Bijur Delimon FZ-A User manual

1 BIJUR DELIMON INTERNATIONAL BA_2020_01_GB_FAX_FBX
Operation manual
in accordance with ATEX Directive 2014/34/EU
Pump FZ-A / FZ-B
ATEX version
BA_2020_D1_FAX_FBX (Rev. B)
December 2020

2 BIJUR DELIMON INTERNATIONAL BA_2020_1_GB_FAX_FBX
Table of contents
1. Introduction .......................................................................................................................................................................................................................4
1.1 Target groups..................................................................................................................................................................................................................4
1.2 Required knowledge and qualifications...................................................................................................................................................................4
1.3 The manufacturer’s contact details .........................................................................................................................................................................4
1.4 Copyright...........................................................................................................................................................................................................................4
1.5 Warranty and disclaimer..............................................................................................................................................................................................4
1.6 Abbreviations...................................................................................................................................................................................................................5
2. Safety ...................................................................................................................................................................................................................................5
2.1 Intended use....................................................................................................................................................................................................................5
2.2 Warnings, signs and symbols ......................................................................................................................................................................................6
2.3 General safety instructions ........................................................................................................................................................................................7
2.4 Basic behaviour when using the pump.....................................................................................................................................................................7
2.5 Safety instructions for maintenance, inspection and assembly work ...........................................................................................................7
2.6 Safety instructions for the operating company ...................................................................................................................................................8
2.7 Specific safety instructions for explosion protection ........................................................................................................................................8
2.8 Notes and pictograms on the pump..........................................................................................................................................................................9
2.9 Type plate .........................................................................................................................................................................................................................9
2.10 General safety instructions for handling lubricants ........................................................................................................................................9
2.10.1 Selecting lubricants........................................................................................................................................................................................ 10
2.10.2 Lubricant ageing .............................................................................................................................................................................................. 10
2.11 Foreseeable misuse ................................................................................................................................................................................................. 10
2.12 Product modifications............................................................................................................................................................................................. 10
2.13 The obligations of the operating company ....................................................................................................................................................... 11
2.13.1 Determining hazards...................................................................................................................................................................................... 11
2.13.2 Personnel qualification and training ......................................................................................................................................................... 11
2.13.3 Providing personal protective equipment................................................................................................................................................ 11
2.13.4 Instructing external assembly fitters ...................................................................................................................................................... 11
2.13.5 Testing and ensuring proper use................................................................................................................................................................ 11
2.13.6 How to behave in emergency situations ................................................................................................................................................... 12
2.14 Dangers if the safety instructions are not observed .................................................................................................................................... 12
2.15 Residual risks............................................................................................................................................................................................................. 12
2.16 Residual risks ATEX.................................................................................................................................................................................................. 12
3. Product description ...................................................................................................................................................................................................... 13
3.1 Introduction.................................................................................................................................................................................................................. 13
3.2 Revision level ................................................................................................................................................................................................................ 13
3.3 Technical data .............................................................................................................................................................................................................. 13
3.4 Dimensions .................................................................................................................................................................................................................... 14
3.5 Pump components....................................................................................................................................................................................................... 15
3.6 Overview of variants................................................................................................................................................................................................... 15
3.6.1 Pump body variants ........................................................................................................................................................................................... 15
3.6.2 Drive variants ...................................................................................................................................................................................................... 16
3.6.3 Reservoir variants ............................................................................................................................................................................................. 16
3.6.4 Accessories .......................................................................................................................................................................................................... 16
3.7 Technical details .......................................................................................................................................................................................................... 17
3.7.1 Functionality ........................................................................................................................................................................................................ 17
3.7.2 Outlet location and labelling ........................................................................................................................................................................... 17
3.7.3 Delivery volume per outlet: ............................................................................................................................................................................. 18
3.7.4 Adjusting the delivery volume: ....................................................................................................................................................................... 18
3.7.5 Drive types in general ....................................................................................................................................................................................... 19
3.7.6 Drive with a flange motor and reduction gear .......................................................................................................................................... 19
3.7.7 Reservoir .............................................................................................................................................................................................................. 20
3.7.8 Fill level monitoring (accessories)................................................................................................................................................................ 21

