Best Barns Brandon-R Safety guide

the Brandon - R Building Size
12'x20'
Revised September 28, 2022
Assembly Book
This manual is copyrighted. Under the copyright laws, this manual
may not be copied, in whole or in part, without consent from
RBS Holdings, LLC © Copyright 2022
Manufactured by RBS Holdings, LLC
205 Arlington Drive Greenville, PA 16125
Remove Watermark Wondershare
PDFelement

Tongue Edge
LAP Edge
800-245-1577 - Mon - Fri 8AM - 5PM EST
724-866-4357 - After hours and weekends
Email - [email protected]
IMPORTANT INFORMATION ABOUT YOUR KIT
Thank you for purchasing our kit. Please read the following information before beginning construction.
Always check with your local HOA or building code office for any requirements or restrictions.
Tools Required: Hand or Circular Saw
Cordless Drill
Hammer
Pencil
Level
Measuring Tape
6'-8' Ladder(s)
Safety Glasses
Dust Mask
Phillips Screwdriver
Framing Square
Always wear safety glasses when cutting or nailing!
Additional Materials - Not included in kit:
Required: Shingles or metal roofing, Drip Edge, Roofing Nails or Screws, Paint
Optional: Caulk, Ridge Vent
Floor: Wood flooring is sold optionally. You may choose to build your own or pour a cement pad.
Windows are purchased separately
Terminology:
Square - Confirm corners are at 90 degrees
Plumb - Confirm walls and trusses are straight vertically
Wall Plate - Top and bottom 2x4s used to frame walls
Tie Plate - 2x4s connecting wall sections together
Header - Spans top of door opening
OSB - Oriented Strand Board
LAP - Edge of siding that overlaps Tongue
Tongue - Edge of siding that is overlapped
Organize:
Unpack all items & organize according to size and type. This will make items easier to find
when instructed.
Review the parts list on the back page. Should there be missing items or sub-par material
contact Best Barns Customer Service.
DO NOT discard any material including the pallet until your project is complete.
Assembly:
Review all instructions before you begin. Please follow steps carefully and in sequence for
successful results.
If you have any questions we are happy to assist you. Please contact us at:
Primed Siding Detail
Remove Watermark Wondershare
PDFelement

1. Stagger the 4x4 timbers as shown below. Cut (2) two 2x4- 8' boards into 2' long blocks
to secure the 4x4s where they butt together.
Assembly Instructions for
Rear Floor Section
4. Install the floor joists cut above between the 8' joist headers. Secure with 16d galv. deck nails.
5. Place floor assembly over the 4x4s. Square floor assembly. Measure the floor diagonally
(corner to corner) and then the opposite corners; these measurements will be the same when
the floor is square. Toenail frame (headers & joists) to the 4x4 runners.
2. Cut (2) two 2x4-8' to a length of 8' -0". They
will be used for the joist headers. Layout, from
left, for 16" on center joist spacing. 'X' marks
where floor joist will be placed.
6. Cut (2) two 2x4-12' to a length of 12' -0". Layout
for 16" joist spacing, See above.
7. Install floor joists between the joist headers. Square
the floor section and install against the section
assembled above. Toenail to the 4x4s runners.
8. Install 4x8 flooring over the 2x4s. Use 8d galv.
spiral nails spaced 8" apart.
Material Description 12' x 20'
2x4 Treated Blocking 2 pcs. 8'
2x4 PT Joist Headers 2 pcs. 8'
2x4 PT Joist Headers 2 pcs. 12'
2x4 PT Floor Joist 17 pcs. 12'
4x4 Treated Runners 4 pcs. 8'
4x4 Treated Runners 4 pcs. 12'
Flooring 5/8" or 3/4" 8 pcs. 4x8
Galv Spiral Floor Nails 3 lb. 8d
Galvanized Deck Nails 5 lb. 16d
Foundation size is 12'-0" x 20'-0". Check local building codes in your area, the construction may
have to change. For a concrete slab, install sill sealer as a moisture barrier between the concrete
and the wall plates. Foam sill sealer can be purchased at home centers in rolls 3-1/2" or wider.
Constructing Details for Deluxe Floor System
3. Cut (17) seventeen 2x4-12' treated boards to 11' -9". These will be the floor joists. Treated
lumber may be thicker than 1-1/2". Take this into account when cutting the length of floor
joists. Shorten joist measurements if necessary to obtain 12'-0" building width.
XXXX
XXXX
X
X
15-1/4" 16" 16"
4x4-8' Treated
Runner
4x8 Flooring
2x4-8' Joist Header
4x4-12' Treated
Runner
4x4-8' Runner
4x4-12' Runner
4x4-12' Runner
Front Floor Section
::
:::
:
:::::::
Remove Watermark Wondershare
PDFelement

