Installation and Operation Manual
Condensation | Heating module
POWER MAX
Installation and Operation Manual
EN

2
RANGE
MODEL CODE
POWER MAX 50 P DEP 20128429
POWER MAX 50 P 20128430
POWER MAX 65 P 20128431
POWER MAX 80 P 20128432
POWER MAX 100 20128433
POWER MAX 110 20128434
POWER MAX 130 20128435
POWER MAX 150 20128436
ACCESSORIES
For a complete list of accessories and details of their compatibility,
refer to the Catalogue.
ENGLISH
Dear heating engineer,
congratulations on having chosen a thermal module B, a qual-
ity product that is designed to give dependable, efcient and safe
service and to provide comfort in the home for many years to come.
This manual provides information that is essential to the installation
of the appliance. Used in conjunction with your own knowledge and
expertise it will enable you to install the appliance quickly, easily, and
correctly.
Please accept our thanks and our congratulations on your choice of
product.
Beretta
CONFORMITY
thermal modules POWER MAX comply with:
- Regulation (EU) 2016/426
- Directive 92/42/EEC on efciency requirements and Annex E
and Pres. Republic Decree n. 412, 26 August 1993 (****)
- Electromagnetic Compatibility Directive 2014/30/EU
- Low Voltage Directive 2014/35/EU
- Ecodesign Directive 2009/125/CE for energy-related products
- Regulation (EU) 2017/1369 Energy labelling
- Delegated Regulation (EU) N. 811/2013
- Delegated Regulation (EU) N. 813/2013
- Standard for gas-red heating boilers - General requirements
and tests - EN 15502-1
- Specic standard for type C appliances and type B2, B3 and
B5 appliances of nominal heat input not exceeding 1000 kW
- EN 15502-2/1
- SSIGA Gas Appliance Directive G1
- AICAA Fire prevention requirements
- CFST LPG Directive Part 2
- VARIOUS cantonal and communal provisions on air quality
and energy saving.
At the end of its life, the product
should be not be disposed of as sol-
id urban waste, but rather it should be
handed over to a differentiated waste
collection centre.

