Berker 2949 Service manual

info pilot lamp
Order-No. : 2949
Operation- and
Assembly Instructions
1 Safety instructions
Electrical equipment may only be installed and fitted by electrically skilled persons.
Always disconnect device before working on it. At the same time, take into account all
circuit breakers that supply dangerous voltage to the device.
Failure to observe the instructions may cause damage to the device and result in fire and
other hazards.
These instructions are an integral part of the product, and must remain with the end
customer.
2 Device components
picture 1: Device components
(1) Information light signal top
(2) Frame
(3) Insert
3 Function
Intended purpose
- Power supply for information light signal top
- Installation in appliance box to DIN 49073.
- Observe the technical data.
Seite 1/2
info pilot lamp
82526411
97-09498-000 23.08.2010

4 Information for qualified electricians
4.1 Fitting and electrical connection
Connecting and mounting the device
DANGER!
Electrical shock when live parts are touched.
Electrical shocks can be fatal.
Before carrying out work on the device or load, disengage all the
corresponding circuit breakers. Cover up live parts in the working environment.
o Connect the insert.
L: live
N: neutral
o Mount the insert (3) in the appliance box (picture 1).
o Attach the frame (2) and the top (1).
5 Appendix
5.1 Technical data
Rated voltage AC 230 V ~
Mains frequency 50 Hz
Connected load 0.8 W
Connection
Single stranded max. 4 mm²
5.2 Accessories
cover for info pilot lamp Order-No. 1345..
5.3 Warranty
We reserve the right to make technical and formal changes to the product in the interest of
technical progress.
Our products are under guarantee within the scope of the statutory provisions.
If you have a warranty claim, please contact the point of sale or ship the device postage free
with a description of the fault to the appropriate regional representative.
Berker GmbH & Co. KG
Klagebach 38
58579 Schalksmühle/Germany
Telefon + 49 (0) 2355/905-0
Telefax + 49 (0) 2355/905-111
www.berker.de
Seite 2/2 23.08.2010
