Bensons for Beds PENELOPE STK770604 User manual

Page<1/5>
Assembly Instructions
Please keep these instructions for future reference.
Regrettably self-assembly items cannot be returned once assembly is part or fully completed
unless the items are found to be faulty. Should you need to return the unassembled product,
please repack in its original packaging.
Important information
— We suggest you spend a short time reading through this leaflet and then follow the simple
step-by-step instructions.
— Carefully check that you have all the parts before beginning assembly.
— Keep fittings out of children's reach and keep children well away from construction area.
— We suggest you retain these instructions for future reference.
—In the unusual event of an issue with your product would you please quote the batch I.D.
number situated on the main parts of the frame (Head End- Foot End- side Rails).
Product information
— Upholstered Bed Using Fabric Material. Conforms to BS EN1725 & BS 5852
Care instructions
— Avoid exposing the furniture to excessive heat or direct sunlight as this can cause cracking and
deterioration of the color.
— Periodically check & re-tighten any fastener.
— Periodically dust lightly with a clean soft cloth.
— Do not use silicone based furniture polish.
— Any spills should be removed immediately with a damp cloth.
— TAKE CARE WHEN MOVING THE FURNITURE AND NEVER DRAG THE PIECES ACROSS
THE FLOOR, AS THIS WILL CAUSE DAMAGE TO THE JOINTS
PENELOPE Bed frame Upholstered 150cm
STK770604/STK770610/STK770617
Minimum Two
Persons Assembly
Approximate
Assembly Time
30 MIN

Component of Carton A Component of Carton B
(1) Head Board 1
Hardware List
(2) Foot Board 1
King: 150cm 200cm
Step 1
Page<2/5>
(A) M8 25 Bolt
4
(E) 5MM Allen key
1
(7) Feet 4
(C) M8 100 Bolt
4
(F) 5MM Allen key
1
(3) Side Rail 2
(6) Slat 32
(5) Support Leg 2
(4)Center Rail 1
(B) M8 35 Bolt(Already inserted
into support legs)
2(D) 5
16" Flat Washer
4
LOOSEN
LOOSEN
2
1
7
7
7
7
F
E
D
D
(8) Plastic end cap 36
(spare 4pcs)
(9) Plastic center cap 18
(spare 2pcs)
CC
E
(G) M8 40 Bolt
8 (pre-installed on frame)
G
G

Page<3/5>
Step 3
Step 2
3
3
4
A
E

Page<4/5>
Step 4
6
6
9
8
8
5
5
5
LOOSEN
B
E
5
B
E
Step 5

Page<5/5>
Step 6
