INTREPID GAS
Table Of Contents

WARNING
WARNINGWARNING
WARNING
The radio controlled model helicopter built from this kit is not a toy and is not meant for
children. It is a flying machine capable of causing property damage and serious bodily
harm to both the operator/assembler and/or spectator if not built and operated correctly
and responsibly. Rotating components, especially the main rotor blades, are an ever-
present danger.
Model helicopters operate differently than model cars and airplanes. Helicopters by their
nature are not positively stable, meaning that even if properly assembled and ad usted,
helicopters will not recover from an unwanted flight attitude, nor will they hold any
particular orientation without constant control inputs from the pilot.
IT IS YOUR EXCLUSIVE RESPONSIBILITY TO PROPERLY BUILD, MAINTAIN
AND OPERATE THIS HELICOPTER. Bergen R/C Helicopters has spent
considerable time making this product reliable and easy to build, but only
the operator can insure that it is safe. Because the safe operation of this
helicopter is beyond the control of the Manufacturer and distributor, the
owner/operator assumes all risk of use.

Construction Manual
Acknowledgments
Bergen R/C Helicopters wishes to thank the facilities and friends for their
continuing support during the development of the Intrepid Helicopter.
Staff
Chris Bergen; Chief Executive Officer
Larry Bergen; Chief Design Engineer and General Manager
Mary Ann Pratt; Marketing Sales and Service
Terri Demeyer; Office Management
Mike Bergen; Programmer, Engineer
Todd Gillesby; Machinist
Bergen R/C Helicopters LLC
1101 Follett Drive
Cassopolis, MI 49031
Voice: [phone]
Fax: [phone]
Web: bergenrc.com
Email: [e-mail]

Introduction
The first of its kind, interchangeable modular engineered helicopter to accommodate
the beginner to a FAI expert…
An idea in 1994 to manufacture an interchangeable, modular helicopter, led to the
research and development in 199 . Focusing on quality, engineering details, and
price, a prototype was produced. After extensive test flights and fine-tuning, the
INTREPID HELICOPTER is now what you see today. The first of its kind, strength
combined with simplicity for easy maintenance and flying.
Although beginners can successfully build and fly their INTREPID, the process can be
made significantly easier with the help of an experienced modeler and instructor pilot.
We recommend that all beginners join the Academy of Model Aeronautics (AMA). The
AMA is a non-profit organization that provides services for modelers. The AMA can
help you locate a model aircraft club in your area with an instructor pilot (you can also
check with your local hobby shop). Membership benefits include a monthly magazine
and liability insurance. Many flying clubs require an AMA modeler’s license to operate
a model on their flying field. For more information on the AMA contact:
Academy of Model Aeronautics
1 1 East Memorial Drive
Muncie, IN 47302
Phone: [phone]

Consumer Warranty
IMPORTANT! Before building the INTREPID GAS Helicopter kit, read and fully understand the
following warranty, and review the entire Construction Manual. By building and/or flying this
helicopter you indicate your acceptance of the following warranty terms and conditions, and further
agree to build and operate this helicopter in safe and responsible manner.
If you find any term or condition unacceptable, or if you feel that this helicopter is just not suited to
you, you may return it to your place of purchase in NEW and UNUSED condition within thirty (30)
days of the date of purchase for a refund of the purchase price less shipping and handling. Partially
assembled kits, and kits with opened parts packs or missing parts can not be returned for a refund.
Warranty:
1. Bergen warrants to the first consumer Purchaser that the INTREPID GAS helicopter
substantially conforms to its published description when used as intended as a
hobby product, and will be free from defects in materials and workmanship for a
period of 90 days after the date of purchase. Bergen R/C will repair or replace (at
our option) any defective part, and supply any missing part at no charge to the
Purchaser within this period. We make no warranty, express or implied. This
warranty does not apply to parts damaged by improper assembly, modification,
abnormal service or handling, or crashes.
2. To take advantage of this warranty, the Purchaser must provide proof of purchase,
fill out the warranty and inventory sheet, signing and returning it within two weeks
of purchase, and ship any defective part (at Purchaser’s cost) to Bergen R/C for
repair or replacement.
3. It is the responsibility of the Purchaser to properly assemble, maintain and operate
this helicopter in accordance with manufacture’s instructions, AMA safety codes,
local laws and ordinances, and COMMON SENSE. It is also the responsibility of the
Purchaser, when operating this helicopter, never to operate it in any way, which
might endanger persons or property including the Purchaser. Purchaser is advised
to carry appropriate liability insurance such as that commonly provided to modelers
by the AMA.
4. THIS WARRANTY SPECIFICALLY EXCLUDES THE IMPLIED WARRANTIES
OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE. The
selection of this helicopter for a particular application or use (beyond
hobby/entertainment) is the sole responsibility of the Purchaser. Any advice supplied
by any representative of Bergen R/C pertaining to any particular application is given
freely as an opinion and is not meant to bind Bergen R/C or in any other way modify
this warranty.

