•Bed frame maximum supporting weight: 1000 lb (455 kg).
•Maximum mattress thickness: 10 in (25.5 cm).
•Mattress weight must be between: 60 lb (27 kg) and 90 lb (41 kg).
•Minimum ceiling height: 85.75 in (2.18 m).
•Minimum holding force required for each fastener: 142 lb (630 N).
•Not for use with folding mattress.
NOTICE
Important information to read
before starting the assembly.
Keep this information for future reference.
MODEL
COLOR
WO
26183-5
IMPACT OR CRUSHING HAZARD: If bed is not properly attached to the wall,
it can suddenly fall, resulting in serious injury or death.
•For wood or masonry wall structure, a qualified person must install the bed to the wall.
•For all other types, a construction professional must install the bed to the wall in compliance
with the codes and regulations in the province, state, or country where installed.
•The choice of wall attachment screw depends on wall type. Use wall attachment screws
suitable for your wall material.
•Verify structural integrity of floor and wall prior to installation.
•Do not open or use the bed if the bed cabinet moves while opening, or if you notice any other
signs of loose or detaching screws.
•Never remove wall attachment screws without first disassembling and removing the mattress
frame and lift cylinders.
•Qualified person must have the skills and tools necessary to locate wall studs, identify type
of wall structure (wood, metal, masonry or other) and install screws correctly to wall structure.
Skills and tools include electronic stud finder, drill motor and bits, screwdriver, and ability
to correctly use these tools.
WARNING
FOR ANY PROBLEM OR INFORMATION
1-888 8BESTAR (1-888 823-7827)

Should you need more information concerning the warranty, do not call to the place
of purchase. Please call our customer service department for immediate assistance
using the toll free number below. Please have your assembly instruction manual on
hand when you call.
BESTAR products are warranted to the original purchaser against defects in material
or workmanship in the furniture. Defects as mentioned in this warranty refer to any
imperfections which may impair the use of the product. Our warranty is expressly
limited to the replacement of furniture parts and components for the time specified
in the product description and following the date of purchase. BESTAR will replace
any part that is defective. This warranty applies under conditions of normal use.
Our furniture products are not intended for outdoor use, except those in the Outdoor
Collection. The warranty does not cover labor or assembly costs or defects caused by
improper assembly or disassembly, after-purchase product modifications, intentional
damage, accidents, or exposure to the elements. Bestar reserves the right to request
a proof of purchase to document a warranty claim. In no event shall BESTAR be liable
for incidental or consequent damages resulting from the misuse of the product.
This warranty is not transferable and is valid only in Canada and the United States
excluding Alaska, Hawaii and Puerto Rico.
Warranty Information
www.bestar.com/warranty

Customer Service
If there are parts missing from your order or if your product was damaged during shipping,
PLEASE CONTACT US DIRECTLY.
Need help?
If you have any questions or concerns,
please visit our website:
or call our toll-free number:
1-888 823-7827
www.bestar.com/support
www.bestar.com/support
Send us an email
www.bestar.ca/contact-us
Need help?
www.bestar.com/faq
Make a phone appointment
www.bestar.com/online-appointment

Activate your Warranty
Activate your warranty now:
Information required to make a warranty claim
A copy of your receipt.
Pictures of the damaged parts.
You must know the name of the product, the item number and the name
of the store where the item was purchased.
Please collect this information BEFORE contacting our customer service.
www.bestar.com/activate-my-warranty
www.bestar.com/activate-my-warranty

Maintenance Tips
Never leave damp clothes, liquids or damp cloths on the furniture.
If a liquid has spilled on the furniture, clean the liquid up immediately.
Clean the furniture with a damp cloth, then wipe dry.
To avoid damaging the finish, do not use cleaning products on the furniture.
Do not put devices with plastic or rubber pads directly on your furniture.
Instead, attach cloth or felt pads to your device.
To avoid dulling the finish, do not place furniture in direct sunlight.
www.bestar.com/maintenance

At Bestar, we take pride in manufacturing stylish and functional furniture for your
home and workspace. We go beyond manufacturing furniture: we oer solutions to
optimize and customize your home and workspace. That’s why customer satisfaction
is our number one priority!
Satisfaction Survey
www.bestar.com/satisfaction
www.facebook.com/Bestar1948/ www.instagram.com/bestarfurniture/ www.youtube.com/user/bestar1948/ www.pinterest.ca/bestarcanada/
www.bestar.com/about-bestar
Stay in touch with us
www.bestar.com/blog

