Bensons for Beds BELLA STK770302 User manual

Page<1/6>
Assembly Instructions
Please keep these instructions for future reference.
Regrettably self-assembly items cannot be returned once assembly is part or fully completed
unless the items are found to be faulty. Should you need to return the unassembled product,
please repack in its original packaging.
Important information
— We suggest you spend a short time reading through this leaflet and then follow the simple
step-by-step instructions.
— Carefully check that you have all the parts before beginning assembly.
— Keep fittings out of children's reach and keep children well away from construction area.
— We suggest you retain these instructions for future reference.
—In the unusual event of an issue with your product would you please quote the batch I.D.
number situated on the main parts of the frame (Head End- Foot End- side Rails).
Product information
— Upholstered Bed Using Fabric Material. Conforms to BS EN1725 & BS 5852
Care instructions
— Avoid exposing the furniture to excessive heat or direct sunlight as this can cause cracking and
deterioration of the color.
— Periodically check & re-tighten any fastener.
— Periodically dust lightly with a clean soft cloth.
— Do not use silicone based furniture polish.
— Any spills should be removed immediately with a damp cloth.
— TAKE CARE WHEN MOVING THE FURNITURE AND NEVER DRAG THE PIECES ACROSS
THE FLOOR, AS THIS WILL CAUSE DAMAGE TO THE JOINTS
BELLA Ottoman Bedframe135cm
STK770302/STK770306/STK770310
Minimum Two
Persons Assembly
Approximate
Assembly Time
60 MIN

Component of Carton A Component of Carton B
(1) Head Board 1
Hardware List
(2) Foot Board 1
(3) Side Rail (R&L) 2
(4) Shelf rail / long 1
(8) Bed Base 1
(7) Lifting arms (R&L) 2
(5) Shelf rail / short 2
Component of Carton D
(9) Shelf 4
Component of Carton C
Step 1
Page<2/6>
(A) M8 20 Bolt
10
(B) 14" 3/4" Bolt
10
(C) 14" Jcn Nut
2
(D) M6 55 Bolt
4
(E) M8 30 Bolt
8
(F) M8 25 Bolt
6
(I) Locknut
2
(G) Ø8 Spring Washer
6
(H) Ø8 Flat Washer
6
(J) Adjuster Bolt
2
(K) 4MM Allen key
2
(L) 5MM Allen key
1
(M) Spanner
1
H
G
F
LOOSEN
L
(6) Support Rail 1
1
2
(N) M8 45 Bolt
2
N
L
(10) Feet 2
10
(O) M8 40 Bolt
6(pre-installed on frame)
O
Unpack the Foot Board (Part 2) and Feet (Part 10)
from the rear of the Head Board.
1
210
(P) Ø45 Pad
4
P
P
P
Double: 135cm 190cm

Page<3/6>
Step 2
Step 3
3(R)
3(L)
J
4
4
Do not tighten Bolt F & O fully until the
bolts for Part 4 &Part 5 in Step 4 are
inserted and connected to bed frame.
O
F

B
B
4
K
Page<4/6>
Step 4
Step 5
8
6
D
7(R)
7(L)
M
I
I
I
M
Step 6
NOTES: Attach cylinders to lifting arms
by using Locknut "I" as shown .
B
C5
54
K
K
K
5
5
4

Page<5/6>
7(R)
Step 8
E
EE
E
L
A
A
A
A
L
Step 7

Page<6/6>
9
9
9
9
Step 10
Step 9
"IMPORTANT NOTICE"
---WARNING: PLEASE DO NOT ALLOW CHILDREN OR PETS INSIDE THE
STORAGE AREA.
---WARNING: PLEASE BE CAREFUL WHEN LIFTING.
ONLY LIFT WITH MATTRESS ON TOP.
TO BE OPERATED BY ADULTS ONLY.
---WARNING: PLEASE DO NOT PRESS DOWN ON THE MATTRESS WHEN
THE BED FRAME IS IN THE LIFT UP POSITION.
---WARNING: THE BED FRAME TOP MUST ONLY BE CLOSED BY USING TWO
HANDS EQUALLY SPACED FROM THE CENTER OF THE
MATTRESS BASE.
Use the strap handle to lift up the mattress base using two hands
Pull the mattress base down using two hands equally spaced from
the center of the mattress base. DO NOT pull down on one side of
base only as this is likely to damage the base system with potential
failure of the mattress base system and lift mechanism.
MATTRESS
MATTRESS