3 BIJUR DELIMON INTERNATIONAL BA_2020_1_GB_FAX_FBX
3.7.9 Pressure limitation (accessory option 200 bar) ...................................................................................................................................... 23
3.8 Coding and sample order .......................................................................................................................................................................................... 25
4. Transport, handling and storage .............................................................................................................................................................................. 25
4.1 Checking the delivery ................................................................................................................................................................................................. 25
4.2 Tools for transport and handling ........................................................................................................................................................................... 25
4.3 Storage conditions...................................................................................................................................................................................................... 26
5. Assembly, installation and commissioning............................................................................................................................................................. 26
5.1 Suitable installation locations ................................................................................................................................................................................. 26
5.2 Minimum installation dimensions ........................................................................................................................................................................... 26
5.3 Fixation options............................................................................................................................................................................................................ 26
5.4 Assembling lubrication lines and system components .................................................................................................................................... 27
5.5 Electrical connection.................................................................................................................................................................................................. 27
5.6 Filling the pump reservoir and lubrication lines................................................................................................................................................ 28
5.7 Commissioning the pump or lubrication system ............................................................................................................................................... 29
5.7.1 Manufacturer’s settings .................................................................................................................................................................................. 29
5.7.2 Checks before commissioning for the first time...................................................................................................................................... 29
5.7.3 Measures during commissioning................................................................................................................................................................... 30
5.8 Determining running and break times.................................................................................................................................................................. 30
5.9 Examples of the systems .......................................................................................................................................................................................... 30
5.9.1 Multi-line system ................................................................................................................................................................................................ 30
5.9.2 Progressive system ........................................................................................................................................................................................... 30
6. Operation.......................................................................................................................................................................................................................... 31
6.1 Operating safety.......................................................................................................................................................................................................... 31
6.2 Operating modes ......................................................................................................................................................................................................... 31
6.3 The pump’s or lubrication system’s control unit ............................................................................................................................................... 31
6.4 Topping up the lubricant ........................................................................................................................................................................................... 31
6.5 Shutting down the pump ........................................................................................................................................................................................... 32
7. Inspection, testing and maintenance...................................................................................................................................................................... 33
7.1 Pressure test................................................................................................................................................................................................................ 33
7.2 Relieving the system pressure................................................................................................................................................................................ 33
7.3 Gear oil............................................................................................................................................................................................................................ 34
7.4 Open reservoir lid........................................................................................................................................................................................................ 35
7.5 Check and renew filter............................................................................................................................................................................................... 35
8. Cleaning ............................................................................................................................................................................................................................ 36
9. Troubleshooting, fault elimination and repair...................................................................................................................................................... 37
10. Disassembly, decommissioning and disposal ........................................................................................................................................................ 38
11. Documents and drawings ............................................................................................................................................................................................ 39
12. Annexes............................................................................................................................................................................................................................. 39
Annex 12.1: Declaration of CE conformity.................................................................................................................................................................. 40
Annex 12.2: Declaration of ATEX conformity ............................................................................................................................................................. 42
Annex 12.3: Motor data sheet ........................................................................................................................................................................................ 43
Annex 12.4: Motor Declaration of ATEX conformity ................................................................................................................................................ 45
Annex 12.5: Level sensor ATEX Declaration of Conformity ................................................................................................................................... 46

4 BIJUR DELIMON INTERNATIONAL BA_2020_1_GB_FAX_FBX
1. Introduction
This operating manual contains important information and warnings relating to all of the product’s life phases. We therefore
strongly advise that all people in the target groups mentioned below read this document carefully before assembly, commissioning
and maintenance. Additionally, it must be ensured that the operating manual is available at the place of use at all times.
We reserve the right to make technical changes that are necessary for improvement to the illustrations and information in this
operating manual. DELIMON retains the copyright to this operating manual. It contains regulations and drawings of a technical
nature that may not be distributed, either in whole or in part, or used without authorisation for competition purposes or
communicated to others.
1.1 Target groups
This operating manual is intended for assembly, operating and maintenance personnel.
1.2 Required knowledge and qualifications
Qualified mechanic
A person with suitable technical training, knowledge and experience who can recognise and prevent the hazards that may occur
during transport, assembly, commissioning, operation, maintenance, repair and disassembly.
Qualified electrician
A person with suitable technical training, knowledge and experience who can recognise and prevent the hazards that can be caused
by electricity.
Operator
A trained person who, based on their knowledge and experience, is capable of commissioning and operating the product. This also
includes preventing potential hazards that may arise during operation.
Specialist for maintenance and servicing in potentially explosive atmospheres
Trained staff member, who is able to recognise hazards and risks in potentially explosive atmospheres through knowledge and
experience and who is able to eliminate these hazards and risks by means of suitable measures. The qualified technician is familiar
with the relevant rules and regulations as per ATEX Directive 2014/34/EU and 19999/92/EC and knows about types of ignition
protection, installation procedures and area classifications.
1.3 The manufacturer’s contact details
Düsseldorf head office
Beierfeld plant
DELIMON GmbH
Arminstrasse 15
40227 Düsseldorf, Germany
Telephone: [phone]
Telefax: 0211 77 74-210
DELIMON GmbH
Am Bockwald 4
08344 Grünhain-Beierfeld, Germany
Telephone: [phone]
E-Mail: [e-mail]
Web: www.bijurdelimon.com
Please address product returns for repairs to the ‘Repair Department’ at the Beierfeld plant.
1.4 Copyright
© Copyright DELIMON, all rights reserved
1.5 Warranty and disclaimer
Warranty
Please refer to our General Terms and Conditions for warranty information
Disclaimer
The manufacturer is not liable for damage caused by
oUnintended use
oFailure to comply with this operating manual

5 BIJUR DELIMON INTERNATIONAL BA_2020_1_GB_FAX_FBX
oUnauthorised modification of the product
oUse of non-genuine DELIMON spare parts
1.6 Abbreviations
The following abbreviations and symbols may be used in the document.
General abbreviations
Technical abbreviations / units
ATEX
ATmosphere EXplosible
Ø
diameter
re.
regarding
©
Copyright
/ Y
delta connection / star connection
approx.
approximately
°C
degrees Celsius
i.e.
Id est (in other words)
°F
degrees Fahrenheit
ESD
Electro Static Discharge
A
Amperes
etc.
et cetera
Ah
Ampere-hours
poss.
possibly
AC / DC
alternating current / direct current
where
necc.
where necessary
cm3 / ccm
cubic centimetres
AAR
As a rule
db (A)
sound pressure level
incl.
Including
Hz
Hertz (frequency)
min.
Minimum
I
Amperage
max.
Maximum
kg
kilograms
no.
Number
kW
kilowatts
PPE
Personal protective equipment
l
litres
ASO
and so on
ml
millilitres
e.g.
Exempli gratia (for example)
mm
millimetres
Time-related abbreviations
mm²
square millimetres
h / hr.
hour
mm3
cubic millimetres
Min.
minute
N / Nm
Newton / Newton meters
s / sec.
seconds
nc / no
N/O (normally open) contact /
N/C (normally closed) contact
d
day
V
Volts
General symbols
W
Watts
o
list
Conversion factors
➢
instruction (chronological)
Pressure
1 bar = 14.5 psi

