SUMMARY
PACK LKS1000 V2+IR 4
WHAT IS LEAKSHOOTER®? 5
HOW TO WORK WITH LEAKSHOOTER®? 5
DETAIL OF LEAKSHOOTER®7
DETAIL OF KEYBOARD 8
DETAIL OF SCREEN 9
BATTERY CHARGING 10
ON / OFF 10
MAIN MENU 11
K, HOW IT WORKS? 13
K, CONDITION OF USE 13
K, WITHOUT SETTINGS 14
K, WITH SETTINGS 14
THERMAL CAMERA – HOW IT WORKS? 15
MAIN ICONS USED IN LEAKSHOOTER®16
ACCESSORIES LEAKSHOOTER®DETAIL 18
—3 —
SYNERGYS TECHNOLOGIES / LEAKSHOOTER ® / User Guide
WHAT IS A
LEAKSHOOTER®?
LEAKSHOOTER®LKS1000 V2+ IR is a portable ultrasonic
detection camera that helps locate, hear, view, measure
and record leaks which emit ultrasounds. It can also
estimate the leak ow and the leak cost with the dedicated
K cost estimator function.
LEAKSHOOTER®LKS1000 V2+ IR, is also a portable
thermal infrared camera that helps locate abnormal tem-
perature problems of an installation (overheating or else).
Main industrial applications are:
LCompressed air leak detection
LCompressed process gases leak detection
LVacuum leak detection
LSteam trap or valve condition listening
LHigh voltage capacitive default detection (corona,
arcing, tracking…)
LTightness checking and seal integrity test (with
ultrasonic emitter)
LThermal analysis (With embedded 160x120 pixels
infrared Camera) for Electrical, Mechanical, Process,
Building inspection.
HOW TO WORK WITH
LEAKSHOOTER®?
LEAKSHOOTER®LKS1000 has been designed to display in
real time the fusion of images of the scene being scanned
and the detected ultrasounds coming from a leak (ultra-
sound received = white or colored dynamic target).
Depending on the leak size (intensity of ultrasonic waves
received around 40 kHz) and on the settled sensitivity
(GAIN), the dynamic target will be big or small (white).
Of course if you want to know the leak severity, please
click on the K function button. The target will then have
a severity color (LEAKSCORE from 0 to 100 is made for a
1 meter distance detection).
—5 —
SYNERGYS TECHNOLOGIES / LEAKSHOOTER ® / User Guide
LEAKSHOOTER®LKS1000 is equipped with a special MAX
RMS value function which thanks to the target, shows you if
you are close to the leak (simple round target) or in front of
the leak (round target + cross in its center).
The method consists of scanning the scene, conscientiously.
From far to close location. Do not forget to decrease GAIN
slowly to avoid saturation.
Start with the maximum of sensitivity (GAIN=106 dB,
settled when the device is switched ON).
Sweep the scene for example from left to right and from
top to bottom, with the aim of going in front of the leak and
thus activating the special MAX value, which will remain
frozen a few seconds (bold vertical line in the bargraph).
If you still have the white target with cross, everywhere,
Leak &
ultrasound
it is because you are in a saturated zone. Look on the
ground with LEAKSHOOTER®, slightly decrease the GAIN to
be in the green part of the bargraph and scan again in such
a way as to nd a direction in which to go.
Thus, go back to the area to nd this special MAX value
(align RMS real time and MAX). You will see a cross in the
center of the dynamic target. You are in front of the leak.
—6 —
SYNERGYS TECHNOLOGIES / LEAKSHOOTER ® / User Guide
DETAIL OF
KEYBOARD
With LEAKSHOOTER®LKS1000 V2+ IR Keyboard
Power plug
(12V-1.5A)
Micro USB plug
Wired head phone
jack plug
External probe plug
ON/OFF
Leak
estimator
Gain
setting
(+or-)
Validation
or Menu Headphones level
setting (+or-)
capture
DETAIL OF A
LEAKSHOOTER®
Thermal
camera
—8 —
SYNERGYS TECHNOLOGIES / LEAKSHOOTER ® / User Guide
DETAIL OF SCREEN
INT or EXT
Internal (cone) or
External sensor
Sensitivity
(Gain) level
Target which is
white or colored
(if K is activated
or not)
Bargraph which
is white or
colored if K is
activated or not
Max RMS
«Large» cursor
Real time RMS
«Thin» cursor
dB RMS
value
Battery level
Flow/Cost
estimation
K value position
K estimator
Severity (0>100)
K value
—9 —
SYNERGYS TECHNOLOGIES / LEAKSHOOTER ® / User Guide
BATTERY CHARGING
LEAKSHOOTER®LKS1000 V2+ IR has an internal NiMH
(Nickel Metal Hybrid) battery pack technology (6x 1,2V-2600
mAh). To charge this battery pack, please only do it with the
delivered charger DC 12V-1,5A.
We recommend if you do not use the LEAKSHOOTER® du-
ring a long period, to charge it fully (100%) before to leave it
on stock. Maximum recommended charging time is about
2H30. We recommend to not leave your device unattended.
Please be careful not to charge several times (connect
- disconnect - connect…) within a few hours. It could
disturb the automatic ending charge detection.
Feeling some heat at the end of the charging process is normal.
Note: Please charge and discharge 1 times completely
before to have correct % values of battery state on screen.
Autonomy is about 5 hours.
ON/OFF
•Switching ON:
Briey press the button , LEAKSHOOTER®starts
5 seconds after initialization.
•Switching OFF:
Press for a longer time (> 3 seconds) the button ,
LEAKSHOOTER® goes to switch OFF.