1. Not withstanding the paragraph above, this warranty is in addition to whatever
implied warranties may be granted to the Purchaser by law. To the extent
permitted by law, all implied warranties, including the warranties of merchantability
and fitness for a particular purpose are limited to a period of (1) year from the date
of purchase. Some states do not allow limitations on how long an implied warranty
last, so the above limitation may not apply.
2. This warranty shall be the sole and exclusive remedy available to the Purchaser.
Correction of defects, in the manner and for the period of time specified above, shall
constitute complete fulfillment of all liabilities and responsibilities of Bergen to the
Purchaser, and shall constitute full satisfaction of all claims, whether based on
contract, negligence, strict liability or otherwise. Bergen R/C shall not be liable for
any cost or expenses incurred in; the replacement of any effective or non-
conforming parts, and IN NO EVENT SHALL BERGEN R/C BE LIABLE FOR
INCIDENTAL OR CONSEQUENTIAL DAMAGES, OR ANY DAMAGES DUE TO
THE USE OR INABILITY TO USE THIS PRODUCT. Bergen R/C shall not be
liable, or in any way responsible, for any damages related to modifications, repairs,
attempted repairs, or crashes. IN NO EVENT SHALL BERGEN R/C’s
OBLIGATIONS TO THE PURCHASER EXCEED THE ORIGINAL PURCHASE
PRICE PAID BY THE PURCHASER.
3. Some states do not allow exclusion of incidental or consequential damages, so the
above exclusion may not apply. This warranty gives the Purchaser specific legal
rights. The Purchaser may also have other rights, which vary, from state to state.
4. No modification or amendment to this warranty will be effective unless reduced to
writing and signed by an authorized representative of Bergen R/C Distributorship.
If you do not understand any aspect of this warranty, you may contact
Bergen R/C Helicopters for clarification. IF YOU DO NOT AGREE WITH ANY ASPECT OF THIS
WARRANTY, RETURN THE UNASSEMBLED HELICOPTER TO THE MANUFACTURER FOR A
REFUND.
Bergen R/C Helicopters believes that information contained within its published materials is accurate
as of the date of publication, and is not responsible for inadvertent errors or omissions. Bergen R/C
reserves the right to make changes and improvements in its products without notice.

