PCT Brands Lyrix Remixx User manual

FCC Compliance
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device
may not cause harmful interference, and (2) this device must accept any interference received, including interference that
may cause undesired operation.
Note 1: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15
of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate frequency energy and, if not installed and used in accor-
dance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures: a) Reorient or relocate the receiving antenna b) Increase the
separation between the equipment and receiver c) Connect the equipment into an outlet different from that to which the
receiver is connected d) Consult the dealer or an experienced radio/TV technician for help.
Note 2: Any changes or modifications to this unit not expressly approved by the party responsible for compliance could void
the user’s authority to operate the equipment.
One (1) Year Limited Warranty
PCT Brands, LLC warrants this product to be free from defects in materials and workmanship. This warranty covers the
original purchaser only, and is not transferable to anyone who subsequently buys, leases, or otherwise obtains from you.
Your One Year Limited Warranty begins on the date of purchase. Your original purchase invoice or sales receipt, showing
date of purchase, is your proof of warranty period. The duration of this warranty does not extend beyond the initial period
of coverage should any repairs or replacements be made or performed.
This warranty does not extend to any product not purchased from PCT Brands, LLC, or an authorized PCT Brands, LLC
reseller. This warranty does not extend to product that has been damaged or rendered defective as a result of use for
which the product is not intended, is contrary to instructions provided in the user manual, as a result of the use of parts
not manufactured or sold by PCT Brands, LLC, or due to any misuse, abuse, negligence, modification, or improper packing
when returning product to PCT Brands, LLC.
EXCEPT FOR THE WARRANTY SET FORTH HEREIN, PCT BRANDS, LLC DISCLAIMS ALL OTHER WARRANTIES, EXPRESSED OR
IMPLIED OR STATUTORY, INCLUDING BUT NOT LIMITED TO THE IMPLIED WARRANTIES OF MERCHANTABILITY OR FITNESS
FOR A PARTICULAR PURPOSE. ANY IMPLIED WARRANTIES THAT MAY BE IMPOSED BY APPLICABLE LAW ARE LIMITED TO
THE TERM OF THIS WARRANTY. IN NO EVENT SHALL PCT BRANDS, LLC BE LIABLE FOR ANY INCIDENTAL, SPECIAL OR
CONSEQUENTIAL DAMAGES, INCLUDING BUT NOT LIMITED TO LOSS OF BUSINESS, PROFITS, DATA OR USE, WHETHER IN
AN ACTION IN CONTRACT OR TORT OR BASED ON A WARRANTY, ARISING OUT OF OR IN CONNECTION WITH THE USE OR
PERFORMANCE OF THE PRODUCT. YOU AGREE THAT REPAIR, AND (UPON AVAILABILITY) REPLACEMENT, AS APPLICABLE,
UNDER THE WARRANTY SERVICESDESCRIBED HEREIN IS YOUR SOLE AND EXCLUSIVE REMEDY WITH RESPECT TO ANY
BREACH OF THE PCT BRANDS, LLC LIMITED WARRANTY SET FORTH HEREIN. THIS WARRANTY GIVES YOU SPECIFIC LEGAL
RIGHTS AND YOU MAY ALSO HAVE OTHER RIGHTS WHICH VARY FROM STATE TO STATE.
How Do I Obtain Warranty Service?
For warranty service, please email PCT Brands, LLC at [email protected] or call [phone] to report a
claim, at which time PCT Brands, LLC technicians will attempt to solve any issues. If unable to resolve your issue, you will
be issued an RMA to authorize the return of the item for repair/replacement. All charges incurred while returning product,
including postage, duties, export taxes, and customs duties, are the responsibility of purchaser, and purchaser assumes all
risk of loss during shipment. For more information visit www.pctbrands.com
PCT Brands, LLC, 3720 Lapeer Rd.,
Auburn Hills, MI 48326 • www.pctbrands.com • Made in China.
PCT Brands, the PCT Brands logo, Lyrix, the Lyrix logo, Remixx, and the Remixx logo are trademarks or registered trademarks of PCT
Brands, LLC. © 2016 PCT Brands, LLC. All rights reserved. Bluetooth and the Bluetooth logo are registered trademarks of Bluetooth
SIG, Inc. Remixx _MAN_6/16
Buttons on Top
of Remixx
Back of
Remixx
Red & Blue LED
Indicators
(Hidden Unless Lit)
Volume Up and Next Song
Play/Pause/Phone
Volume Down and
Previous Song
On/Off Switch
Micro-USB Charging Port
3.5mm Audio-In Port
Package Contents
Lyrix Remixx
Bluetooth
Speaker
USB to Micro-USB
Charging Cable
3.5mm
Audio Cable
User
Guide
Specifications:
• Two-Channel Stereo
• 3D Surround Effect
• Speaker Size: 40mm
• Bluetooth V3.0
• Range: 33’
• Output Power: 3W x 2
• Impedance: 4Ω
• Frequency Response: 90Hz
to 18KHz
• THD: < 0.5% (1Khz/1W)
• SNR: >96db
• Playing Time: Up to 8 Hours
• Charging Time: 3 hours
• Battery: 1200mAh Lithium
Technical Support
Email: [email protected]
Phone: [phone]:30am-5:30pm EST, M-F

Before First Use
Your Lyrix Remixx comes from the factory with a charge and
can be used right out of the box. However, it is best to make
sure that the unit is fully charged before first use.
