ADJ DOTZ MATRIX User manual

DOTZ MATRIX
User Instructions

2
©2021 ADJ Products, LLC all rights reserved. Information, specications, diagrams, images, and
instructions herein are subject to change without notice. ADJ Products, LLC logo and identifying product
names and numbers herein are trademarks of ADJ Products, LLC. Copyright protection claimed includes
all forms and matters of copyrightable materials and information now allowed by statutory or judicial
law or hereinafter granted. Product names used in this document may be trademarks or registered
trademarks of their respective companies and are hereby acknowledged. All non-ADJ Products, LLC
brands and product names are trademarks or registered trademarks of their respective companies.
ADJ Products, LLC and all afliated companies hereby disclaim any and all liabilities for property,
equipment, building, and electrical damages, injuries to any persons, and direct or indirect economic
loss associated with the use or reliance of any information contained within this document, and/or as a
result of the improper, unsafe, insufcient and negligent assembly, installation, rigging, and operation
of this product.
ADJ PRODUCTS LLC World Headquarters
6122 S. Eastern Ave. | Los Angeles, CA 90040 USA
Tel: [phone] | Fax: [phone] | www.adj.com |[email protected]
ADJ Supply Europe B.V.
Junostraat 2 | 6468 EW Kerkrade | Netherlands
Tel: [phone] | Fax: [phone] | www.americandj.eu | [email protected]
Europe Energy Saving Notice
Energy Saving Matters (EuP 2009/125/EC)
Saving electric energy is a key to help protecting the environment. Please turn off all electrical products
when they are not in use. To avoid power consumption in idle mode, disconnect all electrical equipment
from power when not in use. Thank you!
DOCUMENT VERSION
Due to additional product features and/or enhancements, an updated version of this
document may be available online.
Please check www.adj.com for the latest revision/update of this manual before
beginning installation and/or programming.
Date Document
Version
Software
Version DMX Channel Mode Notes
05/27/14 11.04 3/6/7/48/52 Initial Release
06/21/16 21.05 3/6/7/48/53 52 Ch. Mode updated to 53 Ch. Warranty
Updated
12/27/19 2.5 1.06 N/C White Balance Added
04/19/21 3.0 1.07 N/C Update System Menu

CONTENTS
3
General Information 4
Limited Warranty (USA Only) 5
Safety Guidelines 6
Maintenance Guidelines 8
Overview 9
DMX Setup 10
Installation Instructions 12
System Menu 13
DMX Traits: Channel Functions & Values 18
Dimmer Curve Chart 21
Multiple Unit Power Linking 22
Fuse Replacement / Cleaning / Troubleshooting 22
Specications 23

4
GENERAL INFORMATION
INTRODUCTION
Please read and understand all instructions in this manual carefully and thoroughly before attempting
to operate these products. These instructions contain important safety and use information.
UNPACKING
The products in this kit have been thoroughly tested and have been shipped in perfect operating
condition. Carefully check the shipping carton for damage that may have occurred during shipping.
If the carton appears to be damaged, carefully inspect each unit included for damage and be sure all
accessories necessary to operate the units have arrived intact. In the event damage has been found
or parts are missing, please contact our customer support team for further instructions. Please do not
return this kit to your dealer without rst contacting customer support at the number listed below. Please
do not discard the shipping carton in the trash. Please recycle whenever possible.
WARRANTY RETURNS
All returned service items whether under warranty or not, must be freight pre-paid and accompany a
return authorization (R.A.) number. The R.A. number must be clearly written on the outside of the return
package. A brief description of the problem as well as the R.A. number must also be written down on
a piece of paper and included in the shipping container. If the unit is under warranty, you must provide
a copy of your proof of purchase invoice. Items returned without a R.A. number clearly marked on the
outside of the package will be refused and returned at customer’s expense. You may obtain a R.A.
number by contacting customer support.