XX
XX
B
B
X
X
X
X
X
X
A
A
B
A
Do not discard any material until construction is complete. Including short blocks of 2x4s.
Step 1 Assemble 10' Long Side Walls
4. Cut one of the 48" wide siding panels in half lengthways.
5. Square wall frame. Measure diagonally (corner to corner). The measurements will be the same
when the wall is square. Select one of the 2' wide panels with the 'tongue' edge and install this
panel with the 'cut' edge flush with the end of the wall and extending 3/4" below the bottom
plate. Install using 6d galv. nails spaced 8" apart.
6 Install (2) two more siding panels.
Siding Extends 3/4" Below Plate
LAP Edge
1. Position (2) two 2x4-48" boards and (2) two 2x4-72" boards together and indicate with 'X'
marks, where the wall studs will be located. Mark the ends that will butt together with 'the
letters A' an 'B'.
2. Install 72" wall studs between the top and bottom plates. Nail both wall frames together.
3. Repeat to assemble (3) three more 10' long side wall frames.
7. Select another 10' wall frame and repeat to apply siding.
24"
23-1/4"
72" Wall Plate
48" Wall Plate
23-1/4"
Cut Edge
Tongue Edge
72" Wall Plate
48" Wall Plate
4' Wall Plate
Remove Watermark Wondershare
PDFelement

4. Repeat to apply siding to the other 10' wall frame.
Step 2 Assemble Side Walls for 20' Building Length
1. Select one of the 10' side walls assembled in Step 1. Butt a 10' wall frame against the
wall with siding. DO NOT nail these frames together so they can be separated later.
10' Wall Panel from Step 5
6' Wall Plate
2. Square the wall frame. Install a full width siding panel but do not nail along the long edge
that overlaps the 10' wall frame. You can nail this edge after the wall panels are installed.
This will enable you to separate the wall panels making them easier to handle.
Do Not Nail Along This Edge
LAP Edge
4' Wall Plate
3. Install another full width siding panel and
the 2' wide siding panel.
Remove Watermark Wondershare
PDFelement

3. Install (4) four 72" wall studs between (2) two 58-1/2" long 2x4 wall plates
4. Gather (2) two 2x4-72" 2x4s. Cut each board to 71-1/2" and install as a header support on each
wall frame flush with bottom plate. Use 10d sinkers.
6. Install a 16" siding panel with a
tongueedge.Cutedgewillbeflush
with the header support.
If installing the optional window you
can cut the opening in the siding.
Instructions are packed in window box.
XX
X
X
X
X
X
X
Step 3 Assemble Door Wall - Offset Doors
71-1/2" Header Supports
5. Select a 16" wide siding panel with a
'LAP' edge. Install cut edge flush with
header support. The 'LAP' edge will
extend 3-1/2" beyond the wall frame.
Bottom edge will be 3/4" below the
bottom plate.
1. Cut (2) two 11" plates from a 34-3/4" long
2x4. Install (2) two 72" wall studs between the
11" long 2x4 wall plates.
2. Position (2) two 58-1/2" long 2x4s together
and indicate with 'X' marks where the wall
studs will be located.
71-1/2" Header Support
To position the door opening in the center of the wall, go to Step 4. To position
the door opening on the right side of the front wall, flip the walls and apply
siding to the opposite side of the wall frames.
LAP Edge Extends 3-1/2"
Siding Extends
3/4" Below Plate
7. Install the last siding panel. The siding will
extend 3-1/2" past the wall frame.
58-1/2" Wall Plate
19-3/4"
24"
Cut Edge Flush
71-1/2" Header
Support
Remove Watermark Wondershare
PDFelement

