BENSHAW EMX4e-0024B User manual

Low Voltage
Soft Starter
User Guide
EMX4e
710-21918-00A
Software Version (200-102-202-102)
© 2019 Benshaw, Inc
Benshaw retains the right to change specifications and illustrations in text without prior notification.
The contents of this document may not be copied without hte explicit permission of Benshaw.

CONTENTS
Contents
1. About This Manual ................................3
1.1 Disclaimer..............................................3
2. Caution Statements...............................4
2.1 Electrical shock risk...............................4
2.2 Unexpected Operation..........................5
2.3 Avertissements à l'attention des clients
canadiens..............................................6
3. System Design......................................8
3.1 Feature List............................................8
3.2 Model Code...........................................9
3.3 Model Selection.....................................9
3.4 Current Ratings ...................................10
3.5 Dimensions andWeights....................12
3.6 Physical Installation.............................13
3.7 Accessories.........................................13
3.8 Main Contactor....................................14
3.9 Circuit Breaker.....................................14
3.10 Power Factor Correction .....................15
3.11 Short Circuit Protection Devices
(SCPD)................................................15
3.12 IEC Coordination with Short Circuit
Protection Devices...............................16
3.13 UL Coordination with Short Circuit
Protection Devices...............................17
3.14 Fuse Selection for Type 2
Coordination........................................20
3.15 Specifications.......................................21
3.16 Disposal Instructions ...........................22
4. Installation............................................23
4.1 Command Source...............................23
4.2 Setup Procedure Overview.................23
4.3 Inputs...................................................23
4.4 Outputs................................................26
4.5 Control Voltage....................................27
4.6 Power Terminations ............................28
4.7 Typical Installation ...............................30
4.8 Quick Setup.........................................32
5. Setup Tools .........................................33
5.1 Command Source...............................33
5.2 Commissioning....................................33
5.3 Run simulation.....................................33
5.4 Load/Save Settings.............................34
5.5 USB Save & Load...............................35
5.6 Network Address.................................36
5.7 Digital I/O State....................................37
5.8 Analog I/O State..................................37
5.9 Serial Number & Rating......................37
5.10 Software Versions...............................38
5.11 Thermistor Reset.................................38
5.12 Reset Thermal Model..........................38
6. Logs.....................................................39
6.1 Event Log............................................39
6.2 Counters..............................................39
6.3 QR Code.............................................39
7. Keypad and Feedback........................40
7.1 The Keypad.........................................40
7.2 Remote Keypad..................................41
7.3 Lighten/Darken the Display.................41
7.4 Starter status LEDs.............................42
7.5 Displays...............................................42
8. Operation.............................................44
8.1 Start, Stop and Reset Commands......44
8.2 Command Override............................44
8.3 Emergency Mode................................44
8.4 Auxiliary Trip........................................45
8.5 Typical Control Methods.....................45
8.6 Soft Start Methods ..............................47
8.7 Stop Methods......................................49
9. Programmable Parameters ................51
9.1 Main Menu ..........................................51
9.2 Altering Parameter Values..................51
9.3 Adjustment Lock..................................51
9.4 Parameter List.....................................52
9.5 1 Motor Details....................................56
9.6 2 Motor Start/Stop...............................57
9.7 5 Protection Levels..............................59
9.8 6 Protection Action..............................60
9.9 7 Inputs................................................63
9.10 8 Relay Outputs ..................................65
9.11 9 Analog Output..................................67
9.12 10 Display............................................68
9.13 12 Communications Card...................71
9.14 20 Advanced.......................................74
9.15 30 Pump Input Configuration..............75
9.16 31 Flow Protection ..............................77
9.17 32 Pressure Protection........................77
9.18 33 Pressure Control............................78
9.19 34 Depth Protection ............................79
9.20 35 Thermal Protection.........................79
9.21 36 Pump Trip Action............................80
10. Application Examples..........................82
10.1 Smart Card - Pump Protection............82
710-21918-00A EMX4e User Manual 1

CONTENTS
10.2 Smart Card -Level Controlled Pump
Activation.............................................84
11. Troubleshooting...................................85
11.1 Protection Responses.........................85
11.2 Trip Messages.....................................85
11.3 General Faults.....................................91
2EMX4e User Manual 710-21918-00A

