BenQ PB8220 - XGA DLP Projector User manual

PB8220
SERVICE MANUAL
CONTENT
Chapter 1：Engineering Specification 1
1. Appendix A Optical Measurement 5
2. Appendix B Design Verification Test Procedure 8
3. AppendixC DMDImageQuality 10
4. Appendix D Electrical Specification 14
5. Appendix E Power Supply Specification 20
Chapter 2：SparePartsList 21
Chapter 3：Product description and operation 23
1. Shipping Content 23
2. Product Description 24
3. Remote Control Description 26
4.Installation 28
5.Operation 31
6.PackingDescription 37
7.AppearanceDescription 39
8. Lamp Replacement 42
9. Shutdown 45
10. RS232 Codes 46
Chapter 4：CircuitOperationTheory 49
Chapter 5：AlignmentProcedure 61
Chapter 6：Trouble Shooting 80
Chapter 7：Schematics and Assy drawing 92

Chapter 1 Engineering Specification
1.0 Optical Performance Tested under 60” (diagonal) image size unless other
specified. Measurement Details refer to Appendix A.
1.1 ANSI Brightness 1600 Lumens (Minimum)
1.2 Brightness Uniformity 54% (Minimum)
1.3 Contrast Ratio
1.3.1 ANSI Contrast 130:1 (Minimum)
1.3.2 FOFO Contrast 800:1 (Minimum)
1.4 Light Leakage
1.4.1 Light Leakage in Active Area <2 lux within 60” (diagonal) image size
1.4.2 Light Leakage out of Active
Area
<2 lux between of 60” (diagonal) image size and 80”
(diagonal) area
1.5 Color X y
1.5.1 White .305±.040 .325±.040
1.5.4 Red .650±.040 .335±.040
1.5.5 Green .345±.040 .515±.040
1.5.6 Blue .137±.040 .070±.040
1.6 Color Uniformity X y
1.6.1 White < .04 < .04
1.6.2 Red < .04 < .04
1.6.3 Green < .04 < .04
1.6.4 Blue < .04 < .04
2.0 Image Quality
2.1 Throw Ratio 60” ±5% Diagonal at 2m
2.2 Zoom Ratio 1.2:1
2.3 Distortion
2.3.1 Keystone Distortion <1.0%
2.3.2 Vertical TV Distortion <1.0%
2.4 Projection Offset 120% ±5%
2.5 Focus Range 1.5~8m
2.6 Focus 2m
Test Pattern: X pattern
Observation: 2m from observer to screen
Criteria: letter visible all over screen
(Clear level specified by limit sample)
Focus condition: uniformly focused by observer
1.5m and 8m
Criteria: letter visible at center of screen
1

2.7 Lateral Color <2/3 Pixel
2.8 DMD Image Quality See Appendix D
3.0 Mechanical Specification
3.1 Dimensions Follow C109
3.2 Weight 3.2 kg
3.3 Security Slot Kensington compatible slot 150N break away force
3.5 Lens Cover Detached Lens Cover
3.6 Feet Adjustable rear foot
4.0 Packaging Detail refer to C309 (Packing Description)
4.1 Outside Dimensions 460 x 455 x 292mm (L x W x H)
4.2 Weight 7.1 Kg (Including Accessories, Projector)
4.3 Palletization 20 by Air; 728 / 40’ container, or 336/20’ container by sea
5.0 Thermal Specification Maximum temperature 10°~ 40°C
Metal Plastic5.1 Handles, knobs, grips, etc. and surface
Held or touched for short periods only
60°C 85°C
(Bottom Surface) (55°C) (70°C)
Metal Plastic5.2 External surface or equipment which
may be touched
70°C 95°C
5.3 Exhaust Air 80°C
6.0 Environmental
Operating 10-40°C, without condensation 6.1 Temperature
Storage -10 - 60°C, without condensation
Operating 10 - 90%RH, without condensation6.2 Humidity
Storage 10 - 90%RH, without condensation
Typical Normal Mode: 34dBA at @ 25°C
ECO Mode: 32dBA at @ 25°C
6.3 Audible Noise Level
Maximum Normal Mode: 35dBA at @ 25°C
ECO Mode: 33dBA at @ 25°C
6.4 Altitude 0 – 6000 feet above sea level
6.5 Shock Non-operating, 20 ms /50 G
6.6 Drop 76cm, 1 orientation, 6 primary surfaces, 2 selected
corners, and 3 selected edges, total 11 drops
Random 0.015G2/Hz, 5 ~100 Hz6.7 Vibration
Sine 0.5G, 5 ~200Hz
7.0 Regulatory Safety UL Approved (UL 1950, CSA950),
TUV-GS, CCC, CB Report, R-Mark
2