With that out of the way, let me say “Welcome!!” ☺
☺☺
☺You have joined a group,
some call it the Bergen Family, and our goal is to get you up and flying and
enjoying your Helicopter.
This manual covers 2 models, The Intrepid Gasser (standard) and the Intrepid
Gasser EB (Extended Boom). The differences will be noted as we go along
through the manual.
The Photos in this manual can be clicked on and blown up to full screen if you
need to see them in greater detail. Of course if you have ANY questions
whatsoever, you have numerous resources to help you. Call me, Chris Bergen,
at 269-445-2060, e-mail at [e-mail], contact us on bergenrc.com
or you can usually find me, and many Bergen owners on http://helifreak.com/.
For updates, hints, tips and new things we’re working on, visit the Bergen R/C
Forums.
The VERY first thing you should do with your kit is the Inventory. Do the
COMPLETE inventory, noting anything that’s missing. Though we do try hard to
ensure that you get a complete kit, we are human and may make a mistake in
putting all the pieces in the box. Notify us immediately of any discrepancies
AFTER completing the inventory, we will get what you need out to you
immediately. Once you receive all the parts, complete and sign the Warranty
Registration sheet and return it to us in the SASE included with your paperwork.

STANDARD GASSER
BAG 1
1 1574B LANDING GEAR SET
4 * 5030 3X16M SHCS
6 * 5105 3M LOCK NUTS
2 * 5206 3X8 SELF TAP
2 * 3X16M FHCS
BAG 2
1 1506 LOWER FRAME (RIGHT)
1 1507 LOWER FRAME (LEFT)
2 1560 SKID BAR
10 * 5090 3X8M FHCS
1 1520 BATTERY TRAY
2 1530 BATTERY TRAY SPACER
4 * 5010 3X8M SHCS
2 2040 MOTOR MOUNT SPACERS
2
1933 or
1934
STANDOFF 24M FOR LEXAN OR 18M STANDOFF
FOR FIBERGLASS
2
*
5102 3X12 SS
2
*
5010 3X8 SHCS
BAG 3
1 1415 FAN ASSEMBLY
1
1420
GAS FAN
1
1425
GAS FAN HUB
3
5010
3X8 SHCS
1 1455 FAN SHROUD
1 1460 FAN SHROUD MOUNT
4 * 5085 5X12M SHCS
3 * 5091 5X12 FHSCS
4 * 5060 4X12M SHCS
4 * 5030 3X16M SHCS
4 * 5105 3M LOCKNUTS
1 * 5130 ¼ LOCK WASHER
1 * 5086 6X25M SHCS
2 * 5095 3X4M SET SCREWS
7 * 5065 4X16M SHCS
2 * 5010 3X8M SHCS
1 1470 MOTOR MOUNT BRACKET
2 * 5069 5X65M SHCS
2 * 5110 3M FLAT WASHERS

1 2045 THROTTLE ARM
1 2030 MUFFLER SPACER
3 * 5109 4M FLAT WASHER
1 2036 PULL START ADAPTOR
1 * 5190 SHORT BALL
4 * 5141 3X18M SHCS
4 * 5105 3M LOCKNUTS
8 * 231B SPECIAL WASHERS
BAG 4
1 1875 FUEL TANK ASSEMBLY
1 1880 FUEL TANK
1 1850 CLUNK
2 1855 SINGLE END FITTING
1 1860 DOUBLE END FITTING
3 1865 FUEL TANK NUTS
1 1915 FUEL TUBING 24”
BAG 5
2 1475 UPPER FRAME
4 3034 6X12X4F BEARING
2 1620 COLLECTIVE AXLE
3
*
5055 3X40 SHCS
1 1250 MAIN SHAFT BEARING BLOCK ASSEMBLY
1 3040 10X19X7 BEARINGS
1 1255 BEARING BLOCK ONLY
7 * 5050 3X35M SHCS
2 * 5001 3X4M SHCS
10 * 5105 3M LOCK NUT
2 * 5110 3M WASHER
6 * 5010 3X8 SHCS
2 1931 24M CANOPY STANDOFF STEPPED
3 1665 TAIL BOOM CLAMPS
1 280 ELEVATOR CONTROL YOKE ASSEMBLY
1 280A ELEVATOR YOKE
2 280B ELEVATOR CONTROL YOKE A-ARM
2 280C ELEVATOR YOKE ARM PIN
2 1956 PLASTIC BALL LINKS
2 5102 3X12M SET SCREW
2 5095 3X4M SET SCREW
4 3086
3X7X3F BEARINGS
1 1600 ELEVATOR CONTROL SHAFT LONG

