Beyerdynamic TG-X 60 Installation and operation manual

APPLICATIONS
The TG-X 60/61 is designed for close miking vocals especially
in Pop, Soul and Jazz. Due to the proximity effect and the
strong bass accentuation the TG-X 60/61 features a powerful
yet soft and transparent sound in the highs. The hypercardioid
polar pattern ensures a very high gain before feedback.
The TG-X 60/61 can be used as handheld or on a stand
with the supplied microphone clamp.
FEATURES
• Hypercardioid polar pattern
• High volume before feedback
• Vocal tailored frequency response
• Rugged construction to withstand touring damage
• Shock absorbing rubber ring
• Structure borne noise attenuation
• TG-X 61 switched version
SUPPLIED ACCESSORIES
MKV 8 Microphone clamp with 3/8" internal thread,
for shaft diameters of 22 - 32 mm. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Order # 407.216
OPTIONAL ACCESSORIES
BMC 05 FM BK Standard XLR-XLR microphone cable, length 5 m . . . . . . . . . . . . . . . . . . . . . . . . Order # 434.787
BMC 10 FM BK Standard XLR-XLR microphone cable, length 10 m . . . . . . . . . . . . . . . . . . . . . . . Order # 434.795
GST 500 Microphone stand, 3/8", height 0.85 - 1.60 m, with telescopic G 500 boom . . . Order # 406.252
PS 60/80 Popscreen, charcoal-grey . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Order # 437.980
VERSIONS
TGX 60 Dynamic microphone, hypercardioid . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Order # 436.283
TGX 61 same as above, but with ON/OFF switch. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Order # 436.321
TG-X 60
Dynamic Microphone
Germany
Theresienstr. 8
D-74072 Heilbronn
Tel. [phone] / 6 17-0
Fax [phone] / 617-224
E-mail: [email protected]
Internet: www.beyerdynamic.de
United States
56 Central Ave.
Farmingdale, NY 11735
Tel. [phone]
Fax [phone]
E-mail: [email protected]
Internet: www.beyerdynamic.com
Great Britain
17 Albert Drive
Burgess Hill RH15 9TN
Tel. [phone] / 258 258
Fax [phone] / 258 444
E-mail: [email protected]
Internet: www.beyerdynamic.co.uk

FREQUENCY RESPONSE & POLAR PATTERN
This polar pattern and frequency response curve (measuring distance ± 2.5 dB) correspond to a typical production
sample for this microphone.
WIRING DIAGRAMS
Positive pressure produces positive voltage on
red lead (+).
Photos are non-contractual. Contents subject to change without notice.
Frequency response ± 2.5 dB 0 dB 3 mV/Pa TG-X 60
=
^
TECHNICAL SPECIFICATIONS
Transducer type . . . . . . . . . . . . . . . . . . . . . . Dynamic
Operating principle . . . . . . . . . . . . . . . . . . . Pressure gradient
Frequency response
Close miking . . . . . . . . . . . . . . . . . . . . . . 25 - 18,000 Hz
Distant miking . . . . . . . . . . . . . . . . . . . . 90 - 16,000 Hz (measured at 1 metre)
Polar pattern . . . . . . . . . . . . . . . . . . . . . . . . Hypercardioid
Rear attenuation at 1 kHz . . . . . . . . . . . . . > 25 dB at 110°
Open circuit voltage
at 1 kHz (0 dB = 1V/Pa) . . . . . . . . . . . . . . . . 3.0 mV/Pa ± 1.5 dB = -50 dBV
Magnetic field suppression. . . . . . . . . . . . . > 20 dB at 50 Hz
Nominal output impedance . . . . . . . . . . . . 280 Ω
Load impedance . . . . . . . . . . . . . . . . . . . . . ≥1000 Ω
Diaphragm . . . . . . . . . . . . . . . . . . . . . . . . . . Macrolon®
Case/finish. . . . . . . . . . . . . . . . . . . . . . . . . . . Die casting, non-glare black mat
Connection . . . . . . . . . . . . . . . . . . . . . . . . . . 3-pin XLR male
Dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . Length: 205 mm
Head diameter: 50 mm
Weight without cable . . . . . . . . . . . . . . . . . 345 g
TG-X 60
TG-X 61
