Best Barns Glenwood II Safety guide

This manual is copyrighted. Under the copyright laws, this manual
may not be copied, in whole or in part, without consent from Reynolds
Building Systems, Inc. © Copyright 2018
the Glenwood II
Revised July 9, 2019
Assembly Book
Best Barns USA
Building Size
12' x 24'
Manufactured by Reynolds Building Systems, Inc.
205 Arlington Drive Greenville, PA 16125

Tongue Edge
LAP Edge
800-245-1577 - Mon - Fri 8AM - 5PM EST
724-866-4357 - After hours and weekends
Email - [email protected]
IMPORTANT INFORMATION ABOUT YOUR KIT
Thank you for purchasing our kit. Please read the following information before beginning construction.
Always check with your local HOA or building code office for any requirements or restrictions.
Tools Required: Hand or Circular Saw
Cordless Drill
Hammer
Pencil
Level
Measuring Tape
6'-8' Ladder(s)
Safety Glasses
Dust Mask
Phillips Screwdriver
Framing Square
Always wear safety glasses when cutting or nailing!
Additional Materials - Not included in kit:
Required: 8' x 7' Garage Door fitted for 93" of headroom.
Shingles or metal roofing, Drip Edge, Roofing Nails or Screws, Paint
Optional: Caulk, Ridge Vent
Floor: Wood flooring is sold optionally. You may choose to build your own or pour a cement pad.
Terminology:
Square - Confirm corners are at 90 degrees
Plumb - Confirm walls and trusses are straight vertically
Wall Plate - Top and bottom 2x4s used to frame walls
Tie Plate - 2x4s connecting wall sections together
Header - Spans top of door opening
OSB - Oriented Strand Board
LAP - Edge of siding that overlaps Tongue
Tongue - Edge of siding that is overlapped
Organize:
Unpack all items & organize according to size and type. This will make items easier to find
when instructed.
Review the parts list on the back page. Should there be missing items or sub-par material
contact Best Barns Customer Service.
DO NOT discard any material including the pallet until your project is complete.
Assembly:
Review all instructions before you begin. Please follow steps carefully and in sequence for
successful results.
If you have any questions we are happy to assist you. Please contact us at:
Primed Siding Detail

2. Cut (13) thirteen 2x4-12' floor joist to 11'-9". Treated lumber may be thicker than 1-1/2". Take
this into account when cutting the length of floor joists. Shorten the joist measurements if
necessary to obtain 12'-0" building width.
3. Place 4x4-12' treated timbers on the ground. Cut (2) two 2x4-8' boards into 2' long blocks to
secure the 4x4s where they butt together.
Assembly Instructions for Rear Floor Section
4. Install the floor joists cut above between the 12' joist headers. Secure with 16d galv. deck nails.
5. Place floor sections over the 4x4s. Square floor. Measure the floor diagonally (corner to corner).
These measurements will be the same if the floor is square (203-5/8"). To keep the 2x4 frame
from moving, toenail frame to the 4x4 runners.
4x4-12' Treated
Runner
4x8 Flooring
2x4-12' Joist Header
4x4-12' Treated
Runner
Foundation size is 12'-0" x 24'-0". Check local building codes in your area, the construction may
have to change. For a concrete slab, install sill sealer as a moisture barrier between the concrete and
the wall plates. Foam sill sealer can be purchased at home centers in rolls 3-1/2" or wider.
1. Cut (2) two 2x4-12' to a length of 12' -0".
Theywillbeusedfor thejoistheaders.Layout,
from the left, for 12" on center joist spacing.
The 'X' marks where floor joist will be placed.
6. Repeat step number 1 and 2 above and assemble
another floor section.
7. Install this section against the front floor section.
Nail together with 16d galv. deck nails.
8. Install 4x8 flooring over the 2x4s. Use 8d galv.
spiral nails.
Details for Optional Sturdy-Built Floor System
Material Description 12' x 24'
2x4 Blocks 2 pcs. 8'
2x4 Joist Headers 4 pcs. 12'
2x4 Floor Joist 26 pcs. 12'
4x4 Treated Runners 8 pcs. 12'
Flooring 3/4" 9 pcs. 4x8
Screw Floor Nails 5 lb. 8d
Galv. Box Nails 5 lb. 16d
2x4-2' Treated
Blocks
Front Floor Section
XX
XX
X
X
12"11-1/4"
X
X
12"