1 1605 ELEVATOR CONTROL SHAFT SHORT
1 1535 RUDDER SERVO MOUNT
1 9010 DELRIN COUPLER
1 9005 OUTPUT SHAFT
1 1210 COUPLER PIN
1
*
5095 3X4 SET SCREWS
1 270 FRONT TRANSMISSION SUPPORT ASSEMBLY
1 270A BEARING BLOCK ASSEMBLY
1 3040 10X19X7 BEARING
1 270D BEARING BLOCK ONLY
1 270E BEARING BLOCK SUPPORT CRADLE w/bearings
1 270B BEARING BLOCK CRADLE W/O BEARING
2 3056 5X13X4 BEARINGS
1
5025 3X5M PHILLIPS PANHEAD SCREW
1 270C PINION SPACER (BRASS)
1 1745 PINION GEAR
1
*
5094 3X3 SS
BAG 6
1 1233 MAIN SHAFT ASSEMBLY
1 1235 MAIN SHAFT
1 1241 MAIN SHAFT COLLAR
1 5160 4-40X1/2 AMERICAN BOLT
2
1245 SPLIT MAIN SHAFT COLLAR ASSEMBLY
2 1246 SPLIT MAIN SHAFT COLLAR
2 127A SPECIAL SHCS
5 5170 26M FRAME SPACER
10 5175 29M FRAME SPACERS
10
*
5055 3X40 SHCS
1 1265 AUTO HUB ASSEMBLY
4
*
5010 3X8M SHCS
4 * 5110 3M WASHERS
1 1307 CLUTCH BELL ASSEMBLY 14T
1 1318 CLUTCHBELL w/lining only
1 3045 6X19X6 BEARING
1 1340 14TOOTH PINION GEAR
1 1276 CLUTCH ASSEMBLY
1 1285 START SHAFT
1 CLUTCH SHOE
1 1260 START SHAFT BEARING ASSEMBLY
1 1261 START SHAFT BLOCK ONLY

2 3045 6X19X6 BEARING
1 3050 10X19X5 BEARING
1
1286 START SHAFT COLLAR
2
* 5094 3X3 SS
2 1290 DELRIN BUSHING Set
2 1295 STEEL INSERT
2 1300 DELRIN BUSHINGS
2
*
5065 4X16M SHCS
4 * 5308 3X8 SPECIAL LOW HEAD CAP SCREWS
1 1270 MAIN GEAR
BAG 7
1 1185 WASHOUT HUB ASSEMBLY
2 1201 WASHOUT MIXING ARM
4 3086 3X7X3F BEARING
2 * 5140 3X16M SPECIAL SHCS
4 * 5155 3M BRASS WASHER
2 1205 RADIUS LINK
2 1000E RADIUS LINK PIN
6 * 5190 SHORT BALL
1 1215 SWASH PLATE ASSEMBLY
4
*
5094 3X3 SS
4 * 5195 MEDIUM BALL
BAG8
2 1616 COLLECTIVE ARM
1 1625 COLLECTIVE BELLCRANK TRIPLE
1 1630 COLLECTIVE BELLCRANK SINGLE
4 * 5200 LONG BALLS
15 * 5010 3X8M SHCS
7 * 5110 3M WASHERS
1 1540 AILERON SERVO MOUNT
2 1641 AILERON BELL CRANK
8 3031 5X8X2.5 FLANGED BEARINGS
12 * 5190 SHORT BALLS
3 1645 CONTROL ARM JAMNUT
2 * 5030 3X16M SHCS
2 * 5001 3X4M SHCS
1 1651 ELEVATOR X CONTROL ARM
1 * 5035 3X20M SHCS
1 1610 ELEVATOR CONTROL ARM
1 1545 GYRO MOUNT