X
X
X
X
X
X
Left Side Wall Panel Right Side Wall Panel
Step 4 Assemble Door Wall - Doors Centered
71-1/2" Header
Support
5. Select one frame and position so header support is on right.
6. Locate a 16" wide siding panel with a 'LAP' edge. Install this panel with the cut edge flush
with the 2x4 header support. Bottom edge should be 3/4" below bottom plate. Only nail along
cut edge until next panel is installed.
7. Cut a 48-3/4" wide siding panel in half lengthways.
8. Select cut panel with the 'Tongue' edge. Install this panel so cut edge extends 3-1/2" beyond
the end of the frame and tongue edge under the 16" panel. The siding should extend 3/4' below
the bottom plate. Nail both siding panels to frame.
1. Locate (2) two 34-3/4" long 2x4s and position them together.
Indicate with 'X' marks where studs will be located..
2. Install (3) three 72" wall studs between the 34-3/4" wall plates.
3. Locate (1) one 2x4-72" and cut to 71-1/2". Install as a header
support on right side as shown and flush with bottom plate. Use
10d sinkers.
4. Locate (2) two 58-1/2" 2x4s and cut (1) one 34-3/4" plates from
each. Repeat steps 2 and 3 to assemble another wall frame.
Make (2) Two Frames
71-1/2" Header Support
7. Locate a 16" wide siding panel with a 'Tongue' edge and the remaining 24" wide cut panel.
Install these on remaining frame. Make sure header support is oriented to the left.
Cut Edge Extends
Beyond Frame
LAP Edge
Tongue
Edge
Cut Edge Flush
34-3/4" Wall Plate
19-3/4"
Cut Edge Extends
Beyond Frame
Remove Watermark Wondershare
PDFelement

A
A
B
B
XX
XX
X
X
2. Install (8) eight 72" wall studs between the top and bottom plates. Assemble wall frames with
10d sinkers, (2) two nails at each stud end. Nail both wall frames together with 10d sinkers.
3. Square wall frame.
4.
Install the 1st siding panel with the 'LAP' edge extending 3-1/2" past the wall frame.The bottom
will extend 3/4" below the bottom plate.
5. Install (2) two more siding panels. Cut the last panel to extend 3-1/2" beyond the wall frame.
X
X
X
X
X
X
68-1/2" Wall Plate
2x4-72" Wall Studs
Step 5 Assemble 12' Back Wall
1. Gather (4) four 2x4-68-1/2" boards an position together then indicate with 'X' marks, where
the wall studs will be located. Mark the ends that will butt together with the letters 'A' and 'B'.
68-1/2" Wall Plate
24"
19-3/4" 24"
23-1/4"
68-1/2" Wall Plate
AB
Siding to extend 3/4”
below bottom plate
LAP
Edge
A
B
Siding Extends 3-1/2"
Past 2x4 Stud
Remove Watermark Wondershare
PDFelement

6. Secure the 2x4 bottom plate to the truss rafter with
a 2-1/2" wood screw on both ends. Set gable aside.
7. Repeat steps 3-6 to assemble another gable.
72" long 2x4
3/4" Plywood Gusset
2. Repeat to assemble another
12' long bottom plate.
3. Place the bottom gable plate on the floor along with (2) two 80-1/2" long 2x4 truss rafters as
shown below. Bottom plate will be on edge. There are short 2x4s, that may have an angle on
one end, supplied in the kit. Use these to hold the truss rafter and bottom gable plate together
by temporarily screwing the blocks to the floor using 2-1/2" screws. This will ensure that the
gable frames and the trusses, assembled next, are identical.
4. Secure the top of the truss rafters together with a 1"x4" barbed metal drive-on plate.
5. Install (2) two 23-1/2" gable studs with angle cut at one end. Nail through the bottom plate
with 10d sinkers and secure the top with barbed metal drive-on plates.
Step 6 Assemble Roof Gables
1. Butt (2) two 72" long 2x4s together and secure them with a 3-1/2" x 31-3/4" long plywood
gusset across the top where they butt together. Use glue and (12) twelve 6d common nails.
This will be used as the bottom plate on the roof gables.
23-1/2" Gable Stud
Bottom Gable Plate
Barbed Metal Plate
80-1/2" long 2x4
Truss Rafter
2x4 Block
2x4 Block
Remove Watermark Wondershare
PDFelement