5
LIMITED WARRANTY (USA ONLY)
A. ADJ Products, LLC hereby warrants, to the original purchaser, ADJ Products, LLC products to be free of manufacturing
defects in material and workmanship for a prescribed period from the date of purchase (see specic warranty period
on reverse). This warranty shall be valid only if the product is purchased within the United States of America, including
possessions and territories. It is the owner’s responsibility to establish the date and place of purchase by acceptable
evidence, at the time service is sought.
B. For warranty service, you must obtain a Return Authorization number (RA#) before sending back the product-please
contact ADJ Products, LLC Service Department at 800-322-6337. Send the product only to the ADJ Products, LLC
factory. All shipping charges must be pre-paid. If the requested repairs or service (including parts replacement) are
within the terms of this warranty, ADJ Products, LLC will pay return shipping charges only to a designated point within
the United States. If the entire instrument is sent, it must be shipped in its original package. No accessories should be
shipped with the product. If any accessories are shipped with the product, ADJ Products, LLC shall have no liability
whatsoever for loss of or damage to any such accessories, or for the safe return thereof.
C. This warranty is void of the serial number has been altered or removed; if the product is modied in any manner which
ADJ Products, LLC concludes, after inspection, affects the reliability of the product, if the product has been repaired or
service by anyone other than ADJ Products, LLC factory unless prior written authorization was issued to purchaser by
ADJ Products, LLC; if the product is damaged because not properly maintained as set forth in the instruction manual.
D. This is not a service contact, and this warranty does not include maintenance, cleaning or periodic check up. During
the period specied above, ADJ Products, LLC will replace defective parts at its expense with new or refurbished parts,
and will absorb all expenses for warrant service and repair labor by reason of defects in material or workmanship. The
sole responsibility of ADJ Products, LLC under this warranty shall be limited to the repair of the product, or replacement
thereof, including parts, at the sole discretion of ADJ Products, LLC. All products covered by this warranty were
manufactured after August 15, 2012, and bear identifying marks to that effect.
E. ADJ Products, LLC reserves the right to make changes in design and/or improvements upon its products without any
obligation to include these changes in any products theretofore manufactured.
F. No warranty, whether expressed or implied, is given or made with respect to any accessory supplied with products
described above. Except to the extent prohibited by applicable law, all implied warranties made by ADJ Products, LLC
in connection with this product, including warranties of merchantability or tness, are limited in duration to the warranty
period set forth above. And no warranties, whether expressed or implied, including warranties of merchantability or
tness, shall apply to this product after said period has expired. The consumer’s and/or Dealer’s sole remedy shall be
such repair or replacement as is expressly provided above; and under no circumstances shall ADJ Products, LLC be
liable for any loss or damage, direct or consequential, arising out of the use of, or inability to use, this product.
G. This warranty is the only written warranty applicable to ADJ Products, LLC Products and supersedes all prior warranties
and written descriptions of warranty terms and conditions heretofore published.
LIMITED WARRANTY PERIODS
• Non L.E.D. Lighting Products = 1-year (365 days) Limited Warranty (Such as: Special Effect Lighting, Intelligent
Lighting, UV lighting, Strobes, Fog Machines, Bubble Machines, Mirror Balls, Par Cans, Trussing, Lighting Stands etc.
excluding LED and lamps)
• Laser Products = 1 Year (365 Days) Limited Warranty (excludes laser diodes which have 6 month limited warranty)
• L.E.D. Products = 2-year (730 days) Limited Warranty (excluding batteries which have a 180 day limited warranty)
Note: 2 Year Warranty only applies to purchases within the United States.
• StarTec Series = 1 Year Limited Warranty (excluding batteries which have a 180 day limited warranty)
• ADJ DMX Controllers = 2 Year (730 Days) Limited Warranty