1 1550 BATTERY MONITOR MOUNT
2 1546 GYRO MOUNT BLOCK 3 HOLE
1 * 5090 3X8M FHSCS
BAG 9
1 1155 SEESAW TUBE
2 1160 SEESAW END CAPS
2 3020 4X10X4 BEARING
2 * 1165 4M WASHER (SPECIAL)
4 * 5095 3X4M SET SCREW
2 1175 FLYBAR CONTROL ARM
2 1183 FLYBAR PADDLE
6 * 5190 SHORT BALL
6 * 5155 3M BRASS WASHER
2 3015 3X10X4 BEARING
2 * 5205 PAN HEAD SCREW
2 1151 BELL MIXER ARM
4 3086 3X7X3F BEARING
2 * 5136 3X12M W/6M SHOULDER SHCS
2 * 5115 3M NUT
1 1106 HEAD BLOCK
2 1111 BLADE GRIP ASSEMBLY
2 1116 BLADE GRIP W/O BEARING
4 3005 8X16X5 BEARING
2 3006 8X16X5 THRUST BEARING
2 1126 BLADE GRIP PITCH ARM
1 1131 HEAD AXLE W/SNAP RINGS
2 1136 SOLID DAMPENERS (HARD & SOFT)
2 1140 8MX.015 SHIM DAMPENING WASHER
2 1145 8MX.008 SHIM DAMPENING WASHER
2 1147 8X1M SHIM DAMPENING WASHER
2 * 5151 4X25M SHCS SPECIAL W/18M SHOULDER
2 * 5106 4M LOCK NUT
4 * 5005 3X6M SHCS
2 * 5010 3X8M SHCS
2 * 5030 3X16M SHCS
1 * 5035 3X20M SHCS
2 * 5072 5X16M SHCS
2 * 5111 5X10X2 SPACER WASHER
BAG 10A
ASSEMBLY 1

1 232 TAIL ROTOR BLADE GRIPS KIT
2 231-A BLADE GRIP ASSEMBLY ng)
4 3054 5X10X4 BEARINGS
2 231C BLADE GRIPS W/O BEARINGS
2 3052 5X10X4 THRUST BEARING
1
TWIN
1815 TAIL ROTOR MAIN HUB 6M
2 5110 3M FLAT WASHER
2 5005 3X6 SHCS
2 5146 3X19 W/11 SHOULDER SHCS
2 5112 10M OD SPACERS
4 231B BLADE GRIP SPACERS
2 5105 3M LOCK NUT
1 5094 3X4M SET SCREW
ASSEMBLY 2
1 240 PITCH BELLCRANK KIT
1 M240B MAGNUM BELLCRANK ASSEMBLY
1 240A DELRIN INSERT
1 240D ALUMINUM BELLCRANK ONLY
1 240C ALUMINUM SPACER
2 3086 3X7X3 FLANGE BEARING
1 5140 3X16 W/6M SHOULDER SHCS
2 5155 3M BRASS WASHER
1 5195 MEDIUM BALL
1 5105 3M LOCKNUT
ASSEMBLY 3
1 M1960 PITCH SLIDER ASSEMBLY KIT
1 M1786 PITCH SLIDER HUB
1 1792 PITCH SLIDER TUBE (NEW)
1 1793 PITCH SLIDER SPACER (THICK)
1 1794 PITCH SLIDER SPACER (THIN)
2 3036 6X10X3 FLANGE BEARING
1 1801 ALUMINUM PITCH PLATE
2 5137 5X2M BALL
2 5076 2X8M SHCS
2 5120 2M NUT
2 1961 TAIL SPECIAL BALL LINKS
2 1806 PIVOT PLATE ARM EYELET
2 1811 PIVOT PLATE SHOULDER BOLT 4x4
ASSEMBLY 4

