BENSHAW EMX4e User manual

Benshaw retains the right to change specications and illustrations in text without prior notication.
The contents of this document may not be copied without the explicit permission of Benshaw.
©2020 Benshaw, Inc
710-21973-00A
Pronet
Communications option
for EMX4e/EMX4i soft starters
User Guide

Product Compatibility
This expansion card is suitable for use with EMX4e and EMX4i soft starters.
Product description Soft starter name
Basic model EMX4e
Advanced model EMX4i
Parameter Management
Parameter lists vary according to the model and version of soft starter.
Refer to the relevant soft starter literature for a complete parameter list.
For the latest manuals and software, please visit our website.

Contents
1Disclaimer .......................................................................................................................... 1
2Warnings............................................................................................................................ 1
3Important User Information .............................................................................................. 2
4Installation ......................................................................................................................... 2
5Device Configuration ........................................................................................................ 3
6Master Configuration ........................................................................................................ 3
7Operation ........................................................................................................................... 4
8Packet Structures.............................................................................................................. 5
9Network Design ............................................................................................................... 13
10 Specifications .................................................................................................................. 15
1 Disclaimer
The examples and diagrams in this manual are included solely for illustrative purposes. The
information contained in this manual is subject to change at any time and without prior
notice. In no event will responsibility or liability be accepted for direct, indirect or
consequential damages resulting from the use or application of this equipment.
2 Warnings
WARNING
For your safety, isolate the soft starter completely from mains voltage before
attaching or removing accessories.
WARNING
Inserting foreign objects or touching the inside of the starter while the expansion
port cover is open may endanger personnel, and can damage the starter.
Instructions 1

Important User Information Profinet Card
3 Important User Information
It is the installer's responsibility to follow all instructions in this manual and to follow correct
electrical practice.
3.1 Product Design
The Profinet Card allows the soft starter to connect to an Ethernet network and be
controlled or monitored using an Ethernet communication model.
Familiarity with Ethernet protocols and networks is required to operate the device
successfully. For difficulties using this device with third party products, including PLCs,
scanners and commissioning tools, contact the relevant supplier.
4 Installation
4.1 Installing the Expansion Card
1. Push a small flat-bladed screwdriver into the slot in the centre of the expansion port
cover, and ease the cover away from the starter.
2. Line up the card with the expansion port. Gently push the card along the guide rails until
it clicks into the starter.
B4 B5 10
1112 13 14 1521 22
3334 41 42 44 53 54
B4 B5 10
1
112 13 1415 2122
3334 41 42 44 53 54
1 2
18931.A
4.2 Network Connection
Ethernet Ports
The device has two Ethernet ports. If only one connection is required, either port can be
used.
Cables
Use Category 5, 5e, 6 or 6e cable to connect to the device.
EMC Precautions
To minimise electromagnetic interference, Ethernet cables should be separated from motor
and mains cables by 200 mm.
If the Ethernet cable must cross motor or mains cables, the crossing should be at an angle
of 90°.
4.3 Network Establishment
The controller must establish communications directly with each device before the device
can participate in the network.
4.4 Addressing
Each device in a network is addressed using a MAC address and a device name. The MAC
address is fixed within the device and is printed on a label on the front of the device.
2

Profinet Card Device Configuration
5 Device Configuration
Use the Ethernet Device Configuration Tool to configure the device. The Ethernet Device
Configuration Tool is available from your local supplier.
To identify the device using the Ethernet Device Configuration Tool:
1. Start the Ethernet Device Configuration Tool.
2. Click on Search Devices. The software will search for connected devices.
3. To configure a device name, click Configure then select Device Name.
NOTE
The Error LED is on if the device is not configured. If the device is configured but is
not passing I/O data, the Error LED will flash. The Error LED will be active during
the configuration process.
NOTE
If your PC has a firewall enabled, you must add the tool to the list of authorised
programs.
5.2 Enabling Network Control
The soft starter will only accept commands from the Profinet Card if parameter 1A
Command Source is set to 'Network'.
NOTE
If the reset input is active, the starter will not operate. If a reset switch is not
required, use parameter 7I to set the reset input to normally open or fit a link across
terminals 10, 11 on the soft starter.
6 Master Configuration
Import the latest GSDML file into your Master configuration tool. This file is available from
your supplier.
If your Master uses on-screen icons, two graphic bitmap files are available from the
website. SSPM_N.bmp indicates normal mode. SSPM_D.bmp indicates diagnostic mode.
Instructions 3