Charging the Lyrix Remixx
To charge the Lyrix Remixx, insert the Micro USB end of the
included USB to Micro-USB Charging Cable into the Mi-
cro-USB Charging Port on the back of your Remixx and the
other end into a USB Port on your computer or a USB-enabled
wall adapter. The red LED Indicator will glow while the unit is
charging and shut off when the unit is fully charged.
Pairing the Lyrix Remixx with a Smartphone
Move the On/Off Switch on the back of the Remixx to the “ON”
position. The unit will say “Hello,” the blue LED Indicator will
blink to show that it is in pairing mode, and the unit will say
“Pairing.” Activate the Bluetooth function on your Smartphone
and select “Remixx” from the list of available devices. The
Remixx will say “Your phone is connected” and the Blue LED
Indicator will glow steadily when pairing is successful.
If you turn your Lyrix Remixx off and then turn it back on at a
later time, it should automatically re-pair with your smartphone.
The unit will say “Hello,” the blue LED Indicator will blink to
show that it is in pairing mode, and the unit will say “Pair-
ing.” The Remixx will say “Your phone is connected,” and the
Blue LED Indicator will glow steadily to show your Remixx has
successfully re-paired with your Smartphone.
If you unpair your smartphone with the Lyrix Remixx, the Re-
mixx will say “Your phone is disconnected.”
Playing Music
Once you have paired your Smartphone with your Lyrix Re-
mixx, start the music playing on your Smartphone. If the music
does not start playing through your Lyrix Remixx, press the
Play/Pause/Phone Button on the Remixx. The Blue LED Indica-
tor slowly blinks on and off while music is playing.
• To pause music, press the Play/Pause/Phone Button.
• To turn the volume up, press and hold the Volume Up/Next
Song Button. You will hear a beep when maximum volume
is reached.
• To turn the volume down, press and hold the Volume
Down/Previous Song Button.
• To skip to the next song, press and release the Volume Up/
Next Song Button.
• To skip back to the beginning of the song that is playing,
press and release the Volume Down/Previous Song Button.
To skip back to the previous song, press and release the
Volume Down/Previous Song Button a second time.
• When you are done playing music, slide the On/Off Switch
to the “OFF” position to conserve battery power.
Answering an Incoming Phone Call
If your smartphone receives an incoming call during music
playback, the music will stop and your Lyrix Remixx will emit a
10-note chime. Press the Play/Pause/Phone Button to answer
the call. Press the Play/Pause/Phone Button again to end the call
and resume playing music.
Connecting Your Lyrix Remixx to a Non-Bluetooth Device
Plug one end of the included 3.5mm Audio Cable into the
3.5mm Audio In Port on your Lyrix Remixx. Plug the other end
of the cable into your non-Bluetooth device. Move the On/Off
Switch on the Remixx to the “ON” position. Sart the music
playing on the connected device.
Troubleshooting
The Lyrix Remixx should work well within the effective range
of 33 feet. If it does not, please try the following:
• Make sure that your Lyrix Remixx is charged up and turned on.
• Make sure that the smartphone with which you want to pair
has Bluetooth turned and is within 30 feet.
•Move your Lyrix Remixx and/or smartphone away from
sources of electromagnetic interference such as cordless
phones, microwave ovens, wireless network routers, or
other Bluetooth devices.
• If you have difficulty connecting your smartphone with your
Lyrix Remixx after it has been paired with your device, de-
lete it from your smartphone and re-pair.
• If you have too many Bluetooth devices listed under “De-
vices,” the pairing process may take longer or be unsuc-
cessful. Delete one or more devices to improve pairing
performance.
Caution
• Contains no user-serviceable parts. Do not disassemble.
• Do not expose to water or damp conditions.
• Do not expose to heat or high temperatures.
How to Properly Dispose of Batteries
This product contains a lithium-ion battery. To properly dis-
pose of expired batteries, view your city’s website or news-
letter to find what guidelines, if any, should be followed and
to make note of their designated hazardous waste collection
days.
