dB Technologies DVA K5 Manual

www.dbtechnologies.com [e-mail]
DVA K5 Rev 1.1 cod. 4201202 2Q
Quick start user manual
Section 1
The warnings in this manual must be observed together with the "User Manual - Section 2".
Le avvertenze nel presente manuale devono essere osservate congiuntamente al MANUALE D’USO - Sezione2”.
Die Warnungen in diesem Handbuch müssen in Verbindung mit der "BEDIENUNGSANLEITUNG - Abschnitt 2" beobachtet
werden”.
Les avertissements specifiés dans ce manuel doivent être respectés ainsi que les "CARACTERISTIQUES TECHNIQUES -
Section 2"
A.E.B. Industriale Srl Via Brodolini, 8 Località Crespellano 40053 VALSAM GGIA B L GNA (ITALIA) Tel +39
051 969870 Fax [phone] www.dbtechnologies.com [e-mail]

www.dbtechnologies.com [e-mail]
DVA K5 Rev 1.1 cod. 4201202 2Q
Thank you for choosing a dBTechnologies Product!
DVA K5 is a 3-way active line array module, equipped with: two 1” compression driver exit (1.4” voice coil), one 6.5”
neodymium midrange (2” voice coil) and one 8” neodymium woofer (2.5” voice coil).
The powerful DIGIPR ® G3 amplifier section, capable of handling up to 500 W (RMS power), is controlled by a DSP,
which can perform a detailed customization of the output sound of the speaker. In particular, thanks to the new
dual rotary encoder interface, it is possible to quickly tune the line-array configuration coverage, using the FIR filter
technology.
Check the site www.dbtechnologies.com for the complete user manual!
1) Unpacking
The box contains:
N°1 DVA K5
N°1 100-120 V FUSE
This quick start and warranty documentation
2) Easy installation
DVA K5 can be installed in different configurations.
For a quick installation, in each side (left and right) of
the speaker you can find:
Movable bracket for front mounting (A)
Movable bracket for rear mounting, with splay
angles references for line-array setup (B)
Pin locks for a quick installation (C)
These brackets and pins are used to mount DVA K5
speakers each other in line-array configurations, and
to mount them with accessories (not included) for
different installation needs.
For each configuration choice, please consider the
main acoustic coverage (HxV) of one DVA K5 here
shown: 100°x15°.
Four examples of DVA K5 line-array configurations
(with optional accessories not included) are:
For further information about accessories and
configurations, download the complete user manual:
www.dbtechnologies.com/EN/Downloads.aspx or scan
the QR code.
Flown: K5, DRK 10 (DRK 20)
Fly Bar
Flown: K5, DVA KS10
subwoofer, DRK 10 (DRK20)
Fly Bar, SRK-10 k t
Stacked: K5, DVA KS10
subwoofer, SRK-10 k t
Stacked: K5, DVA KS20
subwoofer, DRK20 (drk10) Fly
Bar

www.dbtechnologies.com [e-mail]
DVA K5 Rev 1.1 cod. 4201202 2Q
First switch on for line-array setup:
The DIGIPR G3® amplifier of DVA K5 is controlled
by a powerful DSP. All the connections and controls
are in the rear amplifier control panel:
1 – Mains Fuse
2 – Auto-range mains input
3 – Mains (power) link output
4 – Balanced audio input
5 – Link audio output
6 – Service data mini B-type USB port
7 – DSP preset BCD rotary switches
8 – Audio input sensitivity rotary switch
9 – LEDs (Limiter, Signal, Mute/Prot, Ready)
WARNING
The fuse is factory setted for 220-240 V operation.
If it is necessary to change the fuse to 100-120V range:
1. Disconnect the speaker from any ca le
2. Wait 5 minutes
3. Su stitute the fuse with the correct one supplied
Use only ca les with Neutrik® connectors!
a) nce you have properly set up the desired line-
array configuration (see also the DVA K5 complete user
manual and accessories instructions for further
information), connect the audio input (4). Connect the
useful link output (5) to other DVA K5 modules, for the
audio connection of all the line-array elements. Set the
audio input sensitivity (8) of DVA K5 to 0 dB.
b) Check the rear panel reference label for a
proper DSP regulation. In this label you can find the
suggested position of rotary switches (7) for each type
of installation (Speakers Coupling positions and High
Frequency Compensation). These settings are the main
acoustic corrections to create the best coupling
between the elements of your line-array, in order to
obtain the best coverage conditions.
c) Connect the power link (3) to other DVA K5
modules, to link the power supply between all the
elements of your array. Please note that the maximum
linkable rated power and current depends on the first
module connection conditions.
d) Connect the power supply (2) to the first
module. The related “Ready” LED (9) turns on,
signaling the proper power connection. Turn the audio
input sensitivity (8) to the desired level. The “Signal”
LED (9) start blinking at the presence of audio signal
(greater than -20dBu). Avoid audio distortion
conditions, potentially signaled by the “Limiter” LED
(9).
For further information, download the complete user
manual: www.dbtechnologies.com/EN/Downloads.aspx
or scan the QR code.