Depending on your location pre-cut wall studs vary in
length from 92-1/4" to 93". This doesn't affect construction.
X
X
X
X
X
X
X
X
24"
23-1/4"
144" Wall Plate
24"
Step 1 Assemble 12' Back Wall
LAP
Edge
1. Cut (2) two 2x4-12' (one will be treated) to a length of 144". Position the boards together
and indicate with 'X' marks where the wall studs will be located.
144" Top Wall Plate
Pre-Cut Wall Studs
5. Install (2) two more siding panels. If necessary
cut the last panel flush with the end of the frame.
4. Install the first siding panel with the 'LAP' edge flush with
the end of the wall. Siding will extend 3/4" below the bottom
plate. Nail siding with 6d galv. nails, spaced 8" apart.
Tip: use a 1x4 trim board as a gauge.
Siding Extends 3/4" Below Plate
Siding Flush
Stud Spacing
Top Wall Plate
Treated Bottom Plate
144" Treated Bottom Plate
2. Install (7) seven pre-cut wall studs between the top & bottom plates. Nail top plate to studs
using (2) two 10d sinkers per stud. Nail bottom plate to studs using 16d galv. nails using (2)
two nails per stud.
3. Square wall frame. Measure the wall diagonally (corner to corner). Then measure the opposite
corners. These measurements will be the same if the wall is square.

C
99" Long 2x8
48" OSB Filler
:
:
:
:
:
:
2. Mark a 'C' anywhere first two stud marks. This is referenced in a later step.
3. Install (7) seven pre-cut wall studs between the top & bottom plates. Nail top plate to studs
using 10d sinkers. Nail bottom plate to studs using 16d galv. nails.
XX
XX
X
X
C
X
X
Step 2 Assemble 12' Sidewalls
Step 3 Assemble Door Header
140-1/2" Treated Wall Plate
3. Repeat to assemble (3) three more 140-1/2" long wall frames.
Pre-Cut
Wall Studs
1. Cut (2) two 2x4-12' to a length of 140-1/2". Position the boards together and indicate with
'X' marks where the wall studs will be located.
Locate (2) two 10' long 2x8 boards and (2) 7-1/4" x 48" OSB fillers. Cut the 2x8s to a length
of 99". Install the OSB fillers to a 2x8 board. Apply wood glue to both sides of OSB and nail
2x8 boards together using 10d coated sinkers. Use (12) twelve nails spaced evenly on each side.
140-1/2" Wall Plates
Stud Spacing
Top Wall Plate
Treated Bottom Plate
24"
19-3/4" 24"

X
X
X
X
X
X
X
X
X
X
Cut Edge Flush
Tongue Edge
Flush
Cut Siding Flush
Step 4 Assemble Front Wall Frame
1. Cut (2) two 2x4-12' boards (one will be treated) to a length of 144" for wall plates. Position
the boards together and indicate with 'X' Marks where the wall studs will be located.
96" Finished Door Opening
21" 21"
Treated Bottom Plate
3. Cut (2) pre-cut studs to a length
of 82" and install as header
supports where shown. Nail to
stud using 10d sinkers.
4. Install the door header on the
header supports. Nail to the wall
stud with 10d sinkers.
5. Remove a 2x4 screwed to the
pallet. Measure space between
header and top plate. Cut (5)
fivepiecestothislength.Evenly
space pieces and nail through
top plate and toenail to header.
Use 10d sinkers.
6. Cut a siding panel in half
length-ways. Select the panel
with the 'Tongue' Edge. Save
the other panel for step 9 below.
82" Header Support
nail nail
2x4 Block
Centered
2x8 Door Header
2. Install (4) four pre-cut wall studs between the wall plates where shown. Nail top plate to studs
using 10d sinkers. Nail bottom plate to studs using 16d galv. nails.
96" Door Opening
9. Install remaining panel with LAP
edge flush with door opening.
8. Install (2) two 20"x48" siding panels above the door
opening. Cut siding flush with the bottom of the 2x4.
Siding Extends 3/4" Below Plate
7. Install panel with the 'Tongue' edge flush with door opening and cut edge flush with end of
wall. Siding should extend 3/4" below bottom plate. Use 6d galv. nails.

