Bestisan S6520H User manual

Please read all instructions before use for the best performance
of this product. Save these instructions for future reference.
Best Artisan & Better Than Most
(S6520H / S8520H / S9920H)
Quick Start

Box Contents
Mount Screws and
Wall Mount Brackets Wall mount template
Stereo RCA to
3.5mm audio cable Digital Optical cable Power Adapter
Sound Bar Remote Control Quick Start
LED Indicators and Button Introduction
LED Indicators
TREB-
MOVIE
BT OPT ARC
USB
RCA AUX
MUSIC DIALOG
TREB+ BASS+
BASS-
MUTE
VOL+
VOL-
RESET
Please read all instructions before use for the best performance
of this product. Save these instructions for future reference.
BestArtisan & Better Than Most
(S6520H / S8520H / S9920H)
Quick Start
Standby Bluetooth
Optical
ARC
AUXRCA USB

Right side of Sound Bar
Know Your Remote
Turns the power on or select the source
input mode(Bluetooth -> Optical -> RCA -> AUX
-> ARC -> USB), press and hold to power off.
Adjusts the volume, when adjusting, the
LED indicator flashes until the volume to
the MAX or MIN.
Pause and play, Press and hold to reset
treble and bass to factory settings.
M
MOVIE
TREB+
RESET
BASS+
BASS-TREB-
MUSIC DIALOG
ARC
MUTE
VOL+
VOL-
BT OPT
USB
RCA AUX
Power button
Volume up
Previous track
Play/pause
Movie mode
Dialogue mode
Increase or
decrease bass
Restore factory
settings
Increase or
decrease treble
Music mode
Optical mode
Next track
Volume down
Mute/Unmute
MUTE
VOL+ VOL-
RESET
OPT
MOVIE
DIALOG
MUSIC
BT
BASS+ BASS-
TREB+ TREB-
RCA RCA mode
ARC ARC mode
Bluetooth mode
USB USB mode
AUX AUX mode

Connection Diagram
Bluetooth Device
a
Bluetooth signal
up to 30 feet
USB Power
adapter
DCUSBRCA AUX
g
f
e
d
OPTICAL
b
BD / DVD / Set-top
box / Game console
TV
ARC
c
Bluetooth
a
High speed ARC cable (not supplied)
bDigital Optical cable (supplied)
c
Stereo RCA to 3.5mm
audio cable (supplied)
e
d
Power Adapter (supplied)
g
USB (not supplied)
f

Connecting with a TV
Setting “PCM” on your TV
When all cables are connected properly, and LED indicator
lights properly, if there is no sound from tv or Sound Bar, please
setting your tv as below:
DMethod 3. Connecting using an Optical cable. Select Optical
mode and set the TV’s audio output to “PCM”.
(More information on PCM page)
CMethod 2. Connecting using an High speed ARC cable. Select
ARC mode and set the TV’s audio output to “PCM”.
(More information on PCM page)
BA Method 1. Connecting using a Stereo RCA to 3.5mm audio
cable. Select RCA/AUX mode.
TV
DOptical digital
cable (supplied)
BStereo RCA to 3.5mm
audio cable (supplied)
AStereo RCA to 3.5mm
audio cable (supplied)
CHigh speed ARC
cable (not supplied)
ARCOPTICAL L - RCA - R AUX USB DC
Back of Sound Bar

Connecting a Bluetooth Device
1. Press "Menu" on the TV’s remote control.
2. Press the arrow keys on the remote to scroll to "Audio Settings."
3. Press "OK" on the remote control.
4. Scroll to "Advanced Audio" and press "OK". Some televisions may
not have an"Advanced Audio" menu and may list various audio
settings instead.
5. Scroll to "Audio Output Mode" or "Digital Audio Output Mode" and
press "OK".
6. Scroll until "PCM" is displayed as the current audio output.
7. Press "OK" to save the settings.
BT
or
b. Turn on Bluetooth on the Bluetooth device.
c. Select “S6520H or S8520H or S9920H” and connect it. When your
Bluetooth device is connected, the LED indicator blinks blue slowly.
d. Play music files from the device, connected via Bluetooth, through
the Sound Bar.
Bluetooth signal up to 30 feet
a. Press the “BT” button on the remote or press the “ ” button on
the right side of Sound Bar, the LED indicator blinks blue.

Installing the Wall Mount
1. Place the wall mount guide
against the wall surface. Push
a pencil tip to mark the four
bracket holes for supporting
screws, and then remove the
wall mount guide.
2. Using an appropriately sized
drill bit, drill a hole in the wall at
each marking. Push a screw
throught ench brackets, and then
screw each screw firmly into a
support screw hole.
3. Install the Sound Bar by hanging the bracket on the wall.
3 inches or more
TV
PencilPencil
The template must be level.
Leave 3 inches at least
between the template and TV.
screw
Bracket
screw
Bracket
Wall Mount Equipment

Troubleshooting
If you have a problem with your Sound Bar, there is quick simple
solution, first make sure:
The cables between Sound Bar and input devices are securely connected, the
power adapter is also connected to a working power source.
The adapter LED indicator is lighting, and the LED indicator is lighting in the
middle of Sound bar.
No sound or crackling noise
Check if all cables are connected properly.
Press Mute on the remote to ensure the Sound Bar is not muted.
Press Volume+ on the remote or the right side of your Sound Bar.
Remote isn’t working
Check if the battery is installed properly with power.
I hear buzzing or humming
Ensure all cables and wires are securely connected.
Connect a different source device (TV, Blu-ray player, etc) to see if the buzzing
persists. If it does not, the problem may be with the original device.
Connect your device to a different input on the Sound Bar.
Check if the signal of the receiver is covered by something.
Contact your retailer for assistance.
Make sure you have selected the right input source on your remote, and the
LED is lighting accordingly.
If using Bluetooth, check if the sound on your device is under minimum volume.
If using Optical, check if your device (TV/Cable Box/Projector/etc.) audio output
set to PCM or turn the Dolby/dts off.
When using cable connection, make sure your device has audio output port
(not input).

Bluetooth can’t be connected
Check if the Sound Bar is connected with the third Bluetooth device.
Hear echo when watching TV
Setting your TV audio to External Speaker.
Mute the TV speaker.
Be sure that there are no solid obstructions between the Sound Bar and source
device.(within 30 feet)
Reboot the Bluetooth and connect again.
Have other questions?
Please contact with your retailer for assistance.

Best Artisan Corp.
Best Artisan & Better Than Most
801 DUPONT AVE SUITE F & G, ONTARIO, CA, 91761.
ser[email protected]
Thanks for reading!