This manual, Code 20133145 - Rev. 9 (12/21) comprises 68 pages.
3
CONTENTS
The following symbols are used in this manual:
b
CAUTION! = Identies actions that require caution and ad-
equate preparation.
a
STOP! = Identies actions that you MUST NOT do.
Thismanual,Code
-Rev.
comprises
pages.
1 GENERAL INFORMATION . . . . . . . . . . . . . . . . . 4
1.1 General Safety Information . . . . . . . . . . . . . . . . . . . . . . . . . 4
1.2 Precautions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
1.3 Description of the appliance . . . . . . . . . . . . . . . . . . . . . . . . 5
1.4 Safety devices . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
1.5 Identication. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
1.6 System layout. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
1.7 Technical specications . . . . . . . . . . . . . . . . . . . . . . . . . . 10
1.8 Pumps. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
1.9 Water circuit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
1.10 Positioning the temperature sensors . . . . . . . . . . . . . . . . 13
1.11 Control panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
2 INSTALLATION . . . . . . . . . . . . . . . . . . . . . . . . . . 15
2.1 Unpacking the product . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
2.1.1 Positioning of labels . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
2.2 Overall dimensions and weights. . . . . . . . . . . . . . . . . . . . 15
2.3 Installation premises . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
2.3.1 Recommended minimum distances. . . . . . . . . . . . . . . . . 16
2.4 Installation in older systems and systems requiring
modernisation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
2.5 Moving and removing the packing. . . . . . . . . . . . . . . . . . 17
2.6 Thermal module assembly . . . . . . . . . . . . . . . . . . . . . . . . 17
2.7 Water connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
2.8 Typical water system schematics. . . . . . . . . . . . . . . . . . . 20
2.9 Gas connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
2.10 Discharge of combustion products . . . . . . . . . . . . . . . . . 23
2.10.1 Preparation for the condensate drain . . . . . . . . . . . . . . . . 26
2.11 Neutralising the condensate . . . . . . . . . . . . . . . . . . . . . . . 26
2.11.1 Water quality requirements . . . . . . . . . . . . . . . . . . . . . . . . 26
2.12 System lling and emptying . . . . . . . . . . . . . . . . . . . . . . . 27
2.12.1 Filling. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
2.12.2 Emptying . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
2.13 Wiring diagram. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
2.14 Electrical connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
2.14.1 USER navigation MENU . . . . . . . . . . . . . . . . . . . . . . . . . . 34
2.15 Navigation Menu INSTALLER / MANUFACTURER . . . . . 36
3 COMMISSIONING AND MAINTENANCE. . . . . 41
3.1 Preparing for initial startup. . . . . . . . . . . . . . . . . . . . . . . . . 41
3.2 Initial startup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
3.2.1 Switching the appliance on and off . . . . . . . . . . . . . . . . . 41
3.2.2 Password access. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
3.2.3 Setting the heating parameters. . . . . . . . . . . . . . . . . . . . . 42
3.2.4 Setting the domestic hot water parameters . . . . . . . . . . . 44
3.3 Checks during and after initial start-up. . . . . . . . . . . . . . . 46
3.4 Error List . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
3.4.1 Permanent Errors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
3.4.2 Temporary Errors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
3.4.3 Warnings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
3.5 Transformation from one gas type to another . . . . . . . . . 50
3.6 Adjustments . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52
3.7 Temporary or short-term shut-down . . . . . . . . . . . . . . . . . 53
3.8 Preparing for extended periods of disuse . . . . . . . . . . . . 53
3.9 Display board replacement. . . . . . . . . . . . . . . . . . . . . . . . 53
3.10 Control board replacement . . . . . . . . . . . . . . . . . . . . . . . . 54
3.11 Maintenance. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54
3.12 Cleaning and removing internal components . . . . . . . . . 55
3.12.1 Condensate drain siphon cleaning. . . . . . . . . . . . . . . . . . 59
3.13 Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60
4 SYSTEM MANAGER . . . . . . . . . . . . . . . . . . . . . 61
4.1 Putting into service. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61
4.2 Temporary or short-term shut-down . . . . . . . . . . . . . . . . . 62
4.3 Preparing for extended periods of disuse . . . . . . . . . . . . 62
4.4 Cleaning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 62
4.5 Maintenance. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 62
4.6 Useful information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63
5 RECYCLING AND DISPOSAL. . . . . . . . . . . . . . 64