Temporary Nails
EndMarked 'C'
EndMarked 'C'
End Marked 'C'
Tip: If you are erectingbuilding on a wood floor insert
nails between the 3/4" floor sheathing and the 2x4 floor
frame. Rest the siding on the nails while nailing to frame.
1. Erect back wall and 140-1/2" side walls. IMPORTANT: Install the side wall frames with the
'C' marks oriented against the back and front wall corners. Secure walls together at the corners.
Use (4) four 10d sinkers per corner. Brace side walls with pre-cut wall studs to hold walls secure
and plumb.
2. Cut a siding panel in half lengthways. Select the panel with the 'tongue' edge. Install this panel
with the cut edge flush with the siding on the back wall. Siding should extend 3/4" below bottom
plate. Nail siding to back wall and all 2x4s using 6d galv. nails spaced 8" apart.
Step 5 Set Walls
3. Install (5) five full width siding panels. Install
24" wide siding to finish. Siding should extend
no more than 3-1/2" past wall to receive front
wall panel.
4. Repeat to side opposite side wall.
5. Erect front wall panel and secure corners with
10d sinkers and nail side wall siding to 2x4s.
Brace with pre-cut wall studs.
6. Cut and remove bottom 2x4 from door opening.
7. Nail walls to floor through bottom plate. Space 16d galv. nails 24" apart.
Back Wall
Siding Extends
3/4" Below Plate Cut 2x4 Plate
from Opening
Cut Edge

Step 6 Install 2x4 Tie Plates
Cut 2x4-12' to Fit
2x4-6' Tie Plate
2x4-12' Tie Plate
Step 7 Install Metal 2x4 Joist Hangers
Install (22) twenty two 2x4 joist hangers aligned
with the wall studs on both side walls. Use a short
2x4 block as a gauge to ensure the 2x4s, installed
in next step, will be flush with the top of the 2x4 tie
plate when installed. Secure the hanger with 1-1/2"
hanger nails.
2x4 Gauge Block
2x4-6' Tie Plate
1. Cut a 2x4-12' board in half. Install a 2x4-6' on a side wall, flush with the 2x4 on the back wall.
Install a 2x4-12' next. Install the 2nd 6' long 2x4 flush with the 2x4 on the front wall. Cut length
to fit. Use 10d sinkers to secure the tie plates to front and back walls and along length.
2. Repeat to install 2x4s on the opposite side wall.
3. Cut (2) two 12' long 2x4s to fit between side wall tie plates and install on front and back walls.

Step 8 Install Loft Floor
Step 9A Install Loft Floor Sheathing
Before installing floor sheathing consider where to locate the 2' x 4' access
opening. The detail below shows one possibility. Regardless of desired
layout it is important to install sheathing staggered when possible.
Important: Before securing the 2x4 floor joists make sure the side walls are plumb. The
building width should be 12'-0" measuring from the outside of the 2x4 tie plates.
Cut (11) eleven 2x4-12' boards to a length of 137" and install
in the metal hangers. Use 1-1/2" hanger nails.
4' x 8'
Suggested 2'x4 Opening Location
4' x 8'
4' x 8'
2' x 4'
4' x 8'
4' x 4'
Cut a 4' x 8'
in half
4' x 4'
4' x 4'
Cut a 4' x 8'
in half