30
31
70
00
Part number on the top or on edge
83
60
61 31
41
85
Parts & Hardwares
26183-5 AN 7SERVICE: 1-888 8BESTAR (1-888 823-7827)
80
71
30
Parts
Code Qty
30 1
31 1
41 1
Code Qty
60 1
61 1
70 1
Code Qty
71 1
80 1
Code Qty
83 1
85 1

KI-7653-A-4 1
KI-7653-A-5 1
KI-7653-A-6 2
KI-7653-A-7 4
KI-7653-J 2
KI-7653-V 1
KI-7653-W-1 1
MA-1138 1
Code Qty
CA-7641 2
CR-7639 3
KI-985-E 2
KI-985-G 1
KI-985-H 1
KI-993-I 1
KI-985-K 18
KI-985-L 5
KI-985-M 18
KI-985-Q 1
KI-985-S 40
KI-993-R 40
KI-1115-P 1
KI-7652-A-8 20
KI-7652-C 1
KI-7652-D 1
KI-7652-M 32
KI-7652-O 30
KI-7652-P 2
KI-7652-S 2
KI-7652-W-2-1 1
KI-7652-W-2-2 1
KI-7652-X 2
KI-7652-Y 2
KI-7653-A-1 1
KI-7653-A-2 1
KI-7653-A-3 1
Code Qty Code Qty Code Qty
26183-5 AN 8SERVICE: 1-888 8BESTAR (1-888 823-7827)
Code Qty
BT-1137 1
CA-100 12
EX-7635 2
FO-1136 1
GO-796 14
H-03 4
H-36 4
H206515 1
PA-844 4
PO-959 2
LEG WARNING STICKER 1
Code Qty Code Qty Code Qty
Parts & Hardwares
Hardwares in box 1
3/32 in
(2,5 mm)
1 in
(25 mm)
Hardwares in box 3 — Metal Mechanism for Full-Size Wall Bed
5/8 in (16 mm)
5/8 in
(16 mm)
83 in
(2100 mm)
Not used for this model.
Important Notice
Group together all the hardware required for each step as
the construction of your piece of furniture is progressing.

26183-5 AN 9SERVICE: 1-888 8BESTAR (1-888 823-7827)
Code Qty Code Qty
KI-985-L 5
KI-985-M 18
KI-7652-M 32
VB-1135 6
VC-204 15
VB-1134
VF-232 4
VR-207 42
VR-215 12
3500-400350 42
8
Real Size
Parts & Hardwares
Important Notice
2 in (50 mm)
7/8 in (22 mm)
2 in (51 mm)
1/2 in (13 mm)
5/8 in (16 mm)
5/8 in (16 mm)
2 5/32 in (55 mm)
4 in (102 mm)
2 3/4 in (70 mm)
http://bestar.ca
http://bestar.com
•Bed frame maximum supporting weight: 10 00 lb (455 kg).
•Maximum mattress thickness: 10 in (25.5 cm).
•Mattress weight must be between: 60 lb (27 kg) and 90 lb (41 kg).
•Minimum ceiling height: 91.5 in (2.32 m).
•Minimum holding force required for each fastener: 142 lb (630 N).
•Not for use with folding mattress.
NOTICE
Important information to read
before starting the assembly.
Keep this information for future reference.
MODEL
COLOR
WO
25183-3
Impact or Crushing Hazard: If bed is not properly attached to the wall,
it can suddenly fall, resulting in serious injury or death.
•For wood, metal, or masonry wall structure, a qualified person must install the bed to the wall.
•For all other types, a construction professional must install the bed to the wall in compliance
with the codes and regulations in the province, state, or country where installed.
•The choice of wall attachment screw depends on wall type. Use wall attachment screws
suitable for your wall material.
•Verify structural integrity of floor and wall prior to installation.
•Do not open or use the bed if the bed cabinet moves while opening, or if you notice any other
signs of loose or detaching screws.
•Never remove wall attachment screws without first disassembling and removing the mattress
frame and lift cylinders.
•Qualified person must have the skills and tools necessary to locate wall studs, identify type
of wall structure (wood, metal, masonry or other) and install screws correctly to wall structure.
Skills and tools include electronic stud finder, drill motor and bits, screwdriver, and ability
to correctly use these tools.
WARNING
FOR ANY PROBLEM OR INFORMATION
1-888 8BESTAR (1- 888 823-7827)
For future reference and to allow us to serve
you better, please complete the self-adhesive
sticker and apply it in an accessible space such
as the back of part 60.
Model / Modèle:
Production Number
Numéro de production:
Customer Service
Service à la clientèle
To better serve you!
Pour mieux vous servir!
1-888-823-7827
1/2 in (13 mm)

