TTS-1e / TTS-1nce Product Description
The TTS-1e and the TTS-1nce are designed to work in conjunction with a Vocia Message Server 1 (MS-
1e) to enable text to speech messaging as part of a Vocia system solution. The TTS-1e and TTS-1nce
use Ethernet-based control protocols in conjunction with Cobranet to function within a Biamp Vocia
system and constructs announcements using a set of user-defined templates.
----
-
O TTS-1e e o TTS-1nce são projetados para trabalhar em conjunto com um servidor de mensagem de
Vocia 1 (MS-1e) para permitir mensagens de texto para fala como parte da solução do sistema Vocia. O
TTS-1e e o TTS-1nce usam protocolos de controle baseados em Ethernet em conjunto com Cobranet
para funcionar dentro de um sistema Biamp Vocia e constroem anúncios usando um conjunto de
modelos definidos pelo usuário.
Beim TTS-1e ist ein vernetzter Text-to-Speech-Generator zur Erstellung von browserbasierten
Durchsagen. Das TTS-1e nutzt auf Ethernet basierende Protokolle in Verbindung mit CobraNet zur
Einbindung in ein Vocia-System. Die Erstellung von Durchsagen erfolgt anhand nutzerdefinierter
Vorlagen.
TTS-1e es un motor de texto a voz en red que permite la creación de anuncios de cortesía con base en
un navegador. TTS-1e utiliza protocolos de control basados en Ethernet junto con CobraNet para
funcionar dentro de un sistema Vocia de Biamp y genera anuncios utilizando un conjunto de plantillas
definidas por el usuario.
作为Vocia系统的一部分,TTS-1e 和TTS-1nce 设计与Message Server 1 (MS-1e)
配合使用,是文本转语音装置。TTS-1e 和TTS-1nce 利用以太网控制协议与 CobraNet协议一起, 在
Biamp Vocia 系统中发挥作用,使用用户自定义模板 就可进行创建广播。
---1e
--

TTS-1e / TTS-1nce Setup and Installation
Overview
The Vocia Text to Speech Server 1 (TTS-1e) and The Vocia Text to Speech Server 1 Nurse Call (TTS-
1nce) are designed to work in conjunction with a Vocia Message Server 1 (MS-1 or MS-1e) to enable text
to speech messaging as part of a Vocia system solution.
Voice fonts are available to suit regional languages.
The TTS-1nce also facilitates integration via RS-232 to Nurse call systems that make use of the TAP
protocol. Rauland Responder 4 and 5 are supported natively.
Setup and Use
The Vocia software provides an intuitive interface for configuration of the TTS-1e / TTS-1nce. In addition,
the Vocia Text-to-Speech server supports a web browser to enable user configuration of custom text
strings. The information supplied by this manual relates to physical connections and assignment. For
more details on software setup, please consult the Vocia Help File.
Installation
The unit requires one 1.75 inch (44.45 mm) high and 19 inch wide rack space with 17 inch (432 mm)
depth. Mounting the unit using four screws with washers will prevent marring of the front panel. PVC or
nylon washers are appropriate. The unit should also be supported at the rear to prevent bending of the
enclosure and/or rack ears.
When installing the rack ears, please note that the hardware is not symmetrical. Please install the rack
Remove the screw from the chassis (with a Phillips P2 screw driver)
Attach the appropriate rack ear and re-affix the Phillips screw to the chassis and 4 additional
Phillips screws supplied with the rack ears.
Install the unit away from heat sources, such as vents and radiators, and in rooms with adequate
ventilation. Ensure that air can circulate freely behind, beside, and above the unit. Do not exceed the
maximum ambient operating temperature of 32°-113° F (0° -42°C). Be aware of conditions in an enclosed
rack that may cause the temperature to exceed ambient room conditions.

TTS-1e / TTS-1nce Front
TTS-1e / TTS-1nce Front Panel
The Unit features one power indication LED on the front panel:
Not illuminated: The device is not powered.
Flashing green: The unit is receiving power but not data, or the unit has not been configured
correctly.
Solid green: The unit is operational. Power supply and network traffic are functional.