Operation Profinet Card
7 Operation
The device has been designed for use in a system complying with the Profinet standard.
For successful operation, the controller must also support all functions and interfaces
described in this document.
7.1 Device Classification
The Profinet Card is a Profinet IO-Device and must be managed by an IO-Controller over
Ethernet.
7.2 Ensuring Safe and Successful Control
Data written to the device will remain in its registers until the data is overwritten or the
device is reinitialised.
If the soft starter may be controlled via Command Override (parameter 7A) or may be
disabled via the reset input (terminals 10, 11) fieldbus commands should be cleared from
the registers. If a command is not cleared, it will be re-sent to the starter once fieldbus
control resumes.
7.3 Feedback LEDs
Port 1 Port 2 Keypad
LI NK 2
TX/RX2
LI NK 1
TX/RX1
ERROR
STATUS
17821.A
LED name
LED Status
Description
Error
Off
No error.
Flashing
Connection not established.
On
No physical link or slow physical link.
No configuration.
Status
Off
No error.
Flashing
DCP signal service initiated via the bus.
Link x
Off
No network connection.
On
Connected to a network.
TX/RX x
Flashing
Transmitting or receiving data.
4

Profinet Card Packet Structures
8 Packet Structures
NOTE
The available features and parameter details may vary according to the model
and software version of the starter. Refer to the soft starter user manual for details
of parameters and supported features.
8.1 Control commands (controller to device)
Use output bytes 0-1 to send a control command to the soft starter.
Byte
Bits
Details
0
0 to 1
Reserved
2 to 3
0 = Use soft starter remote input to select motor set
1 = Use primary motor set when starting
2 = Use secondary motor set when starting
3 = Reserved
4
0 = stop action will be as selected in the soft starter
1 = stop action will be a coast to stop
5 to 7
Reserved
1
0
0 = Stop
1 = Start
1 to 2
Reserved
3
1 = Reset
4 to 7
Reserved
2 to 5
Parameter management (see Parameter Management on page 9)
8.2 Status information (device to controller)
Starter status information is always available when the device is connected to a soft starter.
NOTE
For models 0064B and smaller, current reported via communications is 10 times
greater than the actual value (displayed on the keypad).
Bytes 0-1: Control status
Bits
Details
0 to 5
Current (% motor FLC)
6
Command source
0 = Network, Timer
1 = Remote Keypad, Digital Input, Clock
7
1 = Ramping (starting or stopping)
8
1 = Ready
9
1 = Starting, running or stopping
10
1 = Tripped
11
1 = Warning
12 to 15
Reserved
Instructions 5

Packet Structures Profinet Card
Bytes 2-3: Starter state
Bits
Details
0 to 3
The decimal value of bits 0~3 indicates the starter's state:
0 = Communication error between device and soft starter
1 = Ready
2 = Starting
3 = Running
4 = Stopping
5 = Not ready (restart delay, restart temperature check, run simulation, reset
input is open)
6 = Tripped
7 = Menu open (cannot start)
8 = Jog forward
9 = Jog reverse
4
0 = Negative phase sequence
1 = Positive phase sequence
5 1 = Current exceeds FLC
6
0 = Uninitialised
1 = Initialised
7
1 = Communication error between device and soft starter
8 to 15
Reserved
Bytes 4-5: Trip code
Bits
Details
0 to 15
See Trip Codes on page 10
Bytes 6-7: Motor current
Bits
Details
0 to 15
Average rms current across all three phases
Bytes 8-9: Motor temperature
Bits
Details
0 to 15
Motor thermal model (%)
6

Profinet Card Packet Structures
Bytes 10-63: Extended information
Bytes 10~63 report information from the soft starter's internal registers.
Byte
Description
Bits
Details
10-11
Version
0 to 8
Reserved
9 to 15
Product type code:
12 = Basic model
13 = Advanced model
12-13
Model number
0 to 7
Reserved
8 to 15
Soft starter model ID
14-15
Reserved
16-17
Reserved
18-19
Starter state
0 to 4
0 = Reserved
1 = Ready
2 = Starting
3 = Running
4 = Stopping
5 = Not ready (restart delay,
restart temperature check, run simulation,
reset input is open)
6 = Tripped
7 = Programming mode
8 = Jog forward
9 = Jog reverse
5
1 = Warning
6
0 = Uninitialised
1 = Initialised
7
Command source
0 = Network, Timer
1 = Remote Keypad, Digital Input, Clock
8
Reserved
9
0 = Negative phase sequence
1 = Positive phase sequence
10 to 15 See Trip Codes on page 10
20-21
Current
0 to 13
Average rms current across all three
phases
14 to 15
Reserved
22-23
Current
0 to 9
Current (% motor FLC)
10 to 15
Reserved
24-25
Motor temperature
0 to 7
Motor thermal model (%)
8 to 15
Reserved
26-27
Reserved
28-29
% Power factor
0 to 7
100% = power factor of 1
8 to 15
Reserved
Instructions 7