4
1 GENERAL INFORMATION
1.1 General Safety Information
b
After removing the packaging, check the condition and com-
pleteness of the supply. If there are any problems, contact the
company Bthat sold the equipment.
b
This product must be installed by a legally qualied heating
engineer. On completion of the installation, the installer must
issue the owner with a declaration of conformity conrming that
the installation has been completed to the highest standards
in compliance with the instructions provided by Bin this
instruction manual, and that it conforms to all applicable laws
and standards.
b
This product must only be used for the purpose for which it is
designed and made, as specied by B. Bdeclines all
responsibility, contractual or other, for damage to property or
injury to persons or animals caused by improper installation,
adjustment, maintenance or use.
b
In the event of a water leak, disconnect the thermal module
from the main power supply, shut off the water supply and
promptly notify the Technical Assistance Centre Bor pro-
fessionally qualied personnel.
b
Periodically check that operating pressure in the water circuit
is over 1 bar but below the maximum limit specied for the boil-
er. If this is not the case, contact Technical Assistance Centre
B or a professionally qualied heating engineer.
b
The following operations shall be necessary if the thermal mod-
ule is not used for a long period of time:
- Switch the boiler OFF at the control panel
- Turn the main system switch "off"
- Close the fuel cock and heating circuit water cock
- Drain the central heating circuit if there is any risk of freezing.
b
Maintenance must be performed on the thermal module at
least once a year.
b
This manual is an integral part of the appliance and must
therefore be kept with care and must ALWAYS accompany the
thermal module, even when it is passed on to another owner
or user or transferred to another installation. If it is lost or dam-
aged, please contact your local Technical Assistance Centre
Bfor a new copy.
b
This manual must be read carefully so as to ensure the correct
and safe installation, operation and maintenance of the appli-
ance. The Owner must be adequately informed and trained on
how to operate the appliance. Make sure that he/she is familiar
with all the information required for safe system operation.
b
The thermal module, before being connected to the hydraulic
system, the gas network, and the electrical system, may be
exposed to temperatures ranging from 4°C to 40°C. After it can
activate the Frost Protection function, it can be exposed to tem-
peratures ranging from -20°C to 40° C
b
Regularly check that the condensate drain is free from obstruc-
tion.
b
We recommend cleaning inside the exchanger once a year,
extracting jet and burner and removing any installation debris
by suction. This operation should be done by personnel from
the Technical Assistance Centre only.
1.2 Precautions
The operation of any appliance that uses fuel, electrical power and
water demands that a number of fundamental safety precautions be
respected:
a
Do not allow children or inrm persons to operate the system
unsupervised.
a
It is forbidden to use electrical devices or equipment, such as
switches, appliances, etc. if there is a smell of gas or un-burnt
products. If so:
- Ventilate the room, opening doors and windows
- Close the fuel shut-off cock
- Report the fault immediately to the B's Technical Assis-
tance Centre or a professionally qualied heating engineer.
a
Do not touch the boiler while barefoot or wet.
a
Any technical or cleaning activity is forbidden before discon-
necting the appliance from the main power supply by switch-
ing the system's master switch and the appliance's main
switch to the "OFF" position.
a
Do not tamper with or adjust the safety or control devices with-
out prior authorisation and instructions from the manufacturer.
a
Do not plug or block the condensate drain outlet.
a
Never pull, disconnect, or twist the electrical cables coming
from the appliance even if it is disconnected from the mains
electricity supply.
a
Do not obstruct or restrict the vents in the room where the boiler
is installed. Adequate ventilation is essential for correct com-
bustion.
a
Do not expose the appliance to weather elements (without us-
ing the dedicated accessory). It has been designed for indoor
use.
a
Do not switch off the appliance if the outdoor temperature may
drop to below ZERO (frost hazard).
a
Do not leave ammable containers and substances in the
room where the device is installed.
a
Do not dispose of packaging material into the environment, or
leave it within the reach of children, since it can become a po-
tential hazard. Dispose of packaging material in compliance
with applicable legislation.
a
Do not activate the thermal module without water.
a
Individuals without specic qualications and skills are not al-
lowed not remove the thermal module's casing.

5
1.3 Description of the appliance
POWER MAX it is a condensing, pre-mixed thermal module consist-
ing in a modulating thermal element.
It is available in various models, ranging from 34,9kW to 131kW.
Optimal combustion management supports high yields (over 109%,
calculated over NVC, in condensation regime) and low polluting
emissions (Class 6 pursuant to EN 15502).
The thermal module is designed for open chamber operation, but
can be converted to sealed chamber operation by tting a dedicated
accessory.
The appliance in standard conguration is envisaged for indoor in-
stallation to guarantee an IPX4D protection level.
b
POWER MAX appliances may be cascaded to reach a maxi-
mum power of 1.12 MW.
The appliance's key technical features are
- pre-mix burner with constant air-gas ratio;
- helical type heat-exchanger, coil with smooth stainless steel
tube (single coil for models POWER MAX 50 P DEP - POWER
MAX 50 P, double coil for models POWER MAX 65 P ÷ POWER
MAX 150), to guarantee a good corrosion resistance and the
possibility of working with high Δt (up to 40°C) reducing the
time of set-up;
- power from 34,9 to 131 kW;
- maximum ue gas output temperature 100°C;
- microprocessor management and control with self-diagnos-
tics, shown by means of a display, and logging of main errors;
- Anti-Frost function;
- provision for room thermostat / heat request on high or low tem-
perature zones;
- option to manage a CH circuit and a DHW circuit with storage
tank;
- high-efciency and high residual discharge head circulator
(for models up to 68kW; a circulator is available as an acces-
sory upon request for other models);
- climate control function (available only when using the outdoor
temperature sensor accessory).
1.4 Safety devices
All appliance functions are electronically controlled by a dual proces-
sor technology board approved for safety functions.
Any malfunction results in the appliance being shut down and the
automatic closure of the gas valve.
The following is installed on the water circuit:
-
Safety thermostat .
- Flow sensor capable of monitoring the main circuit's ow on
an ongoing basis and of stopping the appliance in the event
of insufcient ow.
- Temperature probes on delivery and return lines that meas-
ure the temperature difference (∆t) between input and output
uid and enable activation of the control.
- Minimum pressure switch .
The following is installed on the combustion circuit:
- Gas solenoid in class B+C , with pneumatic gas ow com-
pensation depending on the suction line's air ow rate.
- Ignition/detection electrode .
- Flue gases temperature probe .
b
The triggering of safety devices indicates the malfunction of
a potentially hazardous thermal module. Therefore, contact
Technical Assistance Centre immediately. After a brief pause,
it is possible to try and restart the appliance (see Paragraph "
Initial startup").
b
Safety devices must be replaced by Technical Assistance
Centre, using only original parts. Refer to the spare parts cat-
alogue supplied with the appliance. After making the repair,
check that the appliance is working properly.
a
The appliance must not be put in service, even temporarily,
when tampered safety devices are not in operation or have
been tampered with.