26183-5 AN 10SERVICE: 1-888 8BESTAR (1-888 823-7827)
Main hardware system. Installation steps.
Pull out
B
Turn
A
How to remove a misplaced assembly bolt (H-36).
Arrow
H-03
2
Insert the cam with the arrow pointing
toward the hole in the edge.
Proper position
H-36
Push down
1
Important Notice
TWO people are required
to assemble and move
this model.
When you have completed the assembly
of your new furniture, install plastic caps
CA-1014
When you have completed
the assembly of your new
furniture, install self-adhesive
caps on unused holes.
CA-99
23/32 in
18 mm
H-03
CA-100
3/32 in
2,5 mm
VC-204
CA-77
3/8 in
10 mm
Unused holes
Properly level your
furniture using the
adjustable legs.
PA-844
Required tools
The use of power tools must be done with vigilance.
#3
Electronic
stud finder
1/4 in (7 mm) Easier with these tools
3/16 in
5 mm
1/2 in
13 mm
1
Insert
2
Required tools
A
Important
Tighten
3B
Main hardware system. Assembly steps.
Make sure to properly tighten each cam to ensure
furniture solidity. Otherwise, parts could be damaged
or the user could be injured.

26183-5 AN 11SERVICE: 1-888 8BESTAR (1-888 823-7827)
GO-796
x 14
H-03
x 4
PA-844
x 4
1 in (25 mm)
Hardware installation
Murphy bed
1
Code
Qty
41
70
31
30
83
NOTICE
Place boxes under parts during
the assembly to avoid damage.
GO-796
GO-796
PA-844
H-03
GO-796
GO-796
GO-796

26183-5 AN 12SERVICE: 1-888 8BESTAR (1-888 823-7827)
VC-204
x 4
Code
Qty
2 in (50 mm)
TWO people
are required
for this step.
Hardware installation & assembly
Murphy bed
2
41 31
30
83
Holes down.
VC-204

26183-5 AN 13SERVICE: 1-888 8BESTAR (1-888 823-7827)
71
70
VC-204
x 11
Code
Qty
2 in (50 mm)
Hardware installation & assembly
Murphy bed
3
NOTICE
Label must face this way.
See next page for detailed view.