3-1/2" x 24" OSB Filler
IMPORTANT: Do not
placeheavyweightonloft
at this point.
96" Between OSB Fillers
Back
Wall Side
Wall
1x3 Corner Trim
Step 10 Install Corner Trim
IMPORTANT: Lower Trim Must Be Installed Before Installing Roof Gables!
1. Locate (3) three 2" x 48-3/4" filler strips. Nail these on top of the siding on the back wall.
Use 6d galv. nails.
2. Install (2) two 99" long 1x3 white pine trim boards as corner trim to the back wall. Cut length
so trim is flush with top of OSB filler and bottom of siding. Install trim flush with the siding
on the side walls. Use 6d galv. nails spaced 12" apart to install all trim.
1x4 Trim Boards
3. Install (2) two 71-7/8" long 1x4 white
pine trim boards between corner
boards. Trim should be flush with
OSB sheathing. Cut 2nd board to fit.
4. Repeat to install trim boards to the
front wall panel.
Step 9B Install Loft Floor Sheathing continued
1. Locate (4) four 3-1/2" x 24" OSB fillers. Install at front and back corners on top of 2x4 tie
plates. Use 7d sinkers. Insure the space between fillers is 96".
2. Install loft flooring between OSB fillers. Edge of sheahting should be flush with front and back
wall tie plates. Refer to the suggested layout on previous page. Install flooring using 7d sinkers
spaced 12" apart.
Siding Filler
OSB Filler
Back
Wall Side
Wall

Step 11A Assemble Gables
32-1/2" Long 2x4s
49-1/2"
Long 2x4
Right Pre-built
Gable Frame
1x4 Block MUST
be Positioned Here
and Another on
Opposite Side
Gable Stud
Detail 'A'
Temporary
1x4 blocks
5-3/4"x14"
Gusset
1. Gather pre-built gable end frames, (1) one left and (1) right, (1) one 49-1/2" long 2x4 and (2)
two 32-1/2" long 2x4s with angled ends.
2. Position these components together as shown below. When aligned correctly the bottom 2x4s
will be straight and measure 12'-0" from end to end. Pre-built gable ends highlighted in gray.
3. Temporarily tack 1x4 blocks to loft flooring around the frame members. These blocks will be
8"-12" long and may have angled ends. Make sure (2) two of these blocks are positioned inside
each pre-built gable end frame as shown. Position the rest of the blocks appropriately spaced
to hold 2x4s in place. These will insure that all trusses and gables are built exactly the same.
DO NOT nail blocks to gable.
4. Secure the bottom 2x4 to the gable stud using (2) two 2-1/2" screws.
5. Locate (2) two 5-3/4"x14" OSB gussets.Attach these to top of each gable stud to secure frame
to 32-1/2" 2x4s. Use 6d common nails. See Detail 'A'.

1. Carefully turn the gable frame over. Temporarily place 2x4s under the gable frame to keep the
frame level while installing the gable siding.
2. Locate pre-cut gable siding. Working left to right install a siding panel with a 'tongue' edge
along right side. Install flush with end of frame and extending 3/4" below the bottom 2x4 plate.
Where 2x4s are flat nail siding with 6d galv. nails. Nail to bottom plate with 8d galv. nails.
Siding Extends 3/4" Below Plate
2x4s Under
Gable Frame
Tongue Edge on Right Side
Flush
Step 12A Install Front Gable Siding
Step 11B Assemble Gables Continued
5. Locate (2) two 50-3/4" long 2x4s.Install these equally
spaced from center of the gable. Secure the bottom 2x4
to the gable studs using (2) two 2-1/2" screws each.
6. Install a wood gusset at peak.
Apply glue between 2x4s and
gusset and nail using (14) fourteen
6d common nails.
7. Locate (2) two 5-1/2"x27-3/4"
gussets.Attach these to top of each
gable stud to secure to the 32-1/2"
2x4s. Use 6d common nails.
50-3/4" Gable Studs
5-1/2"x27-3/4"
Gusset

Step 12B Install Gable Siding continued
Step 13 Install Gable Overhang
4. Install last siding panel.
3. Install center siding. If you purchased a sunburst window you may cut the opening in the
siding at this time. Instructions are packed in the window box. It is advisable to install the
window after the gable is set
30-3/4" Long 2x4 77-3/8" Long 2x4
Do not remove the temporary 1x4 blocks until
the roof trusses and back gable are assembled.
1. Locate (2) two 77-3/8" long 2x4 rafters on gable. Install 2x4s flush with the top of gable
frame. Use 10d sinkers.
2. Locate (2) two 30-1/4" long 2x4 rafters and install to finish. 2x4s will extend beyond end of
gable.