www.dbtechnologies.com [e-mail]
DVA K5 Rev 1.1 cod. 4201202 2Q
Technical Data
Speaker Type: 3-way Active line-array element
Acoustical data
Frequency Response [-3dB]: 70 – 19000 Hz
Max SPL: 129 dB
HF compression driver: (2x) 1" Exit
HF voice coil: (2x) 1.4”
MF: 6.5”, Neodymium
MF Voice Coil: 2”
LF: 8”, Neodymium
LF Voice Coil: 2.5”
Crossover frequencies: 340 Hz (L/M), 1800 Hz (M/H)
FIR filters: yes
Coverage (HxV): 100° x 15° (single unit)
Amplifier
Amp Technology: Digipro® G3
Amp Class: Class-D
RMS Power: 500 W
Peak Power: 1000 W
Processor
Controller: DSP, 28/56 bit 48 kHz
Limiter: Peak, Thermal
Controls: Rotary audio input sensitivity
Rotary presets: 2 Rotary BCD 8 positions for line-array
configuration (Speaker Coupling, High Frequency
Compensation)
Input
Mains connections: PowerCON ® In/link
Signal Input: (Balanced) 1x IN
Signal Out: (Balanced) 1 x XLR link OUT
USB connector: mini USB B-type (for SERVICE DATA)
Mechanics
Housing: Polypropylene PP metal reinforced
Grille: CNC Metal grille black painted
Rigging points: Integrated rigging hardware
Width: 580 mm (23.2 in)
Height: 240 mm (9.6 in)
Depth: 327 mm (13.08 in)
Weight: 14.2 kg (31.3 lbs.)
Download the complete user manual on:
www.dbtechnologies.com/EN/Downloads.aspx
EMI CLASSIFICATION
According to the standards EN 55103 this equipment is designed and suitable to operate in E3 (or lower E2, E1) Electromagnetic environments.
FCC CLASS B STATEMENT ACCORDING TO TITLE 47, PART 15, SUBPART B, §15.105
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against harmful interference in a residential installation.
This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may
cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference
to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
1. Reorient or relocate the receiving antenna.
2. Increase the separation between the equipment and receiver.
3. Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
4. Consult the dealer or an experienced radio/TV technician for help.
WARNING: Make sure that the loudspeaker is securely installed in a stable position to avoid any injuries or damages to persons or properties.
For safety reasons do not place one loudspeaker on top of another without proper fastening systems. Before hanging the loudspeaker check
all the components for damages, deformations, missing or damaged parts that may compromise safety during installation. If you use the
loudspeakers outdoor avoid spots exposed to bad weather conditions.
Contact dB Technologies for accessories to be used with speakers. dBTechnologies will not accept any responsibility for damages caused by
inappropriate accessories or additional devices.
Features, specification and appearance of products are su ject to change without notice.
dBTechnologies reserves the right to make changes or improvements in design or manufacturing without assuming any o ligation to change
or improve products previously manufactured.