EMC FCC Class B requirements, BSMI,
VCCI, C-Tick
Directive 73/23/EEC;CE Marks
Directive 89/336/EEC;
ESD Refer to Appendix X
8.0 Reliability
8.1 MTBF 20000 hours except for DMD chip, Color wheel, Lamp
and Fan
8.2 Lamp Lifetime 2000 hours (50% brightness maintenance)
9.0 Power Requirements Adhere to Appendix F
9.1 Power Supply (Normal) VAC 100 – 240 Auto-switch (50/60Hz), 3 Wire Grounded
Typical 340W9.2 Power Consumption
Standby 15W
9.3 Power Connector IEC-06
10.0 Panel Specification
10.1 Type Single Chip 0.7” XGA 12°tilt DDR DMD
10.2 Pixels H: 1024 X V: 768
10.3 Color Depth 24 Bits (16770000 colors)
11.0 Compatibility
PC Compatible 640X400 Æ1024X768, compressed
1280X1024; Composite-Sync; Sync-on-Green; Interlace
Mode (8514A);
Detailed Support Timing Specification refer to Appendix
E.1
H-Sync 24 ~ 88
KHz
V-Sync 48 ~ 100 Hz
11.1 PC
PC Frequency
Limitation
Pixel Clock 140 MHz
11.2 Video NTSC/ NTSC4.43/ PAL (Including PAL-M, PAL-N)/
SECAM/ PAL60/
11.3 YPbPrNTSC (480i)/ 480p/ PAL (625i)/ 720p, HDTV (1080i/
1035i)
11.4 DDC DDC 2B
12.0 Image Interface Adhere to Appendix E.2
12.1 Analog RGB Input 15 pin D-Sub (Female) x 1
RGB: Video amplitude 1.0 Vp-p : Impedance 75Ω
HD/VD/CS: TTL Level
12.2 Video Input RCA jack (Yellow)
Video amplitude 1.0 Vp-p : Impedance 75Ω
3

12.3 S-Video Input 4 pin Mini-Din (Female)
Y: Luminance amplitude 1.0 Vp-p : Impedance 75Ω
C: Chroma amplitude 0.268 Vp-p : Impedance 75Ω
12.4 YPbPr Input RCA jack (Green/Red/Blue) x 1
Y: Luminance amplitude 1.0 Vp-p: Impedance 75Ω
PbPr/CbCr: Chroma amplitude 0.7 Vp-p : Impedance 75Ω
12.5 Analog RGB Output 15 pin D-Sub (Female) x 1
RGB: Video amplitude 1.0Vp-p : Impedance 75Ω
HD/VD/CS: TTL Level
13.0 Control Interface
13.1 IR Receiver IR Receiver x2 (Front, Rear)
13.2 Serial Connector 8 pin Mini-Din (Female) x 1
RS-232 Standard
13.3 USB Connector B type USB terminal for mouse port
14.0 User Interface Adhere to Appendix E.3
14.1 Operator Keypad Refer to C001
14.2 Indicators Refer to C001
14.3 Remote Control Refer to C001
14.4 On Screen Display Refer to C001
14.5 Electric Keystone ±7°(except 1080i/1035i)
15.0 Audio
15.1 PC Audio Input Φ3.5mm stereo mini jack
350m Vrms 10 KΩor more
15.2 RCA Audio Input RCA jack (White/Red) X 1
350m Vrms 10 KΩor more
15.3 Speaker 4Ω3W x 1
4