TTS-1e / TTS-1nce REAR
1 - AC Power Entrance (IEC)
The IEC power entrance provides for connection of the appropriate power cord (included with unit). An
internal universal switching power supply accepts 100~240VAC @ 50/60Hz, with a maximum power
consumption of 350 watts.
CAUTION
Do not remove or defeat the ground prong on the power cord, as this will constitute a shock hazard. Equipment should be
connected to a mains socket outlet with a protective earthing connection. This plug is the main disconnecting device and should
remain readily operable. There are no user interchangeable parts. Please contact Biamp Technical Support or your local distributor
for all service requirements.
2 - RS-232 Port
This port is not used for the TTS-1e.
This port is used for the TTS-1nce to facilitate interfacing to a external nurse call system. The port
interfaces to a TAP enabled device in order to generate Text to Speech or recorded messages or play
specified configured Vocia Page Codes. The Vocia software allows customization of the rules and
messages. Please refer to the Specifications page for all supported connection speeds. For more details
on setup and configuration, please consult the software Help File.
3 - Network Connection
The TTS-1e / TTS-1nce has four RJ45 Ethernet connectors located on the rear panel (Control, CobraNet,
Spare and Spare). Each connector has two green LEDs, which display Ethernet Link (left LED) and
Activity (right LED). The TTS-1 / TTS-1nce does not display the status of the CobraNet conductor.
LAN-1 Connector (Control)
This port connects the TTS-1e / TTS-1nce to a control network. This should be separate to the LAN that
is being used by the CobraNet port either physically or through the use of managed switches and VLANs.
The TTS-1e / TTS-1nce can be configured in the Vocia software interface via this port, and as such it
should be connected to the same network as the configuration PC during set up.
LAN-2 Connector (CobraNet)
This port is used to communicate with local Vocia devices and as such should be connected to the same
network as the local Vocia system. The data from the CobraNet network should be placed on its own
LAN, either physically or through the use of managed switches and VLANs. Vocia makes dynamic use of
available bundles in CobraNet. Vocia devices are currently not interoperable with non-Vocia devices.
LAN-3 Connector (Spare)
This port is inactive at this time.
LAN-4 Connector (Spare)
This port is inactive at this time.
4 - Inactive
These ports are inactive at this time.
5 - Inactive
This port is inactive at this time

TTS-1e
5
NOTE
Connection of external devices to inactive ports is not required or recommended.
6 - Device ID
The rotary ID switches give the unit a unique Device ID. The switches are in hexadecimal format. All units
of the same device type must have a unique Device ID to function properly within a Vocia Paging World.
The Factory Default Device ID is 01. A Device ID of 00 is invalid and cannot be used.
To assign a Device ID of hex 07, leave the MSB switch on 0 and turn the LSB switch to 7. Device ID
switches should be set using a 0.1 inch (2.5mm) to 0.12 inch (3.0mm) flat blade screwdriver. More
information on setting IDs and the hexadecimal numbering scheme can be found in the Vocia Help File.
NOTE
Changes made to the Device ID while connected to the network require a power cycle in order to take effect.

TTS-1e / TTS-1nce Specifications
Specification Table
Power Consumption:
100~240V AC 50/60Hz
< 300 W
Dimensions:
Height
1.75 Inches (44mm)
Width
19 Inches (483mm)
Depth
17.5 Inches (444mm)
Weight
12 lbs (5.4kg)
Environment:
Ambient Operating Temperature
32-113°F
(0-42°C)
Humidity
5 - 95%
Altitude
0 - 10000 Feet MSL
(0 - 3000 Meters MSL)
Compliance:
UL Listed- USA and Canada E305194
FCC Part 15 Subpart B class A
CE Marked
RoHS Compliant
RCM Marked
EAC Marked
RS-232 Port - TTS-1nce
Default Settings
Baud Rate
9600
Stop Bits
1
Parity
None
Data Bits
8
RTS
Enabled
DTR
Enabled
Flow Control
RTS
Supported Settings
Baud Rate
300, 1200, 2400, 4800, 9600,
19200, 38400, 57600, 115200
Stop Bits
1 or 2
Parity
None, Odd, Even, Mark, Space
Data Bits
7 or 8
RTS
Enabled or Disabled
DTR
Enabled or Disabled
Flow Control
None, XOn/XOff, RTS and
RTS XOff/RTS XOn
Block Diagram

Notes Page

Notes Page
