Bhaptics Tactot DK1 User manual

1x Tactot
2x Micro USB cable
1x Bluetooth dongle
1x Manual
1. LED Status Indicator
2. Battery Connection port
3. On/Off Switch
4. Tactot Vest
5. Vibro-tactile Motors
* External Battery Optional
Unboxing
Getting started -bhaptics player
box contents
Downloads for the Bhaptics Player software are available
on our website, www.bhaptics.com.
Downloading software
Turning Tactot on/off
After connecting the battery and device, press the power
button on the battery to turn the device on. The device will
turn off automatically when it is left unconnected for 2 mins.
Pairing and Unparing
With the PC’s bluetooth turned on (and if needed, with the
dongle plugged in), find Tactot on the Player’s interface.
Right click and find your device name on the ‘pair’ tab.
Once paired, the device will buzz to notify you it is ready.
When the device is connected and not in use, the device
will buzz every 100 secs to notify you. If a device had been
paired once, it will connect automatically when turned on.
To unpair, right click the paired device and find the ‘unpair’
button.
Using the 2 micro USB cable
found in the box, connect both
to the battery and the device.
Once connected, make sure
the device is inserted back
into its pocket like the image.
LED Indication
Connecting device
Tactot is a wireless vest for full torso haptic feedback. Using a
total of 40 discontinuous placement of vibro-tactile motors, 20
in the front and 20 in the back, it creates a continuous form of
tactile sensation around the body. It aims to enhance users’
experience in an audio-visually immersive environment.
Bhaptics Player is an desktop software, for
the optimization and control of your experience with Tactot.
Acting as a link between the device, application and the
Bhaptics Designer, it controls bluetooth connections, device
settings and more.
about tactot
wearable haptic vest
.DK1
1
4
5
connecting battery
specifications
Model
Size
Weight
Connection
Tactot DK1 BHTTT0000
26 - 48 inch (body circumference)
1.6 kg (including battery)
Bluetooth low energy technology
Waiting for connection
blink
Connected to PC
2
3
*
unpair all
ping all
Pair TactotV2.4
TactotV2.1

When an update is available, notification will pop up on the
settings button. The update will be found in the settings tab.
Keep the firmware updated to its latest version. For more
information visit our site.
Path Mode
Draw lines within the dotted
section to create continuous
haptic feedback.
The draw function can be found in the settings tab.
Dot Mode
Select specific vibro-tactile
motors to activate.
testing haptic feedback
Firmware update
wearing device
putting on tactot
Size control
Undo the velcro body straps and put on and zip up the tactot like
you would wear a vest. Pull straps tightly to fit, then secure along
the velcro guide towards the center of the body.
To account for larger fit,
unravel the end of the
velcro strap to fit your size.
For smaller size, roll up the
end of the velcro strap.
Washing
To wash, remove and machine
wash the detachable inner sleeve.
When dry, reattach the inner sleeve,
following the velcro guides.
Getting started -bhaptics designer
Bhaptics designer is a web based application for
creating and editing your own haptic feedback for Tactot. Visit our
website, www.bhaptics.com, for further information.
Bhaptics Plugin
We support plugins for Unity3D and Unreal
Engine, which can be found in the Asset
Store and Marketplace. When using, please
keep to the plugin manual. And for the other
SDKs, please contact us.
Precautions
Before using the tactot, please read this manual carefully.
Safety and Warnings
* Keep this product out of reach of small childrens.
* Do not fasten the body straps excessively.
* Never disassemble or modify the product.
* Do not expose Tactot to extreme weather conditions.
Care and Handling
* Do not throw, drop, or expose the device to physical impact.
* Keep Tactot away from liquids, it is not water-resistant.
* Do not store tactosy in extreme cold or hot areas.
* Do not use chemicals or cleaning solvents on the device.
Contact our email for customer support.
“ [email protected] ”
!

FCC Information to User
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant
to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that interference will not occur in
a particular installation. If this equipment does cause harmful interference to radio or television reception,
which can be determined by turning the equipment off and on, the user is encouraged to try to correct
the interference by one of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is con-nected.
• Consult the dealer or an experienced radio/TV technician for help.
Caution
Modifications not expressly approved by the party responsible for compliance could void the user’s
authority to operate the equipment.
FCC Compliance Information : This device complies with Part 15 of the FCC Rules. Operation is
subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this
device must accept any interference received, including interference that may cause undesired
operation