Appendix A Optical Measurement
1.Scope:
This document describes critical optical related test definitions and Instructions for data or video
projectors. The other general terminologies are specified in ANSI IT7.228-1997.
2.General Requirements
1. The unit under test should be allowed to stabilize without further
adjustment for a minimum of 5 minutes, at nominal ambient room
temperature of 25°C, before making measurements.
2. Measurements shall take place in a light proof room, where the
only source of illumination is the projector. Less than 1 lux of the
light on the screen shall be from any source other than the
projector.
3. All measurements shall be made on flat screens that do not provide
any advantage to the performance of the unit
4. All measurements shall be made at standard color temperature
setting, 100% white image (per ANSI IT7.228-1997), except where
noted
3.Practical Requirements
1. When measuring contrast manually, operators should not wear white clothing since
light reflected from white clothing can influence the measurement.
2. Unless otherwise specified, the projection lens is set in the widest zoom position since
zoom function can influence the measurement.
3. Measurement should be performed with Minolta Chromameter, Model CL-100, or
equivalent.
A1. ANSI BRIGHTNESS
ANSI Lumens = (L1+L2+L3+L4+L5+L6+L7+L8+L9)/9 (lux) x A(m^2)
A (Area) = W * H (m^2)
W: width of projected image (m)
H: height of projected image (m)
L11
L13 L12
L10
L1 L2
L4
L7
L5
L8 L9
L3
L6
Note: L10, L11, L12, L13 are located at 10% of the distance from corner itself to L5
5

A2. BRIGHTNESS UNIFORMITY
Brightness Uniformity = Minimum (L10,L11,L12,L13)/ Average (L1,L2,L3,L4,L5,L6,L7,L8,L9)
A3. JBMA UNIFORMITY
JBMA Uniformity = Average (L1,L3,L7,L9)/ L5
A4. ANSI CONTRAST
ANSI Contrast = Average lux value of the white rectangles/Average lux value of the black
rectangles
Contrast Ratio shall be determined from illuminance values obtained from a
black-and-white ”chessboard” pattern consisting of 16 equal rectangles. The white rectangles
shall be at 100% gray and the black rectangles at 0% gray. Illuminance measurements shall be
made at the center of each of the rectangles.
A5. FOFO CONTRAST
FOFO Contrast = Lux value at the center of a solid white screen/the lux value at the center of a
solid black screen
A6. JBMA CONTRAST
JBMA Contrast = Average (L1,L2,L3,L4,L5,L6,L7,L8,L9) under solid white / Average
(L1,L2,L3,L4,L5,L6,L7,L8,L9) under solid black
A7. LIGHT LEAKAGE
Leakage = The maximum light leakage under a solid black pattern in or outside of the projected
A8. IMAGE DISTORTION
Keystone = (W2-W1)/ (W1+W2) x 100%
Vertical TV dist = (H1+H2-2xH3)/2H2 x100%
Horizontal TV dist = (W1+W2-2xW3)/2W1 x100%
W1: image width at image bottom
W2: image width at image top
W3: image width at the half image height.
H1: image height at image left
H2: image height at image right
H3: image height at half image
Note:
1. Keystone and Vertical TV Distortion are recommended for Front Projection Display
2. Vertical and Horizontal TV Distortion are recommended for Rear Projection Display
6