6
1.5 Identication
The products are identied by:
Technical data plate
It indicates the technical and performance data.
Qm=
RIELLO S.p.A.
Via Ing.Pilade Riello, 7
37046 Legnago (VR)
ITALY
II2H3+
G20 - 20 mbar
Cod.
Caldaia a condensazione
Condensing boiler
Chaudierè a condensation
Caldera de condensación
Centrala in condensatie
Kondensácios kazán
N°
230V ~ 50Hz W
X4D

P.min.G20= 20 mbar
IP
Caldaia regolata per: Boiler set at: Chaudiére adaptée pour: Caldera regulata para: Caldeira regulada para: Kedel indistillet till: Pe c nastavljena za: Centrala reglata pentru: Bojler namenjen za plin:
Paese di destinazione: Destination country: Pays de destination: Pais de destino: Pais de destino: Destinationsland: Ciljna drzva: Tara de destinatie: Destinacija: Kraj przeznaczenia:
0085 / 18
NOx:
bar
kW
Pn=
kW
kW
Pm=
II2H3+
Pm=
I2E(S)
I3+
II2E+3+
LU : G20=20 mbar G31=37 mbar
PL-RU: G20=20 mbar G30= 37 mbar (RU=37mbar)
FR: G20/25= 20/25mbar G30/G31=28-30/37mbar
II2E3B/P
BE : G30/G31=28-30/37mbar G31=28-30/37mbar
PMS=
II2ELL3B/P
PL: G20=20mbar G30/G31=30mbar
II2ELwLs3P
I2E3P
II2H3B/P
II2H3P
II2ESi3B/P
50-30 °C80-60 °C80-60 °C
IT-AT-BE-CH-CY-CZ-DE-DK-EE-ES-FI-FR-GB- GR-HR-HU
I3B/P
SK: G20=20mbar (ES=18mbar) G30=28-30mbar G31=37mbar
II2ESi3+
DE: G20/25=20 mbar G30=50 mbar
FR : G20/G25=20/25 mbar G30/G31=28-30/37 mbar
RO-IE-SI-BG-DK-SK-EE--SE-NO-LV-LT-FI-TR:G20=20mbar G30=30mbar
FR: G20/25= 20/25mbar G30=28-30mbar
II2H3B/P
HR:G20=20mbar G30/G31=30mbar HU: G20=25mbar G30=30mbar
II2H3B/P
SK-CZ-LU-AT-CH:G20=20mbar G30=50mbar
SI-SK: G20=20mbar G31=37mbar
II2L3B/P
NL: G25=25mbar G30=30mbar
0085CP0214
T= °C
Qn=
MT-CY-IS: G30=30mbar
kW
kW
Pn=

IT-GB-GR-IE-PT-SI: G20=20mbar G30/G31=28-30/37mbar
BE : G20/25=20/25 mbar
Pn=
G20
kW Qn=
G20
G25
G25
Qm=
kW
Pn=
kW
kW
kW
Central heating section
Qn Rated heat input
Pn Rated useful heat output
IP Electric degree of protection
PMS Maximum operating pressure, CH circuit
T Temperature
η Efciency
NOx NOx class
b
If these plates or any other means of clearly identifying the product are defaced, removed or lost, proper installation and servicing may
be rendered difcult.