1 M1000
ALUMINUM TAIL ROTOR GEAR BOX ASSEMBLY
1 M1000A GEAR BOX ONLY
1 5094 3X3M SET SCREW
2 5095 3X4M SET SCREW
1 M1000B PITCH ARM BRACKET
1 M1000F
REPLACEMENT GEAR SET W/OUTPUT SHAFT
TWIN
1000D OUTPUT SHAFT
1
BEVEL GEAR
1
BEAVEL GEAR W/SHAFT
1 1000E 10M PIN
1 5095 3X4M SETSCREW
1 M1000C ALUMINUM SPACER
1 3071 10X15X4 FLANGE BEARING
3 3055 5X13X4 BEARING
1 1210 12M PIN
1 1000I INPUT SHAFT FOR GEAR BOX
1 M1000J BRASS SPACER TUBE
1 5025 3X5 PAN HEAD SCREW
2 5001 3X4 SHCS
2 5090 3X8 FLAT HEAD CAP SCREWS
ASSEMBLY 5
2 PAIR 1665 TAILBOOM CLAMPS
1 1667 HORIZONTAL FIN CLAMP
MISC BAG
2 109DA COLLARS FOR TORQUE TUBE DRIVE
1 * 5050 3X35 SHCS
4 * 3X30 SHCS
1 9015 DOGBONE
1 9020 DOGBONE PIN
2
* 5020
3X12 SHCS
4 * 5110 3M WASHERS
7 * 5105 3M LOCKNUTS
2 * 5010 3X8 SHCS
6 * 5094 3X3 SET SCREWS

1 * 5095 3X4 SET SCREWS
2 109A BEARING CARRIER ASSEMBLY
2 3090 .375X.625X1.56 BEARING
2 109C DELRIN INSERT
4 109E O’RINGS
2 109B DELRIN CARRIER
4
1945 CANOPY GROMMETS
4
1946 THUMB SCREWS
1 6015 TAIL ROTOR BLADES
BAG 10B
1 1170 FLYBAR
1 1676 TAILBOOM 33”
1 2117 ARROW DRIVE SHAFT
2 1879 TIE WRAPS
1 1682 PUSH ROD CARBON FIBER SET
1 1681 CARBON FIBER ROD
2 1983 PUSHROD ENDS
2 1956 BALL LINK 2.5
2 5105 3M LOCKNUT
2 5035 3X20M SHCS
1 1709 TAILBOOM SUPPORT SET
2 1710 TAIL BOOM SUPPORT STRUTS
4 1715 TAILBOOM SUPPORT STRUT ENDS
1
M1830 HORIZONTALFIN
1
M1835 VERTICAL FIN
BAG 11
42 1956 BALL LINKS 2.5
10 1947 PLASTIC SERVO MOUNT TABS
2 1985 ELEVATOR LINKAGE 130M
2 1990 ELEVATOR LINKAGE 50M
4 1995 COLLECTIVE LINKAGE 30M
2 2000 COLLECTIVE LINKAGE 50M
2 2005 AILERON LINKAGE 85M
2 2010 SWASH PLATE LINKAGE 40M
2 2020 PITCH LINKAGE 75M
2 2025 FLYBAR LINKAGE SHORT 12M
1 1980 140M THROTTLE LINKAGE
8 * 5137 5X2M BALL
8 * 5207 2X10M PHSMS
16 * 5120 2M NUT

1 1921 CANOPY
1 242 SAMPLE LOCKTITE
1 2049 ZENOAH G26H ENGINE
HARDWARE
1165 2 4M WASHER (SPECIAL)
5001 4 3X4M SHCS
5005 4 3X6M SHCS
5010 37 3X8M SHCS
5020
2 3X12 SHCS
5030 12 3X16M SHCS
5035 2 3X20M SHCS
5050 15 3X35M SHCS
5055 13 3X40 SHCS
5060 4 4X12M SHCS
5065 9 4X16M SHCS
5069 2 5X65M SHCS
5072 2 5X16M SHCS
5085 4 5X12M SHCS
5086 1 6X25M SHCS
5090 11 3X8M FHCS
5091 3 5X12 FHSCS
5093 2 3X16 FHCS
5094 11 3X3 SS
5095 9 3X4M SET SCREWS
5102 2 3X12 SS
5105 37 3M LOCK NUTS
5106 2 4M LOCK NUT
5109 3 4M FLAT WASHER
5110 25 3M FLAT WASHERS
5111 2 5X10X2 SPACER WASHER
5115 2 3M NUT
5120 16 2M NUT
5130 1 ¼ LOCK WASHER
5136 2 3X12M W/6M SHOULDER SHCS
5137 8 5X2M BALL
5140 2 3X16M SPECIAL SHCS

