Heavy Duty Floor Machines
Operator’s Manual
©Betco Corporation. All Rights Reserved • 1001 Brown Avenue • P.O. Box 3127 • Toledo, Ohio 43607-0127 • 800-777-9343 • www.betco.com
CREWMAN™20 HD Item #83014-00
CREWMAN™17 HD Item #83013-00
FOREMAN™ 20 HD Item #85021-00
FOREMAN™ 17 HD Item #85028-00
FOREMAN™20 DS Item #83010-00
FOREMAN™17 DS Item #83009-00

Specifications
•Cleaning Path/Pad Size: 17”, 20”
•Hour Meter: Yes / 0.1 hour resolution
•Motor: 1.5 hp, 120v, 12 A, 60 HZ
•Pad Speed: 175 RPM
•Power Cord: 50’ 14/3 Safety Yellow
•Handle Grips: Anti-Fatigue
•Operating Wheels: 5” Non-marking
•Productivity: Bonnet-1100 sq.ft/hr., buff/scrub-2400 sq.ft/hr., strip-800
sq.ft/hr.
•Weight: 90 lbs.
•Dimensions: Length 24.25”, Width 20”, Height 48”
! WARNING! IMPORTANT SAFETY INSTRUCTIONS
Carefully read and understand this manual before operating this machine.
To reduce risk of fire, electric shock, or injury:
•Do not operate in explosive areas, near flammable liquids or gases.
•Only plug into a properly grounded outlet.
•Do not exposure to rain, store indoors.
•Do not plug in or handle machine with wet hands.
•Do not operate the machine with a damaged cord or plug.
•Do not block or disconnect safety lever.
•Do not leave machine plugged in while unattended.
•Unplug machine before servicing.
•Do not put fingers under the pad or pad holder.
•Unplug the machine before installing or removing the pad.
•Use only high speed burnishing pads.
•Do not put any foreign object into openings. Do not use with any opening
blocked; keep free of dust, lint, hair, & anything that may reduce airflow.
•Keep hair, loose clothing, fingers, & all parts of body away from openings
& moving parts.
•Turn off all controls before unplugging.
•Do not use in or around flammable or combustible liquids such as gasoline
or use in areas where they may be present.
•Connect to a properly grounded outlet only. See grounding instructions.
Betco, Corp. 8/27/2007 Page 3 Floor Machine

Grounding Instructions
This machine must be grounded. If it should electrically malfunction, grounding
provides a path of least resistance for electric current to reduce the risk of electric
shock. This machine is equipped with a cord having an equipment-grounding
conductor & grounding plug. The plug must be plugged into an appropriate outlet
that is properly installed & grounded in accordance with all local codes &
ordinances.
! DANGER!
Improper connection of the equipment-grounding conductor can result in a risk of
electric shock. Check with a qualified electrician or service person if you are in
doubt as to whether the outlet is properly grounded. Do not modify the plug
provided with the machine. If plug will not fit the outlet, have a proper outlet
installed by a qualified electrician.
Replace the plug if the grounding pin is damaged or broken.
Extension cords connected to this machine should be 12 gauge, 3-wire cords
with 3-prong plugs & outlets. DO NOT use extension cords more than 50 feet
long.
Betco, Corp. 8/27/2007 Page 4 Floor Machine

Operating Instructions
Check machine for damage to cord or plug.
Use suitable pads or brushes.
To install or change the pad:
1. Unplug the machine.
2. Tip the machine back on the wheels.
3. Install pad driver or brush.
4. Center the pad on the pad driver.
To operate the machine:
1. Plug into a grounded outlet.
2. Release the handle and lower it.
3. The handle can be locked into a comfortable position for the operator or used
free floating.
4. Press the safety lever and squeeze the trigger to start the machine.
5. Do not operate in one place as damage to the floor or finish could result.
6. Do not operate the machine with the handle in the upright position.
7. Remove the pad after every use.
8. Store the machine tilted back on the transport wheels.
9. Use only new or clean pads and reverse them as needed.
Maintenance Instructions
To maintain appearance – wipe the machine with a damp cloth after use.
Warning – Unplug the machine before servicing
This machine is equipped with an hour meter to signal maintenance intervals of
250 hours. It will begin flashing at 245 hrs and stop at 255 hrs to signal the
operator to check the following:
1. Check the motor brushes for wear or excessive arcing.
2. Check the cord and electrical system.
3. Check the safety lockout on the trigger.
4. Check wheels.
Betco, Corp. 8/27/2007 Page 5 Floor Machine

10
16
9
18
13
16
10
15
14
8
1
7
6
7
6
1
3
5
42
30
23
31
34
31
25
24
26
33
28
27
32
29
22
31
35
38
20
21
36
39
35
11
12
INSIDE
TUBE
INSIDE
TUBE
THESE
PARTS
INSIDE
TUBE
INSIDE
BASE
INSIDE
CORD
HOOK
INSIDE
HANDLE
CAM
LOCK
HANDLE PARTS
19
17
40
41
42
ROD THROUGH BASE
Betco, Corp. 8/27/2007 Page 6 Floor Machine