7
1.6 System layout
POWER MAX 50 P DEP - 50 P
1
3
6
23
22
24
7
17
9
2
5
4
16
13 14 15
1
2
3
4
6
5
7
8
10
9
11
24
21
22
23
25
17
18
19
12
20
1 Flue gas analysis outlet
2 Flue gas exhaust connection
3 Gas valve
4 Fan
5 Flue gases pressure switch
6 Combustion chamber
7 Electrical panel
8 Minimum Pressure Switch set at 0,7 bar
9 Exhaust ue probe
10 Condensate drain siphon
11 Drain cock
12 Main switch
13 Central heating return
14 Gas supply
15 Central heating ow
16 Condensate drain connection
17 Flow-meter
18 Pump
19 Return probe
20 Control panel
21 Safety Thermostat with manual reset by PCB
22 Flow probe
23 Automatic bleed valve
24 Ignition/detection electrode
25 Casing

8
POWER MAX 65 P - 80 P
1
2
3
4
5
1
4
5
6
10
16
6
7
8
9
10
22
20
21
23
24
17
2
21
22
23
3
16
15
1211 13 14
17
18
19
1 Flue gas analysis outlet
2 Flue gas exhaust connection
3 Gas valve
4 Fan
5 Combustion chamber
6 Electrical panel
7 Smoke-exhaust ue non-return valve
8 Drain cock
9 Minimum Pressure Switch set at 0,7 bar
10 Pump
11 Main switch
12 Central heating return
13 Gas supply
14 Central heating ow
15 Condensate drain connection
16 Flow-meter
17 Exhaust ue probe
18 Return probe
19 Control panel
20 Ignition/detection electrode
21 Safety Thermostat with manual reset by PCB
22 Flow probe
23 Automatic bleed valve
24 Casing

9
POWER MAX 100 - 110 - 130 - 150
1
3
4
5
14
17
2
21
22
13
109 11 12
1
2
3
4
5
6
7
8
19
23
14
21
20
22
16
17
15
18
1 Flue gas analysis outlet
2 Flue gas exhaust connection
3 Fan
4 Combustion chamber
5 Electrical panel
6 Smoke-exhaust ue non-return valve
7 Drain cock
8 Minimum Pressure Switch set at 0,7 bar
9 Main switch
10 Central heating return
11 Gas supply
12 Central heating ow
13 Condensate drain connection
14 Flow-meter
15 Gas valve
16 Exhaust ue probe
17 Return probe
18 Control panel
19 Ignition/detection electrode
20 Safety Thermostat with manual reset by PCB
21 Flow probe
22 Automatic bleed valve
23 Casing