ABOUT THIS MANUAL
1. About This Manual
WARNING
Indicates a hazard that may cause personal injury or death.
CAUTION
Indicates a hazard that may damage the equipment or installation.
NOTE
Provides helpful information.
1.1 Disclaimer
The examples and diagrams in this manual are included solely for illustrative
purposes.
The information contained in this manual is subject to change at any time and
without prior notice. In no event will responsibility or liability be accepted for direct,
indirect or consequential damages resulting from the use or application of this
equipment.
© 2019. All Rights Reserved.
710-21918-00A EMX4e User Manual 3

CAUTION STATEMENTS
2. Caution Statements
Caution Statements cannot cover every potential cause of equipment damage but
can highlight common causes of damage. It is the installer's responsibility to read
and understand all instructions in this manual prior to installing, operating or
maintaining the equipment, to follow good electrical practice including applying
appropriate personal protective equipment and to seek advice before operating this
equipment in a manner other than as described in this manual.
NOTE
The EMX4e is not user serviceable. The unit should only be serviced by
authorised service personnel. Unauthorised tampering with the unit will void
the product warranty.
FOR YOUR SAFETY
•The STOP function of the soft starter does not isolate dangerous
voltages from the output of the starter. The soft starter must be
disconnected by an approved electrical isolation device before accessing
electrical connections.
•Soft starter protection features apply to motor protection only. It is the
user’s responsibility to ensure safety of personnel operating machinery.
•The soft starter is a component designed for integration within an
electrical system; it is therefore the responsibility of the system
designer/user to ensure the system is safe and designed to comply with
relevant local safety standards.
2.1 Electrical shock risk
WARNING – ELECTRICAL SHOCK RISK
The voltages present in the following locations can cause severe electric
shock and may be lethal:
•AC supply cables and connections
•Output cables and connections
•Many internal parts of the starter
SHORT CIRCUIT
The EMX4e is not short circuit proof. After severe overload or short circuit,
the operation of the EMX4e should be fully tested by an authorised service
agent.
GROUNDING AND BRANCH CIRCUIT PROTECTION
It is the responsibility of the user or person installing the EMX4e to provide
proper grounding and branch circuit protection according to local electrical
safety codes.
4EMX4e User Manual 710-21918-00A

CAUTION STATEMENTS
2.2 Unexpected Operation
WARNING – ACCIDENTAL STARTS
In some installations, accidental starts may pose an increased risk to safety
of personnel or damage to the machines being driven. In such cases, it is
recommended that the power supply to the soft starter is fitted with an
isolating switch and a circuit-breaking device (eg power contactor)
controllable through an external safety system (eg emergency stop, fault
detector).
WARNING – STARTER MAY START OR STOP UNEXPECTEDLY
The EMX4e will respond to control commands from various sources, and
could start or stop unexpectedly. Always disconnect the soft starter from
mains voltage before accessing the starter or load.
WARNING – DISCONNECT MAINS BEFORE ACCESSING STARTER
OR LOAD
The soft starter has built-in protections which can trip the starter in the event
of faults and thus stop the motor. Voltage fluctuations, power cuts and motor
jams may also cause the motor to trip.
The motor could restart after the causes of shutdown are rectified, which
may be dangerous for personnel. Always disconnect the soft starter from
mains voltage before accessing the starter or load.
CAUTION – MECHANICAL DAMAGE FROM UNEXPECTED RESTART
The motor could restart after the causes of shutdown are rectified, which
may be dangerous for certain machines or installations. In such cases, it is
essential that appropriate arrangements are made against restarting after
unscheduled stops of the motor.
710-21918-00A EMX4e User Manual 5