reference to other documents
Length
1 inch = 25.4 mm
2. Safety
This section describes general and product-specific safety instructions that must be observed and followed. Further safety
instructions can be found at appropriate points in other sections of this operating manual. Please read this section carefully to
understand the safety instructions throughout this document and on the product itself.
2.1 Intended use
The pump described below is intended for commercial use for supplying lubricant to industrial machinery and equipment - within
the approved zone(s) / category(ies) of appropriate equipment ignition protection types. The pump may only be used by qualified
operators. The pump is deemed as functional when connected to a power supply.
The following is also required for intended use:
oConnecting line (pipe or hose) from the pump outlet to at least one suitable lubrication point (e.g. bearing or chain) on an
existing machine or system
oLubricant that is free from contamination and suitable for feeding with the described pump according to the specification
in this operating manual
oCompliance with all specifications, safety instructions and general instructions
The pump described may also be part of a more complex central lubrication system. This may include, for example, several pump
outlets, downstream lubricant distributors and, if necessary, control and monitoring elements. The compatibility of all system
components must be ensured (e.g. operating pressure, approved lubricants, temperature range, etc.).

6 BIJUR DELIMON INTERNATIONAL BA_2020_1_GB_FAX_FBX
Any use that extends beyond this is considered unintended use. The manufacturer is not liable for any damage resulting from this;
the risk is borne solely by the operating company. The filling and feeding of substances that are classified as hazardous (according
to the CLP Regulation 1272/2008) is only allowed following consultation with and written confirmation from Delimon. The use of
any media that enters into food is not permitted.
2.2 Warnings, signs and symbols
This operating manual contains the following symbols according to DIN EN ISO 7010 to indicate health hazards and property
damage and how to avoid them. Failure to observe the safety instructions may put people at risk.
Warnings:
Warning level
Consequence
Probability
Death or serious injury
Imminent
Severe injury
Possible
Slight injury
Possible
Property damage
Possible
Pictograms:
General warning signs
General mandatory signs
General prohibition signs
General warning
General mandatory sign
No unauthorised access
Warning –electric voltage
Observe instructions
Other signs
Warning –slipping hazard
Wear safety goggles
Warning –tripping hazard
Wear hearing protection
Warning –substances that are
harmful to health
Wear safety boots
CE mark
Warning –flammable
substances
Wear safety gloves
Waste electrical and
electronic equipment
symbol
Warning –possibility of hand
injuries
Wear face protection
Warning –possibility of hand
injuries due to pulling in
Wear a safety hat
Warning –hot surface
Wear protective clothing
Warning –explosive
atmosphere
Disconnect from the mains
before commencing work
Warning –suspended load
Earth before use
Warning –possibility of injuries
due to pressure injection
Keep closed
DANGER
WARNING
CAUTION
ATTENTION

7 BIJUR DELIMON INTERNATIONAL BA_2020_1_GB_FAX_FBX
Combined warnings:
WARNING
WARNING
Danger
Example of a hazard warning
Danger
Example of a hazard warning,
with information about how
to avoid it
2.3 General safety instructions
oThe pumps are state-of-the-art and safe to operate.
oThis operating manual must always be available at the machine’s / system’s place of use.
oThis operating manual must be kept for further use.
oThe described product was manufactured according to the current state of the art. However, unintended use could
potentially put people at risk or result in property damage.
oIf safety-related faults occur, the product must be taken out of operation immediately until they have been eliminated. In
addition, the legal accident prevention and environmental protection regulations must be observed.
oNot only the general safety instructions specified in this section Safety must be observed, but also special safety
instructions in the separate chapters.
oThe product may only be used by qualified personnel, in a technically perfect condition and according to the information
and safety instructions contained in this manual.
oPlease read this operating manual carefully and familiarise yourself with the product and how it works. The operating
steps’ sequence must be observed.
2.4 Basic behaviour when using the pump
oFor the pump to be operated, it must be in good working order, installed correctly and, if necessary, connected to the
electrical system by a professional. In the event of any uncertainties, operation of the pump is prohibited until the issues
have been clarified.
oKeep unauthorised or unqualified individuals away from the pump.
oObserve internal company instructions and relevant safety regulations.
oWear personal protective equipment (PPE).
oCheck protective and safety equipment (e.g. pressure limitation valves) regularly. They may not be removed or tampered
with in any way.
oIf safety equipment is replaced, it must be immediately reinstalled and tested to ensure that it is working.
oNever use parts of the pump or the connected central lubrication system as a standing or climbing aid.
2.5 Safety instructions for maintenance, inspection and assembly work
oThe operation, maintenance, inspection and assembly personnel must be appropriately qualified for this work.
oThe personnel’s area of responsibility, competence and supervision must be regulated by the operating company.
Operational precautions and work instructions must be observed.
oThe operating company must ensure that personnel understand the contents of the operating manual in full.
oOnly work on the pump when it is at a standstill, depressurised and disconnected from the mains (secured against
accidental restart).
oPumps or units that feed media that are harmful to health must be decontaminated.
oAll safety and protective equipment must be reattached or put back into operation as soon as the work is completed.
oProduct transport requires suitable transport and lifting equipment. Use marked paths.
oMaintenance and repair work should preferably be carried out at room temperature. The lubricant’s flow properties change
at low or high temperatures.
oDry wet, slippery surfaces or cover them as appropriate.
oCover hot or cold surfaces as appropriate.
oWork on electrical components may only be carried out by qualified electricians using suitable tools and when the
components are de-energised. The valid wiring diagram and local regulations must be observed.