5141 4 3X18M SHCS
5151 2 4X25M SHCS SPECIAL W/18M SHOULDER
5155 10 3M BRASS WASHER
5190 25 SHORT BALL
5195 4 MEDIUM BALL
5200 4 LONG BALLS
5205 2 PAN HEAD SCREW
5206 2 3X8 SELF TAP
5207 8 2X10M PHSMS
5308 4 3X8 SPECIAL LOW HEAD CAP SCREWS
231B 8 SPECIAL WASHERS
GASSER EB
BAG 1
1 1574B LANDING GEAR SET
4 * 5030 3X16 SHCS
6 * 5105 3M LOCK NUTS
2 * 5206 3X8 SELF TAP
2 * 3X16 FHCS
BAG 2
1 1506 LOWER FRAME (RIGHT)
1 1507 LOWER FRAME (LEFT)
2 1560 SKID BAR
10 * 5090 3X8 FHCS
1 1517 BATTERY TRAY EXTENDED
2 1530 BATTERY TRAY SPACER
4 * 5010 3X8 SHCS
2 2040 MOTOR MOUNT SPACERS
2
1933 OR
1934
24M STANDOFF FOR LEXAN OR 13M FOR
FIBERGLASS
2
*
5102 3X12 SS
2
*
5010 3X8 SHCS
BAG 3
1 1415 FAN ASSEMBLY
1
1420
GAS FAN
1
1425
GAS FAN HUB
3
5010
3X8 SHCS
1 1455 FAN SHROUD
1 1460 FAN SHROUD MOUNT
4 * 5085 5X12 SHCS
3 * 5091 5X12 FHSCS

4 * 5060 4X12 SHCS
4 * 5030 3X16 SHCS
4 * 5105 3M LOCKNUTS
1 * 5130 ¼ LOCK WASHER
1 * 5086 6X25 SHCS
2 * 5095 3X4 SET SCREWS
3 * 5065 4X16 SHCS
2 * 5010 3X8 SHCS
1 1470 MOTOR MOUNT BRACKET
2 * 5069 5X65 SHCS
2 * 5110 3M WASHERS
1 2045 THROTTLE ARM
1 2030 MUFFLER SPACER
3 * 5109 4M WASHER
1 2036 PULL START ADAPTOR
1 * 5190 SHORT BALL
4 * 5141 3X18 SHCS
4 * 5105 3M LOCKNUTS
8 * 231B SPECIAL WASHERS
BAG 4
1 1875 FUEL TANK ASSEMBLY
1 1880 FUEL TANK
1 1850 CLUNK
2 1855 SINGLE END FITTING
1 1860 DOUBLE END FITTING
3 1865 FUEL TANK NUTS
1 1915 FUEL TUBING 24”
BAG 5
2 1475 UPPER FRAME
4 3034 6X12X4F BEARING
2 1620 COLLECTIVE AXLE
3
*
5055 3X40 SHCS
1 1250 MAIN SHAFT BEARING BLOCK ASSEMBLY
1 3040 10X19X7 BEARINGS
1 1255 BEARING BLOCK ONLY
7 * 5050 3X35 SHCS
2 * 5001 3X4 SHCS
10 * 5105 3M LOCK NUT
2 * 5110 3M WASHER
6 * 5010 3X8 SHCS