6
SAFETY GUIDELINES
To guarantee a smooth operation, it is important to follow all instructions and guidelines in this manual.
ADJ PRODUCTS LLC is not responsible for injury and/or damages resulting from the misuse of these
devices due to the disregard of the information printed in this manual. Only qualied and/or certied
personnel should perform installation of these devices and only the original rigging parts included with
these devices should be used for installation. Any modications to these devices and/or the included
mounting hardware will void the original manufactures warranty and increase the risk of damage and/
or personal injury.
PROTECTION CLASS 1 – DEVICES MUST BE PROPERLY GROUNDED
THERE ARE NO USER SERVICEABLE PARTS INSIDE THESE DEVICES. DO NOT AT-
TEMPT ANY REPAIRS YOURSELF; DOING SO WILL VOID YOUR MANUFACTURES
WARRANTY. DAMAGES RESULTING FROM MODIFICATIONS TO THESE DEVICES
AND/OR THE DISREGARD OF SAFETY INSTRUCTIONS AND GUIDELINES IN THIS
MANUAL VOID THE MANUFACTURES WARRANTY AND ARE NOT SUBJECT TO
ANY WARRANTY CLAIMS AND/OR REPAIRS.
DO NOT PLUG THIS UNIT INTO A DIMMER PACK!
DO NOT REMOVE THE COVER UNDER ANY CONDITIONS!
NEVER OPERATE THIS UNIT WITH THE COVER REMOVED!
UNPLUG POWER DURING LONG PERIODS OF NON-USE
NEVER TOUCH LIGHT DURING OPERATION, AS IT MAY BE HOT!
KEEP FLAMMABLE MATERIALS AWAY FROM THESE DEVICES!
DO NOT EXCEED OPERATING TEMPERATURES OF 185°F (85°C)!
INDOOR / DRY LOCATIONS USE ONLY!
DO NOT EXPOSE DEVICES TO RAIN AND/OR MOISTURE!
NEVER LOOK DIRECTLY INTO THE LIGHT SOURCE!
RETINA INJURY RISK - MAY INDUCE BLINDNESS!
SENSITIVE PERSONS MAY SUFFER AN EPILEPTIC SHOCK!

SAFETY GUIDELINES
DO NOT position devices close to any FLAMMABLE MATERIALS while operating.
DO NOT attempt installation and/or operation of devices without knowledge how to do so.
DO NOT permit operation by persons who are not qualied to operate these types of devices.
DO NOT shake devices, avoid brute force when installing and/or operating.
DO NOT operate these devices if the main power cord has become frayed, crimped and/or damaged.
Replace any damaged power cords with a similar power rating.
DO NOT remove or break-off the ground plug from the device power cords.
DO NOT remove disassemble devices, there are NO user serviceable parts inside.
ALWAYS disconnect devices from main power source before performing any cleaning.
ALWAYS disconnect light from main power before replacing lamp.
ALWAYS be sure to install these devices in an area that will allow proper ventilation.
NEVER remove the ground prong from the power cable.
Power cords should be safely routed and secured so they are not likely pinched.
Disconnect power cords during long periods of non-use.
Only use recommended rigging hardware as described in this guide.
Use the original packaging and materials to transport these devices in for service.
These devices should be serviced by qualied service personnel when:
• The power cords or plugs have become damaged.
• Objects have fallen on and/or liquid has spilled into the devices.
• The devices have been exposed to rain and/or moisture.
• The devices do not operate normally or exhibit a marked change in performance.
7

8
MAINTENANCE GUIDELINES
DISCONNECT POWER BEFORE PERFORMING ANY MAINTENANCE!
CLEANING
Frequent cleaning is recommended to insure proper function, optimized light output, and an extended
life. The frequency of cleaning depends on the environment in which the device operates in: damp,
smoky or particularly dirty environments can cause greater accumulation of dirt on the lens and/or light
xture optics. Clean the external housing of the xture and the front lens of the light at least every 20
days with a soft cloth to avoid dirt/debris accumulation.
NEVER use alcohol, solvents, or ammonia-based cleaners.
MAINTENANCE
Regular inspections are recommended to insure proper function and extended life.
There are no user serviceable parts inside these devices, please refer all other service issues to an
authorized ADJ service technician. Should you need any spare parts, please order genuine parts from
your local ADJ dealer.
Please refer to the following points during routine inspections:
A detailed review by an approved electrical engineer every three months, to make sure the circuit con-
tacts are in good condition and prevent overheating.
Be sure all screws and fasteners are securely tightened at all times. Lose screws may fall out during
normal operation resulting in damage or injury as larger parts could fall.
Check for any deformations on the light, light-housings, lenses, rigging hardware, and rigging points
(ceiling, suspension, trussing). Deformations could allow for dust to enter into the devices. Damaged
rigging points or unsecured rigging could cause the devices to fall and seriously injure a person(s).
Electric power supply cables must not show any damage, material fatigue or sediments.