8 BIJUR DELIMON INTERNATIONAL BA_2020_1_GB_FAX_FBX
oDo not touch cables or electrical components with wet hands or cloths.
oDo not bypass fuses. Always use the same fuse type in the event of replacement.
oEnsure that the protective earthing conductor is connected correctly.
oObserve tightening torques (if specified). Use a calibrated torque wrench when tightening.
oLabel individual parts after disassembly to avoid mixing them up.
oThe operating manuals must be accessible to operators and maintenance personnel at all times.
Note:
DELIMON holds qualified training courses to ensure maximum safety and efficiency. Please get in touch with your contact
or the DELIMON service address for further information.
2.6 Safety instructions for the operating company
oIf hot or cold machine parts lead to hazards, the customer must secure these parts against contact.
oNever remove contact protection for moving parts (e.g. pendulum lever) while the machine is in operation.
oEliminate leaks so that people and the environment are not put at risk. Legal regulations must be observed.
oTake all necessary measures to eliminate the possibility of hazards caused by electrical energy (for details, see the
regulations set down by the Association for Electrical, Electronic & Information Technologies (VDE) and local power supply
companies).
oEnsure that only authorised persons are in the explosion-protected area.
oBefore working in the explosion-protected area, there must be written permission for the work to be carried out.
oFor work, which cannot be carried out in an explosive atmosphere (e.g. installation and repair work), it is the operator's
responsibility to ensure and monitor a hazard-free dust and gas concentration levels in the given environment.
oThe operator must ensure lightning protection for the entire system in accordance with local regulations.
2.7 Specific safety instructions for explosion protection
oFor transport and handling of the pump within a potentially explosive atmosphere, there must be no sparking caused by
falling, bumping, rubbing or slipping, e.g. by using suitable covers / wrapping.
oAssembly and repair work and electrical work may only be carried out, if no explosive atmosphere is present.
oThe cleaning of the pump must only be carried out if there is no explosive atmosphere. In any event, it must be ensured that
the cleaning aids used cannot lead to electrostatic charging during the cleaning process.
oBefore commissioning, check for any damage to the pump caused by transportation (e.g. damage to the paint), as this can
result in the loss of explosion protection.
oIgnition sources of all kinds (e.g. flames, sparks, hot surfaces) are strictly prohibited within the potentially explosive
atmosphere.
oAlways behave in a manner that avoids the risk of explosion.
oTools and clothing must be approved for the potentially explosive atmosphere (ESD)
oIf parts or devices of the explosion protection are defective or their function cannot be ensured, the pump and higher-level
systems must be switched off immediately.
oMeasures and equipment for explosion protection must never be ignored, modified or deactivated.
oThe ignition temperature of the lubricant must be at least 50° Kelvin above the max. permissible surface temperature of
the pump components.
oThe ignition temperature of the environment (gases or dust) must be at least 50° Kelvin above the maximum possible
surface temperature (according to ATEX specification) of the pump components.
oThe application limits of the pump are clearly specified by the equipment categories, gas and dust groups as well as
temperature classes.
oElectrical plug connections and conductors must never be unplugged when live. This may cause danger to life, if an
explosive gas is present in the environment at that time.
oAll electric drives must be protected against overload, short circuit and earth fault by a safety, monitoring and control
device according to RL 2014/34/EU.
oOrdinary electrical equipment may be fitted in mounting housings; it may only be used in intrinsically safe circuits. The
mounting housings must be approved for the ATEX zone in which they are used. In any event, the manufacturer must
prepare a control drawing (proof of intrinsic safety) and add it to the delivery documentation.
oIt must be ensured that the pump is always filled with fluid and that flammable media inside the pump are not heated above
80 % of their ignition temperature without the application of special measures. (Start-up)

9 BIJUR DELIMON INTERNATIONAL BA_2020_1_GB_FAX_FBX
2.8 Notes and pictograms on t e pump
Warning – possibility of and injuries
Risk of injury due to t e rotating scraper in t e reservoir! Never reac into t e reservoir w ile
t e pump is running. Hands or fingers can be crus ed, cut off or broken.
T e pump can rotate in a clockwise and an anti-clockwise direction
Information sign: only pour clean lubricant into t e reservoir
All labels on t e pump must be legible at all times.
2.9 Type plate
T e type plate contains important specifications for identifying t e pump. T is must always be legible.
Example: FZ pump wit approval for ATEX Zone 1 Example: FZ pump wit approval for ATEX Zone 2 and 22
2.10 General safety instructions for andling lubricants
Lubricants perform different tasks and are selected specifically for t e application. Lubricants’ main functions are:
o Reducing friction and wear
o Protecting against corrosion
o Reducing noise
o Protecting against dirt or foreign matter
o Extending t e service life of bearings, c ains, etc.
o Cooling