CAUTION STATEMENTS
2.3 Avertissements à l'attention des clients canadiens
AVERTISSEMENT
L'icône AVERTISSEMENT ci-contre signale les informations concernant
des risques pouvant entraîner des blessures graves, voire mortelles. Pour
votre sécurité, veuillez consulter les avertissements sur cette page ou
demander une copie du présent manuel en français auprès de votre
distributeur local.
AVERTISSEMENT – RISQUE DE CHOC ÉLECTRIQUE
Les zones suivantes sont soumises à des tensions pouvant provoquer des
risques de chocs électriques graves, voire mortels :
•Raccordement et câbles d'alimentation AC
•Câbles et raccordements de sortie
•De nombreuses pièces internes du démarreur
PAR SÉCURITÉ
•La fonction STOP du démarreur progressif n'isole pas des tensions
dangereuses de la sortie du démarreur. Le démarreur progressif doit
être déconnecté par un dispositif d'isolement électrique approprié avant
d'accéder aux connexions électriques.
•Les fonctions de protection du démarreur progressif ne concernent que
la protection du moteur. Il relève de la responsabilité de l'utilisateur
d'assurer la sécurité des personnes travaillant sur les machines.
•Le démarreur progressif est un appareil conçu pour s'intégrer dans un
système électrique ; il relève donc de la responsabilité du concepteur ou
de l'utilisateur de veiller à ce que ce système soit sûr et conçu selon les
normes de sécurité locales en vigueur.
AVERTISSEMENT – DÉMARRAGES ACCIDENTELS
Dans certaines installations, des démarrages accidentels peuvent
provoquer un risque supplémentaire pour la sécurité des personnes ou
endommager les machines contrôlées. Dans de tels cas, il est
recommandé de doter l'alimentation du démarreur progressif d'un
interrupteur d'isolement et d'un coupe-circuit (par exemple, un disjoncteur)
contrôlable à partir d'un système de sécurité externe (par exemple, un arrêt
d'urgence, un détecteur de défaut).
AVERTISSEMENT – LE DÉMARREUR PEUT DÉMARRER OU
S'ARRÊTER À TOUT MOMENT
L’EMX4e répond aux commandes de contrôle de différentes origines et
peut par conséquent démarrer ou s'arrêter à tout moment. Toujours
déconnecter le démarreur de la tension secteur avant d'accéder au
démarreur ou à la charge.
6EMX4e User Manual 710-21918-00A

CAUTION STATEMENTS
AVERTISSEMENT – DÉCONNECTER L'ALIMENTATION PRINCIPALE
AVANT D'ACCÉDER AU DÉMARREUR OU À LA CHARGE
Le démarreur progressif comporte des protections intégrées qui peuvent
déclencher des mises en sécurité dans l'éventualité de défauts et ainsi
arrêter le moteur. Des fluctuations de tension, des coupures d'alimentation
et des blocages du moteur peuvent produire des mises en sécurité de celui-
ci.
Le moteur pourrait redémarrer une fois que les causes de l'arrêt ont été
résolues, ce qui pourrait mettre en danger le personnel. Toujours
déconnecter le démarreur de la tension secteur avant d'accéder au
démarreur ou à la charge.
AVERTISSEMENT
Ne pas appliquer la tension du secteur au démarreur tant que tout le
câblage n'est pas terminé.
AVERTISSEMENT
Toujours appliquer la tension de commande avant (ou en même temps que)
la tension secteur.
AVERTISSEMENT
Si l'entrée de démarrage est fermée lorsque la tension de commande est
appliquée, le démarreur tentera d'effectuer un démarrage.
Vérifier que l'entrée de démarrage/arrêt est ouverte avant d'appliquer la
tension de commande.
710-21918-00A EMX4e User Manual 7

SYSTEM DESIGN
3. System Design
3.1 Feature List
Streamlined setup process
•Configuration profiles for common
applications
•Built-in metering and inputs/outputs
Easy to understand interface
•Multi-language menus and displays
•Descriptive option names and feedback
messages
•Real-time performance graphs
Supports energy efficiency
•IE3 compatible
•99% energy efficient when running
•Internal bypass
•Soft start technology avoids harmonic
distortion
Extensive range of models
•24 A~580 A (nominal)
•200~525 VAC
•380~600 VAC
Versatile starting and stopping options
•Adaptive Control
•Constant Current
•Current Ramp
•Timed voltage ramp soft stop
•Coast To Stop
Customisable protection
•Motor overload
•Excess Start Time
•Undercurrent
•Overcurrent
•Current imbalance
•Input Trip
•Motor thermistor
Extensive input and output options
•Remote control inputs
(2 x fixed, 2 x programmable)
•Relay outputs
(1 x fixed, 2 x programmable)
•Analog output
Optional features for advanced
applications
•Smart cards
•Communication options:
DeviceNet, Ethernet/IP, Modbus
RTU, Modbus TCP, Profibus,
Profinet
8EMX4e User Manual 710-21918-00A