6. Remove and save the short 2x4 blocks. They
will be used in a later step.
Detail 'B'
Step 7 Assemble Roof Trusses
1. Place (2) two 80-1/2" long 2x4 truss rafters and a 82" long collar tie together as shown below.
The collar tie has an angle cut on both ends. Reposition the lower 2x4 blocks to hold the truss
rafters in place. See 'Detail B'.
2. Secure the 2x4 truss rafters at the top with a 8" x 16" wood gusset. Apply wood glue between
the 2x4s and the gusset. Nail the gusset to the 2x4s with (14) fourteen 6d common nails,
3. Secure teh 2x4 collar tie with (4) four 3" long wood screws at each end. Tip: Pre-drill holes
with an 1/8" bit to prevent wood splitting at ends.
4. Turn this truss over and apply a wood gusset to the opposite side at the ridge.
5. Repeat to assemble (8) eight more trusses.
Ridge Gusset
2x4-82" Collar Tie
!Install collar tie the same
distance from bottom end of
rafters.
80-1/2" Truss Rafter
2x4 Block
2x4 Block
2x4 Block
80-1/2" Truss Rafter
!
Collar Tie Flush
with Rafter
Remove Watermark Wondershare
PDFelement

2. Erect wall panels. IMPORTANT make sure walls are plumb and square. Secure together
at the corners using (4) four 10d sinkers per corner.
3. Nail siding on each 10' wall panel where they butt together.
4. Install the 2x4 door header between the front wall panels. Nail through the wall studs into the
ends of the header. Toenail into the top wall plates.
5. Temporarily install (2) two 2x4-72" boards at both sides of the door opening to hold the wall
straight. These boards will be used later for tie plates.
7. Install (2) two 4-1/4" siding panels over
the door header. The siding should extend
3/4" below the door header. Cut length to
fit. Wall trim, installed later, will hide
where the siding butts the front wall siding.
6. Nail all wall panels to the floor
through the bottom plate. Space 10d
sinkers 24" apart.
Step 8 Set Walls
Door Header
10' Long Wall Panel
10' Long Wall Panel
Nail Along Siding Edge
OSB Filler
1. Assemble door header using (2) two 67-1/2"
long 2x4 boards and 3-1/4" x 67-1/4" OSB filler
panel. Glue both sides of OSB. Nail header
together with (8) eight 10d sinkers on each side.
67-1/2" Long 2x4
Drawing shows building
with the doors offset.
Cut 4-1/4" x 48" Siding Panels to Fit
3/4" Below Bottom of Header
24" Wide
Siding Panel
24" Wide Siding Panel
Remove Watermark Wondershare
PDFelement

Tip; Paint the siding and trim boards before installing the trim.
Step 9 Install Trim
Front Wall
Door Opening
1x4-6' Trim
Side Wall
Install All Trim Flush
With Top Plate
3. Repeat above steps on opposite
side wall and front corner.
4. Butt a 1x4-6' trim board against
1x4 corner trim and flush with top
plate. Nail along top.
5. Cut a second 1x4-6' trim board to
finsh at opposite corner.
6. Repeat to install trim on back wall.
Step 10 Install Primed Soffit and Filler
1. Locate (1) one 7" wide x 48-3/4" long siding panel and cut in half (save one half for other
side wall). Install one half over the side wall with the primed side facing down. Cut edges
should be flush with the inside of the top 2x4 wall plate and flush with the trim on the front
wall. Tack the soffit with a couple 6d common nails. Installing 2x4 tie plates in a later step
will provide more nailing.
2. Install (5) five more soffit panels. Cut the last soffit flush with the back wall trim.
Side
Wall
Soffit Flush with
Inside of 2x4
4. Install (3) three 4-1/4" wide x 48-
3/4" filler panels over the front wall.
Install the filler flush with the 1x4
trim. Cut last filler to fit.
5. Repeat to install filler on back wall.
3. Repeat to install soffit boards on the other side wall.
1x4 Trim 1x4 Trim
Front Wall
Door Opening
Install Filler
Flush to Trim
1. Install (2) two 75-3/4" long 1x4 corner trim boards to the side wall flush with the top 2x4 wall
plate and flush with siding on the front and back walls. Use 6d galv. nails, spaced 12" apart.
2. Install a 75-3/4" long 1x4 trim board to the front wall flush with wall plate and with 1x4 trim.
7" Soffit
4-1/4" Filler
Remove Watermark Wondershare
PDFelement

