BigPlanes F4U Corsair User manual

第 1 页

第 2 页

第 3 页

1. Assemble the aileron. Prepare the servos of aileron, trim
slots to appropriate position in outer wing and aileron,
apply instand type AB glue to the slots in the aileron and
pivot & round hinges. Connect the servo to the horn with
screws.
4. Assemble the flap on the center wing, put the flaps
together, trim slots to appropriate position in center wing
trailing edge and flap, apply instand type ABglue to the
slots in the flap and horns. Connect the servo to the horn
with screws.
2. Assemble the flap on the outer wing. Prepare the servos
for flaps, trim slots to appropriate position in the outer
wing and flaps, apply instand type AB glue to the slots in
the flaps and horns. Connect the servo to the horn with
screws.
5. Epoxy the pinned hinges,horns to the inner gear door
carefully,
Trim slots through the gear door and pinned hinges and
fix the
pinned hinges tightly to the inner gear door. Assemble the
servos to appropriate position in the former of fuselage .
3. Fix the servo to the wing, Keep some space between the
trailing edge and the aileron to make sure it can rotate
smoothly.
6. Photo for the gear door assembly finished .
第 4 页

7. Assemble the main retracts and gear cover parts to the
retract mount with screws .
10. Assemble the out wing to the center wing and lock
them with screws .
8. The pictures after gear door cover install finished and
gear door open .
11. Assemble the wing to the fuselage and lock it with
screws.
9. Epoxy the fiber wing joiner to the center wing tightly . 12. Assemble the servo to appropriate position in the
stabilizer, and connect the horn in the elevator .
第 5 页

13.Glue one side of the stab tube to one stabilizer, assemble
it to the fuselage throught the stab tube, assemble another
stabilizer to the fuselage and lock the stabilizer with screw .
16. Assemble the tail wheel to the tail fuselage .
14.Assemble the rudder arm wire to the tail fuselage as
illustration.
17. Mount the fuel tank. Assemble the servo for rudder
in the fuselage and connect them via the steel wire .
15. Apply AB glue to the slots in the rudder assemble the
rudder to the vertical fin of the plane, epoxy the ply wood
plate to the fuselage .
18. Assemble the ply cowl frame to the fuselage.
第 6 页

19.Install the engine to the firewall with screws, put the
cowling to the engine and glue the cowl to the ply wood
frame.
20. Assemble the propeller and spinner nut to the engine
.
21. Phones when the model assembled completely.
第 7 页

22.Adjust the travel of each control surface to the values
in the diagrams. These values fit general flight
capabilities.Readjust according to your needs and flight
level.
23.Adjust the travel of each control surface to the values
in the diagrams. These values fit general flight
capabilities.Readjust according to your needs and flight
level.
24.Check all the datas well. make sure all sections glue tightly. Otherwise if coming off during flights, you'll lose control of
your airplane which leads to accidents!
25.C.G: Never fly before checking the CG's required position. Never fly the model without well balancing.