OVERVIEW
DOWN Button
UP Button
ENTER Button
Menu Screen
5-Pin DMX IN
3-pin
DMX OUT
POWER OUT
POWER IN
FUSE: 7A
5-Pin DMX OUT
3-pin
DMX IN
Mounting
Bracket Knob
MODE Button
Mounting Bracket Safety Cable
Attachment Point
9

10
DMX SETUP
POWER SUPPLY
The Cob cannon wash contains an automatic voltage switch, which will auto sense the voltage when
it is plugged into the power source. With this switch there is no need to worry about the correct power
voltage, this unit can be plugged in anywhere.
DMX-512
DMX is short for Digital Multiplex. This is a universal protocol used by most lighting and controller
manufactures as a form of communication between intelligent xtures and controllers. A DMX controller
sends DMX data instructions from the controller to the xture. DMX data is sent as serial data that
travels from xture to xture via the DATA “IN” and DATA “OUT” XLR terminals located on all DMX
xtures (most controllers only have a DATA “OUT” terminal).
DMX LINKING
DMX is a language allowing all makes and models of different manufactures to be linked together
and operate from a single controller, as long as all xtures and the controller are DMX compliant. To
ensure proper DMX data transmission, when using several DMX xtures try to use the shortest cable
path possible. The order in which xtures are connected in a DMX line does not inuence the DMX
addressing. For example, a xture assigned a DMX address of 1 may be placed anywhere in a DMX
line, at the beginning, at the end, or anywhere in the middle. Therefore, the rst xture controlled by
the controller could be the last xture in the chain. When a xture is assigned a DMX address of 1, the
DMX controller knows to send DATA assigned to address 1 to that unit, no matter where it is located in
the DMX chain.
DATA CABLE (DMX CABLE) REQUIREMENTS
(FOR DMX AND PRIMARY/SECONDARY OPERATION):
The COB Cannon Wash can be controlled via DMX-512 protocol. The COB Cannon Wash has three
DMX channel modes (1 channel mode, 2 channel mode,
& 3 channel mode). The DMX address is set electronically
using the controls on the rear panel of the unit. Your unit
and your DMX controller require an approved DMX-512
110 Ohm Data cable for data input and data output (Figure
1). We recommend AccuCable DMX cables. If you are
making your own cables, be sure to use standard 110-120
Ohm shielded cable (This cable be purchased at almost all
professional sound and lighting stores). Your cables should
be made with a male and female XLR connector on either
end of the cable. Also remember that DMX cable must be
daisy chained and cannot be split.