LAP Edge
Flush
Step 12 Install Gables
Important: Bottom edge of siding extends
over 1x4 trim. Paint this edge.
2. Install gable on the front wall.
Step 11 Install Siding on Gables
1. Install a gable on the rear wall. The gable siding will extend over the 1x4 trim on the lower
wall. Secure gable to wall by nailing through the gable plate with 10d sinkers. Nail siding along
the 1x4 trim board with 6d galv. nails.
Siding Extends 3/4"
Below Bottom Plate
2x4s-72" Stacked to
Level Gable
1. Select one of the gable frames. Turn the gable over so bottom plate is on edge on floor. Support
gable studs and rafters with (2) two 2x4-72" boards stacked. This will give you a solid surface
when nailing siding.
2. Install left gable siding panel with the 'LAP' edge flush with the end of of bottom plate. Use
6d galv. nails across the top of the 2x4 frame and gable studs. The siding will extend 3/4" below
the bottom 2x4.
3. Install center and right panels. Cut last panel flush with end of bottom plate.
4. Repeat to install siding on
the other gable frame. LAP
Edge
Remove Watermark Wondershare
PDFelement

Inside of Building
Step 14 Layout Roof Trusses
Side Wall
Step 13 Install 2x4 Tie Plates on Side Walls
1. Install a 4' long 2x4 over a side wall, against the
front gable plate and flush with the inside of soffit.
Use 10d sinkers.
2. If used for a wall brace, remove a 72" long 2x4 and
install this next to 4' tie plate. Install another 72"
2x4.
3. Cut a 4' long 2x4 to fit and install against rear gable.
4. Install tie plates on the opposite side wall.
1. Layout the truss spacing from the left side wall of the building. Measure from the backside
of the 2x4 gable frame when marking the location of the first truss. Continue 24" spacing
to other gable. Important: When marking the opposite wall, place the 'X' mark on the same
side of the line so your trusses are parallel when they are installed.
2. Install metal hangers to the tie plate with hanger nails . The opening should line up with the
'X' mark, the bottom of the opening, flush with the 2x4 tie plate. Detail 'D'.
24"
20-5/8"
Measure from
Backside of 2x4
Install
Flush
Detail 'D'
2x4 Tie Plate
Remove Watermark Wondershare
PDFelement

3. Install a 2x4 block at each
end of the soffit, flush with
the 2x4 gable frame.
1. Install a 8-1/2" long trim board, called a keystone,
at the top of the gable flush with the top of the
gable frame. Use 6d galv. nails.
2. Install (2) two 81" long 1x4 trim boards flush
with the top of the gable frame.
Use 6d galv. nails.
2. Install short 2x4 blocks at
both ends of each truss.
Secure 2x4 blocks to the
soffit panel using (2) two
1-1/2" long exterior screws.
Step 15 Set Roof Trusses and Soffit Blocks
1. Set roof trusses. Secure trusses to metal hangers with hanger nails.
Step 16 Install Rear Gable Trim
4 Install small primed siding fillers, packed with the
hardware, over the 2x4 soffit blocks. Siding fillers
will be flush with the gable siding. Use 6d galv. nails.
Siding Filler
Remove Watermark Wondershare
PDFelement