25183-2 AN 14SERVICE: 1-888 8BESTAR (1-888 823-7827)
Assembly
Murphy bed
4
26183-5 AN 14SERVICE: 1-888 8BESTAR (1-888 823-7827)
TWO people
are required
for this step.
WARNING
IMPACT or CRUSHING HAZARD: If wall bed mechanism is not
properly attached to the floor and wall, it can suddenly rotate,
resulting in serious injury or death.
• For wood and masonry floor and wall structure, a qualified person
must install the wall bed mechanism.
• For all other type of floor or wall structure, a professional must install
the wall bed mechanism.
• The choice of attachment screws depends on floor and wall type.
Use attachment screws suitable for your floor and wall material.
• Verify structural integrity of floor and wall prior to installation.
• NEVER use hollow wall anchors.
• ALWAYS use 12 screws for floor and wall attachment.
• NEVER remove floor and wall attachment screws without first
disassembling and removing the lift cylinders and mattress frame.
• Only a professional or qualified person should disassemble this wall bed.
• Disassemble product in reverse order of initial assembly.
• Refer to owner’s manual or download manual at bestar.ca or bestar.com
AVERTISSEMENT
RISQUE DE CHOC ou D’ÉCRASEMENT : Si le mécanisme du lit
escamotable n’est pas correctement fixé au plancher et au mur, il
peut subitement pivoter, entraînant des blessures graves ou la mort.
• Pour les structures de murs et de planchers en bois et en maçonnerie,
une personne qualifiée doit installer le mécanisme du lit escamotable.
• Pour tout autre type de structure de mur et de plancher, un professionnel
doit installer le mécanisme du lit escamotable.
• Le choix de vis de fixation dépend du type de plancher et de mur.
Utilisez
des vis de fixation adaptées au matériau de votre plancher et de votre mur.
• Vérifiez l’intégrité structurale du plancher et du mur avant l’installation.
• N’utilisez JAMAIS de chevilles pour cloison sèche.
• Utilisez TOUJOURS 12 vis pour la fixation au sol et au mur.
• Ne retirez JAMAIS les vis de fixation au sol et au mur sans avoir préa-
lablement démonté et retiré les vérins de levage et le cadre du matelas.
• Seul un professionnel ou une personne qualifiée devrait démonter
ce lit escamotable.
•
Consultez le manuel du propriétaire ou téléchargez le manuel sur bestar.ca.
ADVERTENCIA
PELIGRO DE IMPACTO o APLASTAMIENTO: Si el mecanismo de
la cama abatible no está bien fijado al suelo y a la pared, puede
girar repentinamente y provocar lesiones graves o la muerte.
• Para suelos y paredes de madera y mampostería, una persona
cualificada debe instalar el mecanismo de la cama mural.
• Para cualquier otro tipo de estructura de suelo o pared, un profesional
debe instalar el mecanismo de la cama abatible.
• La elección de los tornillos de fijación depende del tipo de suelo y pared.
Utilice tornillos de fijación adecuados para el material del suelo y la pared.
•
Verifique la integridad estructural del suelo y la pared antes de la instalación.
• Nunca utilice anclajes de pared huecos.
• Utilice siempre 12 tornillos para la fijación al suelo y a la pared.
• Nunca retire los tornillos de fijación al suelo y a la pared sin antes
desmontar y retirar los cilindros de elevación y el armazón del colchón.
•
Sólo un profesional o persona cualificada debe desmontar esta cama abatible.
• Desmonte el producto en el orden inverso al del montaje inicial.
• Consulte el manual del propietario o descargue el manual en bestar.ca
o bestar.com.
122-00098-0
NOTICE
The label must be visible.
122-00098-0
WARNING
IMPACTorCRUSHINGHAZARD:Ifwallbedmechanismisnot
properlyattachedtothefloorandwall,itcansuddenlyrotate,
resultinginseriousinjuryordeath.
•Forwoodandmasonryfloorandwallstructure,aqualifiedperson
mustinstallthewallbedmechanism.
•Forallothertypeoffloororwallstructure,aprofessionalmustinstall
thewallbedmechanism.
•Thechoiceofattachmentscrewsdependsonfloorandwalltype.
Useattachmentscrewssuitableforyourfloorandwallmaterial.
•Verifystructuralintegrityoffloorandwallpriortoinstallation.
•NEVERusehollowwallanchors.
•ALWAYSuse12screwsforfloorandwallattachment.
•NEVERremovefloorandwallattachmentscrewswithoutfirst
disassemblingandremovingtheliftcylindersandmattressframe.
•Onlyaprofessionalorqualifiedpersonshoulddisassemblethiswallbed.
•Disassembleproductinreverseorderofinitialassembly.
•Refertoowner’smanualordownloadmanualatbestar.caorbestar.com
AVERTISSEMENT
RISQUEDECHOCouD’ÉCRASEMENT:
Silemécanismedulit
escamotablen’estpascorrectementfixéauplancheretaumur,il
peutsubitementpivoter,entraînantdesblessuresgravesoulamort.
•Pourlesstructuresdemursetdeplanchersenboisetenmaçonnerie,
unepersonnequalifiéedoitinstallerlemécanismedulitescamotable.
•Pourtoutautretypedestructuredemuretdeplancher,unprofessionnel
doitinstallerlemécanismedulitescamotable.
•Lechoixdevisdefixationdépenddutypedeplancheretdemur.
Utilisez
desvisdefixationadaptéesaumatériaudevotreplancheretdevotremur.
•Vérifiezl’intégritéstructuraleduplancheretdumuravantl’installation.
•N’utilisezJAMAISdechevillespourcloisonsèche.
•UtilisezTOUJOURS12vispourlafixationausoletaumur.
•NeretirezJAMAISlesvisdefixationausoletaumursansavoirpréa-
lablementdémontéetretirélesvérinsdelevageetlecadredumatelas.
•Seulunprofessionnelouunepersonnequalifiéedevraitdémonter
celitescamotable.
•
Consultezlemanueldupropriétaireoutéléchargezlemanuelsurbestar.ca.
ADVERTENCIA
PELIGRODEIMPACTOoAPLASTAMIENTO:
Sielmecanismode
lacamaabatiblenoestábienfijadoalsueloyalapared,puede
girarrepentinamenteyprovocarlesionesgravesolamuerte.
•Parasuelosyparedesdemaderaymampostería,unapersona
cualificadadebeinstalarelmecanismodelacamamural.
•Paracualquierotrotipodeestructuradesueloopared,unprofesional
debeinstalarelmecanismodelacamaabatible.
•Laeleccióndelostornillosdefijacióndependedeltipodesueloypared.
Utilicetornillosdefijaciónadecuadosparaelmaterialdelsueloylapared.
•
Verifiquelaintegridadestructuraldelsueloylaparedantesdelainstalación.
•Nuncautiliceanclajesdeparedhuecos.
•Utilicesiempre12tornillosparalafijaciónalsueloyalapared.
•Nuncaretirelostornillosdefijaciónalsueloyalaparedsinantes
desmontaryretirarloscilindrosdeelevaciónyelarmazóndelcolchón.
•
Sólounprofesionalopersonacualificadadebedesmontarestacamaabatible.
•Desmonteelproductoenelordeninversoaldelmontajeinicial.
•Consulteelmanualdelpropietarioodescargueelmanualenbestar.ca
obestar.com.
122-00098-0