11
1
2
3
DMX +
DMX -
3
1
2
XLR Male Socket
1 Ground
XLR Female Socket
2 Cold 2 Cold
3 Hot
1 Ground
3 Hot
DMX SETUP
Notice: Be sure to follow gures two and three when making your own cables. Do not use the ground
lug on the XLR connector. Do not connect the cable’s shield conductor to the ground lug or allow the
shield conductor to come in contact with the XLR’s outer casing. Grounding the shield could cause a
short circuit and erratic behavior.
DMX512 OäT
3-PIN XLR DMX512 IN
3-PIN XLR
COMMON
SPECIAL NOTE: LINE TERMINATION
When longer runs of cable are used, you may need to use a terminator on the last unit to avoid erratic
behavior. A terminator is a 110-120 ohm 1/4 watt resistor, which is connected between pins 2 and
3 of a male XLR connector (DATA + and DATA -). This unit is inserted in the female XLR connector
of the last unit in your daisy chain to terminate the line. Using a cable terminator (ADJ part number
Z-DMX/T) will decrease the possibilities of erratic behavior.
5-Pin XLR DMX Connectors. Some manufactures use 5-pin DMX-512 data cables for DATAtransmission
in place of 3-pin. 5-pin DMX xtures may be implemented in a 3-pin DMX line. When inserting standard
5-pin data cables in to a 3-pin line a cable adapter must be used, these adapters are readily available
at most electric stores. The chart below details a proper cable conversion.
3
1
Termination reduces signal errors and avoids signal
transmission problems and interference. It is always
advisable to connect a DMX terminal, (Resistance
120 Ohm 1/4 W) between PIN 2 (DMX-) and PIN 3
(DMX+) of the last xture. Figure 4
2
3-Pin XLR to 5-Pin XLR Conversion
Conductor 3-Pin XLR Female (Out) 5-Pin XLR Male (In)
Ground/Sheld Pin 1 Pin 1
Data Compliment (- signal) Pin 2 Pin 2
Data True (+ signal) Pin 3 Pin 3
Not Used Do Not Use
Not Used Do Not Use
XLR Pin Conguration
Pin 1 = Ground
Pin 2 = Data Compliment (negative)
Pin 3 = Data True (positive)

INSTALLATION INSTRUCTIONS
INSTALLATION
This unit should be mounted using a mounting clamp (not provided), afxing it to the mounting bracket
that is provided with the unit. Always ensure that the unit is rmly xed to avoid vibration and slipping
while operating. Always ensure that the structure to which you are attaching the unit is secure and is
able to support the weight of ten (10) times the unit’s weight and any mounting accessories. A safety
cable (optional) is recommended when installing the xture. It is also recommended that a professional
installs the equipment and it must be installed in a place where it is out of the reach of people’s grasp.
The Dotz Matrix is fully operational in two different mounting positions, hanging upside-down from
a ceiling or set on a at level surface. To avoid internal damage to the unit, never mount the unit
on its side as illustrated above. Be sure this xture is kept at least 0.5m away from any ammable
materials (decoration etc.). Always use and install the supplied safety cable as a safety measure to
prevent accidental damage and/or injury in the event the clamp fails. Never use the carrying handles
for secondary attachment.
12

SYSTEM MENU
The xture includes an easy to navigate system menu where xture settings can be adjusted via the
LCD control panel located on the back of the xture. During normal operation, pressing the MODE
button once will access the main menu. Navigate through the various sub-menus by pressing the UP
and DOWN buttons, press the ENTER button to select a specic sub-menu, press the UP and DOWN
buttons to adjust the selected sub-menu settings, and press the ENTER button again to conrm the
sub-menu setting selection. Exit the main system menu at any time without making any adjustments by
pressing the MODE button.
To access the system menu press and hold the MODE button for 3 seconds. The LCD Menu Control
Display will shut OFF automatically about 1 minute from the last button press.
13

01. STATIC CL:RGBFlash00-99
Blackout,
Red-Green-Blue-Yellow-Cyan-Purple-White Flash speed ad-
justable.
02. DREAM
Speed00-99 — Flash00-99 Seven color dreaming Speed & Flash adjustable
03. METEOR
Speed00-99 — Flash00-99
Seven color ow
Speed & Flash adjustable
04. FADE
Speed00-99 — Flash00-99
Seven color ow
Speed & Flash adjustable
05. CHANGE
Speed00-99 — Flash00-99
Seven color ow
Speed & Flash adjustable
06. FLOW 1
Speed00-99 — Flash00-99
Seven color ow
Speed & Flash adjustable
07. FLOW 2
Speed00-99 — Flash00-99
Seven color ow
Speed & Flash adjustable
08. FLOW 3
Speed00-99 — Flash00-99
Seven color ow
Speed & Flash adjustable
09. FLOW 4
Speed00-99 — Flash00-99
Seven color ow
Speed & Flash adjustable
10. FLOW 5
Speed00-99 — Flash00-99
Seven color ow
Speed & Flash adjustable
11. FLOW 6
Speed00-99 — Flash00-99
Seven color ow
Speed & Flash adjustable
12. FLOW 7
Speed00-99 — Flash00-99
Seven color ow
Speed & Flash adjustable
13. FLOW 8
Speed00-99 — Flash00-99
Seven color ow
Speed & Flash adjustable
14. FLOW 9
Speed00-99 — Flash00-99
Seven color ow
Speed & Flash adjustable
15. FLOW 10
Speed00-99 — Flash00-99
Seven color ow
Speed & Flash adjustable
SYSTEM MENU
Built-In-Programs
14