SYSTEM DESIGN
3.2 Model Code
EMX4e-
0
0
6
9
–
–
Control voltage
C1 = 110~120 VAC or 220~240 VAC
C2 = 24 VAC/VDC
Mains voltage
V5 = 200~525 VAC
V7 = 380~600 VAC
Bypass
B = internally bypassed
Nominal current rating
3.3 Model Selection
Starter sizing
The soft starter must be the correct size for the motor and the application.
Select a soft starter that has a current rating at least equal to the motor's full load
current (nameplate) rating, at the start duty.
The soft starter's current rating determines the maximum motor size it can be used
with. The soft starter's rating depends on the number of starts per hour, the length
and current level of the start, and the amount of time the soft starter will be off (not
passing current) between starts.
The soft starter's current rating is only valid when used in the conditions specified in
the AC53b code - the soft starter may have a higher or lower current rating in
different operating conditions.
710-21918-00A EMX4e User Manual 9

SYSTEM DESIGN
3.4 Current Ratings
For operating conditions not covered by these ratings charts, contact your local
supplier.
IEC ratings
•AC53b format
80 A
:
AC-53b
3.5
-
15
:
345
Off time (seconds)
Start time (seconds)
Start current (multiple of motor full load current)
Starter current rating (amperes)
•Ratings
All ratings are calculated at altitude of 1000 metres and ambient temperature of 40 ºC.
3.0-10:350
3.5-15:345
4.0-10:350
4.0-20:340
5.0-5:355
EMX4e-0024B
24
20
19
16
17
EMX4e-0042B
42
34
34
27
32
EMX4e-0052B
52
42
39
35
34
3.0-10:590
3.5-15:585
4.0-10:590
4.0-20:580
5.0-5:595
EMX4e-0064B
64
63
60
51
54
EMX4e-0069B
69
69
69
62
65
EMX4e-0105B
105
86
84
69
77
EMX4e-0115B
115
108
105
86
95
EMX4e-0135B
135
129
126
103
115
EMX4e-0184B
184
144
139
116
127
EMX4e-0200B
200
171
165
138
150
EMX4e-0229B
229
194
187
157
170
EMX4e-0250B
250
244
230
200
202
EMX4e-0352B
352
287
277
234
258
EMX4e-0397B
397
323
311
263
289
EMX4e-0410B
410
410
410
380
400
EMX4e-0550B
550
527
506
427
464
EMX4e-0580B
580
579
555
470
508
10 EMX4e User Manual 710-21918-00A

SYSTEM DESIGN
NEMA motor ratings
All ratings are calculated at altitude of 1000 metres and ambient temperature of 50 ºC.
Light
300%, 10 s,
6 starts per hour
Normal
350%, 30 s,
4 starts per hour
Heavy
450%, 30 s,
4 starts per hour
A
HP
@23
0 VA
C
HP
@46
0 VA
C
HP
@57
5 VA
C
A
HP
@23
0 VA
C
HP
@46
0 VA
C
HP
@57
5 VA
C
A
HP
@23
0 VA
C
HP
@46
0 VA
C
HP
@57
5 VA
C
EMX4e-0024B
24
7.5
15
20
17
5
10
15
14
3
10
10
EMX4e-0042B
42
15
30
40
28
10
20
25
22
7.5
15
20
EMX4e-0052B
52
15
30
50
35
10
25
30
28
10
20
25
EMX4e-0064B
64
20
40
60
52
15
40
40
40
10
25
30
EMX4e-0069B
69
25
50
60
59
20
40
50
46
15
30
40
EMX4e-0105B
100
30
75
100
77
25
60
60
52
15
40
50
EMX4e-0115B
115
40
75
100
81
30
60
75
65
20
50
60
EMX4e-0135B
135
50
100
125
99
30
75
100
77
25
60
75
EMX4e-0184B
164
60
125
150
124
40
100
100
96
30
75
75
EMX4e-0200B
200
75
150
200
131
50
100
125
104
40
75
100
EMX4e-0229B
229
75
150
200
156
60
125
150
124
40
100
100
EMX4e-0250B
250
100
200
250
195
75
150
200
156
60
125
150
EMX4e-0352B
341
125
250
350
240
75
200
200
180
60
150
150
EMX4e-0397B
389
150
300
400
261
100
200
250
203
75
150
200
EMX4e-0410B
410
150
300
450
377
150
300
350
302
100
250
300
EMX4e-0550B
550
200
450
500
414
150
350
450
321
125
250
300
EMX4e-0580B
580
200
500
500
477
200
400
500
361
150
300
350
710-21918-00A EMX4e User Manual 11