26183-5 AN 15SERVICE: 1-888 8BESTAR (1-888 823-7827)
5
Important information to read before starting the assembly.
Keep this information for future reference.
WALL ANCHORING
REQUIREMENTS
& INSTALLATION RECOMMENDATIONS
IMPACT OR CRUSHING HAZARD: If bed is not
properly attached to the wall, it can suddenly fall,
resulting in serious injury or death.
•NEVER use hollow-wall or drywall anchors.
•NEVER attach wall bed directly to drywall, sheetrock,
gypsum, or other wall board.
•ALWAYS attach wall bed to wood stud, steel stud
or masonry wall structure.
•ALWAYS use two (2) screws for wall attachment.
WARNING
IMPACT OR CRUSHING HAZARD: If bed is not properly attached to the wall,
it can suddenly fall, resulting in serious injury or death.
•For wood or masonry wall structure, a qualified person must install the bed to the wall.
•For all other types, a construction professional must install the bed to the wall in compliance
with the codes and regulations in the province, state, or country where installed.
•The choice of wall attachment screw depends on wall type. Use wall attachment screws
suitable for your wall material.
•Verify structural integrity of floor and wall prior to installation.
•Do not open or use the bed if the bed cabinet moves while opening, or if you notice any other
signs of loose or detaching screws.
•Never remove wall attachment screws without first disassembling and removing the mattress
frame and lift cylinders.
•Qualified person must have the skills and tools necessary to locate wall studs, identify type
of wall structure (wood, metal, masonry or other) and install screws correctly to wall structure.
Skills and tools include electronic stud finder, drill motor and bits, screwdriver, and ability
to correctly use these tools.
WARNING

26183-5 AN 16SERVICE: 1-888 8BESTAR (1-888 823-7827)
VB-1134
4 in (102 mm)
1
2
3
Locate stud centerlines using electronic stud finder. Use pencil
to mark stud centerlines above the upper back of wall bed.
Drill a 1/8 in or 3 mm pilot hole into the wall stud to determine the type of wall
structure present.
WOOD found behind the wall board?
a. Use a 1/8 in drill for the pilot hole on part 71.
b. Use the wood stud mounting approach with the six #10 x 4 in VB-1134 screws provided.
VB-1134
4 in (102 mm)
4
CONCRETE found behind the wall board?
a. Use a 5/32 in masonry drill for the pilot hole on part 71 and for the wall.
b. Use the masonry wall structure mounting approach with the six #10 x 4 in VB-1134 screws provided.
WARNING
RISK OF SERIOUS INJURY or DEATH: improper assembly,
use, or loading can lead to product instability, tip-over,
or collapse.
• Assemble following all instructions using all indicated parts
and hardware.
• Attach cabinet to the wall (wood stud, metal stud, or masonry)
structure.
• Verify product is stable on its own.
• Do not allow children to stand, climb, or hang on furniture.
AVERTISSEMENT
RISQUE DE MORT ou DE BLESSURES GRAVES : Un assemblage,
une utilisation ou un chargement inappropriés peuvent entraîner
l’instabilité, le renversement ou l’eondrement du produit.
• Complétez l’assemblage en suivant toutes les instructions et en utilisant
toutes les pièces et le matériel indiqués.
• Fixez le caisson à la structure du mur (montants de bois, montants de métal
ou maçonnerie).
• Vérifiez que le produit est stable.
• Ne laissez pas des enfants grimper et se tenir debout sur le meuble,
ou s’y accrocher.
ADVERTENCIA
RIESGO DE LESIONES GRAVES o DE MUERTE: Un montaje,
uso o carga inadecuados pueden provocar la inestabilidad,
el vuelco o el colapso del producto.
• Ensamble siguiendo todas las instrucciones y utilizando todas las piezas
y herrajes indicados.
• Fije el armario a la estructura de la pared (montante de madera,
montante metálico o mampostería).
• Compruebe que el producto es estable por sí mismo.
• No permita que los niños se pongan de pie, trepen o se cuelguen
de los muebles.
122-00099-0
122-00099-0
WALL ANCHORING INSTRUCTIONS
ATTACHING THE CABINET TO THE WALL STRUCTURE
INSTALLATION RECOMMENDATIONS