15
SYSTEM MENU
DMX Mode - Set the DMX Address and DMX Channel Mode -
1. Press the MENU button until “DMX Mode” and underneath “ADDR: XXX” and “CH:XX” is displayed,
press ENTER.
2. “XXX” will now begin to ash, use the UP and DOWN buttons to nd your desired DMX address,
then press ENTER.
3. “XX” will now begin to ash, use the UP and DOWN buttons to nd your desired DMX Channel
mode, then press ENTER.
Secondary Mode- This will let you set your unit as a secondary in a Primary/Secondary
conguration.
1. Press the MENU button until “Secondary Mode” is displayed. Your unit will now follow the Primary.
Sound Mode - In this mode the unit will run in sound active mode.
1. Press the MENU button until “Sound Mode” is displayed.
2. Press ENTER to adjust your sound sensitivity. When you press ENTER the number next to “Sens”
will begin to ash, use the UP and DOWN buttons to adjust the sound sensitivity. Once you found
your desired sensitivity press ENTER to conrm.
3. When you press ENTER the number next to “FQN” will begin to ash, use the UP and DOWN
buttons to adjust the amount of times you would like the program to cycle before changing to the
next program. Press ENTER to conrm.
Auto Run-
1. Press the MENU button until “Auto Run” is displayed, and “FQN:XX” will be displayed underneath.
“XX” representing the number displayed.
2. Press ENTER and the number will begin to ash, use the UP and DOWN buttons to adjust
the amount of times you would like the program to cycle before changing to the next program. Press
ENTER to conrm.
Built-In Programs - See the chart on page 14 to nd your desired program.
1. Press the MENU button until one of the Programs on page 7 is displayed. The displayed program
depends on the last program you had set the unit to.
2. Press ENTER to move through the various adjustments of each program, and use the UP and
DOWN button to make adjustments.
Pixel Flip - In this mode you adjust the unit so that the LEDs in DMX mode will illuminate at your
desired starting point.
Example: If the unit is set to Flip 1, in 48 Channel mode, the rst pixel will light up starting on the
top right. If set to Flip 2, in 48 Channel mode, the rst pixel will light up starting on the bottom
right.
1. Press the MENU button until “Pixel Flip” is displayed, press ENTER.
2. Either “Standard” or “Flip X”, “X” representing a number between 1-4. Use the UP or DOWN buttons
to nd your desired setting.