10 BIJUR DELIMON INTERNATIONAL BA_2020_1_GB_FAX_FBX
2.10.1 Selecting lubricants
Lubricants are usually selected during machines’ and systems’ design phase. They are selected by the machine manufacturer or, if
appropriate, the machine operating company. The product’s operating temperature or the ambient temperature must also be
taken into account. DELIMON takes the lubricant specification into account during the project planning process and when selecting
suitable central lubrication components. If it does not have any relevant experience with regard to the compatibility of given
lubricants, Bijur Delimon also offers preliminary tests to assess the compatibility.
Material compatibility:
The used lubricants must generally be compatible with the following materials and seals:
Steel, grey cast iron, brass, copper, aluminium
NBR, FPM, FKM, ABS, PA, PU
Only lubricants specified for the product (see the section entitled ‘Technical data’) may be used. All other system
components’ specified lubricants must also be observed! Unsuitable lubricants can lead to functional failure of the
product or the entire system.
Do not mix lubricants. This has an impact on the lubricating properties and feedability, and thus on the central
lubrication system’s function.
It must be ensured that flammable media inside the pump are not heated above 80 % of their ignition temperature
without the application of special measures.
When handling lubricants, the relevant safety data sheets and, if applicable, the hazard labels on the packaging
must be observed
2.10.2 Lubricant ageing
If lubricants are stored in reservoirs or lines for an extended period of time, e.g. due to machine downtime, ageing phenomena may
occur (e.g. separated lubricant components). Before putting the machine / system back into operation, check whether the
lubricant is still suitable for use. If necessary, the lubricant must be replaced before the machine / system is put back into
operation.
2.11 Foreseeable misuse
Misuse is considered to be unintended use, especially in the following cases:
oOperation outside the specified operating temperature range.
oOperation in a more critical explosion protection zone than specified on the type plate and in these operating instructions.
oOperation with explosive gases and vapours, where the ignition temperature is below the maximum specified surface
temperature.
oOperation with explosive dusts with minimum ignition temperature and the glow temperature are below the specified
maximum surface temperature.
oSubsequent alteration of the paint finish that does not comply with the requirements of the applicable ATEX standards.
oOverriding or removing safety equipment (e.g. pressure limitation valve)
oAdding and feeding unspecified or contaminated lubricants
oAdding and feeding lubricants that require written approval from Delimon or are generally prohibited (e.g. hazardous
substances or food fat)
oFilling and transporting lubricants whose temperature is above the maximum permissible ambient temperature.
oForeign bodies in the lubricant reservoir
oOperation in corrosive / aggressive environments without a suitable protective coating or enclosure
oSelecting an unsuitable installation site
oTampering on the pump (e.g. shutting down an outlet)
oReplacing original attachments with unsuitable components, e.g. motor with too high a power / rotation speed
2.12 Product modifications
Modification or alteration of the pump is prohibited. Any modification will have unpredictable influence on the safety and will lead
to the loss of the ATEX conformity.

11 BIJUR DELIMON INTERNATIONAL BA_2020_1_GB_FAX_FBX
2.13 The obligations of the operating company
The operating company must guarantee the prerequisites for safe and proper use of the pump throughout its entire life cycle.
These are described again in detail below.
2.13.1 Determining hazards
Installing the pump in a machine or system belonging to the operating company may cause a more complex hazard situation. It is
the operating company’s responsibility to determine all hazards at the place of use and necessary counter-measures to ensure
safety and health protection.
Explosion protection:
oThe operator must ensure that the work equipment and installation materials are suitable for operation in potentially
explosive atmospheres on the basis of a comprehensive assessment of the workplace. The operator must guarantee that
the equipment is assembled, installed and operated in a way that does not cause an explosion.
oIn the event of modifications and extensions, the operator must ensure that appropriate measures are implemented to
comply with the minimum explosion protection requirements.
oThe operator must identify the potentially explosive atmospheres by means of signs.
oThe operator must document the measures taken to ensure explosion protection.
oThe operator must provide written work instructions.
oThe operator checks and monitors compliance with the measures and work instructions
2.13.2 Personnel qualification and training
The operating company shall ensure that all people authorised to use the pump have the necessary knowledge and qualifications
before they use it for the first time.
The operator must instruct authorised personnel on explosion protection. This includes at least:
othe allocation of zones
oScope and limits of the activities or responsibilities
oUse of the PPE
oImportance of warnings
oEmergency behaviour.
The operator must ensure that this operating manual and any associated documents are accessible at all times and that the
contents of the same are read and understood. It shall also regulate the responsibilities of assembly, operation and maintenance
personnel.
2.13.3 Providing personal protective equipment
The operating company must provide personal protective equipment that is suitable for the relevant place and purpose of use.
2.13.4 Instructing external assembly fitters
Before being deployed, external assembly fitters must be brought to the same required level of knowledge as the operating
company’s own personnel. This includes all of the product information, safety instructions, safety regulations and accident
prevention regulations and regulation with regard to explosion protection issued by the operator.
2.13.5 Testing and ensuring proper use
The operating company shall ensure that the pump is being used as intended by taking suitable, periodic inspection measures. The
periodic inspection should at least include:
oFunction of the pump and safety equipment
oChecking for unauthorised tampering or conversion
oLegibility of all labels and the type plate
oCleanliness of the reservoir contents, the pump and also the surrounding area (including the lubricant storage area)
oCondition of the electrical installation