—10 —
SYNERGYS TECHNOLOGIES / LEAKSHOOTER ® / User Guide
A. INT (cone) or EXT (exible or contact) sensor
B. LED light activation
C. Memory with leakage photos
D. USB LINK activation
E. General settings
F. K (Severity and Estimator of leak ow/cost) settings
G. Limit of green/white part of bargraph adjustment
H. Bluetooth activation
I. Escape icon
MAIN MENU
(VIA OK BUTTON)
A
E
C
G
B
F
I
D
H
—11 —
SYNERGYS TECHNOLOGIES / LEAKSHOOTER ® / User Guide
A. It conrms the used sensor between cone (INT) or
exible/contact (EXT).
When you connect an external sensor, it is automati-
cally detected as EXT (same when removing it).
B. To help you to have a better light to take a picture
in a dark situation.
C. To be able to review stored leakage photos
(READ or CANCEL).
You can navigate with or buttons and escape
with .
To cancel a photo, click on the PHOTO button .
D. To download photos to PC or to update device.
Connect your device (ON) to PC with USB cable, acti-
vate USB LINK and wait with WINDOWS function.
Copy / Paste / Delete your photos. Before
disconnecting, be sure to eject USB with WINDOWS func-
tion.
E. To set clock/date, luminosity (5 per default),
Auto o, frequency mixing (42 kHz per default).
F. K (Severity and Estimator of leak ow/cost) settings.
If you need a ow/cost estimation, please ful-
ll h/Y compressor use and Nm³ cost. To do that, click
on the icon and go to the virtual keyboard with .
Choose your number and valid it with the virtual
keyboard Enter button.
G. Limit of green/white part of bargraph adjustment.
Select this icon and add +0,5 or +1 or +1,5 dB to your
cursor with or button, to make it more closed to
white part than green part of bargraph when you do not
have ultrasounds. It will helps for small leak detection
(target will be more reactive to small ultrasounds). Valid
value with .
H. Bluetooth activation
Select this icon and put your headphones or your
speaker in pairing mode. Wait some seconds and it’ will
be OK.
I. Escape icon to go back to measure mode.
—12 —
SYNERGYS TECHNOLOGIES / LEAKSHOOTER ® / User Guide
K,
HOW IT WORKS?
Only for industrial compressed air (5 to 8 Bar (72
to 116 Psi)).
On screen, target will go from white (standard mode)
to K colored value.
Of course, you can switch OFF/ON this K function
with button.
K,
CONDITION OF USE
Only for industrial compressed air (5 to 8 Bar (72
to 116 Psi)).
« AVOIDING SATURATION »
« DISTANCE BETWEEN LEAK AND CONE »
—13 —
SYNERGYS TECHNOLOGIES / LEAKSHOOTER ® / User Guide
K,
WITHOUT SETTINGS
LEAKSCORE NUMBER:
0 to 100, from very small to very big leakage
LEAKSCORE NUMBER:
0 to 100, from very small to very big leakage
5 colored levels:
•0-20 ;
•20-40 ;
•40-60 ;
•60-80 ;
•80-100
5 colored levels:
•0-20 ;
•20-40 ;
•40-60 ;
•60-80 ;
•80-100
(for about :
•0.2 m³/h;
•0.6 m³/h;
•3.5 m³/h;
•14.5 m³/h;
•31.7 m³/h)
+ Flow m³/h
+ Cost/year estimations
IF IN K MENU, SETTINGS ARE = « 0 » IF IN K MENU, SETTINGS ARE BOTH
DIFFERENT THAN « 0 »
++
Cost of 1x
Nm³ Cost of 1 Nm³
(is about 0,02 €)
Use per year Use per year
K,
WITH SETTINGS
—14 —
SYNERGYS TECHNOLOGIES / LEAKSHOOTER ® / User Guide
THERMAL CAMERA
HOW IT WORKS?
•(-10°C to +200°C (per default) or -10°C to +400°C
range) with AUTOSCALING thermal imaging Mode
•You can see 3 cursors: 1x black centered with T° value
in left-top corner of the screen, 1x red AUTO Max,
1x blue AUTO Min
•Emissivity Ɛ can be adjusted with
and
buttons
•Photo can be taken with with 1x click, twice on the
PHOTO button and a name validated with Enter
button on the virtual keyboard
•to go back in ultrasonic measurement mode
—15 —
SYNERGYS TECHNOLOGIES / LEAKSHOOTER ® / User Guide
BLUETOOTH setting
(Headphones or speaker pairing)
Your use of compressed air / year
(8.760 h/year for 24h/24h use)
Frequency mixer setting
(42 kHz per default)
AUTO OFF setting
Your Nm³ compressed air cost
(for example 0.02 €).
Use # for special non standard money.
Clock & date settings
Internal or external
probes
White LED light ON/OFF
T° unit
for
thermal
camera
USB link
Memory to access to stored photos
(Visible+IR), 1 directory for leaks,
1 directory for STRAPSHOOTER®
K settings
—17 —
SYNERGYS TECHNOLOGIES / LEAKSHOOTER ® / User Guide
lv
v�
j !�
!�
'·
I
OF
OF
l
l
k k
ocf, a� ocf, a� oc
¥j
t�
�o
=
!�
OF OF
l
SYNERGYS TECHNOLOGIES has been established in 1996 in France,
to oer innovative and professional solutions for preventive and
predictive maintenance.
SYNERGYS TECHNOLOGIES is the inventor of the ultrasonic
visualization concept with the LEAKSHOOTER®,the thermal
contour concept with the TSHOOTER®and of the MCP (Machine
Condition Picture) concept with the VSHOOTER®.
We are present worldwide with professional and trained distributors.
Distributed by :
LEAKSHOOTER®,
VSHOOTER®& TSHOOTER®
a SYNERGYS TECHNOLOGIES innovation.