16
SYSTEM MENU
Dim Curve - This setting will let you select your desired dimming curve.
1. Press the MENU button until “Dim Curve” is displayed, press ENTER.
2. 1 of 5 dimming curve settings will be displayed: Standard, Stage, TV, Architectural, or Theatre.
Use the UP and DOWN buttons to select your desired dimming curve and press ENTER to conrm.
White Balance -
(WHITE BALANCE ADDED 12/27/19 WITH SOFTWARE V2.5)
In this mode you are able to the adjust the RGB colors to reach your desired “color temperature”.
Note: When adjusting the white balance, be aware of the current PIXEL FLIP setting you are in.
Adjusting the white balance will affect the other PIXEL FLIP modes. See the pixel ip diagram
settings.
1. Press the MENU button until “WHITEBALANCE” is displayed.
2. Press ENTER to select the rst adjustment. Use the UP and DOWN buttons to scroll through RGB,
press the ENTER button to select the color and advance to the next setting.
3. The next setting will let you scroll through the 16 different light output LEDs. Use the UP and DOWN
buttons to nd the LED you would like to adjust and press ENTER to make your selection and
advance to the next setting.
4. In the next setting you are able to adjust the output brightness for the color and LED you previously
selected. Use the UP and DOWN buttons to adjust the output intensity and press the ENTER button
when you are nished.
5. Repeat steps 2-4 to continue to adjust the RGB colors to your desired output. Press the MENU
button to exit without making any adjustments.
Universal DMX Control: This function allows you to use a Elation® universal DMX-512 controller to
control the chases and patterns, dimmer and strobe. A DMX controller allows you to create unique
programs tailored to your individual needs. The Dotz Matrix has 5 DMX channel modes; a 3 Channel
Mode, 6 Channel Mode, 7 Channel Mode, 48 Channel Mode, & (52 Channel Mode ), 53 Channel
Mode (Added (6/21/18).
1. This function will allow you to control each individual xture’s traits with a standard DMX 512
controller such as the Elation® Show Designer™ or the Elation® DMX Operator.™
2. To run your xture in DMX mode, follow directions on page 8 to set your DMX address and DMX
Channel mode.
3. Plug in the xture via the XLR connections to any standard DMX controller.
4. For longer cable runs (more than a 100 feet) use a terminator on the last xture.
Primary-Secondary Operation: This function will allow you to link up to 16 units together and operate
without a controller. The units will be sound activated. In Primary-Secondary operation one unit will act
as the controlling unit and the others will react to the controlling units programs. Any unit can act as a
Primary or as a Secondary.
1. Using approved DMX data cables, daisy chain your units together via the XLR connector on the rear
of the units. Remember the Male XLR connector is the input and the Female XLR connector is the
output. The rst unit in the chain (primary) will use the female XLR connector only. The last unit in
the chain will use the male XLR connector only. For longer cable runs we suggest a terminator at
the last xture.
2. On the Primary unit set your desired operating mode.
3. On the secondary units press the MODE button until “Secondary Mode” is displayed.
4. The secondary units will now follow the Primary unit.

SYSTEM MENU
STANDARD
Flip 1
Flip 2
Flip 3
Flip 4
17
1 2 3 4
8 7 6 5
9 10 11 12
16 15 14 13
4 3 2 1
5 6 7 8
12 11 10 9
13 14 14 16
13 14 15 16
12 11 10 9
5 6 7 8
4 3 2 1
16 15 14 13
9 10 11 12
8 7 6 5
1 2 3 4
1 2 3 4
5 6 7 8
9 10 11 12
13 14 15 16

18
DMX TRAITS: CHANNEL FUNCTIONS & VALUES
DMX CHANNELS / VALUES / FUNCTIONS (5 DMX Channels)
SUPPORTS SOFTWARE VERSION ≥ 1.07
MODE / CHANNEL VALUE FUNCTION
CH 3 CH 6 CH7 CH 48 CH 53
1 1 1 1 1 RED 1
0-255 0-100%
2 2 2 2 2 GREEN 1
0-255 0-100%
3 3 3 3 3 BLUE 1
0-255 0-100%
4 4 RED 2
0-255 0-100%
5 5 GREEN 2
0-255 0-100%
6 6 BLUE 2
0-255 0-100%
7 7 RED 3
0-255 0-100%
8 8 GREEN 3
0-255 0-100%
9 9 BLUE 3
0-255 0-100%
10 10 RED 4
0-255 0-100%
11 11 GREEN 4
0-255 0-100%
12 12 BLUE 4
0-255 0-100%
13 13 RED 5
0-255 0-100%
14 14 GREEN 5
0-255 0-100%
15 15 BLUE 5
0-255 0-100%
16 16 RED 6
0-255 0-100%
17 17 GREEN 6
0-255 0-100%
18 18 BLUE 6
0-255 0-100%
19 19 RED 7
0-255 0-100%
20 20 GREEN 7
0-255 0-100%
21 21 BLUE 7
0-255 0-100%
22 22 RED 8
0-255 0-100%
23 23 GREEN 8
0-255 0-100%
24 24 BLUE 8
0-255 0-100%

