BenQ W1070 User manual

BenQ America Corp.
15375 Barranca Parkway. Suite A-205. Irvine, CA 92618 Tel: [phone] www.BenQ.us
BenQ is a registered trademark of BenQ Corp. DLP®is a registered trademark of Texas Instruments. All rights reserved.
Product names, logos, brands, and other trademarks featured or referred to in this materials are the property of their respective trademark holders.
Specifications subject to change without notice.
I
W1070
DIGITAL
PROJECTOR
Features Specications
Native Full HD 1080P (1920x1080) Resolution
2000 ANSI Lumens;
10,000:1 High Contrast Ratio
DLP® Link 3D Ready & nVidia 3DTV Play
SmartEco™ Power Saving Technology
Dual HDMI, Built-in 10W Speaker
Projection System
Native Resolution
Brightness
Contrast Ratio
Display Color
Lens
Aspect Ratio
Throw Ratio
Image Size (Diagonal)
Zoom Ratio
Lamp Type
Lamp (Normal/Economic Mode)*
Keystone Adjustment
Lens Shift
Projection Offset
Resolution Support
Horizontal Frequency
Vertical Scan Rate
Compatibility
Interface
Dimensions (WxHxD)
Weight
Power Supply
Power Consumption
Audible Noise
On-Screen Display
Languages
Picture Mode
Accessories (Standard)
Accessories (Optional)
Limited Warranty
DLP®
1080p (1920x1080)
2000 ANSI lumens
10,000:1
1.07 Billion Colors
F=2.59-2.87, f=16.88-21.88mm
Native 16:9 (5 aspect ratio selectable)
1.15-1.5 (79”@2M)
40”-235”
1.3:1
240W
3500/5000/6000 hours
1D, Vertical +/- 20 degrees
Vertical 110%-130%±5%
Vertical 110%-130%±5%
up to WUXGA
15K-102KHz
23-120Hz
SDTV, EDTV, HDTV Compatibility: 480i, 480p, 576i, 576p, 720p, 1080i, 1080p
Video Compatibility: NTSC, PAL, SECAM
Computer in (D-sub 15pin) x 1
HDMI (v1.4a) x 2
Composite Video in (RCA) x 2
S-Video in (Mini DIN 4pin) x 1
Component Video in x 1
Audio in (Mini Jack) x 1
Audio L/R in (RCA) x 1
Audio out (Mini Jack) x 1
Speaker 10W x 1
USB (Type Mini B) x 1
RS232 (DB-9pin) x 1
DC 12V Trigger x 1
12.28” x 4.09” x 9.61” (311.81 x 104.07 x 244.12 mm)
5.84 lbs (2.65 kg)
AC 100 to 240 V, 50 to 60 Hz
359W/110V (typical), Standby < 0.5W
33/30 dBA (Normal/Economic mode)
Arabic/Bulgarian/ Croatian/ Czech/ Danish/ Dutch/ English/ Finnish/
French/ German/ Greek/ Hindi/ Hungarian/ Italian/ Indonesian/
Japanese/ Korean/ Norwegian/ Polish/ Portuguese/ Romanian/
Russian/ Simplied Chinese/Spanish/ Swedish/ Turkish/ Thai/
Traditional Chinese (28 Languages)
Dynamic / Standard / Cinema / 3D / User 1 / User 2 / User 3
Remote Control w/ Battery, Power Cord, User Manual CD,
Quick Start Guide, Warranty Card, VGA (D-sub 15pin) Cable
Spare Lamp Kit P/N: 5J.J7L05.001
Ceilling Mount P/N: 5J.J4N10.001
3D Glasses P/N: 5J.J7K25.011
Carry Bag P/N: 5J.J3T09.001
1 Year Parts/Labor; 1 Year or 2000 hours of lamp life.
W1070 10-24-12-BQus
*Lamp life results will vary depending on environmental conditions and usage. Actual product’s features and specications
are subject to change without notice.
1
2
3
4
5
6
7
8
9
10
Input and Output Terminals
HDMI 1 & 2 (v1.4a)
DC 12V Trigger
Component Video In (RCA)
USB (Mini B)
Computer in (D-sub 15pin)
RS232 (DB-9pin)
S-Video In (Mini DIN 4pin)
Audio In L & R (RCA)
Audio In (Mini Jack)
Component Video in
Audio Out (Mini Jack)
Security Bar
11
12
123456789
10 11 12
HIGH-DEFINITION MULTIMEDIA INTERFACE
TM

Distance Chart
Ceiling Mount Chart
Dimensions
W1070 Digital Projector
4.09”
12.28”
Ceiling Mount Screws:
M4 (Max. L = 25 mm,
Min. L = 20 mm)
<F>: Screen <G>:Center of lens
Floor Installation
9.61”
Units: inch
Units: inch
The screen aspect ratio is 16:9 and the projected picture is 16:9
Ceiling Installation
<F>: Screen <G>:Center of lens
Screen Dimensions Projection Distance <D> (inch) Lowest/Highest
lens position
<E> (inch)
Diagonal <A> Height
<B>
(inch)
Width
<C>
(inch)
Min Distance
(with max
zoom)
Average
Max distance
(with min
zoom)
Inch mm
40 1016 19.6 34.8 39.8 45.8 51.8 .98
50 1270 24.5 43.5 49.8 57.3 64.8 1.2
60 1524 29.4 52.2 59.8 68.7 77.7 1.4
70 1778 34.3 61.0 69.7 80.2 90.7 1.7
80 2032 39.2 69.7 79.7 91.6 103.6 1.9
90 2286 44.1 78.4 89.6 103.1 116.6 2.2
100 2540 49.0 87.1 99.6 114.6 129.5 2.4
110 2794 53.9 95.8 109.6 126.1 142.5 2.6
120 3048 58.8 104.6 119.6 137.5 155.4 2.9
130 3302 63.7 113.3 129.5 149.0 168.4 3.1
140 3556 68.6 122.0 139.5 160.4 181.4 3.4
150 3810 73.5 130.7 149.4 171.9 194.3 3.6
160 4064 78.4 139.4 159.4 183.3 207.3 3.9
170 4318 83.3 148.1 169.4 194.8 220.2 4.2
180 4572 88.2 156.8 179.4 206.3 233.2 4.4
190 4826 93.1 165.5 189.3 217.7 246.1 4.6
200 5080 98.0 174.3 199.3 229.2 259.1 4.9
235 5969 115.1 204.8 234.2 269.3 304.4 5.7
