Bikef BC1 User manual
E-BIKE RECHARGING STATION BC1
Quick Start
Bikef BC1 is an innovative electric bikes recharging station designed to be used in commercial and
consumer purposes. With the BC1 station all the e-bikes equipped with a plug-in system can be
recharged.
Depending on the acquired configuration, the recharging station can be equipped with two or four plugs
for a contemporaneos multi e-bike recharge. The provided recharge cables are specially suitable for the
recharging system installed on every specific e-bike model.
The recharge station is equipped with one control display for every power unit installed. The magnetic
connector sockets are located on both sides.
All the recharge cables are supplied with a magnetic connector for plugging into the recharging station
and one specific connector for the battery vendor and model installed into the e-bike to recharge.
IMPORTANT
The BC1 recharging station can be used with the supplied recharge cables only and manufactured by
Bikef. At every time it’s possible to add cables or recharging stations fully compatible with the owned
ones.
Copyright © 2020, Bikef. Rev.09.2020
1-5
E-BIKE RECHARGING STATION BC1
Quick Start
How to recharge
1.
Plug the charging cable into the battery charge connector.
2.
Remove the cable’s magnetic cap and make sure the control display shows
the “Insert cable”
message.
3.
Insert the magnetic cable connector into the recharging station plug.
NOTE: for a correct plug, make sure that the magnetic connector is accurately
aligned to the recharging station socket.
4.
During recharging, the display shows the total charging time.
A self-test is automatically performed by the station before every recharge.
To interrupt a recharging operation simply unplug the cable from the
recharging station.
5.
The recharging is automatically stopped once the plugged battery is
completely full.
WARNING
If during a recharging operation the “Cable error” with 0x7FFF errorcode appears,
a possible short circuit has been detected. Please immediately unplug the cable
from the recharging station and from the e-bike battery.
Troubleshooting
Copyright © 2020, Bikef. Rev.09.2020
2-5
E-BIKE RECHARGING STATION BC1
Quick Start
Error
Problem’s description
Solution
0x8101
Internal power relay stuck
The power unit relay RL1 is stuck. Please contact Bikef
support (see Contacts)
.
0x8301
No 48V supplied
The internal power supply unit is in failure. Please contact
Bikef support (see Contacts)
.
0x8302
Max voltage out reached
The battery might have an internal failure, please unplug
the cable from the recharging station.
0x8303
Max current out reached
The battery might have an internal failure, please unplug
the cable from the recharging station.
0x7FFF
Short Circuit
Immediately unplug the cable from the recharge station
and from the e-bike battery.
0x7F01
Cable not readable
Check that the socket and the cable magnetic contacts are
clean and fully exposed to contact (see Magnetic
connectors maintenance)
.
Check that the cable connector is completely connected to
the recharge station socket.
If the problem persists, the cable might be damaged. For
reporting a cable problem please contact Bikef support
(see Contacts)
.
0x7F02
Cable not genuine
The cable used was not provided with the recharging
stations or the recharging station is not in Bikef mode . For
reporting a cable problem please contact Bikef support
(see Contacts)
.
0x8000
Generic error
Try to reset the recharging station disconnecting the unit
from the power line. If the problem persists please contact
Bikef support (see Contacts)
.
Copyright © 2020, Bikef. Rev.09.2020
3-5
E-BIKE RECHARGING STATION BC1
Quick Start
Magnetic connectors maintenance
To ease the cable insertion and provide fast release if needed, the Bikef BC1 uses special magnetic
connector sockets.
To ensure a perfectly working system and avoid recharging interruptions during the time due to a lack in
the electrical contact presence between the recharging station sockets and the cables, the magnetic
connectors electrical contacts must be cleaned before use.
During cable plugging into the recharging station socket, it’s highly recommended to remove everything
that can interrupt the electrical contact or can avoid a right mechanical alignment between the two
connectors.
IMPORTANT
➔Please before cleaning the magnetic sockets, unplug the recharging station from the main
line. Remove any material and all the tiny particles using a dry and clean cloth.
➔Please before cleaning cable connectors unplug the cable from the recharging station and
from the e-bike battery. Remove any material and all the tiny particles using a dry and clean
cloth.
Copyright © 2020, Bikef. Rev.09.2020
4-5
E-BIKE RECHARGING STATION BC1
Quick Start
Contacts
BIKEF SRL
Via San Zenone, 13 - 25040 Monticelli Brusati (BS) - Italy
Tel: +39 030 652195
Fax: +39 030 6852961