A9. THROW RATIO
Throw ratio = projection distance / the width of the projected image
A10. ZOOM RATIO
Zoom ratio = maximum / minimum image diagonal size at a fixed projection distance
A11. FOCUS RANGE
The minimum/maximum focus distance is the minimum/maximum projection distance (The
distance between the outermost element of projection lens and screen), expressed in meter, at
which the image is still at its acceptable focus level.(acceptable focus level is specified by
FOCUS LIMIT SAMPLE approved by customer)
A12. COLOR
Color is expressed as (x, y) in 1931CIE chromaticity values
Note: Color is measured at the center of the screen that is entirely the measured color under
default brightness and contrast settings.
A13. ANSI COLOR
ANSI Color is expressed as (u, v) in 1976 CIE chromaticity values
Note: Color is measured at the center of the screen that is entirely the measured color under
default brightness and contrast settings.
A14. COLOR UNIFORMITY
Color Uniformity is the maximum color difference (△x, △y) between any two points out of
L1~L13
A15. ANSI COLOR UNIFORMITY
ANSI Color Uniformity: △u’v’= [(u’1-u’0)^2+(v’1-v’0)^2]^1/2
(u’0,v’0): the average color of L1~L13
(u’1,v’1): the spot with maximum deviation from (u’0,v’0)
A16. PROJECTION OFFSET
Projection Offset= Image height above projection lens optical axis / Total image height x 100%
Note: Optical engine should be kept horizontal attitude
7

Appendix B Design Verification Test Procedure
1. Purpose
This standard establishes the environmental specification for projector related products,
which defines the level of product performance and reliability in the field. It is not necessary the
intent of these specification to simulate a typical user environment, but rather to provide for a
level of product robustness that when applied over a wide range of manufacturing variability and
environmental usage conditions, which is recommended for product assurance testing reference.
2. Test Summary
Dynamic Testing Specification
Package Drop 76cm, 1 drop per orientation, all 6 primary surfaces, plus a minimum o
f
two selected corners, and three selected edges, total of 11 drops
Package Vibration Random, 0.01g2/Hz, 5~100Hz, all primary axis, 20 min per
orientation, total of 60min
Sine, 0.5g, 5~200Hz, 1 octave/min, 15 min dwell on each resonant
frequency, all primary axis, one sweep (30min minimum) per
orientation, total of 90+min
Shock,
non-operating
50g, 20ms half-sine, all primary axis, 1 shock per orientation, total of 3
shocks
Security Lock 150N break away force
Atmospherics
Temperature/Humi
dity, operating
0~35oC/10~90RH, 48hr
Temperature/Humi
dity, non-operating
-10~60oC/10~90RH, 48hr
Altitude, operation 0~6,000ft @30oC, 2hr
8

3.Test Order
Atmospherics, Dynamic, and Safety test sets require separate units and can be processed in
parallel. EUT testing shall be performed serially within each set.
Set 1 (3 units) Set 2 (3 units) Set 3
Dynamics: Atmospherics: Safety/EMC:
Package Drop Temperature/Humidity, Operating EFT
Package Vibration Temperature/Humidity, Non-operating ESD
Shock Altitude, Operating EMI-Radiated
EMI-Conducted
EMI-Susceptibility
4. Noise Testing Standard
(1) Desk high is 75 cm
(2) Projector have to closed to the edge of
desk
(3) Noise meter high is 150 cm & title 30
degree
(4) The distance between noise meter and
projector is 100 cm
(5) Measured four surfaces and calculated
the noise value by log average.
(6) We have designed excel files to calculate
this value. (Avg_Noise.xls)
9

Appendix C DMD Image Quality
1. SCOPE
This document specifies the image quality requirements applicable to the DLPTM XGA Component Set.
The Component Set provides the DLPTM XGA Projector with digital imaging functionality based on
Digital Micromirror Device (DMD) technology.
2. Definitions
2.1 Blemish
A blemish is an obstruction, reflection, or refraction of light that is visible, but out of focus in
the projected image under specified conditions of inspection (see Table 1). It is caused by a
particle, scratch, or other artifact located in the image illumination path.
2.2 Dark pixel
A single pixel or mirror that is stuck in the OFF position and is visibly darker than the
surrounding pixels.
2.3 Bright pixel
A single pixel or mirror that is stuck in the ON position and is visibly brighter than the
surrounding pixels.
2.4 Unstable pixel
A single pixel or mirror that does not operate in sequence with parameters loaded into
memory. The unstable pixel appears to be flickering asynchronously with the image.
2.5 Adjacent pixel
Two or more stuck pixels sharing a common border or common point, also referred to as a
cluster.
2.6 Streaks
Artifact resulting from locallized variation in mirror tilt angle relative to surrounding mirrors.
They are similar in appearance to window scratches but appear at the mirror level. Streaks
appear as faint diagonal or arcing patterns in the image.
2.7 Sea of Mirrors (SOM)
SOM is a rectangular array of off-state mirrors surrounding the active area.
2.8 Eyecatcher
A small localized light “spot” which has high spatial frequency and high differential
brightness. These are due to various DMD window or window aperture “defects” including:
digs, voids, particles and scratches.
2.9 Border Artifacts
All variations of these artifacts are acceptable under this image quality specification.
Border artifacts are a general category of image artifacts that may show up on screen in the
area outside of the active array. Border artifacts include: Exposed Bond Wires, Exposed
Metal 2, and Reflective Edge.
10