Packet Structures Profinet Card
Byte
Description
Bits
Details
30-31
Voltage
0 to 13
Average rms voltage across all three
phases
14 to 15 Reserved
32-33
Current
0 to 13
Phase 1 current (rms)
14 to 15
Reserved
34-35
Current
0 to 13
Phase 2 current (rms)
14 to 15
Reserved
36-37
Current
0 to 13
Phase 3 current (rms)
14 to 15
Reserved
38-39
Voltage
0 to 13
Phase 1 voltage (rms)
14 to 15
Reserved
40-41 Voltage 0 to 13 Phase 2 voltage (rms)
14 to 15
Reserved
42-43
Voltage
0 to 13
Phase 3 voltage (rms)
14 to 15 Reserved
44-45
Parameter list version
0 to 7
Parameter list minor revision
number
8 to 15
Parameter list major version
46-47
Digital input state
For all inputs, 0 = open, 1 = closed (shorted)
0
Start/Stop
1
Reserved
2 Reset (Refer to note)
3
Input A
4
Input B
5 to 15
Reserved
48-49
Trip code
0 to 15
See Trip Codes on page 10
50-59
Reserved
60-63
Parameter
management
See
Parameter Management
on page 9
NOTE
The reset input is normally closed by default. If parameter 7I Reset/Enable Logic is
set to normally open, the reported state will be inverted (0 = closed, 1 = open).
8

Profinet Card Packet Structures
8.3 Parameter Management
The Profinet Card can read parameter values from and write parameter values to the soft
starter. The card handles one parameter at a time.
The device references parameters according to their position in the starter's parameter list.
•Parameter number 1 corresponds to parameter 1A Command Source.
•The basic model has 152 parameters. Parameter number 152 corresponds to
parameter 36J RTD/PT100 B.
•The advanced model has 225 parameters. Parameter number 225 corresponds to
parameter 36J RTD/PT100 B.
CAUTION
Changing the values of the Advanced parameters (parameter group 20) may
cause unpredictable behaviour in the soft starter. Consult your local supplier
before adjusting the Advanced parameters.
Output
Use output bytes 2-5 to read or write a parameter to the soft starter.
Controller > device output bytes are structured as follows.
Byte
Bits
Details
2
0 to 7
Parameter number to read/write
3
0
Reserved
1
1 = Read parameter
2
1 = Write parameter
3 to 7
Reserved
4
0 to 7
Low byte parameter value to write to soft starter/ zero data values
for read
5
0 to 7
High byte parameter value to write to soft starter/ zero data values
for read
Input
Parameter data from the starter is reported in input bytes 60-63.
Device > controller input bytes are structured as follows.
Byte
Bits
Details
60
0 to 7
Echo parameter number
61 0 1 = Invalid parameter number
1
1 = Invalid parameter value
2 to 7
Reserved
62
0 to 7
Low byte parameter value read from soft starter
63
0 to 7
High byte parameter value read from soft starter
Instructions 9

Packet Structures Profinet Card
8.4 Trip Codes
Trip
Code
Description
0
No trip
1
Excess start time
2
Motor overload
3
Motor thermistor
4
Current imbalance
5
Frequency
6
Phase sequence
7
Instantaneous overcurrent
8
Power loss
9
Undercurrent
10
Heatsink overtemperature
11
Motor connection
12
Input A trip
13 FLC too high
14
Unsupported option (function not available in inside delta)
15
Communications card fault
16
Forced network trip
17
Internal fault
18
Overvoltage
19
Undervoltage
23
Parameter out of range
24
Input B trip
26
L1 phase loss
27
L2 phase loss
28
L3 phase loss
29
L1-T1 shorted
30
L2-T2 shorted
31
L3-T3 shorted
33
Time-overcurrent (Bypass overload)
34
SCR overtemperature
35 Battery/clock
36
Thermistor circuit
47
Overpower
48
Underpower
56
Keypad disconnected
57
Zero Speed Detect
58
SCR Itsm
59
Instantaneous overcurrent
60
Rating Capacity
70
Current Read Err L1
71
Current Read Err L2
10