10
1.7 Technical specications
Description
POWER MAX
U.M.
50 P
DEP 50 P 65 P 80 P 100 110 130 150
Appliance type Condensing boiler heating system
B23; B53; B53P; C13*; C33*; C53*; C63*
Fuel - Device category
IT-GB-GR-IE-PT-SI: G20=20mbar G30/G31=28-30/37mbar; II2H3+
SK: G20=20mbar G30=28-30mbar G31=37mbar; II2H3+
ES: G20=18mbar G30=28-30mbar G31=37mbar; II2H3+
BE: G20/25=20/25mbar; I2E(S)
BE: G30/G31=28-30 /37mbar G31=28-30/37mbar; I3+
MT-CY-IS: G30=30mbar; I3B/P
FR: G20/G25= 20/25mbar G30/G31=28-30/37mbar; II2E+3+
PL-RU: G20=20 mbar G30= 37 mbar (RU=37mbar); II2E3B/P
LU: G20=20 mbar G31=37 mbar; I2E3P
DE: G20/G25=20 mbar G30=50 mbar; II2ELL3B/P
PL: G20=20mbar G30/G31=30mbar; II2ELwLs3P
FR: G20/G25=20/25 mbar G30/G31=28-30/37mbar; II2ESi3+
FR: G20/G25= 20/25mbar G30=28-30mbar; II2ESi3B/P
RO-IE-SI-BG-DK-SK-EE: G20=20mbar G30=30mbar; II2H3B/P
SE-NO-LV-LT-FI-TR: G20=20mbar G30=30mbar; II2H3B/P
HR: G20=20mbar G30/G31=30mbar; II2H3B/P
HU: G20=25mbar G30=30mbar; II2H3B/P
SK-CZ-LU-AT-CH: G20=20mbar G30=50mbar; II2H3B/P
SI-SK: G20=20mbar G31=37mbar; II2H3P
NL: G25=25mbar G30=30mbar; II2L3B/P
Combustion chamber vertical
Maximum rated heat input at furnace
referred to HVC (LCV)
38,7
(34,9)
50P
(45)
63
(57)
76
(68)
100
(90)
108
(97)
124
(112)
146
(131) kW
Minimum rated heat input at furnace
referred to HVC (LCV)
10
(9)
10
(9)
15
(14)
15
(14)
21,6
(19,4)
21,6
(19,4)
24,9
(22,4)
29,2
(26,2) kW
Useful (rated) heat output 34,4 44,2 56 68 88 95 110 129 kW
Maximum rated heat
output (80-60°C) P4 G20 34,4 44,2 55,7 67,0 88,3 95,3 109,8 129,0 kW
Maximum nominal heat
output (60-40°C) -G20 36,6 47,0 59,6 71,4 93,8 101,1 116,2 137,3 kW
30% heat output with
return at 30°C P1 G20 11,5 14,7 18,7 22,3 29,4 31,7 36,6 43,0 kW
Minimum rated heat
output (80-60°C) -G20 8,9 8,9 13,5 13,5 19,2 19,2 22,1 26 kW
Efciency class in central heating
mode A A A A - - - -
Seasonal energy ef-
ciency in central heating
mode
ηs94 94 94 94 94 94 94 94 %
Efciency at rated heat
input and High tempera-
ture GCV (NCV) regime
η4
useful
Pn
(60-
80°C)
88,9
(98.6)
88,4
(98.2)
88,4
(97.7)
88,2
(98.5)
88,3
(98.1)
88,2
(98.2)
88,5
(98,0)
88,4
(98.5) %
Efciency at 30% of the
nominal thermal ow
and on low PCS temper-
ature regime
η1
useful
30%
of Pn
98,4
(109,5)
98,2
(109,2)
98,2
(109,2)
98
(108,8)
98,1
(108,9)
98
(108,8)
98
(108,8)
98,1
(108,9) %
Chimney losses with burner on at max.
Pn (80-60°C) 2,3 2,3 2,3 2,3 2,5 2,6 2,5 2,6 %
Chimney losses with burner on at max.
30% Pn (50-30°C) 0,5 0,5 0,5 0,5 0,6 0,6 0,5 0,6 %
Heat loss in standby
mode Pstby 45 57 72 87 115 124 143 168 W
0,1 %
Annual energy con-
sumption QHE 71 91 117 141 ----GJ
Noise level (sound
power) LWA at P
max 51 52 53 54 55 56 57 57 dB(A)
Emissions (**) NOx
(re-
ferred
to
HCV)
42,0 43,9 34,2 36,4 38,1 38,7 39,3 46,1 mg/
kWh
Emissions at max./min.
heat input, G20
CO
2 9 - 9 (*****) %
CO 63/2,3 73/2,3 79/6,5 90/6,5 81/7,5 91,5/7,5 89/4,6 91,5/5,6 ppm
Maximum rated heat
input (LCV) G25 34,9 45 53 65 85 93 107 127 kW
Minimum rated heat
input (LCV) G25 9 9 13 13 18,1 18,5 21,4 24,5 kW