SYSTEM DESIGN
3.5 Dimensions and Weights
Width
mm (inch)
Height
mm (inch)
Depth
mm (inch)
Weight
kg
A
B
C
D
E
(lb)
EMX4e-0024B
4.7
EMX4e-0042B
(10.4)
EMX4e-0052B
4.8
(10.7)
EMX4e-0064B
152
92
336
307
231
EMX4e-0069B
(6.0)
(3.6)
(13.2)
(12.1)
(9.1)
EMX4e-0105B
5.0
(11.0)
EMX4e-0115B
EMX4e-0135B
EMX4e-0184B
EMX4e-0200B
495
11.7
EMX4e-0229B
216
180
(19.5)
450
243
(25.8)
EMX4e-0250B
(8.5)
(7.1)
(17.7)
(9.6)
EMX4e-0352B
12.5
(27.6)
EMX4e-0397B
523
EMX4e-0410B
(20.6)
EMX4e-0550B
15.0
EMX4e-0580B
(33.1)
A
B
CD
E
A
B
C D
E
17043.B
12 EMX4e User Manual 710-21918-00A

SYSTEM DESIGN
3.6 Physical Installation
Between starters
Solid surfaces
A
B
C
D
> 100 mm (3.9 inch)
> 10 mm (0.4 inch)
> 100 mm (3.9 inch)
> 10 mm (0.4 inch)
3.7 Accessories
Expansion Cards
The EMX4e offers expansion cards for users requiring additional inputs and outputs
or advanced functionality. Each EMX4e can support a maximum of one expansion
card.
•Smart Card
The smart card has been designed to support integration with pumping applications
and provides the following additional inputs and outputs:
•3 x digital inputs
•3 x 4-20 mA transducer inputs
•1 x RTD input
•1 x USB-B port
•Remote keypad connector
•Communication Expansion Cards
The EMX4e supports network communication via easy-to-install communications
expansion cards. Each communications card includes a remote keypad connector
port.
Available protocols:
DeviceNet, Ethernet/IP, Modbus RTU, Modbus TCP, Profibus, Profinet.
D
D
17044.B
C
C
B
A
710-21918-00A EMX4e User Manual 13

SYSTEM DESIGN
Remote Keypad
EMX4e starters can be used with a remote keypad, mounted up to 3 metres away
from the starter. Each expansion card includes a keypad connection port, or a
dedicated keypad connector card is available.
Finger Guard Kit
Finger guards may be specified for personnel safety. Finger guards fit over the soft
starter terminals to prevent accidental contact with live terminals. Finger guards
provide IP20 protection when used with cable of diameter 22 mm or greater.
Finger guards are compatible with models EMX4e-0184B ~ EMX4e-0580B.
Soft Starter Management Software
PC software can provide real-time or offline management of soft starters.
•For real-time management in a network of up to 254 starters, the software
must connect to the soft starter via a Modbus TCP or Modbus RTU card.
The software can monitor, control and program the starter across the
network.
•The software can be used to program the starter via the USB port on the
pumping smart card.
•For offline management, a configuration file generated in the software can
be loaded into the starter via the USB port.
3.8 Main Contactor
A main contactor is recommended to protect the soft starter from voltage
disturbances on the network, while stopped. Select a contactor with an AC3 rating
greater than or equal to the full load current rating of the connected motor.
Use the main contactor output (33, 34) to control the contactor.
3.9 Circuit Breaker
A shunt trip circuit breaker may be used instead of a main contactor to isolate the
motor circuit in the event of a soft starter trip. The shunt trip mechanism must be
powered from the supply side of the circuit breaker or from a separate control
supply.
14 EMX4e User Manual 710-21918-00A