2.9.1 Bond Wires
Bond Wires attach the die to the superstructure. If visible, they will appear as short light
parallel lines outside of the Sea of Mirrors (SOM).
2.9.2 Exposed Metal 2
Exposed Metal 2 is due to a shift in positioning of either the die or the window aperture
which may allow light to be reflected off of the layer of metal 2 that is below the super
structure (mirrors). This defect is located at the outer edge of the SOM.
2.9.3 Reflective Edge
Reflective Edge is light that may reflect from the edge of the DMD’s window aperture onto
the projection screen. It will appear as a thin diffuse line outside of the SOM.
2.10 Two Zone Blue 60 Screen
The Two Zone Blue 60 screen is used to test for major dark blemishes. Refer to Figure 1 for
configuration. All areas of the screen are colored a Microsoft Paintbrush blue 60 (green and
red set at 0, blue set at 60).
NOTE: If linear degamma is not used then the Microsoft Paintbrush values must be adjusted
to match the degamma table being used in order to generate an equivalent blue level on the
test screen image.
2.11 Two Zone Gray 10 Screen
The Two Zone Gray 10 screen is used to test for major light blemishes. Refer to Figure 1 for
configuration. All areas of the screen are colored a Microsoft Paintbrush gray 10 (green, red,
and blue set at 10).
NOTE: If linear degamma is not used then the Microsoft Paintbrush values must be adjusted
to match the degamma table being used in order to generate an equivalent gray level on the
test screen image.
3. ACCEPTANCE REQUIREMENTS
3.1 Conditions of Acceptance
All DMD image quality defects must be determined under the following projected image
test conditions:
a. Projector degamma shall be linear.
b. Projector error diffusion shall be “off.”
c. Projector brightness and contrast settings shall be set to nominal.
d. The diagonal size of the projected image shall be a minimum of 60
inches.
e. The projection screen shall be 1X gain.
f. The projected image shall be inspected from an 8 feet minimum viewing
distance.
g. The image shall be in focus during all Table 1 tests.
11

3.2 Test Sequence
Tests shall be run in the sequence listed in Table 1.
TABLE 1. Image Quality Specification
SEQ # TEST SCREEN ACCEPTANCE CRITERIA
1 Major Dark Blemish Two Zone Blue 60 1. No blemish will be darker than Microsoft Blue 60
in the Critical Zone
2. 2 blemishes in the Non-Critical Zone
3. No blemish will be > ½” long/diameter
2 Major Light Blemish Two Zone Gray 10 1. No blemish will be lighter than Microsoft Gray 10 in
the Critical Zone
2. 2 blemishes in the Non Critical Zone
3. No blemish will be > ½” long/diameter
3 Eyecatcher Gray 10 1. No eyecatcher will be lighter than Microsoft Gray 10
Streaks Blue 60
Gray 10
White
1. No streaks
Projected Images Any screen 1. No adjacent pixels
2. No bright pixels (Active Area)
3. 1 bright pixel (SOM)
4. 4 dark pixels
5. 6 minor blemishes
6. No DMD window aperture shadowing on the Active
Area
7. No unstable pixels in Active Area
Notes:
1. Projected blemish numbers include the count for the shadow of the artifact in addition to the
artifact itself, so that the count usually represents a single artifact on the window.
2.
3.
4.
5.
6.
No blemish shall be more than 5 inches long or have a total area of more than 5 square
inches on a 60 inch diagonal projected image. ( ½ inch for Major Blemish tests)
During all Table 1 tests, projected images shall be inspected in accordance with the
conditions of inspection specified in Section 3.
The rejection basis for all cosmetic DMD defects (scratches, nicks, particles) will be the
projected image tests referenced in Table 1.
Any other image quality issue not specifically defined in this document shall be
acceptable.
Black screens shall not be used as a basis for rejecting DMDs for image quality.
12

