THE WORLD MODELS Jeff Troy's TAMEcat DF Trainer User manual

Wing Span
Wing Area
Flying Weight
Fuselage Length
39.5 in / 1000 mm
273 sq in / 17.6 sq dm
28 oz / 790 g
29.0 in / 730 mm
Specifications
*Specifications are subject to change without notice.*
INSTRUCTION MANUAL
Requires : 4-channel radio w/ 4 micro servos,
Ducted Fan Propulsion Unit PL6800010
and Outrunner Motor KM0283110,
Ducted Fan Booster Cone PL6800011,
30A (burst 35A) brushless ESC,
3 cells 11.1V 15C 2100mAh
Li - Po battery and charger.
Jeff Troy's TAMEcat DF Trainer
FACTORY PRE-FABRICATED
ALMOST-READY-TO-FLY(ARF)SERIES
MADE IN CHINA
Warning ! This model is not a toy.
It is designed for maximum performance. Please seek advice if one is not familiar with this kind
of electric powered precision model. Operating this model without prior preparation may cause
injuries. Remember, safety is the most important thing. Always keep this instruction manual at
hand for quick reference.
The World Models
Manufacturing Co., LTD.
www.theworldmodels.com
E245SXMPO23901006
The World Models
Manufacturing Co., LTD.
www.theworldmodels.co m
The World Models
Manufacturing Co., LTD.
www.theworldmodels.co m
The World Models
Manufacturing Co., LTD.
www.theworldmodels.co m
The World Models
Manufacturing Co., LTD.
www.theworldmodels.co m
The World Models
Manufacturing Co., LTD.
www.theworldmodels.co m
The World Models
Manufacturing Co., LTD.
www.theworldmodels.co m
The World Models
Manufacturing Co., LTD.
www.theworldmodels.co m
The World Models
Manufacturing Co., LTD.
www.theworldmodels.co m
The World Models
Manufacturing Co., LTD.
www.theworldmodels.co m
The World Models
Manufacturing Co., LTD.
www.theworldmodels.co m
The World Models
Manufacturing Co., LTD.
www.theworldmodels.co m
The World Models
Manufacturing Co., LTD.
www.theworldmodels.co m
The World Models
Manufacturing Co., LTD.
www.theworldmodels.co m
The World Models
Manufacturing Co., LTD.
www.theworldmodels.co m
The World Models
Manufacturing Co., LTD.
www.theworldmodels.co m
The World Models
Manufacturing Co., LTD.
www.theworldmodels.co m
The World Models
Manufacturing Co., LTD.
www.theworldmodels.com
The World Models
Manufacturing Co., LTD.
www.theworldmodels.com

INDEX
BEFORE YOU BEGIN
BEFORE YOU BEGIN
PARTS LIST
ASSEMBLY
SAFETY PRECAUTIONS
P.1
P.2
P.3-P.11
P.11
Cut off shaded portion.
Ensure smooth non-binding
movement while assembling.
Apply instant glue
(C.A.glue, super glue.)
Assemble left and right
sides the same way.
Peel off shaded portion
covering film.
Pay close attention here!
Apply epoxy glue.
Must be purchased separately !
Drill holes with the specified
diameter (here: 3mm).
Pierce the shaded portion
covering film.
3mm
Do not overlook this symbol !
Warning!
Apply thread locker
Check all parts. If you find any defective or missing parts contact your local dealer. Please
DRY FIT and check for defects for all parts that will require CA or Epoxy for final assembly.
Any parts you find to be defective after the gluing process may be difficult to remove for
warranty replacement. The manufacturer will replace any defective parts, but will not extend
to the parts that are good before gluing to defective parts during assembly. Warranty will
not cover any parts modified by customer.
Symbols used throughout this instruction manual comprise of the following :-
Read through the manual before you begin, so you will have an overall idea of what to do.
1
2
3
P.1