SYSTEM DESIGN
3.10 Power Factor Correction
If power factor correction is used, a dedicated contactor should be used to switch in
the capacitors.
To use the EMX4e to control power factor correction, connect the PFC contactor to
a programmable relay set to Run. When the motor reaches full speed, the relay will
close and power factor correction will be switched in. Do not use the soft starter
relay output to directly switch in power factor correction.
1
Soft starter
2
Programmable output (set = Run)
3
Power factor correction contactor
4
Power factor correction
CAUTION
Power factor correction capacitors must be connected to the input side of
the soft starter. Connecting power factor correction capacitors to the output
side will damage the soft starter.
3.11 Short Circuit Protection Devices (SCPD)
Fuses may be installed to protect the soft starter or the installation.
Type 1 Coordination
Type 1 coordination requires that, in the event of a short circuit on the output side of
a soft starter, the fault must be cleared without risk of injury to personnel. There is no
requirement that the soft starter must remain operational after the fault.
HRC fuses (such as Ferraz/Mersen AJT fuses) can be used for Type 1 coordination
according to IEC 60947-4-2 standard.
Type 2 Coordination
Type 2 coordination requires that in the event of a short circuit on the output side of
a soft starter, the fault must be cleared without risk of injury to personnel or damage
to the soft starter.
Semiconductor fuses for Type 2 circuit protection are additional to HRC fuses or
MCCBs that form part of the motor branch circuit protection.
CAUTION
Integral solid state short circuit protection does not provide branch circuit
protection. Branch circuit protection must be provided in accordance with
the
National Electrical Code and any additional local codes.
K1 K1
1
2
4
3
20234.A
710-21918-00A EMX4e User Manual 15

SYSTEM DESIGN
3.12 IEC Coordination with Short Circuit Protection
Devices
These fuses were selected based on start current of 300% FLC for 10 seconds.
Nominal
Rating (A)
SCR I2t (A2s)
Type 1
coordination
480 VAC, 65 kA
Bussmann NH
fuse links
Type 2
coordination
600 VAC, 65 kA
Bussmann
DIN 43 653
EMX4e-0024B
24
1150
40NHG000B
170M3010
EMX4e-0042B
42
7200
63NHG000B
170M3013
EMX4e-0052B
52
80NHG000B
EMX4e-0064B
64
15000 100NHG000B 170M3014
EMX4e-0069B
69
EMX4e-0105B
105
80000 160NHG00B 170M3015
EMX4e-0115B
115
EMX4e-0135B
135
125000
170M3016
EMX4e-0184B
184
320000
250NHG2B 170M3020
EMX4e-0200B
200
EMX4e-0229B
229
315NHG2B
EMX4e-0250B
250
170M3021
EMX4e-0352B
352
202000
355NHG2B
170M6009
EMX4e-0397B
397
400NHG2B
EMX4e-0410B
410
320000
425NHG2B
170M6010
EMX4e-0550B
550
781000 630NHG3B 170M6012
EMX4e-0580B
580
16 EMX4e User Manual 710-21918-00A