Figure 1. Major Blemish Two Zone Screen
Critical Zone
center 25%
Non Critical Zone
13

Appendix D Electrical Specification
E1 Timing Table
The Default timing is as following:
Standard 640x480
at 60Hz
640x480
at 72Hz
640x480
at 75Hz
720x400
at 70Hz
800x600
at 56Hz
800x600
at 60Hz
Standard Type Industry VESA VESA DOS VESA VESA
Resolution H*V 640x480 640x480 640x480 720x400 800x600 800x600
Polarity H/V -/- -/- -/- -/+ +/+ +/+
H Frequency
(KHz)
31.469 37.861 37.5 31.47 35.16 37.879
V Frequency (Hz) 59.94 72.809 75.00 70.08 56.25 60.317
Pixel Clock (MHz) 25.175 31.5 31.5 28.32 36 40
Standard 800x600
at 72Hz
800x600
at 75Hz
1024x768
at 60Hz
1024x768
at 70Hz
1024x768
at 75Hz
Standard Type VESA VESA VESA VESA VESA
Resolution H*V 800x600 800x600 1024x768 1024x768 1024x768
Polarity H/V +/+ +/+ +/+ -/- +/+
H Frequency
(KHz)
48.077 46.875 48.576 56.476 60.023
V Frequency (Hz) 72.188 75 60.00 70.069 75.029
Pixel Clock (MHz) 50 49.5 65 75 78.75
14

E2 Electrical Interface Character
Interface Definition
• 15 pin definition of the mini D-sub male for DDC1/2B protocol
15
610
11 15
Pin Definition Pin Definition Pin Definition Pin Definition
1 Red video 2 Green Video 3 Blue Video 4 Monitor ID bit
2
5 Return 6 Red Video
Return
7 Green Video
Return
8 Blue Video
Return
9 +5 Volt
Supply
10 Sync. Return 11 Monitor ID bit
0
12 Bi-directional
data (SDA)
13 Horizontal
Sync
14 Vertical Sync 15 Data clock
(SCL)
• Video & Component Input
Component input
456
Pin Definition Pin Definition Pin Definition
1 Composite video input 2 Audio input (left
channel)
3 Audio input (right
channel)
4 Luminance video input 5 B-Y Chroma input 6 R-Y Chroma input
• 3.5 mm phone plug is used for stereo audio signal input.
• S-Video input
Pin Description
1 GND
2 GND
3 Luminance
4 Chroma
Composite input
123
2
4
1
3
15