12 BIJUR DELIMON INTERNATIONAL BA_2020_1_GB_FAX_FBX
2.13.6 How to behave in emergency situations
The operating company must ensure that the pump is shut down quickly in an emergency. To stop the pump, the power supply must
be interrupted –for example by pressing an emergency shutdown switch on the pump or the higher-level machine. Personnel must
be trained in the procedures to be followed in an emergency.
2.14 Dangers if the safety instructions are not observed
Failure to observe the safety instructions may result in personal injury as well as potential damage to the environment and the
machine. In detail, failure to observe the safety instructions may result in the following hazards, for example:
oFailure of key machine / system functions
oExplosion hazard in hazardous areas
oFailure of prescribed maintenance and repair methods
oPeople being put at risk due to electrical, mechanical and chemical effects
oThe environment potentially being polluted due to hazardous substances leaking
Failure to observe the safety instructions may lead to any claims for damages lapsing.
2.15 Residual risks
2.16 Residual risks ATEX
Residual risk
Preventative / remedial measure
Creation of an explosive atmosphere due to the dust
circulation
Avoid dust accumulation by regular control and cleaning.
Select a place of installation with preferably a clean
environment and low dust exposure.
Heating of the lubricating points, which are undersupplied, to
the ignition temperature level due to non-detected
malfunction within the central lubrication system
The operator must examine critically whether operation
without appropriate automated system monitoring leads to a
potential hazard. If necessary, suitable remedial measures
must be taken.
Use in a potentially explosive atmosphere without testing the
potential equalisation for electrical continuity
The potential equalisation must be checked for continuity at
regular intervals. The operator defines the intervals. In any
case, the test must be carried out prior to commissioning and
after repairs / maintenance.
Generation of electrostatic charges, sparks, e.g. due to
components falling down or colliding with each other
Secure part against traps. If necessary, cover components to
prevent sparks from forming.
Use of isolating switching amplifiers in potentially explosive
atmospheres
Only install isolation amplifiers outside the potentially
explosive area.
Risk
Possible in life phase
Preventative / remedial measure
Physical injury, property
damage due to lifted parts
falling
A
B
C
G
H
K
Keep unauthorised individuals away. Do not allow people to
stand under lifted parts. Lift parts with suitable lifting
equipment.
Personal injury / property
damage due to electric shock
if the connection cable is
damaged
B
C
D
E
F
G
H
Check the connection cable for damage before using the
pump for the first time, and at regular intervals
thereafter. Do not mount the cable on moving parts or
chafing points, or take appropriate safety precautions.
Connect and check
the potential equalisation.
Physical injury / property
damage / environmental
pollution due to spilled,
leaked lubricant
B
C
D
F
G
H
K
Take care when filling the reservoir and connecting or
disconnecting the lubricant lines. Only use hydraulic screw
connections and lubrication lines that are suitable for the
specified pressure. Do not install lubrication lines on
moving parts or chafing points.
Life phases:
A = Transport, B = Assembly, C = Commissioning for the first time, D = Operation, E = Cleaning, F = Maintenance, G = Fault, repair, H
= Decommissioning, K = Disposal

13 BIJUR DELIMON INTERNATIONAL BA_2020_1_GB_FAX_FBX
3. Product description
3.1 Introduction
The FZ-A /FZ-B (ATEX version) grease / oil lubrication pump is a positively driven piston pump. The operating principle is
characterised by a very high level of reliability and constant delivery volume, even at a high back pressure. In contrast to other
piston pumps, only one central piston is required to supply up to 12 outlets due to a special design.
Unlike the standard version of the FZ pump, the ATEX version is only available with flange motor and reduction gear. The drive
types with free shaft end or pendulum lever are not available.
Difference: FZ-A and FZ-B pump (standard and ATEX version)
The two pumps only have a different pump body design. The FZ-B pump is available with 1 or max. 2 outlets and feeds 12 times or
2x 6 times the volume of the FZ-A pump due to internal volume combination.
3.2 Revision level
Current revision: Level B
3.3 Technical data
ATEX Type of ignition
protection:
The grease lubrication pumps can be used - depending on the marking - as follows: •
Zone 1 ( Gas Ex, category 2G, EPL Gb) in explosion groups IIA and IIB
Zone 2 ( Gas Ex, category 3G, EPL Gc) in explosion groups IIA and IIB
Zone 22 ( Dust Ex, category 3D, EPL Dc) in explosion groups IIIA and IIIB
ATEX Temperature category:
The qualification with respect to surface temperature is T4; for all gases, vapours, mists with an
ignition temperature > 135 °C, the BMs are not a source of ignition. In the Dust Ex area, 125 °C
is the reference temperature for additional safety considerations with regard to the glow
temperature, etc. (only the operator can decide).
Mode of operation:
Central piston pump, positively driven
Use:
Multi-line and progressive systems
Outlets:
1 –12
Reservoir:
8 l; 15 l; 30 l (with support as an option, recommended for 15 l and 30 l)
Reservoir filling:
via filling nozzle (G1/4")
Operating pressure:
max. 200 bar (pressure limitation with 160 bar or optionally 200 bar)
Drive:
electric, any direction of rotation
Electric drive:
Standard motor:
Three-phase motor 230 V (D) / 400 V (Y) 50 Hz; IMB14-C90- size 63; 0.18 kW -
1,340 min-1 (also see details in the motor data sheet in the annex)
Operating mode: S1
Reduction gear with a defined gear ratio (delivery rate*):
o215:1 (approx. 0.62 cm3/min, or approx. 37.4 cm3/h)
Sound pressure level:
< 70 dB(A)
Approved lubricants:
Grease up to NLGI grade 2 (DIN 51818), oil with an operating viscosity from ISO VG 68
Temperature range:
-20°C ... +40°C
Relative humidity
max. 90%
Protection class:
IP65
Outlet thread:
G1/4” for pipe Ø 10 mm (max.)
Filling connection:
G1” (filling valve optional)