Profinet Card Packet Structures
Trip
Code
Description
72
Current Read Err L3
73
Remove Mains Volts (mains voltage connected in run simulation)
74
Motor Connection T1
75
Motor Connection T2
76
Motor Connection T3
77
Firing Fail P1
78
Firing Fail P2
79
Firing Fail P3
80
VZC Fail P1
81
VZC Fail P2
82 VZC Fail P3
83
Low Control Volts
84~96
Internal fault x. Contact your local supplier with the fault code (X).
8.5 Examples
Control commands (controller to device)
Start the motor using parameter set 1
Byte 0
Byte 1
Byte 2
Byte 3
Byte 4
Byte 5
Byte 6
Byte 7
4
1
Start the motor, select via remote input
Byte 0
Byte 1
Byte 2
Byte 3
Byte 4
Byte 5
Byte 6
Byte 7
0
1
Stop the motor using the programmed soft stop for motor set 2
Byte 0
Byte 1
Byte 2
Byte 3
Byte 4
Byte 5
Byte 6
Byte 7
8
0
Quick stop the motor
Byte 0
Byte 1
Byte 2
Byte 3
Byte 4
Byte 5
Byte 6
Byte 7
16
0
Reset a trip
Byte 0
Byte 1
Byte 2
Byte 3
Byte 4
Byte 5
Byte 6
Byte 7
≤ 28 8
Status information (device to controller)
Read control status - Ready
Byte 0
Byte 1
Byte 2
Byte 3
Byte 4
Byte 5
Byte 6
Byte 7
0 1
Read control status - Running
Byte 0
Byte 1
Byte 2
Byte 3
Byte 4
Byte 5
Byte 6
Byte 7
3
0
Read control status - Tripped, trip code 4 (Current imbalance)
Byte 0
Byte 1
Byte 2
Byte 3
Byte 4
Byte 5
Byte 6
Byte 7
6
0
4
0
Instructions 11

Packet Structures Profinet Card
Parameter Management
Write parameter to starter: parameter number 2, 1B Motor Full Load Current = 55
Byte 0
Byte 1
Byte 2
Byte 3
Byte 4
Byte 5
Byte 6
Byte 7
2
4
55
0
Parameter write response
Byte 56
Byte 57
Byte 58
Byte 59
Byte 60
Byte 61
Byte 62
Byte 63
2
0
55
0
Basic model: Read parameter number 12, 2I Stop Mode
Byte 0
Byte 1
Byte 2
Byte 3
Byte 4
Byte 5
Byte 6
Byte 7
12
2
0
0
Parameter read response: parameter 2I Stop Mode = 1 (TVR Soft Stop)
Byte 56
Byte 57
Byte 58
Byte 59
Byte 60
Byte 61
Byte 62
Byte 63
12 0 1 0
12

Profinet Card Network Design
9 Network Design
The device supports star, line and ring topologies.
9.1 Star Topology
In a star network, all controllers and devices connect to a central network switch.
14697.A
9.2 Line Topology
In a line network, the controller connects directly to one port of the first card. The second
Ethernet port connects to another card, which in turn connects to another device until all
devices are connected.
14695.A
NOTE
The device has an integrated switch to allow data to pass through in line topology.
The device must be receiving control power from the soft starter for the switch to
operate.
NOTE
If the connection between two devices is interrupted, the controller cannot
communicate with devices after the interruption point.
NOTE
Each connection adds a delay to communication with the next device.
The maximum number of devices in a line network is 32. Exceeding this number
may reduce the reliability of the network.
Instructions 13

Network Design Profinet Card
9.3 Ring Topology
In a ring topology network, the controller connects to the first card, via a network switch.
The second Ethernet port of the card connects to another device, which in turn connects to
another device until all devices are connected. The final device connects back to the
switch.
The device supports beacon based ring node configuration.
14696.A
NOTE
The network switch must support loss of line detection.
9.4 Combined Topologies
A single network can include both star and line components.
14700.A
14

Profinet Card Specifications
10 Specifications
Connections
Soft starter ...................................................................................... 16-way pin assembly
Contacts ..................................................................................................... Gold flash
Network ................................................................................................................... RJ45
Settings
IP Address ................................................................................... Automatically assigned
Device name ........................................................... Automatically assigned, configurable
Network
Link speed ................................................................... 10 Mbps, 100 Mbps (auto-detect)
Full duplex
Auto crossover
Power
Consumption (steady state, maximum) ................................................ 35 mA @ 24 VDC
Reverse polarity protected
Galvanically isolated
Certification
CE .............................................................................................................. EN 60947-4-2
Profibus & Profinet International ...............................................................
Instructions 15

BENSHAW
615 Alpha Drive
Pisburgh, PA 15238
Phones: [phone]
Fax: [phone]
BENSHAW Canada
550 Bright Street
Listowel, Ontario N4W 3W3
Phone: [phone]
Fax: [phone]
È710-21973-00AWËÍ
710-21973-00A