48" x 72"
48" x 48"
48" x 83-1/2"
36-1/2" x 83-1/2"
Panel Extends
7-1/2" Beyond
Gable
36-1/2" x 72"
3. Butt (2) two 1x4-4' fascia boards to the 6' board. See sheathing drawing below. Repeat to
install (2) two more 1x4-4' fascia boards on the opposite side.
4. Cut (2) two 48" x 85-3/4" panels from the extension kit. See detail below,
5. Install roof sheathing per layout below. Starting at rear of building install a 48"x48" OSB
roof panel flush with face of 1x4 gable trim. Plumb each truss and gable. Make sure the
sheets meet at center of truss. Use 6d common nails spaced 12" apart. The top row of roof
sheathing will be about 1" below the ridge to allow for optional ventilation. Important: Make
sure the roof sheathing extends 7-1/2" past the siding on the face of the gable.
1x4-6' 1x4-4'
36-1/2" x 48"
Step 17 Install 1x4 Fascia & Roof Sheathing
1x4 -6' Fascia Board
1x4 Fascia
2x4 Truss
Roof Sheathing
Straight Edge
2x4 Tie Plate
2x4 Soffit Block
Nail Fascia to
2x4 Block
1. Starting at the rear of the building, install a 1x4-6' fascia board against the rear gable trim.
Install the fascia so the bottom edge of the roof sheathing will rest on the edge of the 1x4. See
Detail 'E'. Use a straight edge to align the 1x4 board with the top of the trusses.Use 6d galv.
nails.
2. Repeat on opposite side wall.
Detail 'E'
48" x 48"
36-1/2" x 48"
Cut each 48" x 85-3/4" panel from the extension kit
to a 48" x 48" and a 36-1/2" x 48" long panel.
"48" x 48" 48" x
36-1/2"
""
"
"
1x4-4'
Remove Watermark Wondershare
PDFelement

7" Wide Panel
Flush with Bottom of 2x3
1x4 Door Trim
Step 18 Install Front Gable Soffit and Door Trim
2. Gather (2) two 42-3/8" long 2x3s. Starting at the peak
install against gable siding and underside of roof sheathing.
Use 10d sinkers. Repeat on the other side.
3. Gather (2) two 7" wide soffit panels. Install first panel
flush with lower end of 2x3 and against siding. Use 6d
galv. nails. Cut next panel to fit. Repeat on other side.
Nail into Bottom of 2x3
5. Install gable trim and keystone over the 2x3 boards and under
the roof sheathing. Use 6d galv. nails.
4. Starting at the peak install (2) two 42-3/8" long 2x3s between the roof
sheathing and the 7" soffit panels. Use 6d galv. nails on soffit and 6d common
nails through roof sheathing. Set these boards flush with soffit panels. Roof
sheathing will extend past 2x3 boards. Repeat on other side.
Nail with 6d common nails
Nail with 6d Galv.
6. Return to side wallsand cut the last 1x4-7' fascia boards to fit.
42-3/8" Long 2x3
1. Locate (2) two 1x4-72" long trim boards. Tack these, with a couple
nails, flush to each side of the door opening and against bottom of
upper trim.The trim may need to be moved when you install the doors.
Remove Watermark Wondershare
PDFelement

Step 19 Install Doors & Hardware
3. Before fastening the hinges to the side trim,
temporarily prop the doors in the opening. Leave
a space at the top and bottom of the doors and
between the doors and the side trim to allow
room for the doors to expand due to humidity.
If your door opening is out of square, the space
around the doors will not be even. You can
remove and re-position the side trim to make
allowances for this. The side trim does not have
to be flush with the frame of the door opening.
You can move the trim in or out to make the
door spacing equal.
4. Determine position of hinges and install to side
trim with 2" screws.
5. Installdoorhaspondoubledoors.Whenproperly
installed the hasp will fold in half to receive
locking latch and the screw heads will be
covered.
6. Install a barrel bolt on the lower back of
the door to secure this door in place when
closed. You will need to drill a hole for
the round shaft to drop into.
7. Install another barrel bolt at the top of the
door.
Barrel Bolt on the
back of left door
Left Door
Siding Extends Past Trim
1. Locate the door that has a 2x4 fastened, on edge, to the
back side of the door. When doors are closed this 2x4 will
be in the center where doors meet. Lay the door with the
trim facing up and install (3) three 5" hinges to the right
side. To position the hinge properly, hold the rectangular
plate against the frame. Use 1-1/4" black screws.
2. Install hinges on the left side of the other door.
Fold Hasp to Cover
Screws
Remove Watermark Wondershare
PDFelement