Repositioned
1x4 Blocks
12'-0" Span
Step 14 Set Front Gable
1. Install gable on the front wall. Secure bottom of
gable to loft floor and OSB fillers using 10d sinkers.
2. Nail the bottom edge of the siding into the 1x4 trim.
Use 6d galv. nails. Bottom edge of gable siding
extends over 1x4 trim
Step 16 Assemble Roof Trusses
Important: Temporarily brace the gables with 2x4s
to secure gables until the roof sheathing is installed!
1. Insert left and right pre-built truss ends into the blocks that held the gable frames in place. Insure
span is 12'-0" between truss ends as indicated in drawing below.
2. Butt (2) two 77-3/8" long 2x4s against the truss ends. Remove the 1x4 blocks that secured the
bottom gable plate and reposition to keep rafters aligned. Locate a 18-1/2" long 2x4 ridge block
with angled ends and install at peak. Secure rafters and ridge block at peak with a wood gusset.
Install with (14) fourteen 6d common nails and glue.
3. Install gussets on truss ends. See DetailA. Install with (20) twenty 6d common nails and glue.
4. Carefully flip truss over and install another gusset at the peak.
5. Set truss aside. Repeat steps to build (10) ten more trusses.
6. Remove temporary 1x4 blocks.
Front
Wall
Step 15 Assemble Rear Gable
Repeat Steps 11 through 13 to assemble and set rear gable.
Detail 'A'
Tip: Place a gusset under
rafters to help level.
Repositioned
1x4 Blocks
Pre-built Truss
Assembly
77-3/8" long 2x4
Truss Rafter
Wood Gusset
GLUE
18-1/2" Ridge Block
12'-0" Span Measure Span
from Here

Step 17 Set Trusses
2. Continue standing trusses to front of building.
Make sure trusses and gables are plumb. If
necessary span a 2x4 across tops and tack to
keep plumb until roof sheathing is installed.
1. Starting at back gable set a truss by sliding ends over 2x4 floor joist. Truss ends should set flat
atop floor joist. Secure with (10) ten 6d common nails on both sides.
Step 18 Install Sidewall Trim
2. Repeat to install corner trim at the other
three corners.
3. Install a 4' long 1x3 trim along the top
of the sidewall. Use the gauge block
to set where the trim will be installed.
4. Install (3) three 72' long 1x3 trim along
the top of the sidewall. Cut a 4' long 1x3
trim board to finish.
5. Repeat on opposite side wall.
It's easier to install the soffit if the corner and sidewall trim are installed first. This
enables the soffit to rest on the trim where it meets the building. See lower detail.
1. Locate a 3/8" x 3" x 8" siding gauge block packed
in the hardware bag. Place this gauge block under
the 2x4 overhang and butt a 99" long 1x4 trim
board against it. Cut trim board to length and
install the trim flush with the corner trim on the
back of the building. Use 6d galv. nails.
99" Corner Trim
3/8" Gauge Block
1x3 Trim
3/8" Gauge Block

1. Locate (4) four 9-3/4" x 48" soffit panels. On the front gable nail first soffit with the 'LAP'
edge positioned 9-3/4" from the bottom end of the 2x4 to allow for the width of the soffit panels
on the side walls. Use 6d galv. nails.
Step 19 Install Soffit
2. Cut to fit next soffit to cover 2x4 at
the peak. Install (2) two soffit panels
on other side.
3. Locate (7) seven 9-3/4" x 48" soffit
panels. Measure from center of first
truss to edge of soffit on gable. Cut
a soffit panel to this length. Make
sure 'LAP' edge is the side cut off.
4. Nail the soffit panel to the end of
the 2x4s. See Detail 'C' below.
5. Install more soffit panels along the
side of the building cutting the last
soffit panel flush with the 2x4 on
the rear gable.
6. Repeat steps 3-5 to install soffit
panels on the front gable and the
opposite side wall.
Cut Soffit Panel to Meet
Center of Truss
1x4 Trim Board
Detail 'C'
Nail Soffit to End of 2x4
9-3/4"Soffit
Soffit
9-3/4" Wide Soffit