14 BIJUR DELIMON INTERNATIONAL BA_2020_1_GB_FAX_FBX
Coating and colour:
Pump base and reduction gear: RAL 5010 Gentian blue, C3-M lacquered
Pump body: Grey cast iron (EN-GJS-400-1B - GGG40) nickel-plated (EN 12540-Fe//Ni8b)
Pump reservoir: Zinc-nickel coating (DIN 50979-Fe//ZnNi8//An//T0)
Motor: Grey cast iron RAL 5010 Gentian blue
Weight
(not including lubricant):
8 l reservoir
15 l reservoir
30 l reservoir
approx. 32 kg
approx. 34 kg
approx. 36 kg
Optional accessories:
oPressure limitation valve(s) 200 bar (standard 160 bar)
oLevel switch (MIN /MAX)
3.4 Dimensions
Pump’s basic dimensions in mm:
A
8 L = 580
15 L = 600
30 L = 670
B
8 L = 238
15 L = 240
30 L = 306
Drive position 5
Drive position 1

15 BIJUR DELIMON INTERNATIONAL BA_2020_1_GB_FAX_FBX
3.5 Pump components
External main components of the pump:
3.6 Overview of variants
Different pump bodies, drive variants and reservoir sizes can be combined due to the modular pump design. This section provides an
overview of the different variants. Technical details can be found in the section below.
3.6.1 Pump body variants
Depending on the number of outlets, the FZ pump versions differ in the pump body with the following features:
Lubricant reservoir
(available in different
sizes)
Flange motor
Reduction gear
Filling valve
Pump body
Outlets
(protected when
delivered with a red
closing cap)
Pump foot
Flange and coupling
Setting spindle(s)
FZ-A
1 –6 outlets (one row)
FZ-A
7 –12 outlets (two rows)
Outlets
(G1/4”)
Bolted cover
Level monitoring
(optional)
Aeration and deaeration
filter
Overfill protection
FZ-B
1-2 outlets

16 BIJUR DELIMON INTERNATIONAL BA_2020_1_GB_FAX_FBX
3.6.2 Drive variants
The FZ pump (ATEX version) is equipped with a flange-mounted three-phase motor. Other drive types are not possible as opposed to
the standard version. There are two different drive positions to choose from:
Drive position:
3.6.3 Reservoir variants
Selection of the correct reservoir size depends primarily on the expected lubricant consumption. This should take the effort
required for topping up, which would be reduced by larger reservoir volumes, into account. On the other hand, the lubricant’s dwell
time in the reservoir must also be taken into consideration. An insufficient lubricant replacement frequency may have a negative
effect on the lubricating and feeding properties. The available installation space is also a selection criterion.
For 15 and 30 litre reservoirs, we advise using a reservoir support if the pump is exposed to vibrations or acceleration.
3.6.4 Accessories
The FZ pump can be equipped with a level monitoring system with 2 switching points for the use in zones 2 and 22 on request. For
the use in zone 1 (Gas Ex) the level monitoring is compulsory. The pressure limitation at each outlet is set to 160 bar as standard
in order to protect the pump and downstream components, which may only be approved for 160 bar. The pump can optionally be
supplied with a 200 bar pressure limitation.
8 l
(Default)
15 l
30 l
15 / 30 L with support
level switch MIN/MAX
Pressure limitation valve (160 standard or optional 200 bar)
Position 5 (right)
Optional
Position 1 (left)
Standard

17 BIJUR DELIMON INTERNATIONAL BA_2020_1_GB_FAX_FBX
3.7 Technical details
3.7.1 Functionality
The FZ pump is a positively driven piston pump. The centrally arranged piston (3) is driven by a worm wheel (1). It performs both
axial movements (stroke) and, simultaneously, rotary movements around its own axis. The piston’s rotational speed depends on the
selected gear ratio.
The lifting disc (2) has a cam on the top which, during the rotary movement, successively strikes against the six setting spindles (4)
arranged on the pump’s circumference, causing a piston suction stroke each time. The stroke movement and thus the delivery
volume can be varied at each setting spindle.
During the suction stroke, the lubricant flows from the suction chamber (S) into the piston’s vertical grooves and, from there, into
the ring channels (R). During the pressure stroke, the lubricant is fed from the ring channel and into the pressure channel (D) and
then into the outlet openings via a vertical groove.
3.7.2 Outlet location and labelling
The FZ-A pump can be configured with up to 12 outlets. Depending on the number, one pump body either with one row of outlets
(6x) or with two rows of outlets (12x), one above the other, is installed. Open outlets are provided with a screw fitting and pressure
relief valve on delivery. These are clearly identifiable. If there are fewer than 6 or 12 outlets, shut-off outlets are closed with a
sealing plug and there are no setting spindles available.
ATTENTION
Pump damage possible
The outlets’ assignment must not be
changed!
Do not close the factory outlets!
Moving direction
of piston