26183-5 AN 17SERVICE: 1-888 8BESTAR (1-888 823-7827)
Wood studs
WALL COMPOSITION
ACCORDING TO YOUR WALL TYPE AND COMPOSITION, YOUR PROFESSIONAL INSTALLER SHOULD APPROVE
THE CHOICE OF ANCHOR SCREWS AND SELECT, IF REQUIRED, MORE APPROPRIATE ANCHORING DEVICES.
REQUIRED TOOLS
Stud finder
WALL ANCHORING INSTRUCTIONS
INSTALLATION RECOMMENDATIONS — WOOD STUDS
Included
HARDWARE INCLUDED
VB-1134 BT-1137
2 screws 1/4, 4 in (102 mm) Included
H206515
Wood drill bit
1/8 in (3 mm)
Diameter

26183-5 AN 18SERVICE: 1-888 8BESTAR (1-888 823-7827)
1Determine the position of the bed in the room.
3Locate and mark the positioning
of 2 studs using a stud finder.
5Line up back panel #71 on the wall and mark the middle of the studs on the back panel, then pre-drill
part #71 with 1 pilot hole of 1/8 in (3 mm) diameter per stud (2 holes in total).
DO NOT DRILL HOLES INTO THE WOOD STUDS.
2Move the bed if necessary, then remove
the floor trim completely.
4Put the bed back in its place. Level by adjusting
the legs PA-844 previously installed. If you install
the bed on a carpet, you must raise the bed by
an extra 3/8 in (10 mm).
71
71
1/8 in (3 mm)
1/8 in
(3 mm)
71
PA-844
WALL ANCHORING INSTRUCTIONS
INSTALLATION RECOMMENDATIONS — WOOD STUDS

26183-5 AN 19SERVICE: 1-888 8BESTAR (1-888 823-7827)
WALL ANCHORING INSTRUCTIONS
INSTALLATION RECOMMENDATIONS — WOOD STUDS
Put the VB-1134 screws through the holes of part #71 and screw into
the center of the studs until the plywood is tight against the wall.
USE AN ELECTRIC SCREWDRIVER WITH AN ADJUSTABLE TENSION CLUTCH
THAT HELPS PREVENT OVER-TIGHTENING AND STRIPPING.
6
Drywall Wood stud
VB-1134
71

26183-5 AN 20SERVICE: 1-888 8BESTAR (1-888 823-7827)
Masonry
WALL COMPOSITION
HARDWARE
REQUIRED TOOLS
Hammer drill
ACCORDING TO YOUR WALL TYPE AND COMPOSITION, YOUR PROFESSIONAL INSTALLER SHOULD APPROVE
THE CHOICE OF ANCHOR SCREWS AND SELECT, IF REQUIRED, MORE APPROPRIATE ANCHORING DEVICES.
WALL ANCHORING INSTRUCTIONS
INSTALLATION RECOMMENDATIONS — MASONRY
VB-1134
2 screws 1/4, 4 in (102 mm) Included
FO-1136
Masonry drill bit
3/16 in (4 mm)
Diameter
Included
H206515
Wood drill bit
1/8 in (3 mm)
Diameter