ITEM NO. BETCO PART # DESCRIPTION QTY.
1 E283523 NYLON CABLE TIE 2
2 E283132 CORD, HANDLE, 14-3 1
3 E283789 NUT, ELECTRICAL CONDUIT, 1/2" 1
4 E283131 CORD, 75 FEET, 14-3 ST 1
5 E283496 STRAIN RELIEF FOR REPLACEMENT 1
6 E281064 BOLT, HEX, 1/4-20 x 3/4 2
7 E283520 NUT, NYLOCK, 1/4-20 2
8 E283127 GRIP 2
9 E283427 SCREW, PHILLIPS, No. 6 x 1 2
10 E283426 SCREW, PHILLIPS, 1/4-20 x 1.75 4
11 E283130 SPRING 1
12 E283270 CLIP, SPRING 1
13 E285032 SWITCH 1
14 E283129 SAFETY LOCK 1
15 E282752 TRIGGER, SWITCH 1
16 E283325 COVER, SWITCH BOX 1
17 E283125 SWITCH BOX, HANDLE, DUAL SPEED 1
18 E281105 PLATE, SWITCH 1
19 E283451 HANDLE TUBE, 7/8 x 16 1
20 E281065 BOLT, HEX, 1/4-20 x 1-3/4, GRADE 5 1
21 E281070 NUT, NYLOCK, 1/4-20 1
22 E283519 GROMMET, .375 ID 1
23 E283137 CORD HOOK 1
24 E283134 BOLT, ADJUSTABLE, CAM, 5/16-18 1
25 E283135 OVAL WASHER 1
26 E283266 PIN, .25 x .75 1
27 E283268 CAP, PUSH, .25 1
28 E283133 HANDLE, CAM LOCK 1
29 E281379 WASHER, SPRING, 3/8 1
30 E281063 NUT, NYLOK, 5/16-18 2
31 E283145 WASHER, NYLON 5
32 E281077 BOLT, SHOULDER, 3/8 x 1 1
33 E283267 WASHER, SPRING, 1/4 1
34 E283269 WASHER, SPRING, 1/2 1
35 E283143 CAPS, AXLE, 0.5 2
36 E282729 HANDLE ATTACHMENT, WELDED "T" 1
37 E283136 BRACKET, FLAT, HANDLE 1
38 E283711 HANDLE TUBE 1
39 E283452 AXLE, 1/2 x 12.375 1
40 E283662
SPEED CONTROL, DUAL SPEED MACHINE
1
41 E283652 HEAT SINK ROD 1
42 E283608 SWITCH, ROCKER, 2 SPEED 1
HANDLE PARTS
NOTE:
DUAL SPEED FLOOR MACHINE HAS ALL PARTS LISTED.
SINGLE SPEED MACHINE DOES NOT HAVE PARTS 40, 41, AND 42.
Betco, Corp. 8/27/2007 Page 7 Floor Machine

BASE, MOTOR, AND WHEELS
8
1
OR 18B
12
910
11
5
6
13
7
OR 17B
15
14
16
3
4
2
17
18
Betco, Corp. 8/27/2007 Page 8 Floor Machine

ITEM NO. BETCO PART # DESCRIPTION QTY.
1 E283147 HOUR METER 1
2 E283570 SCREW, PHILLIPS, 1/4-20 x 1 4
3 E489334 WASHER, FLAT, 1/4 4
4 E281078 WASHER, LOCK, 1/4 4
5 E281068 WASHER, FENDER, 1/4 2
6 E283425 SCREW, PHILLIPS, 1/4-20 x 1 2
7 E283141 BUMPER 1
8 E281397 COVER, MOTOR, BURGANDY, LOW SPEED 1
9 E283144 WHEEL, 5 INCH 2
10 E283145 WASHER, NYLON 2
11 E283269 WASHER, SPRING, 1/2 2
12 E283143 CAPS, AXLE, 0.5 2
13 E283379 AXLE, 1/2 x 13.875 1
14 E281067 WASHER, LOCK, 5/16 4
15 E281062 WASHER, FLAT, USS, 5/16 4
16 E283641 BOLT, HEX, 5/16-18 x 1.5 4
17 E281129 BASE, 20 INCH, LOW SPEED 1
18 E283191 MOTOR, 1.5 HP, AC 1
17B E281127 BASE, 17 INCH, LOW SPEED 1
18B E281106 MOTOR, 1.5 HP, DUAL SPEED 1
BASE, MOTOR, AND WHEELS
Betco, Corp. 8/27/2007 Page 9 Floor Machine
