actual product’s features and specications are
subject to change without notice.
Input and Output Terminals

Screen Size Distance from screen (in) Vertical
offset
(in)
Diagonal W (in) H (in) Min length Average Min length
Inch mm (Max zoom) (Max zoom)
40 1016 24 32 52.4 57.7 62.9 1.18
50 1270 30 40 65.6 72.1 78.7 1.49
60 1524 36 48 78.7 86.6 94.4 1.81
70 1778 42 56 91.8 101.0 110.2 2.08
80 2032 48 64 105 115.4 125.9 2.40
90 2286 54 72 118.1 129.9 141.7 2.71
100 2540 60 80 131.2 144.3 157.4 2.99
120 3048 72 96 157.4 173.2 188.9 3.58
150 3810 90 120 196.8 216.5 236.2 4.48
200 5080 120 160 262.4 288.7 314.9 5.98
250 6350 150 200 328.0 360.9 393.7 7.51
300 7620 180 240 393.7 433.0 472.4 9.01
Distance Chart
Wall Mount Chart
Dimensions
MX720 Digital Projector
4.09”
12.24”
9.6”
Unit: inch
Ceiling Mount screw: M4
(Max L = 25 mm; Min L = 20 mm)
The screen aspect ratio is 4:3
and the projected picture is 4:3