• RS232 Port
Pin Description Pin Description
1 Reserved 2 Reserved
3 TX 4 Reserved
5 Reserved 6 Reserved
7 RX 8 GND
Local Keyboard Description (Detailed description refer to SW Specification)
Key Name Detailed Description
Power Use this button to turn your Data Projector on and off (standby mode).
Source To select input sources as Computer, Video, S-Video, YpbPr
Menu (1) OSD pop-up. (2) Move next item
Æ(1) Move next page (2) OSD increment & move next sub-item (3) Keystone+.
Å(1) Move previous page (2) OSD decrement & move previous sub-item (3) Keystone-.
Exit (1) Close OSD. (2) Move to page level
Auto Toggle auto-tracking image function
Remote Control Keys Description (Detailed description refer to SW Specification)
IR-Key Name Detailed Description
LED Flashes when any button is pressed.
Power Use this button to turn your Data Projector on and off (standby mode).
Laser Use this button to turn on/off Laser Pointer on Remote Control.
Source To select input sources as Computer, Video, S-Video
Menu/6(1) OSD pop-up. (2) Move next item
4(1) Move next page (2) OSD increment & move next sub-item.
3(1) Move previous page (2) OSD decrement & move previous sub-item.
Exit/5(1) Close OSD. (2) Move to page level
Auto Toggle auto-tracking image function
Freeze This button will freeze a picture. Press again to resume motion.
Blank Press “Blank” key first to blank the screen. Then press “Blanking” key
continuously to show the image for top to bottom smoothly. Stop to press the
key, the image will stop to display
Zoom + In the position state, after pressing this button, a picture will magnify the
picture. If the user presses this key again the picture will magnify again. At the
8 7 6
5 4 3
21
16

same time the user can use 3456 to pan the location.
Zoom - In the position state, after pressing this button, a picture will reduce the picture.
If the user presses this key again the picture will reduce again. At the same time
the user can use 3456 to pan the location.
Return Disable Zoom function
Volume + Press this remote key, the OSD will display the volume bar and user can adjust
the volume to be louder
Volume - Press this remote key, the OSD will display the volume bar and user can adjust
the volume to be quieter
Mute The button will quiet the sound system. Press again to resume sound.
PIP Video The button will activate the PIP function and select the PIP source to Video.
PIP S-Video The button will activate the PIP function and select the PIP source to S-Video.
External Status indicator
LED Name Detailed Description
Power LED Display the power on/off sequence status
Lamp Status LED Display the Lamp status (Lamp fail, Lamp spoil etc.)
Temperature Status LED Display the Thermal status (Fan Fail, Over Temperature, etc.)
E3. Functionality
The Following functionality will be supported: (Detailed description refer to SW Specification)
Functionality Data (Computer) Video/S-Video YPbPr/YCbCr
Volume YES YES YES
Bass YES YES YES
Treble YES YES YES
Mute YES YES YES
Video System NO YES YES
Video Mode YES YES YES
Brightness YES YES YES
Contrast YES YES YES
Color NO YES YES
Tint NO YES YES
Sharpness NO YES NO
Color Temp YES YES YES
H. Position YES NO YES
V. Position YES NO YES
H. Phase YES NO YES
17

H. Size YES NO YES
Keystone YES YES YES
Language YES YES YES
Auto YES YES YES
Image Ratio YES YES YES
Auto Off YES YES YES
Mirror YES YES YES
Source YES YES YES
Freeze YES YES YES
Blank YES YES YES
Magnify YES YES YES
Lamp Reset YES YES YES
PIP Source YES NO NO
PIP Size YES NO NO
PIP Position YES NO NO
PIP H Pos YES NO NO
PIP V Pos YES NO NO
OSD H Pos YES YES NO
OSD V Pos YES YES NO
OSD Timer YES YES YES
Source Scan YES YES YES
Keystone Hold YES YES YES
Mirror Hold YES YES YES
Blank Time YES YES YES
Brightnes
s
NO YES NO
Contrast NO YES NO
Color NO YES NO
Tint NO YES NO
Sharpness NO YES NO
PIP Option
System NO YES NO
Information YES YES YES
Reset YES YES YES
Zoom YES YES YES
Reveal YES NO NO
18

External Message indicator (Detailed description refer to SW Specification)
Message Occasion
PC/Composite Video /S-Video /Analog
YPbPr Searching
The system does not detect the signal
Acquiring Signal The system is auto- adjusting
Out of range The signal is over the specification
Change the lamp and reset the lamp timer. Lamp Hour is over 1900 hours
You have to Change the Lamp! Lamp Hour is over 1980 hours
You have to Change the Lamp! Lamp Hour is over 2000 hours.
Change the lamp Lamp Hour is over 2000 hours, the user will see this message
the system will shutdown in 10 minutes automatically.
19