SYSTEM DESIGN
3.13 UL Coordination with Short Circuit Protection Devices
Standard Fault Short Circuit Current Ratings
Suitable for use on a circuit capable of delivering not more than the stated level of
amperes (symmetrical rms, refer ##1 in table), 600 VAC maximum.
•Maximum fuse rating (A) – Standard fault short circuit current
Model Nominal Rating (A)
3 cycle short cct rating
@600 VAC ##1 †
EMX4e-0024B
24
5 kA
EMX4e-0042B
42
EMX4e-0052B
52
10 kA
EMX4e-0064B
64
EMX4e-0069B
69
EMX4e-0105B
105
EMX4e-0115B
120
EMX4e-0135B
135
EMX4e-0184B
184
18 kA
EMX4e-0200B
225
EMX4e-0229B
229
EMX4e-0250B
250
EMX4e-0352B
352
EMX4e-0397B
397
EMX4e-0410B
410
30 kA
EMX4e-0550B
550
EMX4e-0580B
580
† Suitable for use in a circuit with the prospective current noted, when protected by
any Listed fuses or Listed circuit breakers sized according to the NEC.
710-21918-00A EMX4e User Manual 17

SYSTEM DESIGN
High Fault Short Circuit Current Ratings
•Maximum fuse rating (A) – High fault short circuit current
Suitable for use on a circuit capable of delivering not more than 65,000 rms
symmetrical amperes, 480 VAC maximum, when protected by fuses of the stated
class and rating (refer ##2 and ##3 in table).
Model Nominal
Rating (A)
Short Circuit
Rating @ 480
VAC max.
Listed fuse rating
(A)
##3
Fuse class
##2
EMX4e-0024B
24
30
Any
(J, T, K-1, RK1,
RK5)
EMX4e-0042B
42
50
EMX4e-0052B
52
60
EMX4e-0064B
64
80
EMX4e-0069B
69
80
EMX4e-0105B
105
125
EMX4e-0115B
120
65 kA
125
J, T, K-1, RK1
EMX4e-0135B
135
150
EMX4e-0184B
184
200
J, T
EMX4e-0200B
225
225
EMX4e-0229B
229
250
EMX4e-0250B
250
300
EMX4e-0352B
352
400
Any
(J, T, K-1, RK1,
RK5)
EMX4e-0397B
397
450
EMX4e-0410B
410
450
EMX4e-0550B
550
600
EMX4e-0580B
580
600
18 EMX4e User Manual 710-21918-00A

SYSTEM DESIGN
•Circuit breakers – High fault short circuit current
Suitable for use on a circuit capable of delivering not more than 65,000 rms
symmetrical amperes, 480 VAC maximum, when protected by circuit breaker
models noted in ##4, ##5 or ##6.
Model Nominal
Rating (A)
Breaker 1: Eaton
(rating, A)
##4
Breaker 2: GE
(rating, A)
##5
Breaker 3: LS
(rating, A) 1
##6
EMX4e-0024B
24 HFD3030 (30 A)
SELA36AT0060
(60 A)
UTS150H-xxU-040
(40 A)
EMX4e-0042B
42 HFD3050 (50 A)
UTS150H-xxU-050
(50 A)
EMX4e-0052B
52 HFD3060 (60 A)
UTS150H-xxU-060
(60 A)
EMX4e-0064B
64
HFD3100 (100 A)
SELA36AT0150
(150 A)
UTS150H-xxU-100
(100 A)
EMX4e-0069B
69
EMX4e-0105B
105
HFD3125 (125 A)
UTS150H-xxU-125
(125 A)
EMX4e-0115B
120
EMX4e-0135B
135 HFD3150 (150 A)
UTS150H-xxU-150
(150 A)
EMX4e-0184B
184
HJD3250 (250 A)
SFLA36AT0250
(250 A) UTS250H-xxU-250 (250 A)
EMX4e-0200B
225
EMX4e-0229B
229
EMX4e-0250B 250 HKD3300 (300 A)
SFLA36AT0400
(400 A)
UTS400H-xxU-300
(300 A)
EMX4e-0352B
352
HLD3400 (400 A)
SFLA36AT0600
(600 A)
UTS400H-xxU-400
(400 A)
EMX4e-0397B
397
EMX4e-0410B 410
HLD3600 (600 A)
UTS600H-xxU-600
(600 A)
EMX4e-0550B 550
UTS800H-xxU-800
(800 A)
EMX4e-0580B 580
SGLA36AT0600
(600 A) UTS800H-NG0-800
1For LS breakers, xx represents FM, FT or AT.
710-21918-00A EMX4e User Manual 19