18 BIJUR DELIMON INTERNATIONAL BA_2020_1_GB_FAX_FBX
The outlets are arranged in a circle at increments of 60° and are visibly numbered on the pump body. Arrows indicate the
corresponding setting spindle that the delivery volume can be adjusted with. If there are more than 6 outlets, two outlets are
positioned in pairs, one on top of another (24 mm apart). In this case, the outlet volume can only be adjusted in pairs. This means
that regulation at outlet 1 also inevitably applies to outlet 7 below too.
3.7.3 Delivery volume per outlet:
The guaranteed pump delivery volume when using grease is 0.1 cm3per outlet and piston stroke. With low-viscosity lubricants such
as oil, the delivery volume can also be higher and reach max. 0.15 cm3/stroke. However, all subsequent volume calculations refer to
0.1 cm3. The delivery volume per outlet is independent of the total number of outlets.
The pump’s total delivery volume is then the sum of all outlets:
1 outlet
1x 0.1 cm3/ piston stroke
Total: 0.1 cm3/ piston stroke
2 outlets
2x 0.1 cm3/ piston stroke
Total: 0.2 cm3/ piston stroke
3 outlets
3x 0.1 cm3/ piston stroke
Total: 0.3 cm3/ piston stroke
…
…
12 outlets
12x 0.1 cm3/ piston stroke
Total: 1.2 cm3/ piston stroke
The effective delivery volume / time is determined by the choice of drive. More detailed information and calculations are provided
in the sections below for the relevant drive versions. The maximum possible delivery volume is 1.0 cm3per outlet / min (10
revolutions or strokes / min x 0.1 cm3).
3.7.4 Adjusting the delivery volume:
The FZ pump has 1 to 6 setting spindles depending on the configuration. If there are more than 6 outlets, a setting spindle
controls the delivery volume of the two outlets positioned one above the other. Engraved arrows clearly indicate the spindle –>
outlet association. The top and bottom outlets cannot, therefore, be regulated independently of each other. The pump is set to the
maximum delivery volume at all outlets on delivery. Numbers from 1 to 4 are engraved on the spindles (4 = maximum delivery
volume)
Setting
spindle(s)
Outlet numbering
Example:
Pump body
6 outlets
Example:
Pump body
12 outlets

19 BIJUR DELIMON INTERNATIONAL BA_2020_1_GB_FAX_FBX
Important:
The spindle positions 1 –4 do not cause a proportional change in volume, i.e. position 2 is not the same as 50%, for example. The
actual change in the delivery volume very much depends on the lubricant used (suction behaviour) and must be tested under the
given conditions. When using grease, the setting spindle should not be turned to anything smaller than position 2!
Please proceed as follows to subsequently adjust the delivery volume:
Note: You can connect outlets externally using connected pipelines to
reduce the number of outlets or to specifically combine volumes.
3.7.5 Drive types in general
In contrast to the standard version, the ATEX version of the FZ pump is only available with a pre-assembled flange motor.
Drive provided by the customer
Pre-assembled drive
Not intended for ATEX version of FZ pump
Flange motor
3.7.6 Drive with a flange motor and reduction gear
For the pump configuration with its own flanged drive a reduction gear is always required to reduce the motor’s rotation speed to
the feed piston’s permissible rotation speed. A 4-pole asynchronous motor whose shaft speed is slightly below that of the electric
drive rotating field (1,500 rpm) due to functional slip is used as standard. Our standard motor’s relevant shaft speed is 1,340 min-
1(at 50 Hz) and 1,610 m-1 (at 60 Hz), with which the following volume calculations were carried out.
Reduction gear:
1: Ratio: 215:1
Other ratios are not available for the
ATEX version
Drive speed*:
1,340 m-1 (50 Hz)
1,670 m-1 (60 Hz)
FZ-A: Delivery volume / per outlet (50 Hz):
1: approx. 0.62 cm3/ min -> 37.4 cm3/h
FZ-B: Delivery volume 1 outlet (50 Hz):
approx. 7.44 cm3/ min -> 446.4 cm3/h
FZ-B: Delivery volume 2 outlets (50 Hz):
approx. 3.72 cm3/ min -> 223.2 cm3/h per
outlets
Clockwise direction to
reduce the delivery
volume
AF

20 BIJUR DELIMON INTERNATIONAL BA_2020_1_GB_FAX_FBX
WARNING
Loss of ATEX certification and risk of explosion
The ATEX certification of the FZ pump is only valid in combination with the flange-
mounted motor from the factory.
An unauthorised modification will result in the loss of the ATEX certification.
An unauthorised replacement of the motor with other performance data can lead to
damage to the pump.
An unauthorised replacement of the motor with different performance data may
result in damage to the pump.
3.7.7 Reservoir
The FZ pump offers different reservoir sizes, so it can be well adapted to the lubricant consumption. All reservoir options are made
of metal and are zinc-nickel coated. The reservoir top is bolted on all versions and may only be opened for maintenance purposes
and by authorised personnel. On request, a fill level switch (MIN/MAX) can be installed in the reservoir top (see the section entitled
‘Accessories’).
Note: When using in ATEX Zone 1, a fill level switch is mandatory.
A feed insert with scraper, which rotates while the pump is running, is installed in the reservoir base.
The rotation speed corresponds to the piston speed (max. 10 rpm). The scraper ensures regular
mixing of the lubricant and prevents deposits (when grease is used) on the inner wall of the reservoir,
which can occur especially if the lubricant remains in the reservoir for a long time.
A screen plate is installed in the reservoir base to protect the pump suction chamber against coarse
dirt.
WARNING
Hand injury due to the rotating scraper
Never reach into the reservoir while the pump is running. There
is a risk of hands and fingers being crushed and cut off. Only
refill lubricant via the filling nozzle! No unauthorised access!
Filling connection:
For delivery:
sealed with screw plug G1/4
Version 1:
Use of loosely supplied filling nozzle
Version 2:
Direct connection of a filling line via
G1/4 screw-in fitting