Felt
Paper
1x4 Fascia
1x4 Gable Trim
Air
Space
Truss
Shingles
2. Install shingles according to the instructions on the wrapper.
Building Tip: Install ridge vent in lieu of shingles caps. Ridge vent provides ideal ventilation,
preventing heat and moisture from damaging your building or its contents.
Step 20 Install Roofing — Not Supplied in Kit
1. Install metal roof edging on the
perimeter of the roof area. If you are
not installing shingles at this time, you
can purchase felt paper to protect the
roof sheathing. Install the felt paper
before you install the metal roof edge.
Packing List for 4' Extension Kit
Optional ridge vent provides
ideal ventilation.
Roof Covering - not supplied in kit
12 bdl. Roof Shingles
9 pcs. Roof 'drip' Edge 10'
2 Collar Ties 2x4 82"
4 Rafters 2x4 80-1/2"
6 Wall Studs 2x4 72"
2 Wall Plates 2x4 48"
4 Soffit Blocks 2x4 5" approx.
2 Fascia Trim 1x4 48"
4 Gussets 7/16 8" x 16"
2 Sidng Panels 3/8 48" x 75-3/4"
2 Soffit Panels 3/8 48" x 7"
2 Roof Sheathing 7/16" 48" x 85-3/4"
1 Lb. 10d Sinkers Nails
1 Lb. 6d Common Nails
4 ea. H1 Truss Hangers
Remove Watermark Wondershare
PDFelement

Material Packing List
3 1 lb. box 10d Sinkers
2 1 lb. box Hanger Nails
5 1 lb. box 6d Galv.
3 1 lb. box 6d Common
50 ea. 1-1/2" Exterior Screws
25 ea. 2-1/2" Deck Screws
74 ea. 3" Deck Screws
6 ea. 5" Door Hinges
1 ea. 4-1/2" Door Latch
2 ea. 6" Barrel Bolts
16 ea. 3/4" Pan Head Screws
25 ea. 2" Hinge Screws
25 ea. 1-1/4" Hinge Screws
6 ea. 1x4 Metal Plates
1 ea. Bottle Glue
2 ea. Plywood Gussets 3-1/2" x 32"
2 ea. 1x6 Keystone 8-1/2"
4 ea. 1x4 Gable Trim 81"
4 ea. 1x4 Corner Trim 75-3/4"
4 ea. 1x3 Corner Trim 75-3/4"
4 ea. 1x4 Wall Trim 72"
2 ea. 1x3 Door Trim-sides 72"
1 ea. 1x3 Board (not used) 72"
2 ea. Pre-built Door 32" x 71-1/2"
4 ea. Gable Siding Fillers 2"x3"
24 ea. 2z4 Truss Jig Blocks 5" to 7"
7 Collar Ties 2x4 82"
18 Truss Rafters 2x4 80-1/2"
54 Wall Studs 2x4 72"
4 Wall Plates 2x4 68-1/2"
2 Wall Plates 2x4 67-1/2"
2 Wall Plates 2x4 58-1/2"
2 Wall Plates 2x4 34-3/4"
6 Wall Plates 2x4 48"
4 Gable Studs 2x4 23-1/2"
8 Gable Framing 2x3 42-3/8"
14 Truss Gussets 7/16" 8" x 16"
13 Soffit Panels 3/8" x 7" x 48"
8 Filler Panels 3/8"x 4-1/4" x 48"
14 2x4 Metal Truss Hangers
2 Fascia Boards 1x4 x 84"
2 Fascia Boards 1x4 x 72"
2 Fascia Boards 1x4 x 48"
12 Siding Panels 48" x 75-3/4"
2 Siding Panels 16" x 75-3/4"
2 Gable Siding Panel 48" x 40"
4 Gable Siding Panel 48" x 28"
4 Roof Sheathing 48" Long
4 Roof Sheathing 72" Long
4 Roof Sheathing 83-1/2" Long
2 OSB Filler 3-1/4" x 67-1/4"
Remove Watermark Wondershare
PDFelement