Soffit
Straight Edge
2x4 Rafter
1x6
48" x 51"
48" x 96"
48" x 75"
51"
48" x 96"
48"
48" x 59-1/4"
48" x
35-1/4"
59-1/4"
Step 20 Install 1x6 Fascia on Side Walls
1x6 Fascia Board
2. Install (1) one 48"long 1x6 trim board next.
Continue with (3) three 1x6-6' trim boards.
Cut a 48" long 1x6 trim board flush with the
front soffit overhang to finish.
3. Repeat on opposite side wall.
1. Starting at the back gable, install a 75" long 1x6 trim board flush with the face of the 2x4.
Install the 1x6 board so the top of the board is aligned with the top of the trusses. The roof
sheathing, installed later, should rest on the fascia. Use a straight edge as shown below. Use
6d galv. nails.
Step 21A Install Roof Sheathing
Plyclip
Cut From
48"x96"
Supplied in our component kit.
1. Locate (2) 48"x96" sheets of OSB. Cut from these
(2) two 48"x59-1/4" sheets. From drops cut (2) two
48"x35-1/4" sheets.
2. Following layout below install roof sheathing
according to instructions on next page. Front Gable
Back
Gable
48" x 96"
48" x 96"
48" 48" 48"

2. Install a 30-1/4" long 2x4 between
the roof sheathing and the soffit
panel
3. Repeat on opposite side.
1. Make sure the trusses and gables are plumb.
2. Refer to the roof sheathing layout. Install
a 48"x59-1/4" sheet at lower front corner.
Sheathing should be flush with soffit and
rest on 1x6 fascia. Secure sheathing with
7d sinkers nails. Space nails 12" apart.
Continue to back gable.
3. The top row of sheathing will allow a gap
at the top to allow ventilation if ridge vent
is applied. Insert (2) two ply-clips into the
roof sheathing between each truss at the
top row, see drawing on previous page.
flush
Step 21B Install Roof Sheathing continued
Step 22 Install 2x4s in Front overhang
1. Starting at the peak install a 77-3/8" long 2x4 between the roof sheathing and the soffit
panels. Set this board flush with edge of soffit panels and roof sheathing. Use 6d galv. nails
on soffit and 7d sinkers through the roof sheathing.
Nail with 7d Sinkers
Nail with 6d Galv.
Air
Space
48"x59-1/4"
OSB
48"x35-1/4"
OSB

Step 23 Install Gable and Door Trim
3. Locate (2) two 8' long 1x6s. Cut to fit and install on the sides of the door opening and flush
with face of siding. Use 6d galv. nails.
4. Locate (1) one 8' long 1x6. Cut to fit and install at top of door opening flush with face of siding.
5. Cut a 1x4-10' board to a length of 104". Install centered at dop of door opening and covering
door jamb. Use 6d galv. nails. Trim will extend past vertical trim. Cut shorter if desired.
6. Locate (2) two 8' long 1x4s. Cut to fit and install on the sides of the door opening and covering
door jamb.
1x6 Jamb Material
1x6 Gable Trim
1x4 Door Trim
Covers Jamb
1. On front gable install (2) two 1x6 trim boards over the 2x4 boards, flush with the top of
the OSB roof sheathing. Use 6d galv. nails.
2. Install gable trim on the rear gable.

VIEW FROM INSIDE
If you ordered the optional floor, install the
galvanized door sill. Secure sill with pan
head screws.
Galv. Door Sill
Install Optional Door Sill
Step 24 Install 2x4s around Door Jamb
1x6 Door Jamb
2x4 Cut to Fit
51-1/2" Long 2x4
1. Select (2) two 2x4s. Cut each to fit on either side of door opening against back of jamb.
Secure to stud with 10d sinkers.
2. Select (2) two 2x4s and cut each to 51-1/2" long. Install across top jamb and 2x4s. Secure
to header with 10d sinkers.
Remove 2x4s used for bracing walls