19
DMX CHANNELS / VALUES / FUNCTIONS (11 DMX Channels)
SUPPORTS SOFTWARE VERSION ≥ 1.07
MODE / CHANNEL VALUE FUNCTION
CH 3 CH 6 CH7 CH 48 CH 53
25 25 RED 9
0-255 0-100%
26 26 GREEN 9
0-255 0-100%
27 27 BLUE 9
0-255 0-100%
28 28 RED 10
0-255 0-100%
29 29 GREEN 10
0-255 0-100%
30 30 BLUE 10
0-255 0-100%
31 31 RED 11
0-255 0-100%
32 32 GREEN 11
0-255 0-100%
33 33 BLUE 11
0-255 0-100%
34 34 RED 12
0-255 0-100%
35 35 GREEN 12
0-255 0-100%
36 36 BLUE 12
0-255 0-100%
37 37 RED 13
0-255 0-100%
38 38 GREEN 13
0-255 0-100%
39 39 BLUE 13
0-255 0-100%
40 40 RED 14
0-255 0-100%
41 41 GREEN 14
0-255 0-100%
42 42 BLUE 14
0-255 0-100%
43 43 RED 15
0-255 0-100%
44 44 GREEN 15
0-255 0-100%
45 45 BLUE 15
0-255 0-100%
46 46 RED 16
0-255 0-100%
47 47 GREEN 16
0-255 0-100%
48 48 BLUE 16
0-255 0-100%

20
DMX CHANNELS / VALUES / FUNCTIONS (11 DMX Channels)
SUPPORTS SOFTWARE VERSION ≥ 1.07
MODE / CHANNEL VALUE FUNCTION
CH 3 CH 6 CH7 CH 48 CH 53
4 49
COLOR
0 - 15
16 - 23
24 - 31
32 - 39
40 - 47
48 - 55
56 - 63
64 - 71
72 - 79
80 - 87
88 - 95
96 - 103
104 - 111
112 - 119
120 - 127
128 - 135
136 - 143
144 - 151
152 - 159
160 - 167
168 - 175
176 - 183
184 - 191
192 - 199
200 - 207
208 - 215
216 - 223
224 - 231
232 - 239
240 - 247
248 - 255
MACROS & PROGRAMS
NO FUNCTION
RED
GREEN
BLUE
RED & GREEN
GREEN & BLUE
RED, GREEN, & BLUE
COLOR 1
COLOR 2
COLOR 3
COLOR 4
COLOR 5
COLOR 6
COLOR 7
COLOR 8
COLOR FADE 1
COLOR SNAKE
COLOR FADE 2
COLOR CHANGE
COLOR FLOW 1
COLOR FLOW 2
COLOR FLOW 3
COLOR FLOW 4
COLOR FLOW 5
COLOR FLOW 6
COLOR FLOW 7
COLOR FLOW 7
COLOR FLOW 8
COLOR FLOW 9
COLOR FLOW 10
N/G
4 5 50 0 - 255
0 - 255
MASTER DIMMER/PROGRAM SPEED
MASTER DIMMER 0% - 100%
PROGRAM SPEED SLOW - FAST
5 6 51 0 - 255
STROBING
SLOW - FAST
6 7 52
0 - 41
42 - 84
85 - 127
128 - 170
171 - 213
214 - 255
DIMMER CURVES
STANDARD
STAGE
TV
ARCHITECTURAL
THEATER
DEFAULT TO UNIT CURVE SETTING
53 0 - 255
PROGRAM DIMMING
DIMMING 0% - 100%
When Channel 49 is being used between the values of 136-247, Channel 53 can control program
dimming.
When Channel 49 is being used between the values of 136-247, Channel 50 will control the
speed of the programs.
